Page 1 500L 2 0 1 5 O W N E R ’ S M A N U A L...
Page 2 This manual illustrates and describes the operation of VEHICLES SOLD IN CANADA With respect to any Vehicles Sold in Canada, the name FCA features and equipment that are either standard or op- US LLC shall be deemed to be deleted and the name FCA tional on this vehicle.
Page 3: Introduction 3
TABLE OF CONTENTS SECTION PAGE INTRODUCTION ............. . . 3 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE .
Page 5: Table Of Contents
INTRODUCTION CONTENTS INTRODUCTION ......4 VEHICLE IDENTIFICATION NUMBER ..6 HOW TO USE THIS MANUAL ....4 VEHICLE MODIFICATIONS/ALTERATIONS .
Page 6: Introduction
4 INTRODUCTION INTRODUCTION NOTE: After reviewing the owner information, it should be stored in the vehicle for convenient referenc- Congratulations on selecting your new vehicle. Be as- sured that it represents precision workmanship, distinc- ing and remain with the vehicle when sold. tive styling, and high quality - all essentials that are When it comes to service, remember that your authorized traditional to our vehicles.
Page 7 INTRODUCTION 5...
Page 8: Vehicle Identification Number
6 INTRODUCTION WARNINGS AND CAUTIONS This Owner’s Manual contains WARNINGS against op- erating procedures that could result in a collision or bodily injury. It also contains CAUTIONS against procedures that could result in damage to your vehicle. If you do not read this entire Owner’s Manual, you may miss important information.
Page 9: Vehicle Modifications/Alterations
INTRODUCTION 7 VEHICLE MODIFICATIONS/ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to a collision resulting in serious injury or death. Stamped VIN Location NOTE: It is illegal to remove or alter the VIN.
Page 11 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS ▫ Central Lock/Unlock (Switch Safe Lock A WORD ABOUT YOUR KEYS ... . .11 Device) — If Equipped ....17 ▫...
Page 12 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE ▫ Important Safety Precautions ....30 DOOR LOCKS ......21 ▫...
Page 13: A Word About Your Keys
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 11 A WORD ABOUT YOUR KEYS NOTE: The authorized dealer that sold you your vehicle has the key code numbers for your vehicle locks. These The Key Fob contains the Remote Keyless Entry (RKE) numbers can be used to order duplicate keys from your transmitter with an integrated key.
Page 14 12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • AVV: engine start-up; • MAR: driving position. All electrical devices are en- abled. The ignition switch is fitted with a safety system that requires the ignition key to be turned back to STOP if the engine does not start, before the starting operation can be repeated.
Page 15: Locking Doors With A Key
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 WARNING! WARNING! (Continued) • Do not leave children or animals inside parked • Before exiting a vehicle, always apply the parking vehicles in hot weather. Interior heat build-up may brake, shift the transmission into PARK and re- cause serious injury or death.
Page 16: Key-In-Ignition Reminder
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Key-In-Ignition Reminder NOTE: A key which has not been programmed is also considered an invalid key, even if it is cut to fit the Opening the driver’s door when the key is in the ignition ignition switch lock cylinder for that vehicle.
Page 17: Replacement Keys
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 15 Replacement Keys NOTE: Changes or modifications not expressly approved by the party responsible for compliance could void the NOTE: Only keys that have been programmed to the user’s authority to operate the equipment. vehicle electronics can be used to start the vehicle.
Page 18: To Disarm The System
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. Lock the door using either the Central Lock/Unlock If the horn sounds a second time, check that all doors, switch or the Remote Keyless Entry (RKE) transmitter hood and liftgate are closed correctly, then rearm the and close all doors.
Page 19: Central Lock/Unlock (Switch Safe Lock Device) - If Equipped
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 17 remain in the vehicle and lock the doors with the RKE transmitter, once the Vehicle Security Alarm is armed, when you pull the door handle to exit, the alarm will sound. If this occurs, push the UNLOCK button on the RKE transmitter to disarm the Vehicle Security Alarm.
Page 20: Remote Keyless Entry (Rke)
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The direction indicators flash three times and the LED above the button flashes to indicate that the Safe Lock device has been activated. If one or more of the doors are not closed correctly, the Safe Lock device will not acti- vate, preventing a person from getting stuck inside the passenger compartment by entering the car through, and then closing, the open door.
Page 21: To Unlock The Doors And Liftgate
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19 To Unlock The Doors And Liftgate Programming Additional Transmitters Push and release the UNLOCK button on the RKE Refer to “Sentry Key®” in “Things To Know Before transmitter once to unlock the driver’s door or twice, Starting”...
Page 22: Replacing The Battery In The Key With Remote Control
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Turn the screw C to Unlock using a small screwdriver; Replacing The Battery In The Key With Remote Control • Take out the battery case D and replace the battery E making sure that polarities are correct;...
Page 23: Door Locks
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21 NOTE: Changes or modifications not expressly approved DOOR LOCKS by the party responsible for compliance could void the Push the central LOCK/UNLOCK button located on the user’s authority to operate the equipment. instrument panel, in the switch bank below the radio.
Page 24 22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: With central locking active (LED ON), opening one of the front doors, it is possible to perform a central unlocking (LED OFF). With central locking active (LED ON), in order to open one of the rear passenger doors, it is necessary pulling the internal door handle twice.
