- Page 1 Config Guide AssuredSAN 3xx4 AssuredSAN 3xx4 Config Guide Q1 2016 The following document provides basic specifications on the AssuredSAN 3xx4 (EX) series. 83-00006911-00-01 Rev B Page 1...
- Page 2 Config Guide AssuredSAN 3xx4 Revision Reason For Change Changed By Date AC12062 Initial Release T. DiMauro 11/11/15 AC12176 G22x Updates T. DiMauro 1/25/16 Approvals (See Agile for approval signatures and date) 83-00006911-00-01 Rev B Page 2...
-
Page 3: Table Of Contents
Config Guide AssuredSAN 3xx4 WHAT’S NEW ................................5 CONFIGURATION OVERVIEW: ..........................6 MODEL NUMBERS ..............................7 3.1. Shipping Notes, Components, & Weights: ..........................7 3.1.1. Notes: ..................................... 7 3.1.2. Components/Cables: ................................7 3.1.3. Weights: ....................................8 CONTROLLERS ................................. 10 4.1. - Page 4 Config Guide AssuredSAN 3xx4 9.2.3. Open a Support Ticket ................................. 27 9.2.4. Submitting RMA Requests ..............................27 INTEROPERABILITY & AGENCY CERTIFICATIONS ..................28 10.1. Interoperability Certifications: ............................28 10.1.1. VMware Certifications ..............................28 10.1.2. Microsoft Certifications ..............................28 10.2. Agency Certifications – Safety, Emissions, Harmonics, Country Approvals: ................. 28 DATA SHEET SPECIFICATIONS –...
-
Page 5: What's New
Patented EcoStor™ battery-free cache backup eliminating battery replacement. Rugged, Mobile Applications AssuredSAN 3xx4 models are NEBS Level 3 and MIL STD 810G compliant to meet Telecommunications requirements and Military standards for shock and vibration. New! G22x Firmware A new product firmware “GL22x” is available for the AssuredSAN 3004 solutions. With G22x, the AssuredSAN 3004 solutions support Asynchronous Replication between all AssuredSAN arrays, improving business continuity, backup and disaster recovery scenarios. -
Page 6: Configuration Overview
12GB system cache (6GB per controller) FC, iSCSI, or SAS interface Chassis Options The AssuredSAN 3xx4 is supported in two (2) industry leading chassis that can serve as an RBOD or JBOD. Low Density 12 x 3.5” drives per chassis* 2U12: 24 x 2.5”... -
Page 7: Model Numbers
Config Guide AssuredSAN 3xx4 3. Model Numbers RBOD (RAID) models are available with both converged network controller (CNC) and SAS Models. JBOD (EX) models have 6G SAS ports to connect with the RBOD CNC Connectivity SAS Connectivity JBODs D3824 = 2U x 24 drives... -
Page 8: Weights
Config Guide AssuredSAN 3xx4 3.1.3. Weights: System weights: Below are system weights for 3xx4 systems without packaging. These weights are approximate due to slight variations in drives (multiple vendors) and pounds listed have been rounded. RBODs with dual-controller modules Item... - Page 9 Config Guide AssuredSAN 3xx4 Dot Hill has made ordering easy by creating Top Level Assembly (TLA) part numbers. These TLAs ship with dual controllers, drive full, and AC power supplies, and are available in 2U12 and 2U24 chassis. 3xx4 - CNC...
