Managed Ethernet Extender
Quick Start Guide
DATE:
DOCUMENT NO:
REVISION:
PREPARED BY:
Fortune House, Crabtree Office Village
Eversley Way, Egham Surrey, TW20 8RY, UK
E-Mail: support@metrodata.co.uk
WCM1400
WCM1800
WCM1820
V8
nd
2
April 2012
76-02-087
D
Ian Banbrook
Metrodata Ltd
Tel +44 1 784 744700
Fax: +44 1 784 744730
Advertisement
Table of Contents
Related Manuals for Metrodata WCM1400
Summary of Contents for Metrodata WCM1400
- Page 1 WCM1400 WCM1800 WCM1820 Managed Ethernet Extender Quick Start Guide DATE: April 2012 DOCUMENT NO: 76-02-087 REVISION: PREPARED BY: Ian Banbrook Metrodata Ltd Fortune House, Crabtree Office Village Eversley Way, Egham Surrey, TW20 8RY, UK Tel +44 1 784 744700 Fax: +44 1 784 744730...
- Page 2 Further, Metrodata Ltd reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of Metrodata Ltd to notify any person of such revision or changes. ©...
- Page 3 3 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide Document Revision History January 2011 Document Created February 2011 Document Updated March 2011 Document Released 8th July 2011 Updated for new OAM screens November 2011 Updated VLAN trunking April 2012 Updated for V8 software release...
-
Page 4: Table Of Contents
WCM1820 BNC Rear Panel..........................8 1.1.3 WCM1800 RJ45 Rear Panel..........................8 1.1.4 WCM1800 BNC Rear panel ..........................9 1.1.5 WCM1400 RJ45 Rear panel ..........................9 1.1.6 WCM1400 BNC Rear Panel..........................9 WCM1800 APPLICATIONS ..................10 WCM1800 Normal Mode..........................10 WCM1800 VLAN Trunk Mode ........................10 WCM1800 VLAN Access Mode ........................ - Page 5 5 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide 5.1.5 Welcome Screen ............................26 5.1.6 Warm Start..............................29 5.1.7 Cold Start............................... 29 Configuration of the Data Ports ........................30 5.2.1 LAN Port ............................... 31 5.2.1.1 State..............................31 5.2.1.2 Link Status ............................31 5.2.1.3...
- Page 6 6 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide 5.2.4.5.3 VLAN/S-TAG Allocation ....................... 49 5.2.4.5.4 Control VLAN..........................49 5.2.4.5.5 Control S-TAG ..........................49 5.2.4.6 OAM ..............................49 5.2.4.7 Counters ............................... 50 5.2.5 Traffic Isolation ............................. 51 5.2.5.1 Isolation Mode ............................. 51 5.2.5.2...
-
Page 7: Introduction
WCM1400, WCM1800 and WCM1820 family of Products. The product range allows the extension of Ethernet Services over multiple, bonded E1 Wide Area Network Connections. The WCM1400 provides 4 E1 ports, giving an uplink capacity of approximately 8Mbps. The WCM1800 provides 8 E1 ports giving a maximum uplink bandwidth of approximately 16 Mbps, and the WCM1820 provides 16 E1 ports giving a maximum uplink bandwidth of 32Mbps. -
Page 8: Product Rear Panels
8 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide The WCM1800 supports either IP DSCP, or IEEE802.1p based traffic prioritisation with outgoing traffic being queued in one of four priority queues. The WCM1800 supports link OAM, IEEE802.3ah and RSTP for loop prevention. -
Page 9: Wcm1800 Bnc Rear Panel
9 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide 1.1.4 WCM1800 BNC Rear panel 1.1.5 WCM1400 RJ45 Rear panel 1.1.6 WCM1400 BNC Rear Panel 76-02-087 Rev D... -
Page 10: Wcm1800 Applications
10 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide 2 WCM1800 Applications 2.1 WCM1800 Normal Mode In this application, the WCM1800 is operating with Traffic Isolation Disabled. In this mode, the WCM1800 acts as a simple, layer 2, 5 port switch with packets being switched based on MAC address alone. -
Page 11: Wcm1800 Vlan Access Mode
11 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide In this application, WCM1800-A is connected to a VLAN enabled LAN switch. The LAN switch is configured as a VLAN trunk and all packets are tagged with VLAN Tags. WCM1800-A is operating with VLAN support disabled, but with a VLAN ID allocated to the Manager. -
Page 12: Point To Multi-Point
12 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide 2.5 Point to Multi-Point In this application, the traffic is transported to remote destinations based on the incoming VLAN C-Tag. To support the point to multipoint management, the IP Proxy mode is used with device A acting as the server and B/C acting as clients. -
Page 13: Theory Of Operation
