SE043012083E Ver.ppt11E
CONTENTS
● DISASSEMBLING PROCEDURES ....................................2
● PARTS LIST........................................................................3
● ELECTRICAL PARTS LIST............................................ 4~8
* Refer to the Service Manual for CV-0MW7G21-9(34R038) and
CV-0MW7G21-91(34R039) unless otherwise stated in this.
MITSUBISHI MOTORS

SERVICE MANUAL

POWER AMPLIFIER

MITSUBISHI ELECTRIC CORP. SANDA WORKS
CV-0MW7G21-92,93
Model :
MELCO Code : 34C021,033
PART No. : 8701A473,531
Copyright (C) Mitsubishi Electric Corporation.
CV-0MW7G21-92,-93
2013 Feb.
Your company internal use only.

Advertisement

   Related Manuals for Mitsubishi Electric CV-0MW7G21-92

   Summary of Contents for Mitsubishi Electric CV-0MW7G21-92

  • Page 1: Service Manual

    * Refer to the Service Manual for CV-0MW7G21-9(34R038) and CV-0MW7G21-91(34R039) unless otherwise stated in this. CV-0MW7G21-92,93 Model : MELCO Code : 34C021,033 PART No. : 8701A473,531 MITSUBISHI ELECTRIC CORP. SANDA WORKS Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.

  • Page 2: Disassembling Procedures

    0.8 +0.2/-0.1 Ⓑ 3X10 0.8 +0.2/-0.1 *Confirm the hooks of M002 are latched, insert M002. Ⓒ 3X16 0.8 +0.2/-0.1 (Be careful not to deform.) M005 : ASSY-CHASSIS Ⓓ 0.8 +0.2/-0.1 Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.

  • Page 3: Parts List

    M002 560J33313 CHASSIS-F M003 635J08911 HEAT-SINK-MAIN M004 635K06610 HEAT-SINK-SUB M005 891J06810 ASSY-CHASSIS M006 943M397O7 NAME-CARD(CV-0MW7G21-92) M007 943M397O8 NAME-CARD(CV-0MW7G21-93) 653P11046 SCREW-S-PAN 3X6 653P11048 SCREW-S-PAN 3X10 653P11052 SCREW-S-PAN 3X16 669L077O2 SCREW-TAPPING 3X6 Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.

  • Page 4: Parts List

    50V 153K N931L29812 C3G2 141L181O9 C-CERAMIC-CHIP GRM1882C1H220JZ01D CH50V220J 1608 N931L29812 C630 181P75090 C-ELECTROLYTIC RW2-16V332MI6P2#-T4 16V332M 12.5X25 N931L29712 C501 181P372O5 C-ELECTROLYTIC-TAPE USR1C330MDD1TP 16V 330M N931L29812 C631 181P372O5 C-ELECTROLYTIC-TAPE USR1C330MDD1TP 16V 330M N931L29812 Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.

  • Page 5: Electrical Parts List

    264P588O6 DIODE-ZENER-CHIP MA8270-M-TX N931L29812 L359 351P095O4 COIL-CHOKE-CHIP BK1608LM252-T N931L29812 D011 264L060O1 DIODE-CHIP 1SS355 FNTE-17 N931L29812 L360 351P095O4 COIL-CHOKE-CHIP BK1608LM252-T N931L29812 D012 264P588O6 DIODE-ZENER-CHIP MA8270-M-TX N931L29812 L361 351P095O4 COIL-CHOKE-CHIP BK1608LM252-T N931L29812 Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.

  • Page 6: Electrical Parts List

    1/10W 103J 1608 N931L29812 Q684 260L033O1 TRANSISTOR-CHIP DTC323TK T146 N931L29812 R372 103L293O7 R-CHIP RMC1/16103JTP 1/10W 103J 1608 N931L29812 Q801 260M061O1 TRANSISTOR-CHIP DTA124EKAT146 N931L29812 R373 103L293O7 R-CHIP RMC1/16103JTP 1/10W 103J 1608 N931L29812 Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.

  • Page 7: Cv-0mw7g21-92

    R-CHIP RMC1/16222FTP 1/10W 222F 1608 N931L29812 R819 103L293O3 R-CHIP RMC1/16472JTP 1/10W 472J 1608 N931L29812 R584 103P502O9 R-CHIP RMC1/16222FTP 1/10W 222F 1608 N931L29812 R820 103L291O7 R-CHIP RMC1/16221JTP 1/10W 221J 1608 N931L29812 Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.

  • Page 8

    1/16W 221J 3216 N931L29812 X3G1 285P11422 CRYSTAL-TAPE SMD-49 22.5792MHZ N931L29812 X801 285L012O7 CRYSTAL-TAPE AT-49 PB-FREE 10MHZ 16PF N931L29812 931L29712 S5-PCB-AMP N903L50721 931L29812 S6-PCB-AMP N931L29712 931L29713 S5-PCB-AMP N903L50722 931L29813 S6-PCB-AMP N931L29713 Copyright (C) Mitsubishi Electric Corporation. Your company internal use only.
