Technical Manual
Of
Intel Braswell Series CPU
Based
SBC
NO.G03-NP591-F
Revision: 1.0
Release date: November 12, 2015
Trademark:
* Specifications and Information contained in this documentation are furnished for information use only, and are
subject to change at any time without notice, and should not be construed as a commitment by manufacturer.

Advertisement

Table of Contents
loading

Related Manuals for JETWAY NP591

Summary of Contents for JETWAY NP591

  • Page 1 Technical Manual Intel Braswell Series CPU Based NO.G03-NP591-F Revision: 1.0 Release date: November 12, 2015 Trademark: * Specifications and Information contained in this documentation are furnished for information use only, and are subject to change at any time without notice, and should not be construed as a commitment by manufacturer.
  • Page 2 Environmental Protection Announcement Do not dispose this electronic device into the trash while discarding. To minimize pollution and ensure environment protection of mother earth, please recycle.

  • Page 3: Table Of Contents

    TABLE OF CONTENT ENVIRONMENTAL SAFETY INSTRUCTION ................iv USER’S NOTICE ........................v MANUAL REVISION INFORMATION ..................v ITEM CHECKLIST ........................v CHAPTER 1 INTRODUCTION OF THE MOTHERBOARD FEATURE OF MOTHERBOARD ................1 SPECIFICATION ......................2 LAYOUT DIAGRAM ....................3 CHAPTER 2 HARDWARE INSTALLATION JUMPER SETTING .....................

  • Page 4: Environmental Safety Instruction

    Environmental Safety Instruction  Avoid the dusty, humidity and temperature extremes. Do not place the product in any area where it may become wet.  0 to 40 centigrade is the suitable temperature. (The figure comes from the request of the main chipset) ...

  • Page 5: User's Notice

    USER’S NOTICE COPYRIGHT OF THIS MANUAL BELONGS TO THE MANUFACTURER. NO PART OF THIS MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT MAY BE REPRODUCED, TRANSMITTED OR TRANSLATED INTO ANY LANGUAGE IN ANY FORM OR BY ANY MEANS WITHOUT WRITTEN PERMISSION OF THE MANUFACTURER.

  • Page 6: Chapter 1 Introduction Of The Motherboard Feature Of Motherboard

    Chapter 1 Introduction of the Motherboard Feature of Motherboard ®  Onboard Intel Braswell series SoC Processor, with low power consumption never denies high performance  Onboard optional 2GB/4GB DDR3L 1600 MHz DRAM  Support 1 * SATAIII (6Gb/s) device ...

  • Page 7: Specification

    Specification Spec Description  Pico Form Factor;8-layer SBC; Design  PCB size: 100 mm x 72 mm ®  Intel Braswell SoC CPU* Embedded CPU *CPU model varies from different IPC options. Please consult your dealer for more information of onboard CPU. ...

  • Page 8: Layout Diagram

    * Note: 1. Many PCs now include XHCI USB controllers which allow for the support of USB 3.0 and higher USB speeds. This inclusion of XHCI controllers has lessened the need for EHCI USB controllers within platforms. However, legacy operating systems (OS) may not natively recognize XHCI controllers. You might need to pre-install XHCI driver while desiring to install a non-xHCI OS (ex.Windows* 7) on Intel platforms which do not include EHCI controllers.
  • Page 9 Internal Diagram-Front Side: Front Panel Internal12V Power COM1 USB 2.0 Headers Audio Header Connector Serial Port Header AT_MODE 12V DC-in Power Jack COM2 SATA Slot Serial Port Header USB 3.0 Ports LVDS LVDS INVERTER Onboard Header 2G/4GB DRAM *Display Port RJ-45 LAN Port Full-size...
  • Page 10 Internal Diagram-Back Side: Intel CPU Warning: CPU is the most important part of the board and very fragile to any possible harm. Make sure that there is no damage to the CPU during any installation procedures!
  • Page 11 Connectors Connector Name DCIN 12V DC–in Power Jack Connector ATX2P Internal 12V System DC–in Power Connector USB30 USB 3.0 Port Connector x2 Display Port Connector RJ-45 Gigabit LAN Port Connector SATA1 SATAIII Port Connector SATAPW SATA Power-out Connector Headers Header Name Description FP_AUDIO...

