Page 1 WCM5100 Managed Ethernet Extender V8.51 User Manual DATE: April 2015 DOCUMENT NO: 76-02-087 REVISION: PREPARED BY: Ian Banbrook Metrodata Ltd Laxton House, Crabtree Office Village Eversley Way, Egham Surrey, TW20 8RY, UK Tel +44 1 784 744700 Fax: +44 1 784 744730...
Page 2 Further, Metrodata Ltd reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of Metrodata Ltd to notify any person of such revision or changes. ©...
Page 3: Document Revision History
METRODATA LTD WCM5100 3 of 144 User Manual Document Revision History April 2011 Document Created April 2011 Updated for Multiple VC modes May 2011 Document Released June 2011 Document typos corrected New feature VC-3 allocation added August 2011 Updated to add multiple VC-3 with VCAT...
Page 4: Table Of Contents
Bit switch 8, Factory Default ....................... 17 Rackmounting ............................... 18 WCM5100 APPLICATIONS ..................19 WCM5100 Normal Mode ............................. 19 WCM5100 VLAN Trunk Mode ........................... 19 VLAN Mode ................................20 S-Tag Mode ................................20 QUICK START CONFIGURATION ................21 Cold Start the Unit ..............................21 Access the WCM ..............................
Page 5 WCM5100 5 of 144 User Manual Configure the WAN interface ..........................24 4.4.1 WCM5100 WAN Configuration ........................24 Set IP Address ............................... 25 Set Default Route..............................26 Save the Configuration ............................27 ADVANCED CONFIGURATION ................28 System Configuration ............................28 5.1.1...
Page 6 METRODATA LTD WCM5100 6 of 144 User Manual 5.2.9.10 Forward Delay ............................50 5.2.9.11 Tx Hold ..............................50 5.2.9.12 Version ..............................50 5.2.9.13 Status ..............................51 5.2.9.13.1 Port Role ............................51 5.2.9.13.2 Port State ............................51 Port Set Up Menu ..............................52 5.3.1...
Page 7 METRODATA LTD WCM5100 7 of 144 User Manual 5.3.2.1 Interface Name ............................. 71 5.3.2.2 SFP Type .............................. 71 5.3.2.3 State..............................71 5.3.2.4 Link Status ............................72 5.3.2.5 Port Mode ............................. 72 5.3.2.6 Port Management ..........................72 5.3.2.6.1 Speed ............................... 72 5.3.2.6.2...
Page 8 METRODATA LTD WCM5100 8 of 144 User Manual 5.3.6.3 Path Signal Label ..........................92 5.3.6.4 Receiving ............................. 93 5.3.6.5 J1 Transmit ............................93 5.3.6.6 J1 Expected ............................93 5.3.6.7 Receiving ............................. 93 5.3.6.8 RDI Type ............................. 93 5.3.6.9 VCG ..............................93 V.24 Setup ................................
Page 9 METRODATA LTD WCM5100 9 of 144 User Manual 5.5.6.5 Managers ............................111 5.5.6.6 Statistics ............................. 112 5.5.6.7 Trap Alarms ............................113 5.5.6.7.1 LAN Port Trap Definitions ......................113 5.5.6.7.2 SFP Port Trap Defintions ......................114 5.5.6.7.3 VCG Port Trap Defintions ......................115 5.5.6.7.4...
Page 10 METRODATA LTD WCM5100 10 of 144 User Manual 5.10.2.2 Timeout .............................. 141 5.10.2.3 LAN/SFP Loop Modes ........................141 5.10.2.4 VCG Loop Modes ..........................142 5.10.2.5 WAN Loops ............................143 5.10.2.5.1 LL, Local Loopback Applied ....................... 143 5.10.2.5.2 OL,Outside Loopback Applied ....................143 5.10.2.5.3...
Page 11: Introduction
The WCM5100 has an internal LAN switch offering full wire-speed switching between ports. The WCM5100 uses MAC address filtering to filter all local traffic and only forward traffic destined for remote stations. Each of the WCM5100’s LAN ports support automatic cross-over switching and will therefore connect directly to a Hub/Switch/Router or PC End Station.
Page 12: Wcm5100 Rear Panel
User Manual 1.1 WCM5100 Rear Panel The WCM5100 device is a compact unit, as shown below, occupying half a shelf in a traditional 19inch rack. All power and data connectors and LED status indicators are accessible from the rear of the unit.
Page 13: Electro Magnetic Compatibility
EMC compliance. 1.3.1 EN55022 Statement The WCM5100 is a Class A product. In a domestic environment, this product may cause radio interference, in which case the user will be required to take adequate measures. 1.3.2 FCC Declaration This equipment has been tested and found to comply with the limits of the Class A digital device, pursuant to Part 15 of the FCC rules.
Page 14: Installation
The WCM5100 is available with either AC Mains or DC power options. 2.1.1 Mains Power The WCM5100 has an internal power supply and is supplied via an IEC mains power socket. The WCM5100 operates over the wide range 100 to 250V AC and draws less than 6 watts.
Page 15: Base Label And Bit Switches
User Manual 2.2 Base Label and Bit Switches On the underside of the WCM5100 unit there are bit switches which may be used to configure certain functions within the unit. The bit switches are used to configure the default settings following a cold start.
Page 16: Bit Switch 2, Boot Mode 1
This bit switch determines the operating mode of the SDH WAN interface. SONET OC-3 SDH STM-1 This bit switch is currently unused on the WCM5100 which does not offer SONET operation. 2.2.2.5 Bit switch 5, Timing Mode This bit switch determines the timing source for the SDH WAN interface...