Page 25: Doors Lock With One Or More Doors Open
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23 WARNING! (Continued) WARNING! (Continued) • For personal security and safety in the event of a • Do not leave the Key Fob in or near the vehicle, or collision, lock the vehicle doors as you drive as in a location accessible to children.
Page 26: Auto - Relocking (Only For Rear Doors)
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE maintains the central locking status if key is not inserted To Engage Or Disengage The Child-Protection in Ignition Device, otherwise the vehicle will be unlocked Door Lock System and the LED will be switched OFF. 1.
Page 27: Power Windows
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25 NOTE: For emergency exit from the rear seats when the Child-Protection Door Lock System is engaged, unlock the doors using the central unlock button, roll down the window and open the door using the exterior handle. POWER WINDOWS Power Window Switches The power window controls are located on the driver’s...
Page 28 26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: The power window switches will remain active Auto-Down for up to three minutes after the ignition switch is cycled The window switches have an Auto-Down feature. Push to the OFF position. Opening either front door will cancel the window switch for approximately one second, re- this feature.
Page 29: Wind Buffeting
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27 NOTE: Resetting The Auto Up Feature • If the window runs into any obstacle during auto- Should the “Auto Up” feature stop working, the window probably needs to be reset. To reset “Auto Up”: closure, it will reverse direction and then go back down.
Page 30: Liftgate
28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE open or partially open positions. This is a normal occur- WARNING! rence and can be minimized. If the buffeting occurs with • Driving with the liftgate open can allow poisonous the sunroof open, adjust the sunroof opening to minimize the buffeting or open any window.
Page 31: Liftgate Emergency Release
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 29 Liftgate Emergency Release As a security measure, a Liftgate Emergency Release is built into the liftgate latching mechanism. To access the Liftgate Emergency Release proceed as follows: 1. Remove the rear headrests and fold down the seats completely 2.
Page 32: Occupant Restraint Systems
30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Important Safety Precautions Please pay close attention to the information in this section. It tells you how to use your restraint system properly, to keep you and your passengers as safe as possible.
Page 33 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31 restraints or belt-positioning booster seats. Older chil- side air bags will inflate forcefully into the space dren who do not use child restraints or belt- between occupants and the door and occupants could positioning booster seats should ride properly buckled be injured.
Page 34: Seat Belt Systems
32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Seat Belt Systems outboard front seat passenger BeltAlert) to buckle their seat belts. The Belt Alert feature is active when- Buckle up even though you are an excellent driver, even ever the ignition switch is in the AVV/START or on short trips.
Page 35 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 33 BeltAlert Warning Sequence their seat belt while the vehicle is traveling, the BeltAlert warning sequence will begin until the seat belts are buck- The BeltAlert warning sequence is activated when the led again. The outboard front passenger seat BeltAlert is vehicle is moving above a specified vehicle speed range not active when the outboard front passenger seat is and the driver or outboard front seat passenger is un-...
Page 36 34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Lap/Shoulder Belts WARNING! (Continued) All seating positions in your vehicle are equipped with • In a collision, you and your passengers can suffer lap/shoulder belts. much greater injuries if you are not properly buck- led up.
Page 37 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 35 WARNING! (Continued) WARNING! (Continued) • Wearing your seat belt incorrectly could make your • A twisted seat belt may not protect you properly. In injuries in a collision much worse. You might a collision, it could even cut into you.
Page 38 36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) WARNING! (Continued) • A seat belt that is worn under your arm is danger- frays, or loose parts. Damaged parts must be re- ous. Your body could strike the inside surfaces of placed immediately.
Page 39 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 37 Pulling Out The Latch Plate Inserting Latch Plate Into Buckle 3. When the seat belt is long enough to fit, insert the latch 4. Position the lap belt so that it is snug and lies low plate into the buckle until you hear a “click.”...
Page 40 38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE position. If necessary, slide the latch plate down the webbing to allow the seat belt to retract fully. Lap/Shoulder Belt Untwisting Procedure Use the following procedure to untwist a twisted lap/ shoulder belt. 1.
Page 41 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39 Seat Belts And Pregnant Women Position the lap belt snug and low below the abdomen and across the strong bones of the hips. Place the shoulder belt across the chest and away from the neck. Never place the shoulder belt behind the back or under the arm.
Page 42 40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The pretensioners are triggered by the Occupant Re- Restraints” section of this manual. The table below straint Controller (ORC). Like the air bags, the preten- defines the type of feature for each seating position. sioners are single use items.
Page 43 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41 around the occupant’s mid-section so as to not activate WARNING! the ALR. If the ALR is activated, you will hear a clicking • Never place a rear-facing child restraint in front of sound as the seat belt retracts.
Page 44: Supplemental Restraint System (Srs)
42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE How To Disengage The Automatic Locking Mode WARNING! (Continued) Unbuckle the combination lap/shoulder belt and allow it only used to install rear-facing or forward-facing to retract completely to disengage the Automatic Locking child restraints that have a harness for restraining Mode and activate the vehicle sensitive (emergency) the child.
Page 45 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43 • Supplemental Side Air Bags • Supplemental Knee Air Bags • Front and Side Impact Sensors • Seat Belt Pretensioners • Seat Belt Buckle Switch • Seat Track Position Sensors Advanced Front Air Bags This vehicle has Advanced Front Air Bags for both the Advanced Front Air Bag And Knee Bolster Locations driver and front passenger as a supplement to the seat...
