QuickSpecs
Technical Specifications
Management and Standards
Standards Support
settings, and firmware updates
•
The location and status of Virtual Connect Modules in the HPE c-Class
Enclosure and Onboard Administrator can be viewed from the Hardware
Status page. Including at-a-glance detailed information of the hardware
elements via mouse-over pop-up windows.
• MAC Address Administration allows local administration of predefined or user-
defined MAC address ranges.
• WWN Address Administration allows local administration of predefined WWN
addresses ranges to allow pre-provisioning of SAN volumes
• VC manager runs as a high-availability pair when an HPE VC Module is
installed in the adjacent bay. All configuration data is stored in flash memory
and checkpointed to the standby module. Configurations can also be backed
up to a workstation via the GUI.
• A VC Ethernet module is not required in enclosure interconnect bay 1 or 2
when a VC FlexFabric Module is used in any bay as the primary VC module.
• Up to 128 Network Access Groups can be defined to prevent enabling specific
network combinations in the same server profile.
• Supported by HPE Virtual Connect Enterprise Manager v7.3.2 and higher.
Provides centralized network connection management and workload mobility
for thousands of servers. Learn more at: http://www.hp.com/go/vcem
•
INCITS FC-BB-5 Rev 2.00 (on all downlinks)
• IEEE 802.1Qbb
•
IEEE 802.1Qaz
• IEEE 802.1AB LLDP
• IEEE 802.1Q (VLAN includes Native VLAN support and server side VLAN tag
mapping)
• IEEE 802.2 LLC
•
IEEE 802.3ad Link Aggregation
•
IEEE 802.3ae 10Gb Fiber Ethernet
• IEEE 802.3aq 10Gb LRM Ethernet
•
SNMP v.1, v.2, v.3
• IGMP v1, v2, v3
•
IPv6
•
SR-IOV
• ANCI T11 N_Port ID Virtualization
•
FC-PH Rev. 4.3
• FC-PH-2
•
FC-PH-3
•
FC-FLA
• FC-GS
•
FC-GS-2
• FC-GS-3
•
FC-FG
•
FC-VI
• FC Element MIB RFC 2837
•
Fibre Alliance MIB Version 4.0
• FC-BB5 aka FIP snooping