Page 17: Bit Switch 6,Unused
17 of 144 User Manual 2.2.2.6 Bit switch 6,Unused This bit switch is unused on the WCM5100, 2.2.2.7 Bit switch 7, SFP Mode This bit switch is used to force the configuration of the SFP interface to match the SFP type inserted.
Page 18: Rackmounting
User Manual 2.3 Rackmounting The WCM5100 is a standalone, desktop unit however it may be mounted in a standard 19 inch rack using the rack mounting kit, part number 80-05-256. To mount the WCM5100 in the 19 inch rack mount adaptor first remove the two M3x12 screws and washers from the rear panel of the unit.
Page 19: Wcm5100 Applications
In this application, the WCM5100 is operating with Traffic Isolation Disabled. In this mode, the WCM5100 acts as a simple, layer 2, 5 port switch with packetsswitched based on MAC address alone. The WCM5100 supports both local and remote switching, and forwarding over the WAN trunk.
Page 20: Vlan Mode
METRODATA LTD WCM5100 20 of 144 User Manual 3.3 VLAN Mode In this mode, both WCM units have VLAN support enabled, and all ports are defined as access ports VLAN 101 is used as the management VLAN and in unit WCM-A the VLAN group 101 includes the LAN Port 1, the Manager and the SDH WAN port.
Page 21: Quick Start Configuration
(Normal Operation) position. 4.2 Access the WCM Initial access to the WCM5100 is made using the Terminal Port on the rear panel of the unit. The Terminal port defaults to 19200baud, 8bit, No Parity, 1 Stop Bit. The 9 Way D-...
Page 22: Logging Onto Wcm5100
At the prompt, enter the password to gain access to the WCM. The default password is the product name, ie “wcm5100” For security, the password is obscured with an asterisk (*) being displayed for each character typed. An incorrect password will lead to the welcome banner being redisplayed.
Page 23: User Interface Navigation
METRODATA LTD WCM5100 23 of 144 User Manual 4.3.1 User Interface Navigation The WCM user interface is a simple, menu based interface. Each selectable item may be selected by typing the first capital of the option, e.g. for “Port set-up” type <P>...
Page 24: Configure The Wan Interface
<menu> lan2 <menu> <menu> <menu> <menu> vc-4 <menu> First CAPITAL - select item <escape> - exit menu 4.4.1 WCM5100 WAN Configuration Metrodata WCM5100 "" Alarms: Major SDH1 interface Name SDH1 State sfp type OC-3 SM IR sFP Management <menu>...
Page 25: Set Ip Address
METRODATA LTD WCM5100 25 of 144 User Manual 4.5 Set IP Address From the Main Setup Menu, select Management Entity, Metrodata WCM5100 "" Alarms: Major MANAGEMENT ENTITY proXying <menu> intErface <menu> <menu> <menu> <menu> sNmp <menu> Telnet/SSH <menu> tFtp <menu>...
Page 26: Set Default Route
If DHCP is not used, you must assign the required network mask for correct installation into the network. 4.6 Set Default Route From the Main Setup Menu, select Management, then IP, Metrodata WCM5100 "" Alarms: Major default Ttl Dscp priority default Gateway 192.168.0.254...
Page 27: Save The Configuration
User Manual 4.7 Save the Configuration From the Main Set Up menu, select the Update EEPROM option to save the configuration to non volatile memory. Answer ‘Y’ at the prompt. Metrodata WCM5100 "" Alarms: Major MAIN SET-UP Global status <display>...
Page 28: Advanced Configuration
28 of 144 User Manual 5 ADVANCED CONFIGURATION 5.1 System Configuration The system menu provides the basic administrative configuration items for the WCM5100 and should be configured first. The System Menu is shown below: Metrodata WCM5100 "" Alarms: Major SYSTEM Time &...
Page 29: Setting The Time And Date
User Manual 5.1.1 Setting the Time and Date The WCM5100 does not provide a non volatile Real Time Clock, instead it uses NTP to set the date and time following power up. In applications where NTP is not available, the WCM defaults to providing a simple uptime display.
Page 30: Setting The Node Name
First CAPITAL - select item <escape> - exit menu Once a node name has been defined, in this case “WCM5100 Node A” it is displayed at the top of each user menu to assist the user identify which device is currently connected.
Page 31: Access Control
First CAPITAL - select item <escape> - exit menu 5.1.3.1 Password The local password for the WCM5100 may be changed from the access control menu. The default password is the product name, ie “wcm5100” however for deployment a more secure password may be required.
Page 32: Password Recovery
User Manual 5.1.3.1.1 Password Recovery If for any reason, the password for access to the WCM5100 is lost, the unit may be cold started by using bit switch 8 which will return the unit to the default factory configuration. The default factory password is the product name, “wcm5100”.
Page 33: Authentication
5.1.3.4.2 Timeout The timeout defines how long the WCM5100 unit will wait for a response from the TACACS+ server. The timeout is specified in seconds in the range 1 to 90 seconds.
Page 34: Encryption Key
34 of 144 User Manual 5.1.3.4.6 Encryption Key This key is used by both the WCM5100 and the TACACS+ server to provide a secure, encrypted password exchange and authentication. This must be set the same on both WCM5100 and Server(s).
Page 35: Welcome Screen
By default, the initial access to the WCM will display the welcome banner as shown below: Metrodata WCM5100: Local connection to “WCM5100 Node A” Password (‘view’ to view only ) : However, it is possible to customize the welcome banner to give further information about the unit, or to inform the user of access restrictions.
