Page 1 LHM1000 LVM2000 Managed Ethernet Extender V8.70 User Manual DATE: May 2021 DOCUMENT NO: 76-02-082 REVISION: PREPARED BY: Paul Ingram Metrodata Ltd Laxton House, Crabtree Office Village Eversley Way, Egham Surrey, TW20 8RY, UK Tel +44 1 784 744700 E-Mail: support@metrodata.co.uk...
Page 2 Further, Metrodata Ltd reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of Metrodata Ltd to notify any person of such revision or changes. ©...
Page 3 METRODATA LTD 3 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual Document Revision History December 2010 Document Created June 2011 Document updated for Software version 7.9 and merged with WCM3100 product manual. January 2012 Upgraded for V7.14 application software,...
Page 4: Table Of Contents
METRODATA LTD 4 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual TABLE OF CONTENTS INTRODUCTION ......................12 Product Rear Panels ............................. 14 1.1.1 WCM1100 ..............................14 1.1.2 WCM3100 ..............................14 1.1.3 WCM-Serial..............................15 1.1.4 LHM1000 ..............................15 1.1.5...
Page 5 METRODATA LTD 5 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual VLAN Trunk Mode ............................... 30 S-Tag Mode ................................30 Aggregator End Point Mode ..........................31 QUICK START CONFIGURATION ................32 Cold start the unit ..............................32 Access the WCM ..............................
Page 6 METRODATA LTD 6 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.1.10.5 Input Config ............................56 Operational Modes ..............................57 5.2.1 Aggregation Mode ............................57 5.2.2 VLAN Mode ..............................58 5.2.3 Multiple FID (Forwarding Information Database) ..................58 5.2.4...
Page 7 METRODATA LTD 7 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.3.1.7.1.2.1 Port Mode ......................... 78 5.3.1.7.1.2.2 S-VLAN (Access Port) ..................... 79 5.3.1.7.1.2.3 Priority Source (Access Port) ................... 79 5.3.1.7.1.2.4 Default Priority (Access Port)................... 79 5.3.1.7.1.3...
Page 8 METRODATA LTD 8 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.3.5.4 Mode ..............................102 5.3.5.5 Outgoing Controls ..........................102 5.3.5.6 Incoming Controls ..........................103 5.3.6 LHM1000 WAN Port Configuration ......................104 5.3.6.1 Interface Name ........................... 104 5.3.6.2...
Page 9 METRODATA LTD 9 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.5.2 Interface ............................... 121 5.5.2.1 State..............................121 5.5.2.2 Physical Address ..........................121 5.5.2.3 DHCP ..............................122 5.5.2.4 IP Address ............................122 5.5.2.5 Network Mask ............................ 122 5.5.2.6...
Page 10 METRODATA LTD 10 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.7.3 Test ................................147 5.7.4 Alarms ................................. 147 5.7.4.1 LAN Port Alarms ..........................148 5.7.4.2 SFP Port Alarms ..........................148 5.7.4.3 VCG Alarms ............................149 5.7.4.4...
Page 11 METRODATA LTD 11 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.10.1 Interface ..............................168 5.10.2 Display Mode ............................168 5.10.3 Summary Style ............................169 5.10.4 Physical Layer Stats ..........................169 76-02-082 Rev N...
Page 12: Introduction
WCM1100, WCM3100, WCM-Serial, LHM1000 and LVM2000 will be used for product specific areas. The Metrodata WCM allows for the extension of an Ethernet Service over a Wide Area Network Connection. The WCM is a managed unit allowing for the effective demarcation between LAN and WAN services.
Page 13 METRODATA LTD 13 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual The WCM supports either IP DSCP, or IEEE802.1p based traffic prioritisation with outgoing traffic being queued in one of four priority queues. The WCM supports link OAM, IEEE802.3ah and RSTP for loop prevention.
Page 14: Product Rear Panels
METRODATA LTD 14 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 1.1 Product Rear Panels The WCM device is a compact unit, as shown below, occupying half a shelf in a traditional 19inch rack. All power and data connectors and LED status indicators are accessible from the rear of the unit.
Page 15: Wcm-Serial
METRODATA LTD 15 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 1.1.3 WCM-Serial 1.1.4 LHM1000 1.1.5 LVM2000 76-02-082 Rev N...
Page 16: Safety
METRODATA LTD 16 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 1.2 Safety The WCM must not be connected to cabling which would be required by BS6701 to equipped with over voltage protection. The following ports on the WCM are designated SELV (Safety Extra Low Voltage) within the scope of EN41003.
Page 17: Rohs Compliance
METRODATA LTD 17 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 1.5 RoHS Compliance The WCM is compliant with the EU RoHS Directive 2002/95/EC. The RoHS directive bans the use of six hazardous materials in products placed on the market after July 1 2006.
Page 18: Installation
METRODATA LTD 18 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 2 INSTALLATION 2.1 WCM Rear Panel The WCM is available with either AC Mains or DC power options. 2.1.1 Mains Power The WCM has an internal power supply and is supplied via an IEC mains power socket.
Page 19: Redundant Dc Power
The internal DC power modules are polarity protected, and internally fused. Metrodata recommend the use of fork terminals, (not supplied) for connection of power, as shown: However, if necessary, the stripped and twisted ends of the power wires may be inserted into the screw terminals, as shown.
Page 20: Base Label And Bit Switches
METRODATA LTD 20 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 2.2 Base Label and Bit Switches On the underside of the WCM unit there are bit switches which may be used to configure certain functions within the unit. The bit switches are used to configure the default settings following a cold start.
Page 21: Wcm3100 Base Label
METRODATA LTD 21 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 2.2.2 WCM3100 Base Label 2.2.3 WCM-Serial Base Label 76-02-082 Rev N...
