Page 1 WCM5100 Managed Ethernet Extender V8.38 User Manual DATE: April 2014 DOCUMENT NO: 76-02-087 REVISION: PREPARED BY: Ian Banbrook Metrodata Ltd Fortune House, Crabtree Office Village Eversley Way, Egham Surrey, TW20 8RY, UK Tel +44 1 784 744700 Fax: +44 1 784 744730...
Page 2 Further, Metrodata Ltd reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of Metrodata Ltd to notify any person of such revision or changes. Ó...
Page 3: Document Revision History
METRODATA LTD WCM5100 3 of 134 User Manual Document Revision History April 2011 Document Created April 2011 Updated for Multiple VC modes May 2011 Document Released June 2011 Document typos corrected New feature VC-3 allocation added August 2011 Updated to add multiple VC-3 with VCAT...
Page 4: Table Of Contents
2.2.2.8 Bit switch 8, Factory Default ......................16 Rackmounting ..............................17 WCM5100 APPLICATIONS ..................18 WCM5100 Normal Mode ..........................18 WCM5100 VLAN Trunk Mode ........................18 VLAN Mode ..............................19 S-Tag Mode ..............................19 QUICK START CONFIGURATION ................20 Cold Start the Unit ............................20 Access the WCM .............................20 Logging onto WCM5100 ..........................21...
Page 5 METRODATA LTD WCM5100 5 of 134 User Manual Configure the WAN interface .........................23 4.4.1 WCM5100 WAN Configuration .......................23 Set IP Address ..............................24 Set Default Route ............................25 Save the Configuration............................26 ADVANCED CONFIGURATION ................27 System Configuration............................27 5.1.1 Setting the Time and Date ........................28 5.1.2...
Page 6 METRODATA LTD WCM5100 6 of 134 User Manual Port Set Up Menu ............................50 5.3.1 LAN Port ..............................51 5.3.1.1 State ...............................51 5.3.1.2 Link Status .............................51 5.3.1.3 Cable Tester............................52 5.3.1.4 Auto Negotiation ..........................52 (Max) ................................52 5.3.1.5 Speed..............................52 5.3.1.6 (Max) Duplex ..........................53 5.3.1.7 Negotiated ............................53...
Page 7 METRODATA LTD WCM5100 7 of 134 User Manual 5.3.3.2.1.2 Strip MAC FCS ........................73 5.3.3.2.1.3 Payload Scrambler .......................73 5.3.3.3 LCAS/VCAT ..........................74 5.3.3.4 LCAS Status ...........................74 5.3.3.5 Layer 2 management ........................74 5.3.3.6 Link Loss Forwarding ........................75 5.3.3.7 Rate Limiting ..........................75 5.3.3.8 Counters ............................75 5.3.4...
Page 8 METRODATA LTD WCM5100 8 of 134 User Manual 5.5.1.1.1 Proxying ............................93 5.5.1.1.2 Host Interface ..........................93 5.5.1.1.3 DHCP ............................93 5.5.1.1.4 IP Address..........................94 5.5.1.1.5 Network Mask ..........................94 5.5.1.2 Client Mode Proxy ..........................94 5.5.1.2.1 Interface .............................94 5.5.2 Interface ..............................95 5.5.2.1 State ...............................95 5.5.2.2 Physical Address ..........................95...
Page 9 METRODATA LTD WCM5100 9 of 134 User Manual 5.5.9 Ping ............................... 119 Saving the Configuration ..........................120 Global Status ..............................121 5.7.1 Interface ..............................121 5.7.2 State ..............................121 5.7.3 Test ............................... 122 5.7.4 Alarms ..............................122 5.7.4.1 LAN Port Alarms .......................... 123 5.7.4.2...
Page 10: Introduction
The WCM5100 has an internal LAN switch offering full wire-speed switching between ports. The WCM5100 uses MAC address filtering to filter all local traffic and only forward traffic destined for remote stations. Each of the WCM5100’s LAN ports support automatic cross-over switching and will therefore connect directly to a Hub/Switch/Router or PC End Station.
Page 11: Wcm5100 Rear Panel
User Manual 1.1 WCM5100 Rear Panel The WCM5100 device is a compact unit, as shown below, occupying half a shelf in a traditional 19inch rack. All power and data connectors and LED status indicators are accessible from the rear of the unit.
Page 12: Electro Magnetic Compatibility
EMC compliance. 1.3.1 EN55022 Statement The WCM5100 is a Class A product. In a domestic environment, this product may cause radio interference, in which case the user will be required to take adequate measures. 1.3.2 FCC Declaration This equipment has been tested and found to comply with the limits of the Class A digital device, pursuant to Part 15 of the FCC rules.
Page 13: Installation
The WCM5100 is available with either AC Mains or DC power options. 2.1.1 Mains Power The WCM5100 has an internal power supply and is supplied via an IEC mains power socket. The WCM5100 operates over the wide range 100 to 250V AC and draws less than 6 watts.
Page 14: Base Label And Bit Switches
User Manual 2.2 Base Label and Bit Switches On the underside of the WCM5100 unit there are bit switches which may be used to configure certain functions within the unit. The bit switches are used to configure the default settings following a cold start.