-
Page 10: Controllers
SFP’s from being used in the 3xx4 (EX) controller. Dot Hill branded SFP's must be ordered with the AssuredSAN 3xx4 controllers with the CNC (Converged Network Controller). They are available in 4 packs, so quantity 1 is recommended. They are available in 1G iSCSI, 10G iSCSI, 8G FC, or 16G FC. -
Page 11: Sas Port Expansion Cables
Config Guide AssuredSAN 3xx4 4.3. SAS Port Expansion Cables The SAS controller has 2 physical SAS ports which can accommodate an optional host port-expansion cable. Up to 4 of these cables can be connected to the SAS ports enabling 4 dual-port host connections. Each host-port expansion splits the 4 SAS lanes per port, so that 2 lanes are connected to each host port. -
Page 12: Chassis
Config Guide AssuredSAN 3xx4 5. Chassis: 5.1. 2U12 TLA Overview To build a system a la carte, choose from the TLAs below. Note: Additional TLAs are available. For a full up-to-date list, see our price book. Drive-less RBOD System (include rail kit):... -
Page 13: 2U24 Overview
Config Guide AssuredSAN 3xx4 PFRUKL24-04 Cable Pkg,Y HDminiSAS/miniSAS,2m,MLX,4BK Controller/Miscellaneous components PFRUKC61-01 38X4,CNC,2P,1RM-EX,FRU,PKG PFRUKC76-01 35X4,SAS,2P,1RM-EX,FRU,BB,PKG FHDW018-02 Rack Mount Kit,Shelf,Long,All HW 25"-36" PFRUKA17-01 Chas+MP,2U12,6G,V2,BB,FRU,PKG PFRUKA19-01 Chas+MP,2U24-S2,6G,V2,BB,FRU,PKG 5.2. 2U24 Overview To build a system a la carte, choose from the TLAs below. Note: Additional TLAs are available. For a full up-to-date list, see our price book. -
Page 14: How Many Rbod/Jbod Chassis Are Supported
Config Guide AssuredSAN 3xx4 PFRUKK13 SFP+,10GigE 3.3V 850nm LC Mod,4pk PFRUKK14 SFP+,16GFC 3.3V 850nm LC Mod, 4pk Host Port-Expansion Cable PFRUKL23-01 Cbl Pkg,Y HDminiSAS/HDminiSAS,2m,MLX PFRUKL23-04 Cbl Pkg,Y HDminiSAS/HDminiSAS,2m,MLX,4BK PFRUKL24-01 Cable Pkg,Y HDminiSAS/miniSAS,2m,MLX PFRUKL24-04 Cable Pkg,Y HDminiSAS/miniSAS,2m,MLX,4BK Controller/Miscellaneous components PFRUKC61-01 38X4,CNC,2P,1RM-EX,FRU,PKG... -
Page 15: Expansion Jbods
This 2.5-inch disk enclosure can be attached to any 3xx4 LFF or SFF RBODs. • Each configuration ships with a two .5m mini-SAS to mini-SAS cables for connection to the AssuredSAN 3xx4 array expansion port or existing disk enclosure cascade port. -
Page 16: What Jbods Are Supported Behind 3Xx4 Rbods
Config Guide AssuredSAN 3xx4 6.3. What JBODs are supported behind 3xx4 RBODs Line AssuredSAN Model 3004 2U12 2U24 Bays 38x4/35x4 If you have the above RAID product, the below are "recommended" JBOD's 3120 AssuredSAN 3000 "Titanium" JBODs behind LX 3130... -
Page 17: Drives
Config Guide AssuredSAN 3xx4 7. Drives 7.1. What Drives Are Supported The following table shows what drives are supported in what chassis. AssuredSAN 3004 Supported Drives (Q2 2015) 2U12 2U24 Yes* 300GB 600GB 900GB 1.2TB Yes* 1.8TB 300GB Yes* 450GB... -
Page 18: 512E Drives
Config Guide AssuredSAN 3xx4 2U24: Single: PFRUKF31-01 AMS,SFF Drive Blank,BB,FRU,PKG 48 Pack: PFRUKF31-48 AMS,SFF Drive Blank,BB,48 Bulk Pack 7.4. 512e Drives For AssuredSAN storage arrays, Dot Hill supports emulation, or 512e drives, rather than the 4K native sector format for the drives. These drives include emulation (e) which supports backward compatibility for the many applications and legacy operating systems that do not support 4K native drives. - Page 19 Config Guide AssuredSAN 3xx4 Mappable Physical Volumes per Pool Maximum LUNs per system (This means mapped 1024 1024 volumes) Maximum Volumes per system 512 *note1 2048 Snapshots per system (net usable) 512 *note2 1024 (EX only with license) Master Volumes per system...
