Audiovox Prestige Platinum 128-5730A Installation Manual

Note : When both Passive Arming and Voltage Sensing are selected, you must hardwire the driver's door pin
switch in order to begin the passive arming sequence.
RF Programmable Features :
Feature Selection
1st Door L/UL
2nd Accy Lock
3rd Accy. UL
4th Passive Locks
5th Passive/Active Arm
6th Voltage Sense
7th Siren/Horn
8th Horn Chirp
9th Override Method
10th Two Step Unlock
11th Chirp Delete From Tx On
To program these selectable features;
Turn ignition on No response
Press and release the valet switch 3 times
Within 3 seconds, turn ignition Off
First Then On
Press transmitter Lock button to change
Press transmitter Lock button to change
Second Press and release the valet switch
Press transmitter Lock button to change
Third Press and release the valet switch
Press transmitter Lock button to change
Press transmitter Lock button to change
Fourth Press and release the valet switch
Press transmitter Lock button to change
Fifth Press and release the valet switch
Press transmitter Lock button to change
Sixth Press and release the valet switch
Press transmitter Lock button to change
Seventh Press and release the valet switch
Press transmitter Lock button to change
Press transmitter lock button to change
SELECTABLE FEATURES
1 Chirp 2 Chirps
1 Sec. 3.5 Sec.
Auto Lock On Auto Lock Off
Auto UL Dr. Auto UL All
Passive Active
Passive Arm Active Arm
Voltage Sense Hardwire
Siren/Horn Siren Only
10mS 16mS
Custom Code Valet
On Off
Off
Action
or
or
o r
o r
o r
o r
Model APS-255
Installation Manual
3 Chirps 4 Chirps
1 Sec L, Dbl. U/L
Auto UL Off
Horn Only
30mS
System Response
1 Chirp - LED 1 flash
Short chirp, then long chirp
1 chirp = 1 second door locks
2 chirps = 3.5 second door locks
3 chirps = 1 sec. lock, dbl 1 sec. unlock
2 chirps = auto locks off
1 chirp = auto locks on
3 chirps = auto unlock off
1 chirp = auto unlock dr.
2 chirps = auto unlock all
2 chirps = active locks
1 chirp = passive locks
2 chirps = active arming
1 chirp = passive arming
2 chirps = hardwire
1 chirp = voltage sense
1 chirp = siren and horn output
2 chirps = siren output only
3 chirps = horn output only
Default
1 Sec.
Auto Lock Off
Auto UL Off
Active
Active Arm
Hardwire
Siren/Horn
16mS
Valet
Off
Off