Page 15: Bit Switch 2, Boot Mode 1
This bit switch determines the operating mode of the SDH WAN interface. SONET OC-3 SDH STM-1 This bit switch is currently unused on the WCM5100 which does not offer SONET operation. 2.2.2.5 Bit switch 5, Timing Mode This bit switch determines the timing source for the SDH WAN interface...
Page 16: Bit Switch 6,Unused
16 of 134 User Manual 2.2.2.6 Bit switch 6,Unused This bit switch is unused on the WCM5100, 2.2.2.7 Bit switch 7, SFP Mode This bit switch is used to force the configuration of the SFP interface to match the SFP type inserted.
Page 17: Rackmounting
User Manual 2.3 Rackmounting The WCM5100 is a standalone, desktop unit however it may be mounted in a standard 19 inch rack using the rack mounting kit, part number 80-05-256. To mount the WCM5100 in the 19 inch rack mount adaptor first remove the two M3x12 screws and washers from the rear panel of the unit.
Page 18: Wcm5100 Applications
In this application, the WCM5100 is operating with Traffic Isolation Disabled. In this mode, the WCM5100 acts as a simple, layer 2, 5 port switch with packetsswitched based on MAC address alone. The WCM5100 supports both local and remote switching, and forwarding over the WAN trunk.
Page 19: Vlan Mode
METRODATA LTD WCM5100 19 of 134 User Manual 3.3 VLAN Mode In this mode, both WCM units have VLAN support enabled, and all ports are defined as access ports VLAN 101 is used as the management VLAN and in unit WCM-A the VLAN group 101 includes the LAN Port 1, the Manager and the SDH WAN port.
Page 20: Quick Start Configuration
(Normal Operation) position. 4.2 Access the WCM Initial access to the WCM5100 is made using the Terminal Port on the rear panel of the unit. The Terminal port defaults to 19200baud, 8bit, No Parity, 1 Stop Bit. The 9 Way D-...
Page 21: Logging Onto Wcm5100
At the prompt, enter the password to gain access to the WCM. The default password is the product name, ie “wcm5100” For security, the password is obscured with an asterisk (*) being displayed for each character typed. An incorrect password will lead to the welcome banner being redisplayed.
Page 22: User Interface Navigation
METRODATA LTD WCM5100 22 of 134 User Manual 4.3.1 User Interface Navigation The WCM user interface is a simple, menu based interface. Each selectable item may be selected by typing the first capital of the option, e.g. for “Port set-up” type <P>...
Page 23: Configure The Wan Interface
<menu> <menu> <menu> <menu> vc-4 <menu> vc-3 <menu> First CAPITAL - select item <escape> - exit menu 4.4.1 WCM5100 WAN Configuration Metrodata WCM5100 "" Alarms: Major WAN1 State sfp type OC-3 SM IR sFP Management <menu> Active Port fallBack timeout...
Page 24: Set Ip Address
METRODATA LTD WCM5100 24 of 134 User Manual 4.5 Set IP Address From the Main Setup Menu, select Management Entity, Metrodata WCM5100 "" Alarms: Major MANAGEMENT ENTITY proXying <menu> intErface <menu> <menu> <menu> <menu> sNmp <menu> Telnet/SSH <menu> tFtp <menu>...
Page 25: Set Default Route
If DHCP is not used, you must assign the required network mask for correct installation into the network. 4.6 Set Default Route From the Main Setup Menu, select Management, then IP, Metrodata WCM5100 "" Alarms: Major default TTL DSCP priority Routing table <display>...
Page 26: Save The Configuration
METRODATA LTD WCM5100 26 of 134 User Manual Metrodata WCM5100 "" Alarms: Major Destination Next Hop Type Prot. Mask ----------------------------------------------------------------------------- 192.168.0.0 0.0.0.0 Mgmt direct local 80764 255.255.255.0 0.0.0.0 192.168.0.254 Mgmt indirect local 0.0.0.0 A - add entry D - delete entry any other key to exit: Add a new route table entry with destination and mask as 0.0.0.0 and configure the next...
Page 27: Advanced Configuration
User Manual 5 ADVANCED CONFIGURATION 5.1 System Configuration The system menu provides the basic administrative configuration items for the WCM and should be configured first. The System Menu is shown below: Metrodata WCM5100 "" Alarms: Major SYSTEM Time & date <menu>...
Page 28: Setting The Time And Date
In applications where NTP is not available, the WCM defaults to providing a simple uptime display. To configure the NTP parameters, select the “Time and date” menu from the “System” menu. The menu is as below: Metrodata WCM5100 "" Alarms: Major TIME & DATE local Time...
Page 29: Setting The Node Name
To enable identification of the WCM, it is useful to enter a meaningful name for the unit. The node name is entered as a string of up to 32 alpha numeric characters, including spaces. Metrodata WCM5100 "WCM Node A" Alarms: Major SYSTEM Time &...
Page 30: Access Control
5.1.3.1 Password The local password for the WCM may be changed from the access control menu. The default password is the product name, ie “wcm5100” however for deployment a more secure password may be required. To change the unit password, select “Password” from the system menu. The WCM will...
Page 31: Password Recovery
If for any reason, the password for access to the WCM is lost, the unit may be cold started by using bit switch 8 which will return the unit to the default factory configuration. The default factory password is the product name, “wcm5100”. Note, that returning the unit to factory default will erase the configuration memory and all configuration items including IP address will be lost.