-
Page 20: Realstor
Config Guide AssuredSAN 3xx4 8.2. RealStor RealStor gives users access to several new key features including thin provisioning with UNMAP, SSD read cache, storage pooling, fast rebuilds and virtual pool provisioning. The new features will be accessed via a new User Interface, referred to as Storage Management Console V3. -
Page 21: Mapping In The V3 Interface
Config Guide AssuredSAN 3xx4 8.3.1. Mapping in the V3 Interface: Once the users have added their Disk Groups to create the Pools, they may now create and map volumes. This is very similar to how the customers currently create volumes in the V2 WBI, however volumes are now assigned to a pool instead of a VDisk. -
Page 22: Realthin: Thin Provisioning
Config Guide AssuredSAN 3xx4 With the introduction of the term disk group, RealStor will provide a new set of CLI commands to configure disk groups: add disk-group, remove disk-groups, show disk-groups, etc. Disk groups are a group of disks that together form a RAID set. -
Page 23: Performance Volumes/Luns And Rapid Rebuilds
Config Guide AssuredSAN 3xx4 Note: If you try to disable overcommit and the total space allocated to thin-provisioned volumes exceeds the physical capacity of their storage pool, an error will say that there is insufficient free disk space to complete the operation and overcommit will remain enabled. -
Page 24: Realsnap: Advanced Copy Services / Snapshots
Config Guide AssuredSAN 3xx4 which do not, that small amount of data will remain at risk until the entire VDisk has been rebuilt. Also, performance suffers during the entire rebuild. Another exposure is encountering a media error. If the array is rebuilding two drives and encounters a media error on a third, the rebuild will fail. -
Page 25: Realcache: Ssd Read Cache
Config Guide AssuredSAN 3xx4 No, as each volume (or snapshot) is treated as a standard volume with reference pointers back to the source volume, snapshots have the same performance profile as the original source volume. Q: Are there performance implications when deleting one or multiple snapshots? No, all information relating to snapshots is using reference pointers, once these pointers are deleted the virtual storage services de-allocates the required pages from the overall system map. -
Page 26: Key Cli Commands For Read Cache
Config Guide AssuredSAN 3xx4 8.8.2. Key CLI Commands for Read Cache: The CLI may be used to create disks groups for Autonomic Tiers (HDD) and Read Cache. Figures 4-6 demonstrate the creation of a read cache, the viewing of disk groups, and the deletion of a disk group respectively. The examples highlight a read cache, but the commands may be used for any type of tier. -
Page 27: Sansolve Contact Information
Config Guide AssuredSAN 3xx4 If calling from outside the U.S.A., Phone: 001-303-845-3200 – select #1 for support 9.2.2. SANsolve Contact Information SANsolveHelp@dothill.com or 1-877-368-7924 9.2.3. Open a Support Ticket http://www.dothill.com/support/sansolve/ 9.2.4. Submitting RMA Requests • RMA requests are submitted via SANsolve, Dot Hill’s web-based call center interface. -
Page 28: Interoperability & Agency Certifications
Config Guide AssuredSAN 3xx4 Interoperability & Agency Certifications 10.1. Interoperability Certifications: For the latest Dot Hill Interop Matrix of Hypervisor, Operating System, HBA, and SAN switch certifications, go to http://CRC.Dothill.com. 10.1.1. VMware Certifications http://www.vmware.com/resources/compatibility/search.php?deviceCategory=san 10.1.2. Microsoft Certifications http://www.windowsservercatalog.com/results.aspx?bCatID=1338&cpID=0&avc=10&OR=1 10.2. Agency Certifications – Safety, Emissions, Harmonics, Country Approvals: The following table list certifications received, or in process by chassis. - Page 29 Config Guide AssuredSAN 3xx4 Germany South Korea Pending Pending Taiwan India 83-00006911-00-01 Rev B Page 29...
-
Page 30: Data Sheet Specifications - Rbod (Power, Temp, Acoustic, Dimensions)
Config Guide AssuredSAN 3xx4 Data Sheet Specifications – RBOD (Power, Temp, Acoustic, Dimensions) RBOD 2U24 2U12 Model # D3824, D3524 D3834, D3534 Power Requirements - AC Input: Input Power Requirements 100-240VAC 50/60Hz 100-240VAC 50/60Hz Max Input Power 400W maximum continuous... -
Page 31: Data Sheet Specifications - Jbod (Power, Temp, Acoustic, Dimensions)
Config Guide AssuredSAN 3xx4 Data Sheet Specifications – JBOD (Power, Temp, Acoustic, Dimensions) JBOD 2U24 2U12 Model # J6G24 J6G12 Power Requirements - AC Input: Input Power Requirements 100-240VAC 50/60Hz 100-240VAC 50/60Hz Max Input Power 436W maximum continuous 436W maximum continuous... -
Page 32: General
Config Guide AssuredSAN 3xx4 General 13.1. NEBS level-3 certification Dot Hill uses UL for Safety Certifications and Nationally Recognized Test Lab (NRTL) for EMC and NEBS compliance testing. Dot Hill 2U12 and 2U24 products also have TUV-GS mark for ease of shipment within Germany. -
Page 33: Other Sources Of Information
Config Guide AssuredSAN 3xx4 13.4. Other Sources of Information AssuredSAN™ 3xx4 Series 83-00004787-11-01_VSS_VDS.pdf AssuredSAN 3004 Series Getting Started (GL105) AssuredSAN 3004 Series Getting Started (GL200) AssuredSAN 3004 Series FRU Installation and Replacement Guide (GL200) AssuredSAN 3004 Series FRU Installation and Replacement Guide (GL105)
