English - TP-Link CPE210 Installation Manual

Hardware Connection
Please connect and install the device as shown in the figure below.
LAN0
Ethernet cable length up to 60m
Slide to replace the cover
of the CPE when all
connections are nished.
PoE
You should prepare an adequate
Ethernet cable to connect the CPE
and the passive PoE adapter.
Shielded CAT5e (or above) cable
with ground wire is recommended.
At the selected site,
approximately align the CPE
to the direction that you have
oriented.
01
LAN
Connect to a computer,
router or switch.
(Depending on your intended
usage and/or network
topology.)

English