Page 22: Lhm1000 Base Label
METRODATA LTD 22 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 2.2.4 LHM1000 Base label 2.2.5 LVM2000 Base label 76-02-082 Rev N...
Page 23: Bit Switches
METRODATA LTD 23 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 2.2.6 Bit Switches The bit switches are used to configure the default settings following a cold start, either from the console, or by powering on with switch 8 in the OFF position.
Page 24: Bit Switch 5, Timing Mode/Resync
METRODATA LTD 24 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual DS-3 G.703 C-Bit Framed (WCM3100) E1/E3/DS-3 G.703 Unframed This bit switch is unused on the WCM-Serial or LHM1000 which do not offer framed modes.
Page 25: Bit Switch 7, Sfp Mode
METRODATA LTD 25 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual DS-3 G.703 This bit switch is not used on the WCM-Serial as the interface mode is automatically selected by the auto sensing cables. LHM1000 uses a fixed HSSI port and LVM2000 uses a fixed LVDS port.
Page 26: Rack Mounting
METRODATA LTD 26 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 2.3 Rack mounting The WCM is a standalone, desktop unit however it may be mounted in a standard 19 inch rack using the rack mounting kit, part number 80-05-256.
Page 27: Lvm2000 Lvds Eia-644 Dte Port
METRODATA LTD 27 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 2.4 LVM2000 LVDS EIA-644 DTE Port The LVDS interface is presented on a 25-way male D-type connector. The rear panel connector layout is shown below:...
Page 28 METRODATA LTD 28 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 76-02-082 Rev N...
Page 29: Wcm Applications
METRODATA LTD 29 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 3 WCM APPLICATIONS 3.1 WCM Normal Mode In this application, the WCM is operating with Traffic Isolation Disabled. In this mode, the WCM acts as a simple, layer 2, 5 port switch with packets switched based on MAC address alone.
Page 30: Vlan Trunk Mode
METRODATA LTD 30 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 3.3 VLAN Trunk Mode In this mode, both WCM units have VLAN support enabled, and all ports are defined as access ports VLAN 101 is used as the management VLAN and in unit WCMx100-A the VLAN group 101 includes the LAN Port 1, the Manager and the PDH WAN port.
Page 31: Aggregator End Point Mode
METRODATA LTD 31 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 3.5 Aggregator End Point Mode In this application, the MC12000 chassis is fitted with a WCC-1400, 4 port E1 Aggregation module. The Management Module in the MC12000 has the aggregate data stream connected to one of the front panel Gigabit Ethernet ports, and this stream is fed across the backplane to each individual modules.
Page 32: Quick Start Configuration
METRODATA LTD 32 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 4 QUICK START CONFIGURATION The following guide gives a simple, quick start introduction to configuring the WCM for Normal Mode operation as shown in section 2.1 4.1 Cold Start the Unit...
Page 33: Logging Onto Wcm
Password (‘view’ to view only) : Metrodata WCM3100: Local connection to “” Password (‘view’ to view only) : Metrodata WCM-Serial: Local connection to “” Password (‘view’ to view only) : Metrodata LHM1000: Local connection to “” Password (‘view’ to view only) : Metrodata LVM2000: Local connection to “”...
Page 34: User Interface Navigation
METRODATA LTD 34 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual <escape> - exit menu 4.3.1 User Interface Navigation The WCM user interface is a simple, menu based interface. Each selectable item may be selected by typing the first capital of the option, e.g. for “Data port set-up” type <D>...
Page 35: Configure The Wan Interface
In order for two WCM units to communicate they must be connected using the WAN port. The WAN interface must be configured to match the network NTU configuration. The WAN port is configured by selecting the Port Set-Up Menu, Metrodata WCM1100 "" Alarms: Major PORT SET-UP lan1 <menu>...
Page 36: Wcm3100 E3 Configuration
METRODATA LTD 36 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 4.4.2 WCM3100 E3 Configuration The WCM3100 WAN E3 port configuration menu is shown below: Metrodata WCM3100 "" Alarms: Major State Interface Timing Internal Framing G.832...
Page 37: Wcm-Serial Configuration
The multi serial interface is presented on an HD60 connector and is compatible with standard Cisco serial cables. The interface automatically senses the cable type that is connected, and configures itself accordingly. The WAN Configuration Menu when a CAB-V35-FC is fitted is shown below: Metrodata WCM-Serial "" Alarms: Major State interface V.35...
Page 38: Lhm1000 Configuration
The LHM1000 has a HSSI interface presented on the 50 way SCSI-2 connector. The interface supports clock rates upto 65Mbps and is presented as a DTE port.. The WAN Configuration Menu is shown below: Metrodata LHM1000 "" Alarms: Major interface Name...
Page 39: Lvm2000 Configuration
The LVM2000 has an LVDS interface presented on the 25 way D male connector. The interface supports clock rates upto 51.84Mbps and is presented as a DTE port.. The WAN Configuration Menu is shown below: Metrodata LVM2000 "" Alarms: Major interface Name...
Page 40: Set Ip Address
METRODATA LTD 40 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 4.5 Set IP Address From the Main Setup Menu, select Management Entity, Metrodata WCM3100 "" Alarms: Major MANAGEMENT ENTITY proXying <menu> intErface <menu> <menu>...
Page 41: Set Default Route
If DHCP is not used, you must assign the required network mask for correct installation into the network. 4.6 Set Default Route From the Main Setup Menu, select Management, then IP, Metrodata WCM3100 "" Alarms: Major default TTL DSCP priority...
Page 42: Save The Configuration
WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 4.7 Save the Configuration From the Main Set Up menu, select the Update EEPROM option to save the configuration to non volatile memory. Answer ‘Y’ at the prompt. Metrodata WCM3100 "" Alarms: Major MAIN SET-UP Global status <display>...