13 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide 3 Theory of Operation 3.1 Frame Encapsulation The WCM1800 uses the Generic Framing Procedure (GFP) to encapsulate the Ethernet frames for transmission over the WAN link(s). GFP is a byte aligned procedure and hence is suitable for use with multi link bonding. -
Page 14: Virtual Concatenation And Lcas
14 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide The GFP frame contains an optional FCS, Frame Check Sequence. Packets received with an FCS error will be discarded. Since the GFP frame is protected from bit errors by the GFP payload FCS, the MAC FCS may be stripped and recalculated at the remote end to save bandwidth. -
Page 15: Quick Start Configuration
15 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide 4 Quick Start Configuration The following guide gives a simple, quick start introduction to configuring the WCM1800 for Normal Mode operation as shown in section 2.1 4.1 Access the WCM1800 Initial access to the WCM1800 is made using the Terminal Port on the rear panel of the unit. -
Page 16: User Interface Navigation
16 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide 4.2.1 User Interface Navigation The WCM1800 user interface is a simple, menu based interface. Each selectable item may be selected by typing the first capital of the option, e.g. for “Data port set-up” type <D>... -
Page 17: Configure The Wan Interface
17 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide 4.3 Configure the WAN interface In order for two WCM1800 units to communicate they must be connected using the E1 WAN ports. The E1 interfaces must be configured to match the network NTU configuration. -
Page 18: Configure The Vcat Group
18 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide Ensure that the WAN port is set to Framed mode, and that CRC-4 is enabled. If a WAN port is not used, the port state should be changed to down to remove it from the alarm tables. - Page 19 19 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide 76-02-087 Rev D...
-
Page 20: Set Ip Address
20 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide 4.5 Set IP Address From the Main Setup Menu, select Management, and then the Interface Menu. 76-02-087 Rev D... -
Page 21: Set Default Route
21 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide To change the IP settings for installation: Dhcp For operation in a DHCP enabled network and automatic IP address allocation set this parameter to ON to enable DHCP address allocation. IP Address... -
Page 22: Save The Configuration
22 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide Add a new route table entry with destination and mask as 0.0.0.0 and configure the next hop as required. Note, that the default route is added automatically when DHCP is used. -
Page 23: Advanced Configuration
23 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide 5 Advanced Configuration 5.1 System Configuration The system menu provides the basic administrative configuration items for the WCM1800 and should be configured first. The System Menu is shown below: 76-02-087 Rev D... -
Page 24: Setting The Time And Date
24 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide 5.1.1 Setting the Time and Date The WCM1800 does not provide a non volatile Real Time Clock, instead it uses NTP to set the date and time following power up. In applications where NTP is not available, the WCM1800 defaults to providing a simple uptime display. -
Page 25: Setting The Password
5.1.3 Setting the Password The password for the WCM1800 may be changed from the system menu. The default password is product specific either “wcm1820”, “wcm1800” or “wcm1400” However, for deployment a more secure password may be required. To change the unit password, select “Password” from the system menu. The WCM1800... -
Page 26: Welcome Screen
26 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide 5.1.5 Welcome Screen By default, the initial access to the WCM1800 will display the welcome banner as shown below: Metrodata WCM1800: Local connection to “” Password (‘view’ to view only ) : However, it is possible to customize the welcome banner to give further information about the unit, or to inform the user of access restrictions. - Page 27 27 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide To configure the Welcome Screen enter each line using alpha numeric characters with each line supporting upto 80 characters as in the example below: Once the welcome message has been defined, it may be displayed using the display screen option.
- Page 28 28 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide which leads to a welcome banner displayed as follows when a management session is started up: 76-02-087 Rev D...