Page 46 44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE output appropriate to the severity and type of collision as WARNING! determined by the Occupant Restraint Controller (ORC), • Being too close to the steering wheel or instrument which may receive information from the front impact sensors or other system components.
Page 47 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45 Advanced Front Air Bag Operation Seat belts are necessary for your protection in all colli- sions, and also are needed to help keep you in position, Advanced Front Air Bags are designed to provide addi- away from an inflating air bag.
Page 48 46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Knee Impact Bolsters Supplemental Driver Knee Air Bag The Knee Impact Bolsters help protect the knees of the This vehicle is equipped with a Supplemental Driver driver and front passenger, and position the front occu- Knee Air Bag mounted in the instrument panel below the pants for improved interaction with the Advanced Front steering column.
Page 49 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 47 When the SAB deploys, it opens the seam on the outboard side of the seatback’s trim cover. The inflating SAB de- ploys through the seat seam into the space between the occupant and the door. The SAB moves at a very high speed and with such a high force that it could injure occupants if they are not seated properly, or if items are positioned in the area where the SAB inflates.
Page 50 48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The SABICs deploy downward, covering the side win- dows. An inflating SABIC pushes the outside edge of the trim out of the way and covers the window. The SABICs inflate with enough force to injure occupants if they are not belted and seated properly, or if items are positioned in the area where the SABICs inflate.
Page 51 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 49 The SABICs and SABs (“Side Air Bags”) are designed to WARNING! activate in certain side impacts and certain rollover • Your vehicle is equipped with left and right events. The Occupant Restraint Controller (“ORC”) de- termines whether the deployment of the Side Air Bags in Supplemental Side Air Bag Inflatable Curtains a particular side impact or rollover event is appropriate,...
Page 52 50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE help keep you in position, away from inflating Side Air WARNING! (Continued) Bags. To get the best protection from the Side Air Bags, properly. In some collisions, Side Air Bags won’t occupants must wear their seat belts properly and sit deploy at all.
Page 53 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 51 The Side Air Bags will not deploy in all side collisions, Air Bags is appropriate, the rollover sensing system will including some collisions at certain angles, or some side also deploy the seat belt pretensioners on both sides of collisions that do not impact the area of the passenger the vehicle.
Page 54 52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE normally heal quickly. However, if you haven’t healed WARNING! significantly within a few days, or if you have any blistering, see your doctor immediately. Deployed air bags and seat belt pretensioners cannot protect you in another collision.
Page 55 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 53 on the nature of the event, the ORC will determine ENHANCED ACCIDENT RESPONSE SYSTEM whether to have the Enhanced Accident Response Sys- RESET PROCEDURE tem perform the following functions: After the event occurs, when the system is active, a •...
Page 56 54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Customer Action Customer Will See Customer Action Customer Will See 1. Turn Ignition OFF. 6. Turn Left Turn Signal Left Turn Light Is ON (Turn Signal Switch Must Switch ON. SOLID. Right Turn Light Be Placed In Neutral Is ON SOLID.
Page 57 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 55 Air Bag Warning Light the MAR/ACC/ON/RUN position. After the self-check, the Air Bag Warning Light will turn off. If the ORC The air bags must be ready to inflate for your protection detects a malfunction in any part of the system, it turns in a collision.
Page 58 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • The Air Bag Warning Light comes on intermittently or Event Data Recorder (EDR) remains on while driving. This vehicle is equipped with an event data recorder (EDR). The main purpose of an EDR is to record, in NOTE: If the speedometer, tachometer, or any engine certain crash or near crash-like situations, such as an air related gauges are not working, the Occupant Restraint...
Page 59: Child Restraints
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 57 These data can help provide a better understanding of Child Restraints the circumstances in which crashes and injuries occur. Everyone in your vehicle needs to be buckled up at all times, including babies and children. NOTE: EDR data are recorded by your vehicle only if a non-trivial crash situation occurs;...
Page 60 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Before buying any restraint system, make sure that it has WARNING! (Continued) a label certifying that it meets all applicable Safety great that you could not hold the child, no matter Standards. You should also make sure that you can install how strong you are.
Page 61 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 59 Summary Of Recommendations For Restraining Children In Vehicles Child Size, Height, Weight Or Age Recommended Type Of Child Restraint Infants and Toddlers Children who are two years old or younger Either an Infant Carrier or a Convertible and who have not reached the height or Child Restraint, facing rearward in the weight limits of their child restraint...
Page 62 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Infants And Child Restraints WARNING! Safety experts recommend that children ride rear-facing • Never place a rear-facing child restraint in front of in the vehicle until they are two years old or until they an air bag.
Page 63 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 61 remain in a forward-facing child seat with a harness for WARNING! (Continued) as long as possible, up to the highest weight or height directions exactly when installing an infant or allowed by the child seat. child restraint.
Page 64 62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Children Too Large For Booster Seats 5. Can the child stay seated like this for the whole trip? Children who are large enough to wear the shoulder belt If the answer to any of these questions was “no,” then the comfortably, and whose legs are long enough to bend child still needs to use a booster seat in this vehicle.
Page 65 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 63 Recommendations For Attaching Child Restraints Restraint Type Combined Use any attachment method shown with an “X” Below Weight of the LATCH – Seat Belt Only LATCH – Seat Belt + Top Child + Child Lower Anchors Lower Anchors Tether Anchor...