  • Page 12: Jumper Setting

    Chapter 2 Hardware Installation 2-1 Jumper Setting Pin 1&2 of JP1 (6-pin): Clear CMOS RAM Function Setting → Pin 1&2 of JP1 Clear CMOS RAM 1-2 Open: Normal; Pin 1 1-2 Closed: Clear CMOS(One Touch). Pin 1 Pin 3&4 of JP1 (6-pin): Reset all RTC Register Bits →...
  • Page 13 Pin (5&6) of J1 (6-pin): Flash Descriptor Security Override → Pin (5&6) of JP1 TXE Security Function Select 5-6 Open: Normal; Pin 1 5-6 Closed: Override. Pin 1 JP2 (4-pin): COM1 Header Pin9 Function Select → COM1 Header Pin-9 2 4 6 2 4 6 1 3 5 1 3 5...
  • Page 14 JP5 (4-pin): LVDS VCC 3.3V/5V/12V Select JP5→LVDS VCC 2-4 Closed: 3-4 Closed: 4-6 Closed: VCC = 3.3V VCC = 5V; VCC = 12V; JP6 (3-pin): INVERTER Backlight 5V/12V Select JP6→INVERTER Backlight 1-2 Closed: Inverter Backlight= 5V; 2-3 Closed: Inverter Backlight= 12V. ：...
  • Page 15 AT_MODE (2-pin): AT Mode Function Select AT-MODE 1-2 Open: Normal; 1-2 Closed: AT Mode Selected. *ATX Mode Selected: Press power button to power on after power input ready; AT Mode Selected: Directly power on as power input ready. JP4 (8-pin): LVDS Panel Resolution Type Select Pin1 User can select LVDS panel resolution by jumper settings.
  • Page 16  Open: in which user leave jumper hat just in pin 2, pin4, pin6 or pin8. Jumper Setting Description Panel Resolution Color Depth Pin 1-2: Close Pin 3-4: Close 800 x 480 @ 60Hz 18-bit Pin 5-6: Close Pin 7-8: Close Pin 1-2: Open Pin 3-4: Close...

  • Page 17: Connectors And Headers

    Pin 1-2: Close Pin 3-4: Open 1366 x 768 @ 60Hz 24-bit Pin 5-6: Close Pin 7-8: Open Pin 1-2: Open Pin 3-4: Open 1440 x 900 @ 60Hz 18-bit Pin 5-6: Close Pin 7-8: Open Pin 1-2: Close Pin 3-4: Close 1440 x 900 @ 60Hz 24-bit Pin 5-6:...
  • Page 18 Icon Name Function For user to connect compatible power 12V DC-in Power Jack adapter to provide power supply for the Connector system. To connect USB keyboard, mouse or other USB 3.0 Port devices compatible with USB specification. USB 3.0 ports supports up to 5Gbps data transfer rate.
  • Page 19 (3) SATA1 (7-pin): SATAIII Port connector SATA1 port is a high-speed SATAIII port that supports 6GB/s transfer rate. Pin No. Definition (4) SATAPW(4-pin): SATA Power Connector Pin 1 Warning: Make sure that Pin-1 of compatible SATA Power connector is inserted into corresponding Pin-1 of SATA PW to avoid possible damage to the board and hard disk driver!