Page 43: Advanced Configuration
WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5 ADVANCED CONFIGURATION 5.1 System Configuration The system menu provides the basic administrative configuration items for the WCM and should be configured first. The System Menu is shown below: Metrodata WCM3100 "" Alarms: Major SYSTEM Time & date <menu>...
Page 44: Setting The Time And Date
In applications where NTP is not available, the WCM defaults to providing a simple uptime display. To configure the NTP parameters, select the “Time and date” menu from the “System” menu. The menu is as below: Metrodata WCM3100 "" Alarms: Major TIME & DATE local Time...
Page 45: Setting The Node Name
To enable identification of the WCM, it is useful to enter a meaningful name for the unit. The node name is entered as a string of up to 32 alpha numeric characters, including spaces. Metrodata WCM3100 "WCM Node A" Alarms: Major SYSTEM Time &...
Page 46: Access Control
WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.1.3 Access Control The access control menu defines the security policy for management access to the WCM unit. The Access Control menu is shown below: Metrodata WCM3100 "WCM Node A" Alarms: Major ACCESS CONTROL Password ********...
Page 47: Password Recovery
The super me option will raise the user level to super user which will enable some extra diagnostic and debug screens. 5.1.3.4 TACACS+ Where greater access control and security is required, the WCM units support TACACS+ for central password authentication. Metrodata WCM3100 "" Alarms: Major TACACS+ Authentication Local...
Page 48: Authentication
METRODATA LTD 48 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.1.3.4.1 Authentication The WCM supports three modes of password access control and authentication. The options are: Local (Default) The password access control is handled locally by the WCM unit and the unit password should be used to log in.
Page 49: Encryption Key
METRODATA LTD 49 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.1.3.4.6 Encryption Key This key is used by both the WCM and the TACACS+ server to provide a secure, encrypted password exchange and authentication. This must be set the same on both WCM and Server(s).
Page 50: Welcome Screen
However, it is possible to customize the welcome banner to give further information about the unit, or to inform the user of access restrictions. To configure the welcome screen select the “welcome screen” menu item which will lead to the menu: Metrodata WCM "WCM Node A" Alarms: Major WELCOME SCREEN Welcome screen...
Page 51 51 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual If a customized welcome is required, change to enabled and the menu will change as shown below: Metrodata WCM "WCM Node A" Alarms: Major WELCOME SCREEN Welcome screen...
Page 52: Software Version
METRODATA LTD 52 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual Metrodata WCM3100 "WCM Node A" Alarms: Major WELCOME SCREEN -------------- This is an example of a Welcome Banner Welcome to the WCM Please enter the password>...
Page 53: Warm Start
METRODATA LTD 53 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.1.7 Warm Start A warm Start will force the WCM to restart and reload the configuration from the EEPROM. Note, any changes to configuration that have not been saved to the EEPROM will be lost.
Page 54: Maintenance
WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.1.10 Maintenance The maintenance menu contains the event log and config generation functions and can be seen below: Metrodata WCM3100 "WCM Node A" Alarms: Major MAINTENANCE System event log <display>...
Page 55: Alarm Event Log
WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.1.10.2 Alarm Event Log The alarm event log stores the set and clear times for all alarm conditions as shown below: Metrodata WCM3100 "WCM Node A" Alarms: Major --- Alarm Event Log --- 1/1/2000...
Page 56: Input Config
METRODATA LTD 56 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.1.10.5 Input Config The input configuration menu item allows a configuration file to be loaded onto the WCM unit using the serial port. The configuration file for use may have been generated using either the serial output configuration option, or have been saved via TFTP.
Page 57: Operational Modes
WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.2 Operational Modes The operational mode menu defines the operating mode for the unit. The menu is shown below: Metrodata WCM3100 "WCM Node A" Alarms: Major OPERATIONAL MODES aGgregation Mode...
Page 58: Vlan Mode
METRODATA LTD 58 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.2.2 VLAN Mode The WCM units support two modes of operation, C-VLAN and QinQ/S-VLAN. The modes are explained below: In C-VLAN mode, frames may be untagged, or tagged with an IEEE 802.1q VLAN tag with Ethertype 8100.
Page 59: Mac Learning
METRODATA LTD 59 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.2.5 MAC Learning The heart of the WCM unit is a layer 2 switch which uses the MAC Address Forwarding Information Database to make switching decisions. The MAC addresses are automatically learnt as each packet traverses the switch.
Page 60: Rate Limiting Mode
METRODATA LTD 60 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.2.8 Rate Limiting Mode Each port supports rate limiting to police the input traffic stream. This configuration items determines the method of calculating the traffic stream bandwidth. The options are as...
Page 61: Priority Management
WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.2.9 Priority Management This configuration menu provides the configuration for the WCM QOS support. The priority management menu is as below: Metrodata WCM3100 "WCM Node A" Alarms: Major PRIORITY MANAGEMENT DSCP->C-Tag Mapping <menu>...
Page 62: Queue Priorities
5.2.9.2 Queue Priorities The WCM has four levels of priority queue, and these queues operate in a strict priority manner. The queue priorities menu is shown below: Metrodata WCM1100 "" Alarms: Major C-TAG->QUEUE PRIORITY MAPPING Queue Priority:...
Page 63: Vlan Override
5.2.9.3 VLAN Override The VLAN override menu allows the user to overwrite the PCP tag of incoming user frames to force the PCP to a defined level. The menu is as shown below: Metrodata WCM1100 "" Alarms: Major VLAN-BASED PRIORITY OVERRIDE...
Page 64: Rstp
The WCM supports RSTP for loop prevention when resilient network topology is used. This menu defines the global RSTP configuration for the switch, port specific parameters, including PortFast are configured under the port menus. The RSTP configuration menu, once enabled, is as below: Metrodata WCM1100 "WCM1100" Alarms: Major RSTP Mode...