Page 36 METRODATA LTD WCM5100 36 of 144 User Manual If a customized welcome is required, change to enabled and the menu will change as shown below: Metrodata WCM5100 "WC5100M Node A" Alarms: Major WELCOME SCREEN Welcome screen Enabled 1st line 2nd line...
Page 37: Software Version
METRODATA LTD WCM5100 37 of 144 User Manual Metrodata WCM5100 "WCM5100 Node A" Alarms: Major WELCOME SCREEN -------------- This is an example of a Welcome Banner Welcome to the WCM Please enter the password> <Escape> - exit, other key - refresh...
Page 38: Warm Start
EEPROM. Note, any changes to configuration that have not been saved to the EEPROM will be lost. When a user issues a warm start request, the WCM5100 will indicate that a warm start is in progress and then close the connection.
Page 39: Maintenance
Once confirmed the unit will restart, and default the internal non volatile configuration memory returning the unit to the factory default state. 5.1.10 Maintenance The maintenance menu contains the event log and config generation functions and can be seen below: Metrodata WCM5100 "WCM5100 Node A" Alarms: Major MAINTENANCE System event log <display>...
Page 40: Alarm Event Log
40 of 144 User Manual 5.1.10.2 Alarm Event Log The alarm event log stores the set and clear times for all alarm conditions as shown below: Metrodata WCM5100 "WCM5100 Node A" Alarms: Major --- Alarm Event Log --- 1/1/2000 00:00:02...
Page 41: Input Config
The input configuration menu item allows a configuration file to be loaded onto the WCM5100 unit using the serial port. The configuration file for use may have been generated using either the serial output configuration option, or have been saved via TFTP.
Page 42: Operational Modes
QinQ/S-Tag and the multiple FID table is disabled. Selection of the Aggregation End Point mode enables the End Point Discovery Protocol which allows the WCM5100 unit to automatically detect and configure the aggregation tag used on the SDH link.
Page 43: Vlan Mode
43 of 144 User Manual 5.2.2 VLAN Mode The WCM5100 units support two modes of operation, C-VLAN and QinQ/S-VLAN. The modes are explained below: In C-VLAN mode, frames may be untagged, or tagged with an IEEE 802.1q VLAN tag with Ethertype 8100.
Page 44: Mac Learning
Forwarding Information Database to make switching decisions. The MAC addresses are automatically learnt as each packet traverses the switch. It is not recommended to disable the MAC learning table in the WCM5100 when used as a multi port device. 5.2.6 Flow Control The WCM5100 supports IEEE 802.3x pause frame based flow control on all auto...
Page 45: Rate Limiting Mode
METRODATA LTD WCM5100 45 of 144 User Manual 5.2.8 Rate Limiting Mode Each port supports rate limiting to police the input traffic stream. This configuration items determines the method of calculating the traffic stream bandwidth. The options are as follows:...
Page 46: Priority Management
<escape> - exit menu 5.2.9.1 DSCP->C-Tag Mapping The WCM5100 allows priority to sourced from the IP DSCP marker. DSCP is a 6 bit control, and as such has a range of 0 to 63. When DSCP is used to source a tag priority there are only 3 bits used thus a translation is required.
Page 47: Queue Priorities
PCP values. Whether the pcp used is odd or even is dependant upon the port default priority, as shown 5.2.9.2 Queue Priorities The WCM5100 has four levels of priority queue, and these queues operate in a strict priority manner. The queue priorities menu is shown below: Metrodata WCM5100 "WCM5100 Node A"...
Page 48: Vlan Override
PCP value. 5.2.9.4 Scheduling Mode The WCM5100 internally supports four levels of priority queues. These queues may be serviced using a strict priority or a weighted round robbin basis. Strict Priority means that the queues are serviced in order, meaning only when the high priority traffic is exhausted do the lower priority queues get serviced.
Page 49: Rstp
49 of 144 User Manual 5.2.9.5 RSTP The WCM5100 supports RSTP for loop prevention when resilient network topology is used. This menus defines the global RSTP configuration for the switch, port specific parameters, including PortFast are configured under the port menus.
Page 50: Hello Time
METRODATA LTD WCM5100 50 of 144 User Manual 5.2.9.9 Hello Time The Hello Time parameter defines the period between configuration BPDU transmissions on designated ports. 5.2.9.10 Forward Delay The Forward Delay is the timeout used by a port which is not receiving BPDU’s before a port will transition from DISCARDING to FORWARDING.
Page 51: Status
User Manual 5.2.9.13 Status The status screen enables the user to determine the RSTP state of the device and its position within the network topology. Metrodata WCM5100 "WCM5100 Node A" Alarms: Major RSTP STATUS ----------- | Root | Time Since...
Page 52: Port Set Up Menu
WAN, and LAN ports. A simple configuration will be shown for each type of port. The port configuration is accessed from the main setup menu by selecting the data port menu. The data port menu gives the following options Metrodata WCM5100 "WCM5100 Node A" Alarms: Major PORT SET-UP lan1 <menu>...
Page 53: Lan Port
User Manual 5.3.1 LAN Port The WCM5100 has two external copper LAN ports which by default operate in 10/100/1000BaseT auto negotiating, auto crossover mode. The LAN ports are presented on RJ45 connectors and support access to the other external local LAN ports, the management processor or the WAN forwarding port.
Page 54: Port Mode
5.3.1.5 Port Management The port management menu allows the physical configuration of the LAN port to be defined. The port management menu is shown below: Metrodata WCM5100 "WCM5100 Node A" Alarms: Major PORT MANAGEMENT max spEed 1000M...