Page 32: Tacacs
METRODATA LTD WCM5100 32 of 134 User Manual 5.1.3.4 TACACS+ Where greater access control and security is required, the WCM units support TACACS+ for central password authentication. Metrodata WCM5100 "" Alarms: Major TACACS+ Authentication TACACS+,Local Timeout Retries Server 192.168.100.45 Encryption key...
Page 33: Server
METRODATA LTD WCM5100 33 of 134 User Manual 5.1.3.4.4 Server This defines the IP address of the TACACS+ Authentication server. When a login attempt is made, this server will be accessed. 5.1.3.4.5 Encryption Key This key is used by both the WCM and the TACACS+ server to provide a secure, encrypted password exchange and authentication.
Page 34: Welcome Screen
However, it is possible to customize the welcome banner to give further information about the unit, or to inform the user of access restrictions. To configure the welcome screen select the “welcome screen” menu item which will lead to the menu: Metrodata WCM5100 "WCM Node A" Alarms: Major WELCOME SCREEN Welcome screen...
Page 35 METRODATA LTD WCM5100 35 of 134 User Manual If a customized welcome is required, change to enabled and the menu will change as shown below: Metrodata WCM5100 "WCM Node A" Alarms: Major WELCOME SCREEN Welcome screen Enabled 1st line 2nd line...
Page 36: Software Version
METRODATA LTD WCM5100 36 of 134 User Manual Metrodata WCM5100 "WCM Node A" Alarms: Major WELCOME SCREEN -------------- This is an example of a Welcome Banner Welcome to the WCM Please enter the password> <Escape> - exit, other key - refresh...
Page 37: Output Config
To output the configuration file, you will need a terminal emulator such as Tera Term or Hyper Term which have the capability of capturing the screen output. When output config is selected, the following prompt is displayed Metrodata WCM5100 "WCM Node A" Alarms: Major Start capture then press a key.
Page 38: Cold Start
The event logging system on the WCM units provide a diagnostic capability to assist problem diagnosis when errors or faults occur in the network. The event log menu is as shown below: Metrodata WCM5100 "WCM Node A" Alarms: Major EVENT LOGS System event log <display>...
Page 39: System Event Log
User Manual 5.1.11.1 System Event Log The system event log stores events that are related to the operation of the system as shown below: Metrodata WCM5100 "WCM Node A" Alarms: Major --- System Event Log --- 1/1/2000 00:00:00 performance log cleared...
Page 40: Config Event Log
40 of 134 User Manual 5.1.11.3 Config Event Log The config event log stores all changes that are made to the unit configuration as shown below: Metrodata WCM5100 "WCM Node A" Alarms: Major --- Config. Event Log --- 5/1/2000 17:59:07 Config. updated...
Page 41: Operational Modes
METRODATA LTD WCM5100 41 of 134 User Manual 5.2 Operational Modes The operational mode menu defines the operating mode for the unit. The menu is shown below: Metrodata WCM5100 "" Alarms: Major OPERATIONAL MODES VLAN Mode C-VLAN bAckplane Summary <display>...
Page 42: Flow Control
METRODATA LTD WCM5100 42 of 134 User Manual 5.2.3 Flow Control The WCM supports IEEE 802.3x pause frame based flow control on all auto negotiating ports. Flow control may be globally enabled or disabled for the device. If flow control is enabled, then any port will advertise flow control during auto negotiation and if required generate pause frames to throttle a port to prevent packet loss.
Page 43: Rate Limiting Mode
METRODATA LTD WCM5100 43 of 134 User Manual 5.2.5 Rate Limiting Mode Each port supports rate limiting to police the input traffic stream. This configuration items determines the method of calculating the traffic stream bandwidth. The options are as follows:...
Page 44: Priority Management
WCM5100 44 of 134 User Manual 5.2.6 Priority Management This configuration menu provides the configuration for the WCM QOS support. The priority management menu is as below: Metrodata WCM5100 "" Alarms: Major PRIORITY MANAGEMENT DSCP->C-Tag Mapping <menu> Queue Priorities <menu>...
Page 45: Queue Priorities
5.2.6.2 Queue Priorities The WCM has four levels of priority queue, and these queues operate in a strict priority manner. The queue priorities menu is shown below: Metrodata WCM1100 "" Alarms: Major C-TAG->QUEUE PRIORITY MAPPING Queue Priority:...
Page 46: Vlan Override
5.2.6.3 VLAN Override The VLAN override menu allows the user to overwrite the PCP tag of incoming user frames to force the PCP to a defined level. The menu is as shown below: Metrodata WCM1100 "" Alarms: Major VLAN-BASED PRIORITY OVERRIDE...
Page 47: Rstp
The WCM supports RSTP for loop prevention when resilient network topology is used. This menus defines the global RSTP configuration for the switch, port specific parameters, including PortFast are configured under the port menus. The RSTP configuration menu, once enabled, is as below: Metrodata WCM5100 "WCM1100" Alarms: Major RSTP Mode...
Page 48: Hello Time
METRODATA LTD WCM5100 48 of 134 User Manual 5.2.7.4 Hello Time The Hello Time parameter defines the period between configuration BPDU transmissions on designated ports. 5.2.7.5 Forward Delay The Forward Delay is the timeout used by a port which is not receiving BPDU’s before a port will transition from DISCARDING to FORWARDING.