Page 66 64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Lower Anchors And Tethers For Children (LATCH) Your vehicle is equipped with the child restraint anchor- Restraint System age system called LATCH, which stands for Lower Anchors and Tethers for CHildren. The LATCH system has three vehicle anchor points for installing LATCH- equipped child seats.
Page 67 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 65 LATCH Positions For Installing Child Restraints In This Vehicle • Lower Anchorage Symbol 2 anchorages per seating position • Top Tether Anchorage Symbol...
Page 68 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE What is the weight limit (child’s weight + 65 lbs Use the LATCH anchorage system until the combined weight of the child restraint) for using the (29.5 kg) weight of the child and the child restraint is 65 lbs LATCH anchorage system to attach the child (29.5 kg).
Page 69 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 67 Can the rear-facing child restraint touch The child seat may touch the back of the front passen- the back of the front passenger seat? ger seat if the child restraint manufacturer also allows contact.
Page 70 68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Locating The Upper Tether Anchorages There are tether strap anchorages behind each rear seating position located on the back of the seat, near the floor. Tether Anchorage Routing Position LATCH-compatible child restraint systems will be equipped with a rigid bar or a flexible strap on each side.
Page 71 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 69 tether strap. The tether strap will have a hook at the end Always follow the directions of the child restraint to attach to the top tether anchorage and a way to tighten manufacturer when installing your child restraint.
Page 72 70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE restraint to get a better fit. If the rear seat can be moved 6. Test that the child restraint is installed tightly by forward and rearward in the vehicle, you may wish to pulling back and forth on the child seat at the belt move it to its rear-most position to make room for the path.
Page 73 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 71 Installing Child Restraints Using The Vehicle Seat WARNING! Belt • Improper installation of a child restraint to the The seat belts in the passenger seating positions are LATCH anchorages can lead to failure of the re- equipped with a Switchable Automatic Locking Retractor straint.
Page 74 72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Lap/Shoulder Belt Systems For Installing Child Restraints In This Vehicle • ALR = Switchable Automatic Locking Retractor...
Page 75 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 73 What is the weight limit (child’s Weight limit of the Child Restraint Always use the tether anchor when weight + weight of the child using the seat belt to install a restraint) for using the Tether forward facing child restraint, up Anchor with the seat belt to attach to the recommended weight limit...
Page 76 74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Installing A Child Restraint With A Switchable 5. To lock the seat belt, pull down on the shoulder part of Automatic Locking Retractor (ALR) the belt until you have pulled all the seat belt webbing out of the retractor.
Page 77 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 75 strap. See the section “Installing Child Restraints WARNING! (Continued) Using the Top Tether Anchorage” for directions to tether strap of a rear-facing car seat to the tether attach a tether anchor. anchorage that is approved for that seating position, 9.
Page 78 76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE tether anchorage for that seating position, move the child restraint to another position in the vehicle if one is available. 2. Route the tether strap to provide the most direct path for the strap between the anchor and the child seat. If your vehicle is equipped with adjustable rear head restraints, raise the head restraint, and where possible, route the tether strap under the head restraint and...
Page 79: Transporting Pets
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 77 ENGINE BREAK-IN RECOMMENDATIONS WARNING! A long break-in period is not required for the engine and • An incorrectly anchored tether strap could lead to drivetrain (transmission and axle) in your vehicle. increased head motion and possible injury to the Drive moderately during the first 300 miles (500 km).
Page 80: Safety Tips
78 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CAUTION! WARNING! • Do not leave children or animals inside parked Never use Non-Detergent Oil or Straight Mineral Oil in the engine or damage may result. vehicles in hot weather. Interior heat build-up may cause serious injury or death.
Page 81: Exhaust Gas
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 79 Exhaust Gas WARNING! (Continued) • If it is necessary to sit in a parked vehicle with the WARNING! engine running, adjust your heating or cooling Exhaust gases can injure or kill. They contain carbon controls to force outside air into the vehicle.
Page 82: Safety Checks You Should Make Inside The Vehicle
80 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Safety Checks You Should Make Inside The not lit during starting, see your authorized dealer. If the Vehicle light stays on, flickers, or comes on while driving, have the system checked by an authorized dealer. Seat Belts Defroster Inspect the seat belt system periodically, checking for...
Page 83 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 81 WARNING! WARNING! (Continued) • Check mounting of mats on a regular basis. Always Pedals that cannot move freely can cause loss of properly reinstall and secure floor mats that have vehicle control and increase the risk of serious per- been removed for cleaning.
Page 84: Periodic Safety Checks You Should Make Outside The Vehicle
82 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Periodic Safety Checks You Should Make Outside Door Latches The Vehicle Check for proper closing, latching, and locking. Tires Fluid Leaks Examine tires for excessive tread wear and uneven wear Check area under vehicle after overnight parking for fuel, patterns.
Page 85 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS ▫ Rear Seats......96 MIRRORS ......86 ▫...
Page 86 84 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ▫ Turn Signals ......108 ▫ To Resume Speed .....120 ▫...
Page 87 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 85 ▫ Programming A Rolling Code ... . .131 CIGAR LIGHTER — IF EQUIPPED ..142 ▫...