Page 55: Auto Negotiation
METRODATA LTD WCM5100 55 of 144 User Manual 5.3.1.5.3 Auto Negotiation The port may be configured to automatically determine the optimal operating parameters for link speed and duplex. Alternatively, it may be disabled to enable configuration of fixed operating parameters.
Page 56: Cable Tester
Where unreliable operation is detected on a port, running a cable test will verify that the cable is correctly connected, and terminated. The display for a good, 1000M connection is as below: Metrodata WCM5100 "WCM5100 Node A" Alarms: Major Cable Tester...
Page 57: Link Loss Forwarding
). Frames priority is determined using the ingress, or overridden PCP value which may also be based on the DSCP value as determined in the operating mode menu. The rate limiting menu is as shown: Metrodata WCM5100 "WCM5100 Node A" Alarms: Major RATE LIMITING, LAN1 mOde...
Page 58: Mode
WCM5100 58 of 144 User Manual The individidual rate limits are applied by selecting the queue type and then entering the required rate limits as shown: Metrodata WCM5100 "WCM5100 Node A" Alarms: Major RATE LIMITING, LAN1, HIGH Limiting Enabled First CAPITAL - select item <escape>...
Page 59: Cbs
METRODATA LTD WCM5100 59 of 144 User Manual 5.3.1.6.3.4 CBS The CBS ( Committed Burst Size ) defines the maximum burst size for frames ingressing at a rate in excess of the CIR. The CBS is defined in bytes. The value 10000 may be entered as...
Page 60: Layer 2 Management
User Manual 5.3.1.7 Layer 2 Management The L2 management menu configures the layer 2 frame processing and control protocol support. The L2 management menu is as shown below: Metrodata WCM5100 "WCM5100 Node A" Alarms: Major L2 MANAGEMENT, LAN1 Tagging & Priority <menu>...
Page 61: Vlan Allocation
METRODATA LTD WCM5100 61 of 144 User Manual 5.3.1.7.1.1.1 VLAN Allocation The VLAN Allocation defines which VLAN’s this port has membership of, Ingress frames with VLAN ID’s included in the allocation will be accepted, ID’s outside this range will be discarded.
Page 62: Priority Source
The valid range is 0 (low) to 7 (high) 5.3.1.7.1.1.6 Control C-VLAN The control C-VLAN is used for CFM OAM traffic where that option is available. It is not supported in the WCM5100 so this setting may be left in the default setting. 76-02-087 Rev H...
Page 63: Qinq/S-Vlan Mode
WCM5100 63 of 144 User Manual 5.3.1.7.1.2 QinQ/S-VLAN Mode When the operational mode of the WCM5100 is set to QinQ/S-VLAN mode the tagging and priority menu is as below, for access ports Metrodata WCM5100 "WCM5100 Node A" Alarms: Major TAGGING & PRIORITY, LAN1...
Page 64: S-Vlan (Access Port)
METRODATA LTD WCM5100 64 of 144 User Manual 5.3.1.7.1.2.2 S-VLAN (Access Port) The S-VLAN definition defines the ID to be used for tags pushed onto frames ingressing an access port. This value also defines that frames ingressing a trunk port with this ID will egress with the S-Tag popped from this port.
Page 65: S-Vlan Allocation (Trunk Port )
METRODATA LTD WCM5100 65 of 144 User Manual 5.3.1.7.1.3.1 S-VLAN Allocation (Trunk Port ) A trunk port will only accept frames which are tagged with an S-Tag having a valid Ethertype and also an ID that is within the allocated range. Untagged, or ID’s outside the allocation will be discarded.
Page 66: Oam
METRODATA LTD WCM5100 66 of 144 User Manual 5.3.1.7.2 OAM The WCM5100 supports IEEE 802.3ah Link OAM which may be configured on a per port basis: Metrodata WCM5100 "WCM5100 Node A" Alarms: Major OAM, LAN1 Mode Active Status <display> counTers <display>...
Page 67: Oam Status
Node name: "Test Unit" Interface: LAN1 Interface AdSt OpSt LAN2 Down Down <Esc> - exit, <Enter> - refresh Where the peer device is another Metrodata device, proprietary extensions to OAM are used to report further remote peer status information. 76-02-087 Rev H...
Page 68: Oam Counters
5.3.1.7.2.3 OAM Counters The counters provide an indication of the OAM interactions taking place. In normal operation, the information frames should be incrementing at a rate of 1 per second. Metrodata WCM5100 "WCM5100 Node A" Alarms: Major OAM Statistics --------------...
Page 69: Rstp
5.3.1.7.3 RSTP When RSTP is enabled on the WCM unit, there are several parameters which need to be defined on a per port basis. The port rstp menu is shown below: Metrodata WCM5100 "WCM5100 Node A" Alarms: Major RSTP, LAN1...
Page 70: Counters
METRODATA LTD WCM5100 70 of 144 User Manual 5.3.1.8 Counters Each LAN port provides a set of counters supporting the basic MIB-2 SNMP parameters as below: Metrodata WCM5100 "WCM5100 Node A" Alarms: Major Interface Statistics -------------------- ifInOctets ifInUcastPkts ifInNUcastPkts ifInDiscards...
Page 71: Sfp Port
SFP MSA definition. Metrodata supplied SFP devices will indicate the SFP type, however some lower cost, lower quality SFP devices may not be correctly programmed and will indicate “UNKNOWN”...
Page 72: Link Status
When AN is disabled, the configured speed and duplex are displayed. 5.3.2.6 Port Management The port management menu allows the physical configuration of the LAN port to be defined. The port management menu is shown below: Metrodata WCM5100 "WCM5100 Node A" Alarms: Major PORT MANAGEMENT max spEed 1000M...