Page 65: Hello Time
METRODATA LTD 65 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.2.9.9 Hello Time The Hello Time parameter defines the period between configuration BPDU transmissions on designated ports. 5.2.9.10 Forward Delay The Forward Delay is the timeout used by a port which is not receiving BPDU’s before a port will transition from DISCARDING to FORWARDING.
Page 66: Status
WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.2.9.13 Status The status screen enables the user to determine the RSTP state of the device and its position within the network topology. Metrodata WCM1100 "WCM1100" Alarms: Major RSTP STATUS ----------- | Root...
Page 67: Port Set Up Menu
WAN, and LAN ports. A simple configuration will be shown for each type of port. The port configuration is accessed from the main setup menu by selecting the data port menu. The data port menu gives the following options. Metrodata WCM3100 "WCM Node A" Alarms: Major PORT SET-UP lan1 <menu>...
Page 68: Lan Port
RJ45 connectors and support access to the other external local LAN ports, the management processor or the WAN forwarding port. The LAN port menu allows for configuration of the LAN port parameters and VLAN settings. Metrodata WCM3100 "WCM Node A" Alarms: Major LAN1 interface Name...
Page 69: Port Mode
When AN is disabled, the configured speed and duplex are displayed. 5.3.1.5 Port Management The port management menu allows the physical configuration of the LAN port to be defined. The port management menu is shown below: Metrodata WCM3100 "WCM Node A" Alarms: Major PORT MANAGEMENT max spEed 1000M...
Page 70: Auto Negotiation
METRODATA LTD 70 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.3.1.5.3 Auto Negotiation The port may be configured to automatically determine the optimal operating parameters for link speed and duplex. Alternatively, it may be disabled to enable configuration of fixed operating parameters.
Page 71: Cable Tester
Where unreliable operation is detected on a port, running a cable test will verify that the cable is correctly connected, and terminated. The display for a good, 1000M connection is as below: Metrodata WCM3100 "WCM Node A" Alarms: Major Cable Tester...
Page 72: Link Loss Forwarding
(utilization/information/L3). Frames priority is determined using the ingress, or overridden PCP value which may also be based on the DSCP value as determined in the operating mode menu. The rate limiting menu is as shown: Metrodata WCM1100 "" Alarms: Major RATE LIMITING, LAN1 mOde...
Page 73: Mode
WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual The individual rate limits are applied by selecting the queue type and then entering the required rate limits as shown: Metrodata WCM1100 "" Alarms: Major RATE LIMITING, LAN1, HIGH...
Page 74: Cbs
METRODATA LTD 74 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.3.1.6.3.4 CBS The CBS (Committed Burst Size) defines the maximum burst size for frames ingressing at a rate in excess of the CIR. The CBS is defined in bytes.
Page 75: Layer 2 Management
WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.3.1.7 Layer 2 Management The L2 management menu configures the layer 2 frame processing and control protocol support. The L2 management menu is as shown below: Metrodata WCM3100 "WCM Node A" Alarms: Major L2 MANAGEMENT, LAN1 Tagging & Priority <menu>...
Page 76: Vlan Allocation
METRODATA LTD 76 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.3.1.7.1.1.1 VLAN Allocation The VLAN Allocation defines which VLAN’s this port has membership of, Ingress frames with VLAN ID’s included in the allocation will be accepted, ID’s outside this range will be discarded.
Page 77: Priority Source
METRODATA LTD 77 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.3.1.7.1.1.4 Priority Source The priority source is used to determine the source of the priority value in the frames egress tag. The options are as below:...
Page 78: Qinq/S-Vlan Mode
WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.3.1.7.1.2 QinQ/S-VLAN Mode When the operational mode of the WCM is set to QinQ/S-VLAN mode the tagging and priority menu is as below, for access ports Metrodata WCM3100 "WCM Node A" Alarms: Major TAGGING & PRIORITY, LAN1 port Mode...
Page 79: S-Vlan (Access Port)
METRODATA LTD 79 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.3.1.7.1.2.2 S-VLAN (Access Port) The S-VLAN definition defines the ID to be used for tags pushed onto frames ingressing an access port. This value also defines that frames ingressing a trunk port with this ID will egress with the S-Tag popped from this port.
Page 80: S-Vlan Allocation (Trunk Port)
METRODATA LTD 80 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.3.1.7.1.3.1 S-VLAN Allocation (Trunk Port) A trunk port will only accept frames which are tagged with an S-Tag having a valid Ethertype and also an ID that is within the allocated range. Untagged, or ID’s outside the allocation will be discarded.
Page 81: Oam
81 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.3.1.7.2 OAM The WCM supports IEEE 802.3ah Link OAM which may be configured on a per port basis: Metrodata WCM3100 "" Alarms: Major OAM, LAN1 Mode...
Page 82: Oam Status
Node name: "Test Unit" Interface: LAN1 Interface AdSt OpSt LAN2 Down Down <Esc> - exit, <Enter> - refresh Where the peer device is another Metrodata device, proprietary extensions to OAM are used to report further remote peer status information. 76-02-082 Rev N...
Page 83: Oam Counters
WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.3.1.7.2.3 OAM Counters The counters provide an indication of the OAM interactions taking place. In normal operation, the information frames should be incrementing at a rate of 1 per second. Metrodata WCM3100 "" Alarms: Major OAM Statistics --------------...
Page 84: Rstp
WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.3.1.7.3 RSTP When RSTP is enabled on the WCM unit, there are several parameters which need to be defined on a per port basis. The port rstp menu is shown below: Metrodata WCM3100 "" Alarms: Major RSTP, LAN1 Priority...
