  • Page 1 Manual LED Mini Matrix 5x5 white 2700K...

  • Page 2: Table Of Contents

    Table of contents Safety instructions ..........................3 1.1. For safe and efficient operation ....................3 Designated use ..........................4 2.1. Overhead installation ....................... 5 Introduction ............................7 3.1. Product overview ........................7 3.2. Dimensions ..........................8 Connections ............................. 9 4.1. Electrical connections ......................

  • Page 3: Safety Instructions

    1. Safety instructions • This device is suitable for indoor use (not outdoors) only. device is suitable for indoor use (not outdoors) only. • All modifications to the device will void the warranty. All modifications to the device will void the warranty. •...

  • Page 4: Designated Use

    2. Designated use This device was developed for professional use on stages, in discos, theatres etc. The device is only approved for a connection up to 230V 50/60 Hz AC voltage and only for indoor use. Regular breaks during operation increase the lifetime of your device. Avoid convulsions or any form of forceful impact during the installation or the start-up of the device.

  • Page 5: Overhead Installation

    2.1. Overhead installation Overhead installation Danger of life! life! You have to observe the regulations of BGV C1 (formerly VBG 70) and You have to observe the regulations of BGV C1 (formerly VBG 70) and You have to observe the regulations of BGV C1 (formerly VBG 70) and EN60598-2-17 17 Installations are to carry out by skilled personnel only.
  • Page 6 The maximum drop exceed must not exceed 20cm. A safety rope once exposed to failing load or damaged may not be used furthermore. Adjust the desired inclination angle via the mounting bracket and tighten the screw. 6 / 16...

  • Page 7: Introduction

    3. Introduction Thank you for buying the LED Mini Matrix 5x5 white 2700K. It is a powerful device. For a successful installation and operation, please read this manual carefully. 3.1. Product overview 7 / 16...

  • Page 8: Dimensions

    3.2. Dimensions 8 / 16...

  • Page 9: Connections

    4. Connections 4.1. Electrical connections If you wish to change the power supply settings, see the chapter Appendix. Connect the fixture to the mains with the enclosed power cable and plug. The earth has to be connected. Cable (EU) Cable (US) International Brown Black...

  • Page 10: Control

    5. Control Press MENU, with the arrow keys you can choose the required point of menu. Confirm with ENTER. You can make your settings also with the arrow keys and conform them with ENTER. 5.1. Structure of the menu Menu Submenu 1 Submenu 2 Function...
  • Page 11 Speed … M:2*2 FONT Mode in 2x2 matrix run mode. … … M:4*4 FONT Mode in 4x4 matrix run mode. … LED 1 – 000 – 255 Dimmer LED 1 – 25 0 – 100%. LED 25 System error Shows system errors. DMX monitor Shows the DMX values.

  • Page 12: Dmx Chart

    6. DMX chart 6.1. DMX mode 1 (1 channel) Channel Value from Value to Function Dimmer 0 – 100% 6.2. DMX mode 2 (2 channels) Chanel Value from Value to Function Dimmer 0 – 100% Strobe slow - fast 6.3. DMX mode 3 (5 channels) Channel Value from Value to...

  • Page 13: Dmx Mode 4 (25 Channels)

    60 – 69 ID 6 ID 27 ID 50 70 – 79 ID 7 ID 28 ID 51 80 – 89 ID 8 ID 29 ID 52 90 – 99 ID 9 ID 30 ID 53 100 – 109 ID 10 ID 31 ID 54 110 –...

  • Page 14: Matrix

    7. Matrix 7.1. Connect the devices 1. Put two pieces on the same plane. 2. Connect the devices. 3. Press the quick lock, and then rotate 90°. 14 / 16...

  • Page 15: 2X2 Matrix

    4. Connect the other devices in the same way. 7.2. 2x2 Matrix 1. Connect 4 devices to a 2x2 Matrix. 2. For first device set Master Signal – ON - and Run Mode – M:2*2 -. 3. For the other devices set Run Mode – SL-2 / SL-3 / SL- 4. 4.

  • Page 16: Technical Data

    8. Technical data Power supply Voltage 100 – 240 V AC / 50-60 Hz Power consumption max. 230 W Light source LM type LED single color Color spectrum 2700 K Power 230 W Number / Power 25 x 3W Optics Beam angle 15°...
