Feature - Aputure V-SCREEN VS-5 Product Manual

FEATURE

Full
Full Info. Mode
In this mode, you can monitor the footage. In the mean time, vectorscope,
Info.
waveform, RGB histogram, and volume bar are provided to assist shooting.
Waveform
120
100
There are two waveform modes: Overlay, and Parade, which allows simple
75
50
measurement without additional measurement equipment.
25
0
Vectorscope
Yl
G
There are two vectorscope modes: 1X, and 2X, which can be used to
R
Cy
display color gamut.
Mg
B
Co-Zebra
Utilize both zebra marking and over exposure monitoring features to assist
in exposure adjustment.
Peak
You can select Red, Yellow, Blue, or White to highlight the contours of
sharpest focusing areas, or choose Highlight to present the focusing area
by brightness contrast.
False Color
False Color is used to aid in the setting of camera exposure, which enables
proper exposure to be achieved without the use of costly, complicated
external test equipment. With the Scale, which is below the image, the
user can evaluate the exposure more accurately.
RGB
The RGB Histogram is a representation of the distribution of colors in an
image. It shows the red, green, and blue channels in histogram.
Histogram
-3-