Page 85: E-Tree Branch
A port configured as an E-Tree Branch can only pass data to a non branch port. Non branch ports can pass data to all ports. 5.3.1.8 Counters Each LAN port provides a set of counters supporting the basic MIB-2 SNMP parameters as below: Metrodata WCM3100 "WCM Node A" Alarms: Major Interface Statistics -------------------- ifInOctets...
Page 86: Sfp Port
SFP MSA definition. Metrodata supplied SFP devices will indicate the SFP type, however some lower cost, lower quality SFP devices may not be correctly programmed and will indicate “UNKNOWN”...
Page 87: Link Status
When AN is disabled, the configured speed and duplex are displayed. 5.3.2.6 Port Management The port management menu allows the physical configuration of the LAN port to be defined. The port management menu is shown below: Metrodata WCM3100 "WCM Node A" Alarms: Major PORT MANAGEMENT max spEed 1000M...
Page 88: Negotiated
The menu also allows the notifications to be defined to allow for traps and alarms to be generated based on the SFP diagnostic information. The SFP management menu is shown below: Metrodata WCM3100 "WCM3100_Left" Alarms: none SFP MANAGEMENT Device Details <display>...
Page 89: Device Details
METRODATA LTD 89 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.3.2.7.1 Device Details This menu displays further information regarding the SFP device: Metrodata WCM3100 "WCM Node A" Alarms: Major SFP Info Interface: SFP --------...
Page 90: Notifications
The Notifications menu allows traps and alarms to be generated based on alarms or warnings raised by the SFP diagnostic information. The menu is shown below, with a common set up with traps/alarms enabled for the high termperature and low receive power. Metrodata WCM3100 "WCM3100_Left" Alarms: none NOTIFICATIONS 1 - Temp High Alarm &...
Page 91: Layer 1 Management
Refer to section 5.3.1.7 for a full description 5.3.2.11 Counters The SFP provides counters to show the packets that pass over this port as shown below: Metrodata WCM3100 "WCM Node A" Alarms: Major Interface Statistics -------------------- ifInOctets ifInUcastPkts...
Page 92: Wcm1100 Wan E1/T1 Port
Short-haul Framing Framed crc-4 Enabled siGnalling Disabled First CAPITAL - select item <escape> - exit menu And for T1: Metrodata WCM1100 "WCM Node A" Alarms: Major interface Name State Interface T1 (RJ45) Timing Internal rx sEnsitivity DSX-1 tx line Build-Out...
Page 93: State
METRODATA LTD 93 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.3.3.2 State The state configuration defines the Administrative State of the WAN port. For normal operation it must be set to UP. In applications where the WAN link is not used, the state should be set to Down to disable the alarm processing on the WAN port.
Page 94: Rx Sensitivity
METRODATA LTD 94 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.3.3.5 RX Sensitivity The WAN port supports both short and long haul modes of operation. The Rx Sensitivity mode may be toggled between: For E1 mode...
Page 95: Framing
METRODATA LTD 95 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.3.3.7 Framing The WAN port may be configured to operate in the following modes For E1 mode Unframed Clear channel, 2.048Mbps Framed G.704 Framed, 1.984Mbps payload Fractional G.704 Framed, Nx64...
Page 96: Allocation
WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.3.3.11 Allocation When Fractional Framing mode is selected, this configuration item allows the required timeslots to be configured. Metrodata WCM1100 "" Alarms: Major State Interface E1 Unbal (BNC) Timing...
Page 97: Wcm3100 Wan Port
METRODATA LTD 97 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.3.4 WCM3100 WAN Port The WCM3100 WAN Port menu is as below: Metrodata WCM3100 "" Alarms: Major interface Name State Interface Timing Internal Framing G.832...
Page 98: State
METRODATA LTD 98 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.3.4.2 State The state configuration defines the Administrative State of the WAN port. For normal operation it must be set to UP. In applications where the WAN link is not used, the state should be set to Down to disable the alarm processing on the WAN port.
Page 99: Framing
METRODATA LTD 99 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.3.4.6 Framing The WAN port may be configured to operate in the following modes Unframed Clear channel, E3 or DS-3 Framed G.832 E3 / C-Bit DS-3...
Page 100: Wcm-Serial Wan Port Configuration
5.3.5 WCM-Serial WAN Port Configuration The main serial port menu varies depending upon which cable type is fitted. Below are the options shown for no cable, V.35 and X.21 For no cable fitted: Metrodata WCM-Serial "" Alarms: Major interface Name State...
Page 101 METRODATA LTD 101 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual With X.21 DTE (CAB-X21-MT) fitted Metrodata WCM-Serial "" Alarms: Major Interface Name State interface X.21 mode 'C' control 'I' state First CAPITAL - select item <escape>...
Page 102: Interface
METRODATA LTD 102 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.3.5.3 Interface This display item shows the type of cable that is fitted, and the electrical specification of the serial interface. The following options are supported: V.35...
Page 103: Incoming Controls
METRODATA LTD 103 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.3.5.6 Incoming Controls The serial interface supports several modem control outputs, the controls available depends upon the interface type. These display items show the state of the incoming modem controls.
Page 104: Lhm1000 Wan Port Configuration
METRODATA LTD 104 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.3.6 LHM1000 WAN Port Configuration The WAN port menu is shown below: Metrodata WCM-Serial "" Alarms: Major interface Name State tX timing External Ta control...
Page 105: Outgoing Controls
METRODATA LTD 105 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.3.6.4 Outgoing Controls The HSSI interface supports the TA control output. The options for TA are Always ON, normal operation Always off LOOP Looped to incoming CA 5.3.6.5 Incoming Controls...
Page 106: Lvm2000 Wan Port Configuration
METRODATA LTD 106 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.3.7 LVM2000 WAN Port Configuration The WAN port menu is shown below: Metrodata WCM-Serial "" Alarms: Major interface Name State tX timing External Tr control...
