Automatic setting

You can restart auto channel setting if the channel reception setting
(Ô page 11) fails for some reason.
After performing steps 1–4 (Ô page 42)
5
Press [e,r] to select "Auto-Setup
Restart" and press [ENTER].
The confirmation screen appears.
6
Press [w,q] to select "Yes" and
press [ENTER].
For Australia and N.Z.
• If the Country setting menu appears on the television
Press [e,r] to select the country and press [ENTER].
You can also use the following method to restart Auto-Setup.
When the unit is on and stopped
Press and hold [2 CH] and [CH 1] on the main unit until the
Country setting screen or the Auto-Setup screen appears.
• All the settings except for the ratings level, ratings password and
time settings return to the factory preset. The timer recording
programmes are also cancelled.
To exit the screen
Press [RETURN] several times.
To return to the previous screen
Press [RETURN].
List of TV Reception Channels
For Australia and N.Z.
Tuner Channel
VHF
System Coverage
PAL-B Australia 0-12
PAL-BG New Zealand 1-11
For Asia
Channel
Tuner System VHF
Coverage
PAL-DK,
OIRT R1-R12
SECAM-DKK1
PAL-BGH,
CCIR E2-E12 E21-E69
SECAM-BG
Hong
PAL-I
Kong
PAL-D China 1-12
For Middle East and South Africa
Channel
Tuner System VHF
Coverage
PAL-BGH,
CCIR E2-E12 E21-E69
SECAM-BG
UHF CATV
28-69 45 MHz–470 MHz
21-69 44 MHz–470 MHz
UHF CATV
21-69 44 MHz–470 MHz
S01-S05
M1-M10, U1-U10
S21-S41
– 21-69 –
13-57 Z1-Z35
UHF CATV
S01-S05
M1-M10, U1-U10
S21-S41

TV System

Refer to the control reference on page 38.
Change this setting if you connect an NTSC television or to record
NTSC video from another source.
1
While stopped
Press [FUNCTIONS].
2
Press [e,r] to select "To Others" and
press [ENTER].
3
Press [e,r] to select "Setup" and
press [ENTER].
4
Press [e,r] to select "Connection"
and press [q].
5
Press [e,r] to select "TV System"
and press [ENTER].
6
Press [e,r] to select the TV system
and press [ENTER].
TV System
Setup
PAL
NTSC
Tuning
Disc
• PAL (factory preset)
– Select when connecting to a PAL or Multi-system
television. Programmes recorded using NTSC are played
as PAL 60.
– Select to record television programmes and PAL input from
other equipment.
• NTSC
– Select when connecting to an NTSC television. Television
programmes cannot be recorded properly.
– Select to record NTSC input from other equipment.
The confirmation screen appears.
7
Press [w,q] to select "Yes" and press
[ENTER].
To exit the screen
Press [RETURN] several times.
To return to the previous screen
Press [RETURN].
n To change the setting all at once (PAL
While stopped, press and hold [g] and [; OPEN/CLOSE] on the
main unit at the same time for about 5 seconds.
↔
NTSC)
RQT8317
43