Page 88: Mirrors
86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE MIRRORS Inside Day/Night Mirror A single ball joint mirror is provided in the vehicle. It is a twist on mirror that has a fixed position at the wind- shield. The mirror installs on the windshield button with a counterclockwise rotation and requires no tools for mounting.
Page 89: Conversation Mirror - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 87 to the left of the button will illuminate to indicate when CAUTION! the dimming feature is activated. The sensor to the right of the button does not illuminate. To avoid damage to the mirror during cleaning, never spray any cleaning solution directly onto the mirror.
Page 90: Power Mirrors
88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Conversation Mirror Location Conversation Mirror To gain access to the conversation mirror, pull downward Power Mirrors on the mirror to the open position. The power mirror controls are located on the driver’s door trim panel. To adjust a mirror, turn the control knob toward the left or right mirror positions indicated.
Page 91: Folding Mirrors
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 89 move. When you are finished adjusting the mirror, turn Folding Mirrors the control to the center position to prevent accidentally The exterior mirrors are hinged to allow the mirror to moving a mirror. pivot forward or rearward to help avoid damage.
Page 92 90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To use the “Slide-On-Rod” feature, rotate the sun visor downward and unclip it. Pull the sun visor along the “Slide-On-Rod” until the sun visor is in the desired position. Sun Visor (Driver Side Shown) Sun Visor “Slide-On-Rod”...
Page 93: Seats
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 91 SEATS Front Seats Forward/Rearward Adjustment The adjusting bar is located at the front of the seats, near the floor. While sitting in the seat, lift up on the bar and move the seat forward or rearward. Release the bar once the desired position is reached.
Page 94 92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! • Adjusting a seat while driving may be dangerous. Moving a seat while driving could result in loss of control which could cause a collision and serious injury or death. • Seats should be adjusted before fastening the seat belts and while the vehicle is parked.
Page 95 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 93 Recliner Adjustment The recline lever is located on the outboard side of the seat. To recline the seat, lean forward slightly, lift the lever, lean back to the desired position and release the lever.
Page 96 94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! (Continued) adjusted properly and you could be injured. Adjust the seat only while the vehicle is parked. • Do not ride with the seatback reclined so that the shoulder belt is no longer resting against your chest.
Page 97 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 95 WARNING! • Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaus- tion or other physical condition must exercise care when using the seat heater.
Page 98: Rear Seats
96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Rear Seats While sitting in the seat, lift up on the bar and move the seat forward or rearward. Release the bar once the Rear Seats Forward/Rearward Adjustment desired position is reached. Then, using body pressure, The adjusting bar is located at the front of the seats, near move forward and rearward on the seat to be sure that the floor.
Page 99 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 97 Reclining Rear Seats WARNING! The recliner handle is located on the outside of the seat Do not ride with the seatback reclined so that the cushion. To adjust the seatback, lift upward on the shoulder belt is no longer resting against your chest.
Page 100 98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Seatback Release Lever Seatback Folded 2. Fold the seatback forward. 3. Locate the seatback recline lever on the outboard side of the seat and lift upward on the lever.
Page 101 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 99 Seatback Recline Lever Folding Rear Seat 4. Slowly flip the entire seat forward. 5. Slowly flip the entire seat rearward and firmly lock the seat into position. 6. Raise the rear seatback and firmly lock the seatback into position.
Page 102: Head Restraints
100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Rear Armrest — If equipped To use the armrest, lower it downward. Armrest Cupholder Head Restraints Head restraints are designed to reduce the risk of injury by restricting head movement in the event of a rear- Folding Rear Seat Armrest impact.
Page 103 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 101 To raise the head restraint, pull upward on the head WARNING! restraint. To lower the head restraint, push the adjust- ment button located at the base of the head restraint, and The head restraints for all occupants must be prop- push downward on the head restraint.
Page 104 102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! • A loose head restraint thrown forward in a colli- sion or hard stop could cause serious injury or death to occupants of the vehicle. Always securely stow removed head restraints in a location outside the occupant compartment.
Page 105 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 103 Rear Head Restraints button at the base of each post while pulling the head restraint up. To reinstall the head restraint, put the head The rear seats are equipped with adjustable head re- restraint posts into the holes and push downward.
Page 106: Opening And Closing The Hood
104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! ALL the head restraints MUST be reinstalled in the vehicle to properly protect the occupants. Follow the re-installation instructions above prior to operating the vehicle or occupying a seat. OPENING AND CLOSING THE HOOD To open the hood, two latches must be released to open the hood.
Page 107 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 105 Hood Release Lever Safety Catch Lever 2. Move to the outside of the vehicle and push the red CAUTION! safety catch lever to the left and raise the hood. The safety catch lever is located under the center front To prevent possible damage, do not slam the hood to edge of the hood.
Page 108: Lights
106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: The external lights can only be turned on with CAUTION! (Continued) the ignition in the ON/RUN position. secure both latches. Never drive your vehicle unless the hood is fully closed, with both latches engaged. WARNING! Be sure the hood is fully latched before driving your vehicle.
Page 109: Headlights
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 107 Headlights NOTE: When the headlights are turned on, the Daytime Running Lights will be deactivated. Rotate the end of the multifunction lever up- Daytime Running Lights — If Equipped ward to the first detent for headlight operation. To activate the Daytime Running Lights (DRL), rotate the end of the multifunction lever to the O symbol.