Page 107: Outgoing Controls
METRODATA LTD 107 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.3.7.4 Outgoing Controls The LVDS interface supports the TR control output. The options for TR are Always ON, normal operation Always off LOOP Looped to incoming RR 5.3.7.5 Incoming Controls...
Page 108: Vcg
5.3.8 The VCG (virtual concatenation group) configuration menu is used to define the encapsulation method used for frames being transported over the WAN port. The VCG configuration menu is as below: Metrodata WCM3100 "" Alarms: Major interface Name State Encapsulation <menu>...
Page 109: Encapsulation
109 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.3.8.3 Encapsulation This menu allows the configuration of the packet encapsulation mode for transporting packets across the WAN port. Metrodata WCM3100 "" Alarms: Major ENCAPSULATION, VCG Encapsulation HDLC...
Page 110: Strip Mac Fcs
METRODATA LTD 110 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.3.8.4.1.2 Strip MAC FCS A LAN packet is protected by a 32 bit FCS. Since the encapsulator will add an HDLC FCS it is possible to save bandwidth by removing the Ethernet FCS and recalculate at the far end.
Page 111: Gfp
The WCM1100 offers GFP encapsulation when used on a framed, byte synchronous interface. GFP uses idle packets to delimit and pad, and appends a four byte header to the packet along with a 32 bit FCS. Additional options are: Metrodata WCM1100 "" Alarms: Major ENCAPSULATION, VCG...
Page 112: Lcas/Vcat
In framed modes, insert a single VCAT control byte and run the LCAS protocol over the top. 5.3.8.6 LCAS Status In the event that LCAS is being used, the LCAS status screen gives useful information about the status of the link. Metrodata WCM1100 "" Alarms: Major LCAS Status ----------- outbound (source)
Page 113: Layer 2 Management
The Layer 2 management menu is used to configure the L2 frame processing and control protocol support Refer to section 5.3.1.7 for a full description 5.3.8.9 Counters The VCG provides counters to show the packets that pass over this port as shown below: Metrodata WCM1100 "WCM Node A" Alarms: Major Interface Statistics -------------------- ifInOctets...
Page 114: Setup
WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.4 V.24 Setup The V.24 setup menu configures the local terminal interface for the WCM device. The menu is shown below: Metrodata WCM3100 "" Alarms: Major V.24 SET-UP Usage...
Page 115: Console Set Up
115 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.4.2 Console Set Up This menu defines the operating parameters of the terminal interface as shown: Metrodata WCM3100 "" Alarms: Major CONSOLE SET-UP Terminal type via Modem...
Page 116: Baud Rate
METRODATA LTD 116 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.4.2.3 Baud Rate This sets the baud rate for the terminal interface. The default setting is 19200baud. The options are: 2400 4800 9600 19200 5.4.2.4 Parity...
Page 117: Data Bits
METRODATA LTD 117 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.4.2.5 Data Bits This sets the number of data bits per character for the terminal interface. The default setting is 8. The options are 5.4.2.6 Stop Bits...
Page 118: Management Entity
WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.5 Management Entity The management entity menu defines the IP functionality of the WCM unit to enable remote management access via the LAN, SFP or WAN ports. Metrodata WCM3100 "" Alarms: Major MANAGEMENT ENTITY proXying <menu>...
Page 119: Server Mode Proxy
A client can be supported at the far end of each port of the unit, though in general, only remote units connected via the VCG will be managed as proxy clients. The proxy client set up menu is shown below: Metrodata WCM3100 "" Alarms: Major Proxying...
Page 120: Ip Address
5.5.1.2 Client Mode Proxy When a device is set to be a Proxy client, it simply needs to be configured for which port will be used for the proxy management. The client menu is as below: Metrodata WCM3100 "" Alarms: Major PROXYING...
Page 121: Interface
5.5.2.2 Physical Address The physical address is the unique MAC address assigned to this unit. This address will be of the form: 00:C0:81:xx:yy:zz where 00:C0:81 is the Metrodata OUI, and xx.yy.zz is the unit identifier 76-02-082 Rev N...
Page 122: Dhcp
METRODATA LTD 122 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.5.2.3 DHCP The management entity can use DHCP for automatic IP address allocation, or it may be disabled for manual administration. Options DHCP active, will try to get an IP address from a DHCP server, otherwise will use the default IP address 169.254.42.42...
Page 123: At Table
WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.5.2.6 AT Table The AT table is a display of the ARP resolutions that the WCM unit has made as shown below: Metrodata WCM3100 "" Alarms: Major AT TABLE --------...
Page 124: C-Vlan
The valid range is 0 to 7, with 7 being highest priority. 5.5.3 IP The IP menu defines the layer 3 functionality for the manager interface and is shown below: Metrodata WCM3100 "" Alarms: Major default TTL DSCP priority default Gateway...
Page 125: Default Ttl
METRODATA LTD 125 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.5.3.1 Default TTL The default TTL setting is used as the TTL field in all management IP packets transmitted. The default value is 32. The TTL value is decremented at each router hop and is intended to prevent undelivered packets circulating the internet forever.
Page 126: Routing Table
To assist the manager in understanding how to route frames to remote subnets, the IP routing table gives directions on how to reach each remote destination. The routing table with a default route added automatically by DHCP is shown below: Metrodata WCM3100 "" Alarms: Major Destination Next Hop Type Prot.
Page 127: Delete A Route
5.5.3.4.2 Delete a Route To delete a routing table entry, select delete entry and enter the IP address of the subnet you wish to delete along with the net mask as shown Metrodata WCM3100 "" Alarms: Major Destination Next Hop Type Prot.