-
Page 29: Warm Start
29 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide 5.1.6 Warm Start A warm Start will force the WCM1800 to restart and reload the configuration from the EEPROM. Note, any changes to configuration that have not been saved to the EEPROM will be lost. -
Page 30: Configuration Of The Data Ports
30 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide 5.2 Configuration of the Data Ports This section deals with the configuration of each of the user data port types including E1, and LAN ports. A simple configuration will be shown for each type of port. -
Page 31: Lan Port
31 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide 5.2.1 LAN Port The WCM1800 has two external copper LAN ports which by default operate in 10/100/1000BaseT auto negotiating, auto crossover mode. The LAN ports are presented on RJ45 connectors and support access to the other external local LAN ports, the management processor or the WAN forwarding port. -
Page 32: Speed
32 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide Note, the Auto Negotiating algorithm works optimally with a link partner that also supports auto negotiation. For operation where one end of a link uses fixed configuration and does not negotiate, it must be noted that only Speed, 10 or 100M, can be determined, the auto negotiating node will fall back to use half duplex. -
Page 33: Counters
33 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide 1.1.1.1 Counters Each LAN port provides a set of counters supporting the basic MIB-2 SNMP parameters as below: 5.2.1.8 Traffic Management The Traffic management menu configures Port Based and Tag based VLAN operation as... -
Page 34: Traffic Type
34 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide 5.2.1.8.1 Traffic Type In order to provide port based traffic isolation this parameter defines what type of traffic passes over this interface. The options are as below User + Mgmt This port carries user and management traffic. Management frames are switched to the processor, whilst user frames are switched to the WAN port. -
Page 35: Default Priority
In disabled mode, OAM will be disabled. When OAM is enabled, the port OAM status may be displayed when the peer device is identified as a member of the Metrodata MetroConnect product range, proprietary enterprise extensions are used to extract further useful information about the remote unit status. -
Page 36: Wan Port
5.2.2 WAN Port The WAN Port menu is selectes as below: Note, ports 5,6,7 and 8 are not available on the WCM1400, the WCM1820 supports ports upto 16. To configure the parameters for the individual E1 ports select the port number to lead to... -
Page 37: State
37 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide The available options are as below: 5.2.2.1 State The port state determines the administrative state of the port. When the port is in the UP state it is available for use and mayl form part of a VCAT group. If it is disabled it will not pass any user traffic, or process alarms. -
Page 38: Crc-4
38 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide 5.2.2.6 CRC-4 When operating in Framed or Fractional mode CRC-4 multiframe mode may be enabled or disabled. For VCAT operation, CRC-4 MUST be enabled. 5.2.2.7 sigNalling When operating in framed mode, the signaling option determines whether timeslot 16 is available for payload. -
Page 39: Sfp Port
SFP MSA definition. Metrodata supplied SFP devices will indicate the SFP type, however some lower cost, lower quality SFP devices may not be correctly programmed an will indicate “UNKNOWN”... -
Page 40: Speed
40 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide 5.2.3.4 Speed The speed setting selects between 1000BaseX and 100BaseFX operating mode. This setting should be set to match the SFP device inserted. Alternatively, this can be set to AUTO, in which case the software will read the device type from the SFP and select either 1000BaseX or 100BaseFX determined by the information read back. -
Page 41: Counters
41 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide 5.2.3.8 Counters The counters option displays the MIB-2 statistics gathered for the SFP port. 5.2.3.9 Traffic Management The Traffic management menu configures Port Based and Tag based VLAN operation as shown:... -
Page 42: Traffic Type
42 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide 5.2.3.9.1 Traffic Type In order to provide port based traffic isolation this parameter defines what type of traffic passes over this interface. The options are as below User + Mgmt This port carries user and management traffic. Management frames are switched to the processor, whilst user frames are switched to the WAN port. -
Page 43: Default Priority
In disabled mode, OAM will be disabled. When OAM is enabled, the port OAM status may be displayed when the peer device is identified as a member of the Metrodata MetroConnect product range, proprietary enterprise extensions are used to extract further useful information about the remote unit status. -
Page 44: Vcg ( Vcat Group Configuration )
44 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide 5.2.4 VCG ( VCAT Group Configuration ) A VCAT Group, VCG is a collection of E1 ports bonded together. The WCM1800 supports upto 4 VCAT Groups, with VLAN/STAG ID being used to select which VCG a frame will traverse. -
Page 45: State
