Configure the Access Point (AP)
1. Log in to PharOS and go to the Quick Setup page.
Operation Mode: Select Access Point and click Next.
2.
LAN Settings: Click Next.
3.
4. Wireless AP Settings:
a. Create a new SSID (Network name) for your wireless network.
b. Select WPA-PSK/WPA2-PSK for the Security method and create a
PSK Password to protect your AP.
c. Enter the distance between the Access Point and the Client into
the Distance Setting field.
d. Select the MAXtream checkbox, and click Next.
Finish: Verify your settings and click Finish to complete the
5.
configuration.
Configure the Client
1. Log in to PharOS and go to the Quick Setup page.
Operation Mode: Select Client and click Next.
2.
3. LAN Settings: Change the IP Address to 192.168.0.X (X ranges
between 2 and 253), the same subnet with the access point, and
click Next.
4. Wireless Client Settings:
a. Click Survey and select the SSID of the Access Point in the AP list,
then click Connect.
b. Select WPA-PSK/WPA2-PSK from the Security option, enter the
same PSK password and distance value of the Access Point, then
click Next.
Finish: Verify your settings and click Finish to complete the
5.
configuration.