Page 128 METRODATA LTD 128 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual The available statistics are shown below: Metrodata WCM3100 "" Alarms: Major IP Statistics ------------- ipInReceives ipInHdrErrors ipInAddrErrors ipForwDatagrams ipInUnknownProtos ipInDiscards ipInDelivers ipOutRequests ipOutDiscards ipOutNoRoutes...
Page 129: Udp
WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.5.4 UDP The UDP menu displays the port numbers used for SNMP Get and Set operations as well as for Trap operation. These should not be altered. Metrodata WCM3100 "" Alarms: Major snmp Port snmp Trap port Stats.
Page 130: Statistics
METRODATA LTD 130 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.5.5.1 Statistics The statistics menu displays the SNMP MIB-2 IfTable TCP statistics as shown: Metrodata WCM3100 "" Alarms: Major TCP Statistics -------------- tcpActiveOpens tcpPassiveOpens...
Page 131: Snmp Management
5.5.6.2 Contact Person The contact person is the SNMP MIB-2 system SysContact parameter, the default setting Metrodata Limited, Fortune House, Eversley Way, Egham, Surrey, TW20 8RY The parameter may be up to 255 characters and should be configured to reflect the actual installation requirements.
Page 132: Node Name
The WCM supports up to 10 configured Network Management Stations. The manager may be configured to operate as SNMP V1 or V2c The Add Manager Menu is as below: Metrodata WCM "" Alarms: Major ADD MANAGER IP address 0.0.0.0...
Page 133: Statistics
The SNMP version may be configured for the manager to support either SNMP V1 or SNMP V2c. 5.5.6.6 Statistics The WCM management entity provides a set of SNMP MIB-2 IfTable SNMP statistics for the interface: Metrodata WCM3100 "" Alarms: Major SNMP Statistics --------------- snmpInPkts...
Page 134: Trap Alarms
This menu allows the individual alarm conditions to be defined as to whether they will force a trap to be generated or not. There is a separate configuration menu for each port type within the unit as shown below: Metrodata WCM3100 "" Alarms: Major TRAP ALARMS lan1 <menu>...
Page 135: Sfp Port Trap Defintions
METRODATA LTD 135 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.5.6.7.2 SFP Port Trap Defintions Metrodata WCM3100 "" Alarms: Major 0 - LOS Trap 1 - LKDN Trap 2 - NF Trap 3 - LLF...
Page 136: Vcg Port Trap Defintions
METRODATA LTD 136 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.5.6.7.3 VCG Port Trap Defintions Metrodata WCM3100 "" Alarms: Major 1 - LKDN Trap 3 - LLF Trap 4 - DEG Trap 5 - OAM...
Page 137 METRODATA LTD 137 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual The alarm definitions for the WAN port are as follows Loss of Signal Loss of Frame All 1’s Received Remote Alarm Indication Loss of VCAT Multiframe Alignment...
Page 138: Telnet / Ssh / Http
5.5.7 Telnet / SSH / HTTP The WCM unit allows remote management by either TELNET or the more secure, encrypted SSH V2. This menu configures the device for remote management access as shown: Metrodata WCM3100 "" Alarms: Major TELNET/SSH Telnet...
Page 139: Tftp
5.5.8.1 TFTP Configuration Under the management menu, select TFTP and enter the parameters as required: 5.5.8.1.1 Client Mode Select client mode to display the menu as below: Metrodata WCM3100 "" Alarms: Major TFTP Mode Client remote IP 192.168.0.100...
Page 140 METRODATA LTD 140 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 76-02-082 Rev N...
Page 141: Get New Software
5.5.8.1.1.2 Get New Software The Get New Software option is selected for performing a main application code update. Following the Get New Software option the warning message below will appear: Metrodata WCM3100 "" Alarms: Major TFTP Software Upgrade CAUTION: Proceding further will mean that the unit must be re-started, and the performance log may be cleared, even if the upgrade is unsuccessful.
Page 142: Boot S/W Upgrade
The Boot S/W update option is selected for performing a boot code update. Following the Boot S/W update option the warning message below will appear: Metrodata WCM3100 "" Alarms: Major TFTP Software Upgrade CAUTION: Proceding further will mean that the unit must be re-started, and the performance log may be cleared, even if the upgrade is unsuccessful.
Page 143: Get Configuration File
For units that support SAM service validation tests, the put report option will allow the generated service birth certificate to be uploaded. This is not supported on the WCM units. 5.5.8.1.2 Server Mode Select SERVER mode to display the menu as below: Metrodata WCM "" Alarms: Major TFTP Mode Server remote IP 192.168.100.70...
Page 144: Ping
Ping is a simple IP/ICMP utility that enables the management connectivity to be verified. Simply enter the IP address of the remote unit and ping will repeatedly send an ICMP Echo request, as shown below: Metrodata WCM3100 "" Alarms: Major Destination: 192.168.100.70 press any key to stop test sending...okay, time=1.7ms...
Page 145: Saving The Configuration
WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.6 Saving the Configuration Once the WCM has been configured, the configuration must be saved to the EEPROM to provide non-volatile storage. Metrodata WCM3100 "" Alarms: Major MAIN SET-UP Global status <display>...
Page 146: Global Status
The Global status screen gives an overview of the status of the WCM unit, and should always be the first port of call when attempting to diagnose a network, or operational problem. The Global Status screen is shown below: Metrodata WCM3100 "" Alarms: Major GLOBAL STATUS History last cleared:...
Page 147: Test
METRODATA LTD 147 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.7.3 Test If a port has a test mode enabled it is indicated in this column. The indications are as below: Test mode not active on this port...
Page 148: Lan Port Alarms
METRODATA LTD 148 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.7.4.1 LAN Port Alarms The following alarms may be indicated for a LAN port: LKDN Link Down. A port will enter the link down state if it is not connected, no cable plugged in, or the remote unit is not powered up;...