Page 73: Negotiated
The menu also allows the notifications to be defined to allow for traps and alarms to be generated based on the SFP diagnostic information. The SFP management menu is shown below: Metrodata WCM5100 "WCM5100 Node A" Alarms: Major SFP MANAGEMENT Device Details <display>...
Page 74: Device Details
METRODATA LTD WCM5100 74 of 144 User Manual 5.3.2.7.1 Device Details This menu displays further information regarding the SFP device: Metrodata WCM5100 "WCM5100 Node A" Alarms: Major SFP Info Interface: SFP -------- Transmit Status Type Vendor Part No. Wavelength --------------------------------------------------------------------------...
Page 75: Notifications
SFP diagnostic information. The menu is shown below, with a common set up with traps/alarms enabled for the high termperature and low receive power. Metrodata WCM5100 "WCM5100 Node A" Alarms: Major NOTIFICATIONS 1 - Temp High Alarm &...
Page 76: Layer 1 Management
Refer to section 5.3.1.7 for a full description 5.3.2.11 Counters The SFP provides counters to show the packets that pass over this port as shown below: Metrodata WCM5100 "WCM5100 Node A" Alarms: Major Interface Statistics -------------------- ifInOctets ifInUcastPkts...
Page 77: Vcg
The VCG ( virtual concatenation group ) configuration menu is used to define the encapsulation method used for frames being transported over the WAN port. The VCG configuration menu for VC4 is as below: Metrodata WCM5100 "WCM5100 Node A" Alarms: Major interface Name...
Page 78: Interface Name
First CAPITAL - select item <escape> - exit menu The WCM5100 offers GFP encapsulation. GFP uses idle packets to delimit and pad, and appends a four byte header to the packet along with a 32 bit FCS. 5.3.3.3.1.1 GFP FCS The GFP FCS, frame check sequence, may be added to the frame to provide error protection.
Page 79: Strip Mac Fcs
Both ends of the link MUST match otherwise traffic will not flow. 5.3.3.4 LCAS/VCAT The WCM5100 supports VCAT and LCAS for bonding multiple links together. In VC-4 operating mode, only a single link is used and the VCAT only mode is selected. In VC-3...
Page 80: Lcas Status
User Manual 5.3.3.5 LCAS Status In the event that LCAS is being used in VC-3 mode, the LCAS status screen gives useful information about the status of the link. Metrodata WCM5100 "WCM5100 Node A" Alarms: Major LCAS Status ----------- outbound (source)
Page 81: Counters
METRODATA LTD WCM5100 81 of 144 User Manual 5.3.3.8 Counters The VCG provides counters to show the packets that pass over this port as shown below: Metrodata WCM5100 "WCM5100 Node A" Alarms: Major Interface Statistics -------------------- ifInOctets Decapsulated Pckts 0...
Page 82: Sdh Ports
User Manual 5.3.4 SDH Ports The WCM5100 is fitted with two SDH ports presented using SFP modules supporting STM-1. The ports must be configured for the same timing, framing and payload options as they operate as a 1 for 1 backup link. When fall back is enabled, alarms occurring on the active port will force a fallback to the backup link if it is available.
Page 83: Sfp Type
The menu also allows the notifications to be defined to allow for traps and alarms to be generated based on the SFP diagnostic information. The SFP management menu is shown below: Metrodata WCM5100 "WCM5100 Node A" Alarms: Major SFP MANAGEMENT Device Details <display>...
Page 84: Device Details
METRODATA LTD WCM5100 84 of 144 User Manual 5.3.4.4.1 Device Details This menu displays further information regarding the SFP device: Metrodata WCM5100 "WCM5100 Node A" Alarms: Major SFP Info Interface: SDH1 -------- Transmit Status Type Vendor Part No. Wavelength --------------------------------------------------------------------------...
Page 85: Notifications
5.3.4.5 Active Port The WCM5100 has a pair of SDH ports, however only one of these is active and passing data at any point. This display indicates which is the currently active SDH port. 76-02-087 Rev H...
Page 86: Fallback Timeout
5.3.4.7 Timing When the WCM5100 is connected to an SDH network, the SDH ports should be configured to operate in loop timing mode, with the timing sourced from the network. When used over a dark fibre, either internal/internal or internal/loop may be used.
Page 87: Overhead
The J0 transmit option allows the Path Trace Label to be defined for this SDH port. In the example above the label is defined as “WCM5100-A”. This label allows for equipment to verify it is connected to the correct circuit.
Page 88: Receiving
00 state. 5.3.4.10 Payload The WCM5100 offers two payload options for the transport of Ethernet over STM-1, which one to use is determined by the STM-1 service supplied by the network operator. VC-4 The STM-1 Frame transports a single VC-4 container giving around 149Mbps payload capability.
Page 89: Configuration
5.3.5 VC-4 Configuration Whether the payload is configured for VC4 or VC-3, a VC-4 is used and must therefore be configured. The VC-4 configuration menu is as shown below: For VC-4 payload Metrodata WCM5100 "WCM5100 Node A" Alarms: Major VC-4 interface Name...
Page 90: State
The J1 overhead is the High Order path Trace Label and is used to allow for links to be identified. To identify the path, a meaningful label should be defined, eg “WCM5100 VC-4” 5.3.5.6 J1 Expected To provide protection against misconnection, and expected value may be supplied for the J1 Path Trace label.
Page 91: Rdi Type
METRODATA LTD WCM5100 91 of 144 User Manual 5.3.5.8 RDI Type By default the RDI operating mode is set to a single bit, in which case an RDI is simply sent in response to a received fault condition. If the RDI is set to 3-bit, the RDI will comprise the RDI alarm indication along with an extra status to indicate the type of fault encountered.