Page 49: Status
49 of 134 User Manual 5.2.7.8 Status The status screen enables the user to determine the RSTP state of the device and its position within the network topology. Metrodata WCM5100 "" Alarms: Major RSTP STATUS ----------- | Root | Time Since...
Page 50: Port Set Up Menu
WAN, and LAN ports. A simple configuration will be shown for each type of port. The port configuration is accessed from the main setup menu by selecting the data port menu. The data port menu gives the following options Metrodata WCM5100 "WCM Node A" Alarms: Major PORT SET-UP lan1 <menu>...
Page 51: Lan Port
RJ45 connectors and support access to the other external local LAN ports, the management processor or the WAN forwarding port. The LAN port menu allows for configuration of the LAN port parameters and VLAN settings Metrodata WCM5100 "WCM Node A" Alarms: Major LAN1...
Page 52: Cable Tester
Where unreliable operation is detected on a port, running a cable test will verify that the cable is correctly connected, and terminated. The display for a good, 1000M connection is as below: Metrodata WCM5100 "" Alarms: Major Cable Tester...
Page 53: Max) Duplex
METRODATA LTD WCM5100 53 of 134 User Manual 5.3.1.6 (Max) Duplex When in auto negotiating mode, the max duplex displayed is the highest that will be advertised to the link partner. In non auto negotiating mode, the duplex is manually set by the user.
Page 54: Mdi/Mdix
Present MDIX Interface, direct connection to PC 5.3.1.9 L2 Management The L2 management menu configures the layer 2 frame processing and control protocol support. The L2 management menu is as shown below: Metrodata WCM5100 "" Alarms: Major L2 MANAGEMENT, LAN1 Tagging & Priority <menu>...
Page 55: Tagging And Priority
QinQ/S-Tag mode, ports defined as access will have tags pushed, whilst ports defined as trunk will egress with tags applied. 5.3.1.9.1.1 C-VLAN Mode The Tagging and Priority menu when in C-VLAN mode is shown below: Metrodata WCM5100 "" Alarms: Major TAGGING & PRIORITY, LAN1 vlan Alloc...
Page 56: Untagged
METRODATA LTD WCM5100 56 of 134 User Manual 5.3.1.9.1.1.2 Untagged The Untagged action option defines the action taken when an untagged frame ingresses the port. The valid options are: Discard Untagged frames will be discarded by this port Leave Untagged Untagged frames will be accepted at this port.
Page 57: Default Priority
WCM so this setting may be left in the default setting. 5.3.1.9.1.2 QinQ/S-VLAN Mode When the operational mode of the WCM is set to QinQ/S-VLAN mode the tagging and priority menu is as below, for access or trunk ports Metrodata WCM5100 "" Alarms: Major TAGGING & PRIORITY, LAN1 port Mode...
Page 58: Port Mode
METRODATA LTD WCM5100 58 of 134 User Manual Metrodata WCM5100 "" Alarms: Major TAGGING & PRIORITY, LAN1 port Mode Trunk s-vlan Alloc EtherType 9100 Control S-VLAN First CAPITAL - select item <escape> - exit menu 5.3.1.9.1.2.1 Port Mode The port determines whether the port will act as an access or a trunk port.
Page 59: Default Priority (Access Port)
METRODATA LTD WCM5100 59 of 134 User Manual DSCP, Default For incoming IP frames use the DSCP priority, with the translation to determine the PCP value. For non IP use the default value. C-Tag, DSCP, Default For incoming tagged frames, the priority will be taken from the tag PCP priority.
Page 60: Oam
METRODATA LTD WCM5100 60 of 134 User Manual 5.3.1.9.2 OAM The WCM supports IEEE 802.3ah Link OAM which may be configured on a per port basis: Metrodata WCM5100 "" Alarms: Major OAM, LAN1 Mode Active Status <display> counTers <display> Events <display>...
Page 61: Oam Status
Node name: "Test Unit" Interface: LAN1 Interface AdSt OpSt LAN2 Down Down <Esc> - exit, <Enter> - refresh Where the peer device is another Metrodata device, proprietary extensions to OAM are used to report further remote peer status information. 76-02-087 Rev G...
Page 62: Oam Counters
User Manual 5.3.1.9.2.3 OAM Counters The counters provide an indication of the OAM interactions taking place. In normal operation, the information frames should be incrementing at a rate of 1 per second. Metrodata WCM5100 "" Alarms: Major OAM Statistics --------------...
Page 63: Rstp
User Manual 5.3.1.9.3 RSTP When RSTP is enabled on the WCM unit, there are several parameters which need to be defined on a per port basis. The port rstp menu is shown below: Metrodata WCM5100 "" Alarms: Major RSTP, LAN1 Priority...
Page 64: Link Loss Forwarding
). Frames priority is determined using the ingress, or overridden PCP value which may also be based on the DSCP value as determined in the operating mode menu. The rate limiting menu is as shown: Metrodata WCM5100 "" Alarms: Major RATE LIMITING, LAN1 bRoadcast <menu>...
Page 65: Limiting
METRODATA LTD WCM5100 65 of 134 User Manual 5.3.1.11.1 Limiting At each priority level, the rate limit policing may be enabled or disabled. When disabled, ingress frames at this priority are not limited. When rate limiting is enabled, ingress frames of this priority are limited according to the CIR/CBS parameters.