Page 110: Flash-To-Pass
108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Flash-To-Pass NOTE: If either light remains on and does not flash, or there is a very fast flash rate, check for a defective outside You can signal another vehicle with your headlights by light bulb.
Page 111: Front Fog Lights - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 109 is pulled, the activation of the lights will be extended by Interior Lights 30 seconds. The activation of the lights can be extended to The interior light switches are located in the overhead a maximum of 210 seconds.
Page 112 110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE On/Right Position Off/Left Position Push the switch to the off/left position from its center Leave the switch in the center position, and the lights are position and the lights are always off. turned on and off when the doors are opened or closed.
Page 113 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111 Center Position Map/Reading Light Switches The switches on the left and right sides of the overhead CAUTION! console controls the map or reading function of the lights. Push the switch to the right to turn on the right light and Before getting out of the vehicle be sure that the push the switch to the left to turn on the left light.
Page 114: Windshield Wipers And Washers
112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Interior Light Timing (Center Position) NOTE: The timer is deactivated when the key is moved into the ON/RUN position. There are four different modes of operation that can be activated in this position: •...
Page 115 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 113 Intermittent Speed Rotate the end of the lever upward to the first detent. The wipers will operate at intermittent speed. Low Speed Rotate the end of the lever upward to the second detent. The wipers will operate at low speed. High Speed Windshield Wiper Lever Windshield Wiper Off...
Page 116 114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Manual High Speed/Mist Push the lever upward from the off position. The wipers will operate at high speed to clear off road mist or spray from a passing vehicle. This operation will continue until the lever is released.
Page 117: Rear Window Wiper/Washer
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 115 Rear Window Wiper/Washer CAUTION! Activation • Turn the windshield wipers off when driving Rotate the windshield wiper lever center ring upwards to through an automatic car wash. Damage to the operate the rear window wiper as follows: windshield wipers may result if the wiper control is left in any position other than off.
Page 118 116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Rear Window Wiper Operation Rear Window Washer Operation Pushing the windshield wiper lever forward activates the Deactivation rear window washer. Keep the windshield wiper lever The function stops when the windshield wiper lever is pushed for more than half a second to activate the rear released.
Page 119: Tilt/Telescoping Steering Column
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 117 TILT/TELESCOPING STEERING COLUMN To unlock the steering column, pull the control handle down. To tilt the steering column, move the steering This feature allows you to tilt the steering column wheel upward or downward as desired. To lengthen or upward or downward.
Page 120: Electronic Speed Control
118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ELECTRONIC SPEED CONTROL When engaged, the Electronic Speed Control takes over accelerator operations at speeds greater than 25 mph (40 km/h). The Electronic Speed Control buttons are located on the right side of the steering wheel. Electronic Speed Control Buttons 1 —...
Page 121: To Activate
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 119 NOTE: In order to ensure proper operation, the Elec- WARNING! tronic Speed Control system has been designed to shut down if multiple Speed Control functions are operated at Leaving the Electronic Speed Control system on the same time.
Page 122: To Deactivate
120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Deactivate The drivers preferred units can be selected through the instrument panel settings if equipped. Refer to “Under- A soft tap on the brake pedal, pushing the CANC button, standing Your Instrument Panel” for more information. or normal brake pressure while slowing the vehicle will The speed increment shown is dependent on the selected deactivate Electronic Speed Control without erasing the...
Page 123: To Accelerate For Passing
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121 • If the button is continually pushed, the set speed will • If the button is continually pushed, the set speed will continue to increase until the button is released, then continue to decrease until the button is released, then the new set speed will be established.
Page 124: Rear Park Assist - If Equipped
122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: The Electronic Speed Control system maintains REAR PARK ASSIST — IF EQUIPPED speed up and down hills. A slight speed change on The Rear Park Assist system provides an audible indica- moderate hills is normal. tion of the distance between the rear fascia/bumper and a detected obstacle when backing up, e.g.
Page 125: Rear Park Assist Sensors
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 123 Rear Park Assist Sensors Rear Park Assist Audible Alerts The four Rear Park Assist sensors, located in the rear If an obstacle is behind the vehicle when the transmission fascia/bumper, monitor the area behind the vehicle that is placed into REVERSE, an audible alert is activated.
Page 126 124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Audible And Visual Signals Supplied By The Rear Park Assist System SIGNAL MEANING INDICATION Obstacle Distance An obstacle is Audible signal (dashboard loudspeaker) • Sound pulses emitted at a rate that increases as the distance present within the sensors’...
Page 127: Failure Indications
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 125 While audible signals are emitted, the audio system is not Refer to Electronic Vehicle Information Center (EVIC) in muted. “Understanding Your Instrument Panel” for further information. The audible signal is turned off immediately if the distance increases.
Page 128: Park Assist System Usage Precautions
126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE jet/high pressure washing nozzles at least 4 in (10 cm) from not detect an obstacle behind the fascia/bumper, or it the sensors. Do not scratch or poke the sensors. Otherwise, could provide a false indication that an obstacle is you could damage the sensors.
Page 129 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 127 CAUTION! (Continued) WARNING! (Continued) • The vehicle must be driven slowly when using • Before using ParkSense®, it is strongly recom- Rear Park Assist in order to be able to stop in time mended that the ball mount and hitch ball assem- when an obstacle is detected.