Page 92: Interface Name
When the payload is configured for VC-3 mode, the VC-3’s must be configured. When selecting the VC_3 configuration menu, firstly the individual VC-3 ( 1,2 or 3 ) must be selected, leading to the menu: Metrodata WCM5100 "WCM5100 Node A" Alarms: Major VC-3#1...
Page 93: Receiving
The J1 overhead is the Low Order path Trace Label and is used to allow for links to be identified. To identify the path, a meaningful label should be defined, eg “WCM5100 VC-3-1” 5.3.6.6 J1 Expected To provide protection against misconnection, and expected value may be supplied for the J1 Path Trace label.
Page 94: Setup
Normal terminal interface available Disabled Terminal port disabled. When the console is disabled, any attempt to access the WCM5100 unit via the terminal port will receive the following prompt: Console is disabled. A disabled console may be restored by either cold starting the unit, or from a telnet/ssh management session.
Page 95: Console Set Up
METRODATA LTD WCM5100 95 of 144 User Manual 5.4.2 Console Set Up This menu defines the operating parameters of the terminal interface as shown: Metrodata WCM5100 "WCM5100 Node A" Alarms: Major CONSOLE SET-UP Terminal type via Modem Baud rate 19200 bps...
Page 96: Baud Rate
METRODATA LTD WCM5100 96 of 144 User Manual 5.4.2.3 Baud Rate This sets the baud rate for the terminal interface. The default setting is 19200baud. The options are: 2400 4800 9600 19200 5.4.2.4 Parity This sets the parity for the terminal interface. The default setting is None...
Page 97: Stop Bits
METRODATA LTD WCM5100 97 of 144 User Manual 5.4.2.6 Stop Bits This sets the number of stop bits per character for the terminal interace. The default setting is 2. The options are 5.4.2.7 Load New Config Once the parameters for the terminal interface have all been configured, they must be loaded using the Load New Config command.
Page 98: Management Entity
WCM5100 98 of 144 User Manual 5.5 Management Entity The management entity menu defines the IP functionality of the WCM5100 unit to enable remote management access via the LAN, SFP or WAN ports. Metrodata WCM5100 "WCM5100 Node A" Alarms: Major...
Page 99: Server Mode Proxy
A client can be supported at the far end of each port of the unit, though in general, only remote units connected via the VCG will be managed as proxy clients. The proxy client set up menu is shown below: Metrodata WCM5100 "WCM5100 Node A" Alarms: Major Proxying...
Page 100: Ip Address
When a device is set to be a Proxy client, it simply needs to be configured for which port will be used for the proxy management. The client menu is as below: Metrodata WCM5100 "WCM5100 Node A" Alarms: Major PROXYING...
Page 101: Interface
5.5.2.2 Physical Address The physical address is the unique MAC address assigned to this unit. This address will be of the form: 00:C0:81:xx:yy:zz where 00:C0:81 is the Metrodata OUI, and xx.yy.zz is the unit identifier 76-02-087 Rev H...
Page 102: Dhcp
If DHCP is not available, enter the required net mask 5.5.2.6 AT Table The AT table is a display of the ARP resolutions that the WCM unit has made as shown below: Metrodata WCM5100 "WCM5100 Node A" Alarms: Major AT TABLE --------...
Page 103: Statistics
METRODATA LTD WCM5100 103 of 144 User Manual 5.5.2.7 Statistics The management interface provides a full set of MIB-2 IfTable statistics for the port as shown below: Metrodata WCM5100 "WCM5100 Node A" Alarms: Major Interface Statistics -------------------- ifInOctets 12451 ifInUcastPkts...
Page 104: Default Ttl
WCM5100 104 of 144 User Manual 5.5.3 IP The IP menu defines the layer 3 functionality for the manager interface and is shown below: Metrodata WCM5100 "WCM5100 Node A" Alarms: Major default TTL DSCP priority default Gateway 192.168.0.254 Routing table <display>...
Page 105: Routing Table
IP routing table gives directions on how to reach each remote destination. The routing table with a default route added automatically by DHCP is shown below: Metrodata WCM5100 "WCM5100 Node A" Alarms: Major Destination Next Hop Type Prot.
Page 106: Delete A Route
5.5.3.5 Forwarding For products that provide a routing function, forwarding enables packets to be forwarded between IP subnets, the WCM5100 product range does not support routing and as such forwarding is fixed as disabled. 5.5.3.6 Statistics...
Page 107: 76-02-087 Rev H
METRODATA LTD WCM5100 107 of 144 User Manual The available statistics are shown below: Metrodata WCM5100 "WCM5100 Node A" Alarms: Major IP Statistics ------------- ipInReceives ipInHdrErrors ipInAddrErrors ipForwDatagrams ipInUnknownProtos ipInDiscards ipInDelivers ipOutRequests ipOutDiscards ipOutNoRoutes ipReasmReqds ipReasmOKs ipReasmFails ipFragOKs ipFragFails ipFragCreates...
Page 108: Udp
User Manual 5.5.4 UDP The UDP menu displays the port numbers used for SNMP Get and Set operations as well as for Trap operation. These should not be altered. Metrodata WCM5100 "WCM5100 Node A" Alarms: Major snmp Port snmp Trap port Stats.
Page 109: Statistics
METRODATA LTD WCM5100 109 of 144 User Manual 5.5.5.1 Statistics The statistics menu displays the SNMP MIB-2 IfTable TCP statistics as shown: Metrodata WCM5100 "WCM5100 Node A" Alarms: Major TCP Statistics -------------- tcpActiveOpens tcpPassiveOpens tcpAttemptFails tcpEstabResets tcpInSegs tcpOutSegs tcpRetransSegs tcpInErrs...