Page 66: Counters
METRODATA LTD WCM5100 66 of 134 User Manual 5.3.1.12 Counters Each LAN port provides a set of counters supporting the basic MIB-2 SNMP parameters as below: Interface Statistics ------------------------- ifInOctets 808916 ifInUcastPkts 2012 ifInNUcastPkts 5600 ifInDiscards ifInErrors ifInUnknownProtos ifOutOctets 186612...
Page 67: Sfp Port
SFP MSA definition. Metrodata supplied SFP devices will indicate the SFP type, however some lower cost, lower quality SFP devices may not be correctly programmed and will indicate “UNKNOWN”...
Page 68: Speed
METRODATA LTD WCM5100 68 of 134 User Manual 5.3.2.4 Speed When a unit cold starts, the default speed is set according to the setting of bit switch 7 on the underside of the unit. The options are: 1000 1000 Base X Mode 100 Base FX Mode This setting should be set to match the SFP device inserted.
Page 69: Sfp Management
The menu also allows the notifications to be defined to allow for traps and alarms to be generated based on the SFP diagnostic information. The SFP management menu is shown below: Metrodata WCM5100 "" Alarms: none SFP MANAGEMENT Device Details <display>...
Page 70: Notifications
The Notifications menu allows traps and alarms to be generated based on alarms or warnings raised by the SFP diagnostic information. The menu is shown below, with a common set up with traps/alarms enabled for the high termperature and low receive power. Metrodata WCM3100 "WCM3100_Left" Alarms: none NOTIFICATIONS 1 - Temp High Alarm &...
Page 71: Link Loss Forwarding
The menu configures the priority based rate limiting. Please refer to section 5.3.1.11 for configuration details. 5.3.2.9 Counters The SFP provides counters to show the packets that pass over this port as shown below: Metrodata WCM5100 "" Alarms: Major Interface Statistics --------------------...
Page 72: Vcg
The VCG ( virtual concatenation group ) configuration menu is used to define the encapsulation method used for frames being transported over the WAN port. The VCG configuration menu for VC4 is as below: Metrodata WCM5100 "" Alarms: Major State Encapsulation <menu>...
Page 73: Encapsulation
METRODATA LTD WCM5100 73 of 134 User Manual 5.3.3.2 Encapsulation This menu allows the configuration of the packet encapsulation mode for transporting packets across the WAN port. Metrodata WCM5100 "" Alarms: Major ENCAPSULATION, VCG Encapsulation GFP FCS Enabled strip MAC FCS...
Page 74: Lcas/Vcat
User Manual 5.3.3.3 LCAS/VCAT The WCM5100 supports VCAT and LCAS for bonding multiple links together. In VC-4 operating mode, only a single link is used and the VCAT only mode is selected. In VC-3 mode, 1, 2 or 3 containers may be used with VCAT + LCAS enabled...
Page 75: Link Loss Forwarding
VCG rate limiters will ever be enabled. For full configuration details, refer to section 5.3.1.11 of the manual. 5.3.3.8 Counters The VCG provides counters to show the packets that pass over this port as shown below: Metrodata WCM5100 "" Alarms: Major Interface Statistics --------------------...
Page 76: 76-02-087 Rev G
METRODATA LTD WCM5100 76 of 134 User Manual 76-02-087 Rev G...
Page 77: Sdh Ports
User Manual 5.3.4 SDH Ports The WCM5100 is fitted with two SDH ports presented using SFP modules supporting STM-1. The ports must be configured for the same timing, framing and payload options as they operate as a 1 for 1 backup link. When fall back is enabled, alarms occurring on the active port will force a fallback to the backup link if it is available.
Page 78: Sfp Management
The menu also allows the notifications to be defined to allow for traps and alarms to be generated based on the SFP diagnostic information. The SFP management menu is shown below: Metrodata WCM5100 "" Alarms: none SFP MANAGEMENT Device Details <display>...
Page 79: Notifications
5.3.4.4 Active Port The WCM5100 has a pair of WAN ports, however only one of these is active and passing data at any point. This display indicates which is the currently active WAN port. 76-02-087 Rev G...
Page 80: Fallback Timeout
5.3.4.6 Timing When the WCM5100 is connected to an SDH network, the WAN ports should be configured to operate in loop timing mode, with the timing sourced from the network. When used over a dark fibre, either internal/internal or internal/loop may be used.
Page 81: Overhead
The J0 transmit option allows the Path Trace Label to be defined for this SDH port. In the example above the label is defined as “WCM5100-A”. This label allows for equipment to verify it is connected to the correct circuit.
Page 82: Receiving
SDH interfaces have problems with E0, and as such this can normally be left in the default 00 state. 5.3.4.9 Payload The WCM5100 offers two payload options for the transport of Ethernet over STM-1, which one to use is determined by the STM-1 service supplied by the network operator. VC-4 The STM-1 Frame transports a single VC-4 container giving around 149Mbps payload capability.
Page 83: Configuration
5.3.5 VC-4 Configuration Whether the payload is configured for VC4 or VC-3, a VC-4 is used and must therefore be configured. The VC-4 configuration menu is as shown below: For VC-4 payload Metrodata WCM5100 "" Alarms: Major VC-4 State Path signal label...
