V-Tail - Spektrum DX6 Manual

WING TYPE SELECTION (CONTINUED)
TO ACTIVATE FLAPERON (FPR) MIXING (WING TYPE MODE)
1. In System Setup mode, press the
2. Press the
INCREASE

V-TAIL

V-Tail Mixing requires two servos, each connected to the right and left tail control surfaces. Connect the left tail
servo to channel #3 (ELE) and the right tail servo to channel #4 (RUD) in the receiver . Individual functions (e.g.,
servo reversing, sub-trims, etc.) are available for each servo. Use sub-trims for individual neutral adjustments
and to vary the up and down travel as desired by using the dual rate function to adjust elevator vs. rudder travel
independently.
TO ACTIVATE V-TAIL (VTL) MIXING
1. In System Setup mode, press the
2. Press the
CHANNEL
3. Next press either the
also possible to activate both the Flaperon (FPR) and V-Tail (VTL) functions to work
simultaneously. While it is unlikely to have an aircraft that would require both, it is possible.
34
button until "MIX WNG" appears on the screen.
SCROLL
button to activate Flaperon Mixing.
button until "MIX WNG" appears on the screen.
SCROLL
button once to access the V-Tail Mixing screen.
or
INCREASE DECREASE
Distributed by www.modelflight.com.au
buttons once to activate V-Tail Mixing. Note: It is
SPEKTRUM DX6 • AIRCRAFT PROGRAMMING GUIDE