Page 130: Parkview® Rear Back Up Camera - If Equipped
128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE PARKVIEW® REAR BACK UP CAMERA — IF out of REVERSE unless the forward vehicle speed ex- EQUIPPED ceeds 8 mph (13 km/h), the transmission is shifted into PARK or the vehicle’s ignition is cycled to the OFF Your vehicle may be equipped with the ParkView®...
Page 131 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 129 The following table shows the approximate distances for each zone: Zone Distance to the rear of the vehicle 0 - 1 ft (0 - 30 cm) Yellow 1 ft - 3 ft (30 cm - 1 m) Green 3 ft or greater (1 m or greater) WARNING!
Page 132: Garage Door Opener - If Equipped
130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: If snow, ice, mud, or any foreign substance builds up on the camera lens, clean the lens, rinse with water, and dry with a soft cloth. Do not cover the lens. GARAGE DOOR OPENER — IF EQUIPPED HomeLink®...
Page 133: Programming A Rolling Code
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131 For more efficient programming and accurate transmis- Programming A Rolling Code sion of the radio-frequency signal it is recommended that For programming garage door openers that were manu- a new battery be placed in the hand-held transmitter of factured after 1995.
Page 134 132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 3. Push and hold the HomeLink® button you want to program while you push and hold the hand-held transmitter button. 4. Continue to hold both buttons and observe the indi- cator light. The HomeLink® indicator will flash slowly and then rapidly after HomeLink®...
Page 135: Programming A Non-Rolling Code
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 133 NOTE: You have 30 seconds in which to initiate the next 2. Push and hold the desired HomeLink® button until step after the LEARN button has been pushed. the indicator light begins to flash after 20 seconds. Do not release the button.
Page 136: Canadian/Gate Operator Programming
134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 3. Push and hold the Homelink® button you want to Reprogramming A Single HomeLink® Button program while you push and hold the hand-held (Non-Rolling Code) transmitter button. To reprogram a channel that has been previously trained, follow these steps: 4.
Page 137 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 135 Canadian radio frequency laws require transmitter sig- successfully accepted the frequency signal. The indi- nals to time-out (or quit) after several seconds of trans- cator light will flash slowly and then rapidly when mission –...
Page 138: Using Homelink
136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Reprogramming A Single HomeLink® Button hand-held transmitter of the device may also be used at (Canadian/Gate Operator) any time. If the ignition is switched to the OFF position, HomeLink® will remain active for three minutes. During To reprogram a channel that has been previously trained, this time, if the vehicle is locked, HomeLink®...
Page 139: Troubleshooting Tips
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 137 Troubleshooting Tips WARNING! If you are having trouble programming HomeLink®, • Vehicle exhaust contains carbon monoxide, a dan- here are some of the most common solutions: gerous gas. Do not run your vehicle in the garage •...
Page 140: General Information
138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • The term IC before the certification/registration num- General Information ber only signifies that Industry Canada technical speci- This device complies with FCC rules Part 15 and Industry fications were met. Canada RSS-210. Operation is subject to the following two conditions: POWER SUNROOF —...
Page 141 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 139 WARNING! • Never leave children alone in a vehicle, or with access to an unlocked vehicle. Never leave the Key Fob in or near the vehicle or in a location accessible to children. Occupants, particularly unattended children, can become entrapped by the power sun- roof while operating the power sunroof switch.
Page 142: To Open
140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Open Wind Buffeting • Pull the power sunroof switch for approximately one Wind buffeting can be described as the perception of pressure on the ears or a helicopter-type sound in the second and the sunroof will stop at the vented posi- ears.
Page 143: Power Outlets
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 141 NOTE: During the automatic opening and closing stages, if the power sun blind switch is pulled again it will stop the blind movement. POWER OUTLETS Passenger Compartment Power Socket The power outlet is located on the central tunnel, in front of the shift lever, between the two cup holders.
Page 144: Cigar Lighter - If Equipped
142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CIGAR LIGHTER — IF EQUIPPED This is located on the central tunnel, next to the parking brake lever. To activate the cigar lighter, push and release the knob. After a few seconds the knob automatically returns to its initial position, and the cigar lighter is ready for use.
Page 145: Cupholders
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 143 CUPHOLDERS WARNING! For the driver and front passenger, cupholders are lo- When the cigar lighter is in use it becomes very hot. To cated on the floor console between the front seats. avoid serious injury, handle the cigar lighter with care. Always check that the cigar lighter has turned off.
Page 146: Storage
144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE For the rear seat passengers their is one cupholder STORAGE located in the center armrest. Glove Compartment Your vehicle is equipped with a upper and lower glove compartment which is located on the right side of the instrument panel.
Page 147 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 145 Upper And Lower Glove Compartments Glove Compartment Storage...
Page 148: Front Center Armrest Storage - If Equipped
146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Front Center Armrest Storage — If Equipped The front center armrest can also be lifted up and adjusted in three positions, this is done by pulling up on The front center armrest contains a storage compartment. the armrest, push the latch down to adjust the armrest To open the storage compartment push in the upper down.
Page 149: Rear Cargo Storage Features
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 147 REAR CARGO STORAGE FEATURES is advisable to use this position only for the actual period in which the objects are transported, then The car features a load platform which can be adjusted to return the platform to position 1 or 2.
Page 150 148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! (Continued) positioned at raised level) do not add objects with a higher weight. Access to double load compartment To access the double load compartment, proceed as follows: 1. Grip handle and raise platform, holding it with one hand.