Page 84: Path Signal Label
The J1 overhead is the High Order path Trace Label and is used to allow for links to be identified. To identify the path, a meaningful label should be defined, eg “WCM5100 VC-4” 5.3.5.5 J1 Expected To provide protection against misconnection, and expected value may be supplied for the J1 Path Trace label.
Page 85: Vcg
METRODATA LTD WCM5100 85 of 134 User Manual This value should be configured according to the network operator requirements, though can usually be left in the default state. 5.3.5.8 VCG This configuration item defines which VCG this VC-4 container is allocated to.
Page 86: State
When the payload is configured for VC-3 mode, the VC-3’s must be configured. When selecting the VC_3 configuration menu, firstly the individual VC-3 ( 1,2 or 3 ) must be selected, leading to the menu: Metrodata WCM5100 "" Alarms: Major VC-3#1...
Page 87: J1 Transmit
The J1 overhead is the Low Order path Trace Label and is used to allow for links to be identified. To identify the path, a meaningful label should be defined, eg “WCM5100 VC-3-1” 5.3.6.5 J1 Expected To provide protection against misconnection, and expected value may be supplied for the J1 Path Trace label.
Page 88: Setup
METRODATA LTD WCM5100 88 of 134 User Manual 5.4 V.24 Setup The V.24 setup menu configures the local terminal interface for the WCM device. The menu is shown below: Metrodata WCM5100 "" Alarms: Major V.24 SET-UP Usage Console Console set-up <menu>...
Page 89: Console Set Up
METRODATA LTD WCM5100 89 of 134 User Manual 5.4.2 Console Set Up This menu defines the operating parameters of the terminal interface as shown: Metrodata WCM5100 "" Alarms: Major CONSOLE SET-UP Terminal type via Modem Baud rate 19200 bps Parity...
Page 90: Baud Rate
METRODATA LTD WCM5100 90 of 134 User Manual 5.4.2.3 Baud Rate This sets the baud rate for the terminal interface. The default setting is 19200baud. The options are: 2400 4800 9600 19200 5.4.2.4 Parity This sets the parity for the terminal interface. The default setting is None...
Page 91: Data Bits
METRODATA LTD WCM5100 91 of 134 User Manual 5.4.2.5 Data Bits This sets the number of data bits per character for the terminal interface. The default setting is 8. The options are 5.4.2.6 Stop Bits This sets the number of stop bits per character for the terminal interace. The default setting is 2.
Page 92: Management Entity
92 of 134 User Manual 5.5 Management Entity The management entity menu defines the IP functionality of the WCM unit to enable remote management access via the LAN, SFP or WAN ports. Metrodata WCM5100 "" Alarms: Major MANAGEMENT ENTITY proXying <menu>...
Page 93: Server Mode Proxy
A client can be supported at the far end of each port of the unit, though in general, only remote units connected via the VCG will be managed as proxy clients. The proxy client set up menu is shown below: Metrodata WCM5100 "" Alarms: Major Proxying...
Page 94: Ip Address
5.5.1.2 Client Mode Proxy When a device is set to be a Proxy client, it simply needs to be configured for which port will be used for the proxy management. The client menu is as below: Metrodata WCM5100 "" Alarms: Major PROXYING...
Page 95: Interface
5.5.2.2 Physical Address The physical address is the unique MAC address assigned to this unit. This address will be of the form: 00:C0:81:xx:yy:zz where 00:C0:81 is the Metrodata OUI, and xx.yy.zz is the unit identifier 76-02-087 Rev G...
Page 96: Dhcp
If DHCP is not available, enter the required net mask 5.5.2.6 AT Table The AT table is a display of the ARP resolutions that the WCM unit has made as shown below: Metrodata WCM5100 "" Alarms: Major AT TABLE --------...
Page 97: C-Vlan
METRODATA LTD WCM5100 97 of 134 User Manual 5.5.2.7 Statistics The management interface provides a full set of MIB-2 IfTable statistics for the port as shown below: Metrodata WCM5100 "" Alarms: Major Interface Statistics -------------------- ifInOctets 12451 ifInUcastPkts ifInNUcastPkts ifInDiscards...
Page 98: Default Ttl
METRODATA LTD WCM5100 98 of 134 User Manual 5.5.3 IP The IP menu defines the layer 3 functionality for the manager interface and is shown below: Metrodata WCM5100 "" Alarms: Major default TTL DSCP priority Routing table <display> Forwarding Disabled Stats.
Page 99: Routing Table
To assist the manager in understanding how to route frames to remote subnets, the IP routing table gives directions on how to reach each remote destination. The routing table with a default route added automatically by DHCP is shown below: Metrodata WCM5100 "" Alarms: Major Destination Next Hop Type Prot.
Page 100: Delete A Route
5.5.3.3.2 Delete a Route To delete a routing table entry, select delete entry and enter the IP address of the subnet you wish to delete along with the net mask as shown Metrodata WCM5100 "" Alarms: Major Destination Next Hop Type Prot.
Page 101: 76-02-087 Rev G
METRODATA LTD WCM5100 101 of 134 User Manual The available statistics are shown below: Metrodata WCM5100 "" Alarms: Major IP Statistics ------------- ipInReceives ipInHdrErrors ipInAddrErrors ipForwDatagrams ipInUnknownProtos ipInDiscards ipInDelivers ipOutRequests ipOutDiscards ipOutNoRoutes ipReasmReqds ipReasmOKs ipReasmFails ipFragOKs ipFragFails ipFragCreates ipRoutingDiscards press any key to continue...