Page 110: Snmp Management
5.5.6.2 Contact Person The contact person is the SNMP MIB-2 system SysContact parameter, the default setting Metrodata Limited, Laxton House, Eversley Way, Egham, Surrey, TW20 8RY The parameter may be up to 255 characters and should be configured to reflect the actual installation requirements.
Page 111: Node Name
The WCM supports up to 10 configured Network Management Stations. The manager may be configured to operate as SNMP V1 or V2c The Add Manager Menu is as below: Metrodata WCM5100 "WCM5100 Node A" Alarms: Major ADD MANAGER IP address 0.0.0.0...
Page 112: Statistics
The SNMP version may be configured for the manager to support either SNMP V1 or SNMP V2c. 5.5.6.6 Statistics The WCM management entity provides a set of SNMP MIB-2 IfTable SNMP statistics for the interface: Metrodata WCM5100 "WCM5100 Node A" Alarms: Major SNMP Statistics --------------- snmpInPkts...
Page 113: Trap Alarms
There is a separate configuration menu for each port type within the unit as shown below: Metrodata WCM5100 "WCM5100 Node A" Alarms: Major TRAP ALARMS lan1 <menu>...
Page 114: Sfp Port Trap Defintions
METRODATA LTD WCM5100 114 of 144 User Manual Loss of CFM ( 802.1ag ) contact with peer MEP 5.5.6.7.2 SFP Port Trap Defintions Metrodata WCM5100 "WCM5100 Node A" Alarms: Major 0 - LOS Trap 1 - LKDN Trap 2 - NF...
Page 115: Vcg Port Trap Defintions
METRODATA LTD WCM5100 115 of 144 User Manual OTDR OTDR Alarm 5.5.6.7.3 VCG Port Trap Defintions Metrodata WCM5100 "WCM5100 Node A" Alarms: Major 1 - LKDN Trap 3 - LLF Trap 4 - DEG Trap 5 - OAM Trap 6 - CFM...
Page 116: Traps
Trace Identifier Mismatch, this indicates that the received J0 string does not match the expected value, possibly indicating a mis connected circuit. 5.5.6.7.5 VC-4 Traps At the VC-4 level, the following alarms may be raised Metrodata WCM5100 "WCM5100 Node A" Alarms: Major VC-4 0 - LOP Trap...
Page 117: Traps
Trace identifier Mismatch, This alarm indicates that the received J1 string does not match the expected value. 5.5.6.7.6 VC-3 Traps At the VC-3 level, the following alarms may be raised Metrodata WCM5100 "WCM5100 Node A" Alarms: Major VC-3#1 0 - LOP...
Page 118: 76-02-087 Rev H
METRODATA LTD WCM5100 118 of 144 User Manual The VC-3 alarms are raised on the Path Overhead section of the SDH frame structure. Loss of Pointer, this indicates that the pointer to the start of the VC-3 container cannot be found, usually only seen when LOF is also active.
Page 119: Telnet / Ssh
119 of 144 User Manual 5.5.7 Telnet / SSH The WCM5100 unit allows remote management by either TELNET or the more secure, encrypted SSH V2. This menu configures the device for remote management access as shown: Metrodata WCM5100 "WCM5100 Node A"...
Page 120: Tftp
User Manual 5.5.8 TFTP The WCM5100 may be upgraded in the field using TFTP to upgrade the application software, or to save or load the configuration. In networks where firewalls and NAT addressing is used server mode must be used otherwise either client or sever mode may be used.
Page 121: Get New Software
5.5.8.1.1.2 Get New Software The Get New Software option is selected for performing a main application code update. Following the Get New Software option the warning message below will appear: Metrodata WCM5100 "WCM5100 Node A" Alarms: Major TFTP Software Upgrade CAUTION: Proceding further will mean that the unit must be re-started, and the performance log may be cleared, even if the upgrade is unsuccessful.
Page 122: Boot S/W Upgrade
The Boot S/W update option is selected for performing a boot code update. Following the Boot S/W update option the warning message below will appear: Metrodata WCM5100 "" Alarms: Major TFTP Software Upgrade CAUTION: Proceding further will mean that the unit must be re-started, and the performance log may be cleared, even if the upgrade is unsuccessful.
Page 123: Get Confuration File
Get Config menu option. At the prompt enter the required filename. Enter file name, then wait > wcm5100.cfg Once the file has downloaded, the unit will save it to the non volatile EEPROM and will then reboot and restart with the new configuration file loaded.
Page 124: Server Mode
–i “WCM IP Address” put “Source Filename” “Software File Name” tftp –i 192.168.0.1 put wcm5100.823 software Which will load a file named “wcm5100.823” onto the WCM with IP address 192.168.0.1 and load as a file called “software” 76-02-087 Rev H...
Page 125: Ping
Ping is a simple IP/ICMP utility that enables the management connectivity to be verified. Simply enter the IP address of the remote unit and ping will repeatedly send an ICMP Echo request, as shown below: Metrodata WCM5100 "" Alarms: Major Destination: 192.168.100.70 press any key to stop test sending...okay, time=1.7ms...
Page 126: Saving The Configuration
126 of 144 User Manual 5.6 Saving the Configuration Once the WCM has been configured, the configuration must be saved to the EEPROM to provide non-volatile storage. Metrodata WCM5100 "WCM5100 Node A" Alarms: Major MAIN SET-UP Global status <display> alarm eXtension <menu>...