  • Page 20: Headers

    2-2-2 Headers (1) FP_AUDIO (9-pin): Line-Out, MIC-In Header This header connects to Front Panel Line-out, MIC-In connector with cable. Pin 1 (2) FP_USB20 (9-pin): USB 2.0 Port Header +DATA +DATA -DATA -DATA Pin 1...
  • Page 21 (3) COM1/COM2 (9-pin): Serial Port Header COM1: RS232/422/485Serial Port Header COM2: RS232 Serial Port Header COM1 COM2 *RS422 *RS485 Pin NO. RS232 (COM1) (COM1) Pin 1 DATA- Pin 2 DATA+ Pin 3 Pin 4 Pin 5 Pin 6 Pin 7 Pin 8 6 7 8 9 Pin 9...
  • Page 22 (4) JW_FP (9-pin): Front Panel Header Pin 1 (5) LAN_LED (2-pin): LAN Activity LED Header Pin1...
  • Page 23 (6) LVDS (30-pin): 24-bit Dual Channel LVDS Header Pin 1 Pin2 Pin NO. Pin Define Pin NO. Pin Define Pin 1 LVDSB_DATAN3 Pin 2 LVDSB_DATAP3 Pin 3 LVDS_CLKBN Pin 4 LVDS_CLKBP Pin 5 LVDSB_DATAN2 Pin 6 LVDSB_DATAP2 Pin 7 LVDSB_DATAN1 Pin 8 LVDSB_DATAP1 Pin 9...
  • Page 24 (7) INVERTER (8-pin): LVDS Inverter Header Pin No. Definition Backlight Enable Backlight PWM VLED VLED Backlight Up SW Pin 1 Backlight Down SW Warning! Find Pin-1 location of the inverter and make sure that the installation direction is correct! Otherwise serious harm will occur to the board/display panel!!

  • Page 25: Chapter 3 Introducing Bios

    Chapter 3 Introducing BIOS Notice! The BIOS options in this manual are for reference only. Different configurations may lead to difference in BIOS screen and BIOS screens in manuals are usually the first BIOS version when the board is released and may be different from your purchased motherboard. Users are welcome to download the latest BIOS version form our official website.

  • Page 26: Bios Menu Screen

    BIOS Menu Screen The following diagram show a general BIOS menu screen: Menu Bar General Help Items Current Setting Value Menu Items Function Keys Function Keys In the above BIOS Setup main menu of, you can see several options. We will explain these options step by step in the following pages of this chapter, but let us first see a short description of the function keys you may use here: ...

  • Page 27: Getting Help

     Press <+>/<–> keys when you want to modify the BIOS parameters for the active option.  [F1]: General help.  [F2]: Previous values.  [F3]: Optimized defaults.  [F4]: Save & Exit.  Press <Esc> to quit the BIOS Setup. ...

  • Page 28: Main Menu

    Main Menu Main menu screen includes some basic system information. Highlight the item and then use the <+> or <-> and numerical keyboard keys to select the value you want in each item. System Date Set the date. Please use [Tab] to switch between date elements. System Time Set the time.