Page 102: Udp
User Manual 5.5.4 UDP The UDP menu displays the port numbers used for SNMP Get and Set operations as well as for Trap operation. These should not be altered. Metrodata WCM5100 "" Alarms: Major snmp Port snmp Trap port Stats.
Page 103: Statistics
METRODATA LTD WCM5100 103 of 134 User Manual 5.5.5.1 Statistics The statistics menu displays the SNMP MIB-2 IfTable TCP statistics as shown: Metrodata WCM5100 "" Alarms: Major TCP Statistics -------------- tcpActiveOpens tcpPassiveOpens tcpAttemptFails tcpEstabResets tcpInSegs tcpOutSegs tcpRetransSegs tcpInErrs tcpOutRsts press any key to continue 5.5.5.2 Connection Table...
Page 104: Snmp Management
5.5.6.2 Contact Person The contact person is the SNMP MIB-2 system SysContact parameter, the default setting Metrodata Limited, Fortune House, Eversley Way, Egham, Surrey, TW20 8RY The parameter may be up to 255 characters and should be configured to reflect the actual installation requirements.
Page 105: Node Name
The WCM supports up to 10 configured Network Management Stations. The manager may be configured to operate as SNMP V1 or V2c The Add Manager Menu is as below: Metrodata WCM5100 "" Alarms: Major ADD MANAGER IP address 0.0.0.0...
Page 106 The SNMP version may be configured for the manager to support either SNMP V1 or SNMP V2c. 5.5.6.6 Statistics The WCM management entity provides a set of SNMP MIB-2 IfTable SNMP statistics for the interface: Metrodata WCM5100 "" Alarms: Major SNMP Statistics --------------- snmpInPkts...
Page 107: Trap Alarms
This menu allows the individual alarm conditions to be defined as to whether they will force a trap to be generated or not. There is a separate configuration menu for each port type within the unit as shown below: Metrodata WCM5100 "" Alarms: Major TRAP ALARMS lan1 <menu>...
Page 108: Sfp Port Trap Defintions
METRODATA LTD WCM5100 108 of 134 User Manual Loss of CFM ( 802.1ag ) contact with peer MEP 5.5.6.7.2 SFP Port Trap Defintions Metrodata WCM5100 "" Alarms: Major 0 - LOS Trap 1 - LKDN Trap 2 - NF Trap...
Page 109: Vcg Port Trap Defintions
METRODATA LTD WCM5100 109 of 134 User Manual OTDR OTDR Alarm 5.5.6.7.3 VCG Port Trap Defintions Metrodata WCM3100 "" Alarms: Major 1 - LKDN Trap 3 - LLF Trap 4 - DEG Trap 5 - OAM Trap 6 - CFM...
Page 110: Traps
Trace Identifier Mismatch, this indicates that the received J0 string does not match the expected value, possibly indicating a mis connected circuit. 5.5.6.7.5 VC-4 Traps At the VC-4 level, the following alarms may be raised Metrodata WCM5100 "" Alarms: Major VC-4 0 - LOP Trap...
Page 111: Traps
Trace identifier Mismatch, This alarm indicates that the received J1 string does not match the expected value. 5.5.6.7.6 VC-3 Traps At the VC-3 level, the following alarms may be raised Metrodata WCM5100 "" Alarms: Major VC-3#1 0 - LOP Trap...
Page 112: 76-02-087 Rev G
METRODATA LTD WCM5100 112 of 134 User Manual The VC-3 alarms are raised on the Path Overhead section of the SDH frame structure. Loss of Pointer, this indicates that the pointer to the start of the VC-3 container cannot be found, usually only seen when LOF is also active.
Page 113: Telnet/Ssh
User Manual 5.5.7 Telnet / SSH The WCM unit allows remote management by either TELNET or the more secure, encrypted SSH V2. This menu configures the device for remote management access as shown: Metrodata WCM5100 "" Alarms: Major TELNET/SSH tElnet Enabled...
Page 114: Tftp
5.5.8.1 TFTP Configuration Under the management menu, select TFTP and enter the parameters as required: 5.5.8.1.1 Client Mode Select client mode to display the menu as below: Metrodata WCM5100 "" Alarms: Major TFTP Mode Client remote IP 192.168.0.100...
Page 115: Get New Software
5.5.8.1.1.2 Get New Software The Get New Software option is selected for performing a main application code update. Following the Get New Software option the warning message below will appear: Metrodata WCM5100 "" Alarms: Major TFTP Software Upgrade CAUTION: Proceding further will mean that the unit must be re-started, and the performance log may be cleared, even if the upgrade is unsuccessful.
Page 116: Boot S/W Upgrade
The Boot S/W update option is selected for performing a boot code update. Following the Boot S/W update option the warning message below will appear: Metrodata WCM5100 "" Alarms: Major TFTP Software Upgrade CAUTION: Proceding further will mean that the unit must be re-started, and the performance log may be cleared, even if the upgrade is unsuccessful.