Page 127: Global Status
127 of 144 User Manual 5.7 Global Status The Global status screen gives an overview of the status of the WCM5100 unit, and should always be the first port of call when attempting to diagnose a network, or operational problem.
Page 128: Test
METRODATA LTD WCM5100 128 of 144 User Manual 5.7.3 Test If a port has a test mode enabled it is indicated in this column. The indications are as below: Test mode not active on this port Local Loop Applied Outside Loop Applied...
Page 129: Lan Port Alarms
METRODATA LTD WCM5100 129 of 144 User Manual 5.7.4.1 LAN Port Alarms The following alarms may be indicated for a LAN port: LKDN Link Down. A port will enter the link down state if it is not connected, no cable plugged in, or the remote unit is not powered up; or if auto negotiation has not or cannot complete.
Page 130: Vcg Alarms
METRODATA LTD WCM5100 130 of 144 User Manual Link OAM Alarm. If OAM is enabled and responses from the peer device are not received for 3.5seconds the port will declare an OAM alarm. Once the OAM frames are received again, the alarm will be cleared.
Page 131: Sdh Ports
METRODATA LTD WCM5100 131 of 144 User Manual 5.7.4.4 SDH Ports The alarm definitions for the SDH port are as follows Loss of Signal, No optical signal can be detected by the SFP module due to either the fibre not being connected, the remote unit not...
Page 132: Alarms
METRODATA LTD WCM5100 132 of 144 User Manual Remote Defect Indication, this alarm is generated as a response to a LOP/UNEQ/PLM alarm. Signal Defect, this alarm is raised when the bit error rate exceeds the threshold Trace identifier Mismatch, This alarm indicates that the received J1 string does not match the expected value.
Page 133: Vlan Allocation
METRODATA LTD WCM5100 133 of 144 User Manual 5.7.6 VLAN Allocation The VLAN Allocation shows the VLAN ID’s for which this port is a member. Where a port is adding a tag, typically this will show a single ID. The VLAN Allocation is shown, as a string of maximum length 6 characters meaning more...
Page 134: Alarm Extension
In the event that an external alarm bell, or audible warning device is connected it is highly desirable to be able to silence the alarm once the alarm has been acknowledged. The alarm extension menu performs this function Metrodata WCM5100 "" Alarms: Major ALARM EXTENSION clear Alarm outputs <display>...
Page 135: Alarm Actions
METRODATA LTD WCM5100 135 of 144 User Manual 5.8.2 Alarm Actions For each alarm on each port, it may be selectively configured as a Major Alarm, Minor Alarm or none. Major Alarms will activate the major alarm relay, while minor alarms will activate the minor alarm relay.
Page 136: Performance Data
The performance data loggers will collect interface alarm and error statistics for a rolling 24 hour period storing the information in 15 minute buckets. The performance data setup menu is shown below: Metrodata WCM5100 "" Alarms: Major PERFORMANCE DATA Interface...
Page 137: Summary Style
Shows the errored seconds as a percentage of the total seconds Counts Display the raw count information 5.9.4 Physical Layer Stats The physical layer statistics screen is shown below: Metrodata WCM5100 "" Alarms: Major 06:13:51 Sat 1/1/2000 PERFORMANCE SUMMARY WAN1...
Page 138: Circuit / Flow Tests
<escape> - exit menu 5.10.1 Traffic Generator The Test Traffic Generator allows test traffic to be generated and received/monitored to determine the quality of a link when a loopback is applied. Metrodata WCM5100 "WCM5100 Node A" Alarms: Major TRAFFIC GENERATOR Interface...
Page 139: Interface
139 of 144 User Manual 5.10.1.1 Interface The test traffic generator may send/receive test traffic on any of the ports on the WCM5100. The required port should be selected from the list: LAN1 LAN2 5.10.1.2 Running In order to start a test, change the running state to YES.
Page 140: Port Loops
1 loopback to the WAN Port, LAN Port or SFP Port. The loops are physical layer loops and simply loop frames back as they are received. The port loop menu is as shown below: Metrodata WCM5100 "" Alarms: Major PORT LOOPS...
Page 141: Timeout
METRODATA LTD WCM5100 141 of 144 User Manual 5.10.2.2 Timeout To prevent a phy loopback being left on indefinitely, a timeout may be configured after which time the loop is removed, the default setting is 1 second, and the timeout may be...
Page 142: Vcg Loop Modes
METRODATA LTD WCM5100 142 of 144 User Manual When Phy Loops are enabled, the following loops may be applied and now any traffic switched to the port will be looped. Broadcast packets will be looped so applying any of these loops may cause storms and problems on a network.
Page 143: Wan Loops
METRODATA LTD WCM5100 143 of 144 User Manual 5.10.2.5 WAN Loops The following loop types may be applied to the WAN port None No Loopback applied, normal operation 5.10.2.5.1 LL, Local Loopback Applied The local loop can only be applied when PHY LOOPS are enabled. This loop will loopback all traffic passing over the WAN port.
Page 144: Metrodata Ltd Wcm5100 5 Of
5.10.2.5.3 RL, Remote Loop Applied The Remote Loop is used to apply a loop to a remote WCM5100. The loop up/down command is contained in the VC4/VC3 path overhead so a remote unit will see the command and activate or remove the link with no need for management intervention.

Metrodata WCM5100 User Manual

1 Introduction

2 Installation

3 Wcm5100 Applications

4 Quick Start Configuration

5 Advanced Configuration

Quick Links

Need help?

Questions and answers

Related Manuals for Metrodata WCM5100

Summary of Contents for Metrodata WCM5100

Table of Contents