45 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide 5.2.4.1 State The state configuration item controls the admin state for the VCG. If a VCG is in the admin up state it can pass data and will generate alarms when error conditions exist. If a VCG is not used, it should be placed in the admin down state to prevent alarms being raised. -
Page 46: Strip Mac Fcs
46 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide 5.2.4.2.3 Strip MAC FCS Ethernet frames are protected by a 32 bit checksum. When the GFP FCS is enabled it is possible to strip the MAC checksum to save WAN bandwidth and recalculate at the remote end. -
Page 47: Lcas/Vcat
47 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide 5.2.4.3 LCAS/VCAT The WCM1800 may operate in one of 3 modes WAN bonding is disabled, only single WAN ports may be used. VCAT WAN Bonding enabled, however ALL circuits must be operational for traffic to flow. -
Page 48: Traffic Management
48 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide 5.2.4.5 Traffic Management The traffic management menu controls the selection of VLAN ID’s that will pass over this VCG. 5.2.4.5.1 Traffic Type There are two types of traffic that may traverse the VCG. User traffic is traffic not destined for the manager, whilst Mgmt is traffic directed to the management CPU. -
Page 49: Vlan/S-Tag Allocation
The WCM1800 offers IEEE 802.3 clause 57 link OAM over the VCG and bonded WAN ports. The OAM controller may be disabled, active or passive. Where a Metrodata MetroConnect product is found at the far end of the link, additional status is made available,... -
Page 50: Counters
50 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide 5.2.4.7 Counters The VCG provides counters showing the packets correctly transmitted and received as below 76-02-087 Rev D... -
Page 51: Traffic Isolation
51 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide 5.2.5 Traffic Isolation The WCM1800 has three modes of operation and the traffic isolation menu selects the mode: 5.2.5.1 Isolation Mode There are three operating modes None VLAN/STAG ID processing disabled... -
Page 52: Untagged To
52 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide 5.2.5.3 Untagged To The VCG’s will only pass traffic that has a VLAN or STAG ID. Untagged frames will have an ID of 0 added before traversing the VCG. This option selects which group will include ID 0 frames. -
Page 53: Global Status Screen
53 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide 5.3 Global Status Screen The Global Status Screen gives an overall summary of the unit as shown below: 5.3.1 State For each port, the Global Status shows the Admin status of the port. This may be Up or Down. -
Page 54: Proxy Mode Remote Management
54 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide Proxy Mode Remote Management To enable management of the remote units in a point to multipoint configuration the WCM1800 provides proxy mode management of the remote stations. This method of management enables a single management connection to effectively manage units on different VLANs. - Page 55 55 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide Once the server has been configured, the remote clients need to be configured using the client configuration screen, and for remote management over a VCG select the VCG With proxy mode management, the server acts as a proxy for all the remote units and then...
-
Page 56: Snmp Management
5.5.2 Contact Person The contact person is the SNMP MIB-2 system SysContact parameter, the default setting Metrodata Limited, Fortune House, Eversley Way, Egham, Surrey, TW20 8RY The parameter may be up to 255 characters and should be configured to reflect the actual installation requirements. -
Page 57: Location
57 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide 5.5.4 Location The location is the SNMP MIB-2 system SysLocation parameter. By default this entry is blank. The parameter may be up to 255 characters and should be configured to reflect the actual installation requirements. -
Page 58: Saving The Configuration
58 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide 5.6 Saving the Configuration Once the WCM1800 has been configured, the configuration must be saved to the EEPROM to provide non-volatile storage. To save the configuration, select “Update EEPROM” from the Main Setup Menu. At the prompt, respond <Y>... -
Page 59: Tftp Software Update
59 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide 6 TFTP Software UPDATE The WCM1800 may be upgraded in the field using TFTP to upgrade the application software, or to save or load the configuration. In networks where firewalls and NAT addressing is used server mode must be used otherwise either client or sever mode may be used. -
Page 60: Server Mode
60 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide 6.1.2 Server Mode Select SERVER mode to display the menu as below: In server mode, the transfer is initiated from an external client. If the file downloaded matches that configured for Software or Config then they will be used to upgrade the software or configuration. -
Page 61: Metrodata Ltd Wcm1400/Wcm1800/Wcm1820
61 of 61 METRODATA LTD WCM1400/WCM1800/WCM1820 Quick Start Guide 7 Alarms The WCM1800 generate many alarm conditions which are described below: 7.1 WAN E1 Port Loss of Signal Loss of Frame Loss of VCAT/LCAS MultiFrame Receiving AIS, All 1’s Remote Alarm Indication VCAT/LCAS in failed state so do not use this link 7.2 LAN Port...