Page 117: Get Confuration File
Get Config menu option. At the prompt enter the required filename. Enter file name, then wait > wcm5100.cfg Once the file has downloaded, the unit will save it to the non volatile EEPROM and will then reboot and restart with the new configuration file loaded.
Page 118: Server Mode
–i “WCM IP Address” put “Source Filename” “Software File Name” tftp –i 192.168.0.1 put wcm5100.823 software Which will load a file named “wcm5100.823” onto the WCM with IP address 192.168.0.1 and load as a file called “software” 76-02-087 Rev G...
Page 119: Ping
Ping is a simple IP/ICMP utility that enables the management connectivity to be verified. Simply enter the IP address of the remote unit and ping will repeatedly send an ICMP Echo request, as shown below: Metrodata WCM5100 "" Alarms: Major Destination: 192.168.100.70 press any key to stop test sending...okay, time=1.7ms...
Page 120: Saving The Configuration
WCM5100 120 of 134 User Manual 5.6 Saving the Configuration Once the WCM has been configured, the configuration must be saved to the EEPROM to provide non-volatile storage. Metrodata WCM5100 "" Alarms: Major MAIN SET-UP Global status <display> alarm eXtension <menu>...
Page 121: Global Status
The Global status screen gives an overview of the status of the WCM unit, and should always be the first port of call when attempting to diagnose a network, or operational problem. The Global Status screen is shown below: Metrodata WCM5100 "" Alarms: Major GLOBAL STATUS History last cleared:...
Page 122: Test
METRODATA LTD WCM5100 122 of 134 User Manual 5.7.3 Test If a port has a test mode enabled it is indicated in this column. The indications are as below: Test mode not active on this port Local Loop Applied Outside Loop Applied...
Page 123: Lan Port Alarms
METRODATA LTD WCM5100 123 of 134 User Manual 5.7.4.1 LAN Port Alarms The following alarms may be indicated for a LAN port: LKDN Link Down. A port will enter the link down state if it is not connected, no cable plugged in, or the remote unit is not powered up; or if auto negotiation has not or cannot complete.
Page 124: Vcg Alarms
METRODATA LTD WCM5100 124 of 134 User Manual Link OAM Alarm. If OAM is enabled and responses from the peer device are not received for 3.5seconds the port will declare an OAM alarm. Once the OAM frames are received again, the alarm will be cleared.
Page 125: Sdh Ports
METRODATA LTD WCM5100 125 of 134 User Manual 5.7.4.4 SDH Ports The alarm definitions for the SDH port are as follows Loss of Signal, No optical signal can be detected by the SFP module due to either the fibre not being connected, the remote unit not...
Page 126: Alarms
METRODATA LTD WCM5100 126 of 134 User Manual Remote Defect Indication, this alarm is generated as a response to a LOP/UNEQ/PLM alarm. Signal Defect, this alarm is raised when the bit error rate exceeds the threshold Trace identifier Mismatch, This alarm indicates that the received J1 string does not match the expected value.
Page 127: Vlan Allocation
METRODATA LTD WCM5100 127 of 134 User Manual 5.7.6 VLAN Allocation The VLAN Allocation shows the VLAN ID’s for which this port is a member. Where a port is adding a tag, typically this will show a single ID. The VLAN Allocation is shown, as a string of maximum length 6 characters meaning more...
Page 128: Alarm Extension
In the event that an external alarm bell, or audible warning device is connected it is highly desirable to be able to silence the alarm once the alarm has been acknowledged. The alarm extension menu performs this function Metrodata WCM5100 "" Alarms: Major ALARM EXTENSION clear Alarm outputs <display>...
Page 129: Alarm Actions
METRODATA LTD WCM5100 129 of 134 User Manual 5.8.2 Alarm Actions For each alarm on each port, it may be selectively configured as a Major Alarm, Minor Alarm or none. Major Alarms will activate the major alarm relay, while minor alarms will activate the minor alarm relay.
Page 130: Performance Data
The performance data loggers will collect interface alarm and error statistics for a rolling 24 hour period storing the information in 15 minute buckets. The performance data setup menu is shown below: Metrodata WCM5100 "" Alarms: Major PERFORMANCE DATA Interface...
Page 131: Summary Style
Shows the errored seconds as a percentage of the total seconds Counts Display the raw count information 5.9.4 Physical Layer Stats The physical layer statistics screen is shown below: Metrodata WCM5100 "" Alarms: Major 06:13:51 Sat 1/1/2000 PERFORMANCE SUMMARY WAN1...
Page 132: Circuit / Flow Tests
5.10 Circuit / Flow Tests The circuit / flow test menu enables the user to apply test loopbacks to the various ports of the device. The test menu is shown below: Metrodata WCM5100 "" Alarms: Major CIRCUIT/FLOW TESTS port Loops <menu>...
Page 133: Phy Loops
METRODATA LTD WCM5100 133 of 134 User Manual 5.10.1.1 PHY Loops In order to prevent inadvertent application of the phy loops, the PHY LOOPS must be enabled, and once enabled, the loops are automatically disabled after a defined timeout. Options,...
Page 134: Metrodata Ltd Wcm5100 5 Of
METRODATA LTD WCM5100 134 of 134 User Manual 5.10.1.4 WAN Loops The following loop types may be applied to the WAN port None No Loopback applied, normal operation Local Loopback Applied Outside Loopback Applied Remote Loop Applied 76-02-087 Rev G...