  • Page 29: Advanced Menu

    3-7 Advanced Menu  Trusted Computing Press [Enter] to make settings to make further settings in the following settings: Security Device Support Use this item to enable or disable BIOS support for security device. O.S. will not show security device. TGG EFI protocol and INT1A interface will not be available. The optional settings are: [Disabled];...
  • Page 30 ACPI Sleep State Use this item to select the highest ACPI sleep state the system will enter when the suspend button is pressed. The optional settings are: [Suspend Disabled]; [S3 (Suspend to RAM)].  Super I/O Configuration *Note: ‘Super IO Configuration’ is only optional for model NP591D4 series. Press [Enter] to make settings for the following sub-items: Super IO Configuration ...
  • Page 31 FIF0]. ERP Function The optional settings:[Disabled]; [Enabled]. This item should be set as [Disabled] if you wish to have all active wake-up functions. WatchDog Reset Timer Use this item to enable or disable WDT reset function. When set as [Enabled], the following sub-items shall appear: WatchDog Reset Timer Value User can set a value in the range of [10] to [255].
  • Page 32 Press [Enter] to make settings for the following sub-items: COM1 Console Redirection Use this item to enable or disable COM1 Console Redirection. The optional settings are: [Disabled]; [Enabled]. When set as [Enabled], user can make further settings in the ‘Console Redirection Settings’...
  • Page 33 Legacy OS Redirection Resolution The optional settings are: [80x24]; [80x25]. Putty Keypad The optional settings are: [VT100]; [LINUX]; [XTERMR6]; [SCO]; [ESCN]; [VT400]. Redirection After BIOS POST The optional settings are: [Always Enable]; [BootLoader]. Serial Port for Out-of-Band Management/ Windows Emergency Management Services (EMS) Console Redirection The optional settings: [Disabled];...
  • Page 34 Parity The default setting is: [None]. *This item may or may not show up, depending on different configuration. Stop Bits The default setting is: [1]. *This item may or may not show up, depending on different configuration.  PC Health Status Press [Enter] to view current hardware health status and set value in ‘Shutdown Temperature’.
  • Page 35 Max CPU C-state The optional settings: [Disabled]; [Enabled]. The optional items are: [C7]; [C6]; [C1].  SATA Configuration Press [Enter] to make settings for the following sub-items: SATA Controller(s) The optional settings are: [Enabled]; [Disabled]. When set as [Enabled], user can make further settings in the ‘SATA Mode Selection’...
  • Page 36 option will not be created. Ipv6 PXE Support The optional settings are: [Disabled]; [Enabled]. Use this item to enable Ipv6 PXE Boot Support. When set as [Disabled], Ipv6 boot optional will not be created. PXE boot wait time Use this item to set wait time to press [ESC] key to abort the PXE boot. Media Detect Count Use this item to set number of times presence of media will be checked.
  • Page 37 Wake-up System with Dynamic Time Use this item to enable or disable system wake-up by RTC alarm. The optional settings: [Disabled]; [Enabled]. When set as [Enabled], system will wake on the current time + increased minute(s). *This function is supported when EUP Function is set as [Disabled]. USB Wake-up from S3-S4 The optional settings: [Enabled];...
  • Page 38 The optional settings are: [10 sec]; [20 sec]; [30 sec]; [40 sec]. Device Power-up Delay Use this item to set maximum time the device will take before it properly reports itself to the host controller. ‘Auto’ uses default value: for a root port it is 100 ms, for a hub port the delay is taken from hub descriptor.

  • Page 39: Chipset Menu

    Intel RMT (Ready Mode Technology) SSDT table will be loaded if enabled.  Intel(R) I211 Gigabit Network Connection- XX:XX:XX:XX:XX:XX This item shows current network brief information. 3-8 Chipset Menu  North Bridge Press [Enter] to view current using memory information and make settings for the following sub-items: PAVC Use this item to enable or disable Protected Audio Video Control.
  • Page 40 [256M]; [288M]; [320M]; [352M]; [384M]; [416M]; [448M]; [480M]; [512M]. DVMT Total Gfx Mem Use this item to select DVMT 5.0 total graphics memory size used by the internal graphics device. The optional settings are: [128 MB]; [256 MB]; [MAX]. Aperture Size The optional settings are: [128 MB];...

  • Page 41: Security Menu

    [Disabled]: Azalia will be unconditionally disabled; [Enabled]: Azalia will be unconditionally enabled. Azalia HDMI Codec Use this item to enable or disable internal HDMI codec for Azalia. The optional settings are: [Enabled]; [Disabled]. PWR Status after PWR Failure Use this item to select AC power state when power is re-applied after a power failure.

  • Page 42: Boot Menu

    3-10 Boot Menu Setup Prompt Timeout Use this item to set number of seconds to wait for setup activation key. Bootup Numlock State Use this item to select keyboard numlock state. The optional settings are: [On]; [Off]. Quiet Boot The optional settings are: [Disabled]; [Enabled]. Boot Option Priorities Boot Option #1( Boot Option #2/…) Use this item to decide system boot order from available options.

  • Page 43: Save & Exit Menu

    Hard Drive BBS Priorities Press [Enter] to use this item to set system boot order from available the legacy device sin this group. 3-11 Save & Exit Menu Save Changes and Reset This item allows user to reset the system after saving the changes. Discard Changes and Reset This item allows user to reset the system without saving any changes.
  • Page 44 Boot Override Boot Override UEFI:xx/… Press this item to select the device as boot disk after save configuration and reset. Reset System with TXE Disable Mode Press [Enter] for TXE to run into the temporary disable mode. Ignore if TXE Ignition...