Page 149: Vcg Alarms
METRODATA LTD 149 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual Link OAM Alarm. If OAM is enabled and responses from the peer device are not received for 3.5seconds the port will declare an OAM alarm.
Page 150: E1/E3 Wan Ports
METRODATA LTD 150 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.7.4.4 E1/E3 WAN Ports The following alarms may be seen on an E1 or E3/DS3 interface. Loss of Signal. No signal, or all zero’s is being received on the WAN interface.
Page 151: Mode, Speed, Duplex
METRODATA LTD 151 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.7.5 Mode, Speed, Duplex The Mode, Speed and Duplex columns indicate the fixed or negotiated parameters for the LAN and SFP interfaces. 5.7.6 VLAN Allocation The VLAN Allocation shows the VLAN ID’s for which this port is a member.
Page 152: Alarm Extension
In the event that an external alarm bell, or audible warning device is connected it is highly desirable to be able to silence the alarm once the alarm has been acknowledged. The alarm extension menu performs this function Metrodata WCM3100 "" Alarms: Major ALARM EXTENSION clear Alarm outputs <display>...
Page 153 METRODATA LTD 153 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual The WCM units only provide a major alarm relay which is accessed via the 9 way D connection and is shared with the terminal port.
Page 154: Circuit / Flow Tests
METRODATA LTD 154 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.9 Circuit / Flow Tests The circuit/flow test menu is as shown: Metrodata WCM3100 "" Alarms: Major CIRCUIT/FLOW TESTS Traffic Generator <menu> port Loops <menu>...
Page 155: Physical Loops
METRODATA LTD 155 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.9.1.1 Physical Loops As the WCM units are LAN service delivery platforms and loopbacks within an Ethernet can cause major problems due to broadcast storms, great care must be taken when using loopbacks for testing.
Page 156: Lan / Sfp Loops
METRODATA LTD 156 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.9.1.4 LAN / SFP Loops The LAN and SFP ports support the following loopback options: 5.9.1.4.1 Phy Line Loop (OL) In order to use the copper phy line loopback (loop receive back to transmit) first the PHY LOOPs must be enabled.
Page 157: Wan Port
METRODATA LTD 157 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.9.1.6 WAN Port The WAN port supports the following loops. 5.9.1.6.1 WAN Remote Loop In order to test the WAN circuit a remote loop may be requested by sending a loop up command to the remote unit.
Page 158: Ol, Outside Loop
METRODATA LTD 158 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.9.1.6.3 OL, Outside Loop When Phy Loops are enabled, an Outside loop (Loop transmit back to receive) may be applied to the WAN port.
Page 159: Test Pattern (For E1, E3 And Ds3 Wan Ports)
RL command to the remote WCM unit to perform an end to end test on the line. If this fails, then contact the network operator to have loopbacks applied to the intermediate nodes to prove the circuit in segments. The WAN test pattern menu is as shown below: Metrodata WCM3100 "" Alarms: Major TEST PATTERN, WAN State...
Page 160: State
METRODATA LTD 160 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.9.2.1 State The state indicates the state of the BERT generator. The options are: Disabled WAN payload contains normal user traffic Enabled WAN payload contains a BERT test pattern.
Page 161: Results
METRODATA LTD 161 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.9.2.4 Results The results display shows the results as the test progresses. Metrodata WCM3100 "" Alarms: Major BERT Test Results ----------------- Test Seconds Out of Sync Seconds...
Page 162: Bit Error Rate
METRODATA LTD 162 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.9.2.4.4 Bit Error Rate The bit error rate is calculated based on the number of errors received as a rate based on the total received bit count.
Page 163: Interface
METRODATA LTD 163 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual The WAN test pattern menu is as shown below: Metrodata WCM3100 "" Alarms: Major TEST PATTERN, WAN interface pattern BERT Polarity Normal Mode Tx&Rx Results <display>...
Page 164 METRODATA LTD 164 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual Note, Ensure that the Test Pattern Mode is Tx&Rx before requesting loops from the carrier otherwise loops may be applied to live LAN traffic. Also, ensure the loops have been removed before the BERT test pattern is disabled.
Page 165: Results
METRODATA LTD 165 of 169 WCM1100 / WCM3100 / WCM-Serial / LHM1000 / LVM2000 User Manual 5.9.3.5 Results The results display shows the results as the test progresses. Metrodata WCM3100 "" Alarms: Major BERT Test Results ----------------- Test Seconds Out of Sync Seconds...
Page 166: Bit Error Rate
Typing <E> will inject a single bit error into the bit stream. 5.9.4 Traffic Generator The Test Traffic Generator allows test traffic to be generated and received/monitored to determine the quality of a link when a loopback is applied. Metrodata WCM1100 "WCM Node A" Alarms: Major TRAFFIC GENERATOR Interface...
Page 167: Running
5.9.4.3 Packet Size This setting defines the size of the test packets. (64 to 1518 bytes) 5.9.4.4 Counters The counters display shows the results of the running test as shown below: Metrodata WCM1100 "WCM Node A" Alarms: Major Packet Generator Statistics ---------------------------...
Page 168: Performance Data
The performance data loggers will collect interface alarm and error statistics for a rolling 24 hour period storing the information in 15 minute buckets. The performance data setup menu is shown below: Metrodata WCM3100 "" Alarms: Major PERFORMANCE DATA Interface...
Page 169 Shows the errored seconds as a percentage of the total seconds Counts Display the raw count information 5.10.4 Physical Layer Stats The physical layer statistics screen is shown below: Metrodata WCM3100 "WCM3100_Right" Alarms: none 03:24:34 Sat 1/1/2000 PERFORMANCE SUMMARY Current Alarms: none...
