Specifications

Recording System
DVD-RAM:
DVD-R:
DVD-R DL (Dual Layer):
DVD-RW:
+R
+R DL (Double Layer)
+RW
Recording time
Maximum 8 hours (using 4.7 GB disc)
XP: Approx. 1 hour SP: Approx. 2 hours
LP: Approx. 4 hours EP: Approx. 6 hours/8 hours
Recordable discs
DVD-RAM:
Ver. 2.1/3x–SPEED DVD-RAM Revision 1.0
Ver. 2.2/5x–SPEED DVD-RAM Revision 2.0
DVD-R:
for General Ver. 2.0/4x–SPEED DVD-R Revision 1.0
for General Ver. 2.x/8x–SPEED DVD-R Revision 3.0
for General Ver. 2.x/16x–SPEED DVD-R Revision 6.0
for DL Ver. 3.x/4x–SPEED DVD-R for DL Revision 1.0
DVD-RW:
Ver. 1.x/2x–SPEED DVD-RW Revision 1.0
Ver. 1.x/4x–SPEED DVD-RW Revision 2.0
Ver. 1.x/6x–SPEED DVD-RW Revision 3.0
+R:
+RW:
Quick Start for Recording (Quick Start: On)
1 Sec. Quick Start for Recording on DVD-RAM
From the power off state, recording on DVD-RAM starts about
1 second after first pressing the Power button and then
sequentially pressing the REC button (Quick Start Mode).
Playable discs
DVD-RAM (DVD Video Recording format), DVD-R (DVD-Video
format, DivX), DVD-R DL (Dual Layer) (DVD-Video format), DVD-
RW (DVD-Video format, DVD Video Recording format), +R,
+R DL (Double Layer), +RW, DVD-Video, DVD-Audio, CD-Audio
(CD-DA), Video CD, CD-R/RW (CD-DA, Video CD, MP3, JPEG,
DivX formatted discs)
Audio
Recording System:
Audio In: AV1/AV2 (21 pin), AV3/AV4 (pin jack)
Input Level: Standard: 0.5 Vrms, Full scale: 2.0 Vrms at 1 kHz
Input Impedance:
Audio Out: AV1/AV2 (21 pin), Audio Out (pin jack)
Output Level: Standard: 0.5 Vrms, Full scale: 2.0 Vrms at 1 kHz
Output Impedance:
Digital Audio Out: Optical terminal (PCM, Dolby Digital, DTS)
Video
Video System:
PAL colour signal, 625 lines, 50 fields
For Australia and N.Z.
NTSC colour signal, 525 lines, 60 fields
For Asia, Middle East and South Africa
SECAM (only input)/PAL colour signal, 625 lines, 50 fields
NTSC colour signal, 525 lines, 60 fields
Recording System:
For Australia and N.Z.
Video In (PAL/NTSC):
AV1/AV2 (21 pin), AV3/AV4 (pin jack) 1 Vp-p 75 Ω, termination
For Asia, Middle East and South Africa
Video In (SECAM/PAL/NTSC):
AV1/AV2 (21 pin), AV3/AV4 (pin jack) 1 Vp-p 75 Ω, termination
For Australia and N.Z.
S-Video In (PAL/NTSC):
AV2 (21 pin), AV3/AV4 (S terminal) 1 Vp-p 75 Ω, termination
For Asia, Middle East and South Africa
S-Video In (SECAM/PAL/NTSC):
AV2 (21 pin), AV3/AV4 (S terminal) 1 Vp-p 75 Ω, termination
Video Out (PAL/NTSC):
AV1/AV2 (21 pin), Video Out (pin jack) 1 Vp-p 75 Ω, termination
S-Video Out (PAL/NTSC):
AV1 (21 pin), S-Video Out (S terminal) 1 Vp-p 75 Ω, termination
RGB Out (PAL/NTSC):AV1 (21 pin) 0.7 Vp-p (PAL) 75 Ω, termination
Component video output (NTSC 480p/480i, PAL 576p/576i)
DVD Video Recording format
DVD-Video format
DVD-Video format
DVD-Video format
Ver. 2.0
for General Ver. 2.0
for DL Ver. 3.0
Ver. 1.1
Ver. 1.0
Ver. 1.1
Ver. 1.2
Ver. 1.3
for DL Ver. 1.0
Ver. 1.1
Ver. 1.2/4x–SPEED
Dolby Digital 2ch
More than 10 kΩ
Less than 1 kΩ
MPEG2 (Hybrid VBR)
Y: 1.0 Vp-p 75 Ω, termination
: 0.7 Vp-p 75 Ω, termination
P
B
: 0.7 Vp-p 75 Ω, termination
P
R
Television System
For Australia and N.Z.
Tuner Channel
VHF
System Coverage
PAL-B Australia 0-12
PAL-BG New Zealand 1-11
RF converter output:
For Asia
Channel
Tuner System VHF
Coverage
PAL-DK,
OIRT R1-R12
SECAM-DKK1
PAL-BGH,
CCIR E2-E12 E21-E69
SECAM-BG
Hong
PAL-I
Kong
PAL-D China 1-12
RF converter output:
For Middle East and South Africa
Channel
Tuner System VHF
Coverage
PAL-BGH,
CCIR E2-E12 E21-E69
SECAM-BG
RF converter output:
Optical pick-up:
System with 1 lens, 2 integration units
(662 nm wavelength for DVDs, 780 nm wavelength for CDs)
LASER Specification
Class 1 LASER Product
Wave Length:
Laser Power:
No hazardous radiation is emitted with the safety protection
DV Input (PAL/NTSC)
Others
Region Code:
For Middle East and South Africa
For Asia
For Australia and N.Z.
Operating temperature:
Operating humidity range:
Power supply:
For Australia and N.Z.
For Asia, Middle East and South Africa
Power consumption:
Dimensions (W×D×H):
Mass:
Power consumption in standby mode:
Note
Specifications are subject to change without notice.
Mass and dimensions are approximate.
UHF CATV
28-69 45 MHz–470 MHz
21-69 44 MHz–470 MHz
Not provided
UHF CATV
21-69 44 MHz–470 MHz
S01-S05
M1-M10, U1-U10
S21-S41
– 21-69 –
13-57 Z1-Z35
Not provided
UHF CATV
S01-S05
M1-M10, U1-U10
S21-S41
Not provided
780 nm (CDs), 662 nm (DVDs)
IEEE 1394 Standard, 4 pin: 1 pc
5 °C to 40 °C
10 % to 80 % RH (no condensation)
AC 220 V to 240 V, 50 Hz
AC 220 V to 240 V, 50/60 Hz
Approx. 22 W
430 mm × 316 mm × 58 mm
3.2 kg
approx. 2 W (Power Save mode)