Page 151 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 149 Load Platform Load Compartment 3. Then reposition the platform correctly in the housings 1 — Handle on the side panels and rear crossmember. 2 — Platform 2. Place the desired objects in compartment.
Page 152 150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Moving the load platform To move the load platform from lower to upper position, proceed as follows: 1. Grip handle and raise the platform, holding it with one hand. Platform Housings 1 — Front Locations 2 —...
Page 153: Securing Your Load
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 151 Load Platform Raised Position 1 — Handle 1 — Front Housing Locations 2 — Platform 2 — Rear Housing Locations 2. Position the platform correctly on housing on the side Securing Your Load panels.
Page 154 152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE A further two tie downs located on the rear crossmember. Cargo Side Panel Hook Locations Cargo Tie Down Locations 1 — Release Button Two hooks are also available on the side panels to fix 2 —...
Page 155: Storage Compartments
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 153 CAUTION! The maximum load admitted per each bag hook is 22 lbs (10 kg). Storage Compartments There are two storage compartments located on the rear side panels. Storage Compartment REAR WINDOW FEATURES Rear Window Defroster The rear window defroster button is located with the climate controls on the instrument panel.
Page 156: Roof Luggage Rack-If Equipped
154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE indicator in the button will illuminate when the rear CAUTION! (Continued) window defroster is on. The rear window defroster • Do not use scrapers, sharp instruments, or abrasive automatically turns off after approximately 20 minutes. window cleaners on the interior surface of the To manually shut the defroster off, push the button a window.
Page 157 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 155 WARNING! Cargo must be securely tied before driving your vehicle. Improperly secured loads can fly off the vehicle, particularly at high speeds, resulting in per- sonal injury or property damage. Follow the roof rack cautions when carrying cargo on your roof rack.
Page 159: Understanding Your Instrument Panel
UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS ▫ Trip Computer ..... . .175 INSTRUMENT PANEL FEATURES ..159 ▫...
Page 160 158 UNDERSTANDING YOUR INSTRUMENT PANEL ▫ Player Operation ..... .183 ▫ Get Started ......205 ▫...
Page 161: Instrument Panel Features
UNDERSTANDING YOUR INSTRUMENT PANEL 159 INSTRUMENT PANEL FEATURES 1 — Side Vent 7 — Fixed Upper Air Vent 13 — Climate Controls 2 — Steering Wheel Audio Control — Lo- 8 — Passenger Advanced Front Air Bag 14 — USB Port/SD Card/AUX Socket cated On Back Side Of Steering Wheel 3 —...
Page 162: Instrument Cluster
160 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER...
Page 163: Instrument Cluster Descriptions
UNDERSTANDING YOUR INSTRUMENT PANEL 161 INSTRUMENT CLUSTER DESCRIPTIONS 4. Electronic Stability Control (ESC) Activation / Mal- function Indicator Light 1. Speedometer The ESC Activation/Malfunction Indicator The Speedometer shows the vehicle speed in miles per Light in the instrument cluster will come on for hour (mph) and/or kilometers per hour (km/h).
Page 164 162 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: WARNING! • The ESC Off Indicator Light and the ESC Activation/ Driving a vehicle with the red brake light on is Malfunction Indicator Light come on momentarily dangerous. You could have a collision. Have the each time the ignition switch is turned to ON/RUN.
Page 165 UNDERSTANDING YOUR INSTRUMENT PANEL 163 The light also will turn on when the parking brake is NOTE: The fuel gauge and range will not immediately applied with the ignition switch in the ON/RUN position. update accurately when refueling with the engine on. 9.
Page 166 164 UNDERSTANDING YOUR INSTRUMENT PANEL CAUTION! WARNING! (Continued) Vehicle.” Follow the warnings under the “Cooling Driving with a hot engine cooling system could System Pressure Cap” paragraph. damage your vehicle. If all the segments of the temperature gauge are lit, pull over and stop the 11.
Page 167 UNDERSTANDING YOUR INSTRUMENT PANEL 165 12. High Beam Indicator 14. Tachometer This light indicates that the headlights are on high The white area of the scale shows the permissible engine beam. Pull the turn signal lever toward the steer- revolutions-per-minute (RPM x 1000) for each gear range. ing wheel to switch the headlights to low beam.
Page 168 166 UNDERSTANDING YOUR INSTRUMENT PANEL 16. Air Bag Warning Light 18. Oil Pressure Warning Light This light will turn on for four seconds as a This light indicates low engine oil pressure. The bulb check when the ignition switch is first light should turn on momentarily when the engine is turned to ON/RUN.
Page 169 UNDERSTANDING YOUR INSTRUMENT PANEL 167 Certain conditions, such as poor fuel quality, etc., may WARNING! illuminate the MIL after engine start. The vehicle should be serviced if the light stays on through several of your A malfunctioning catalytic converter, as referenced typical driving cycles.
Page 170 168 UNDERSTANDING YOUR INSTRUMENT PANEL As an added safety feature, your vehicle has been combined with the low tire pressure telltale. When the equipped with a Tire Pressure Monitoring System system detects a malfunction, the telltale will flash for (TPMS) that illuminates a low tire pressure telltale when approximately one minute and then remain continuously one or more of your tires is significantly under-inflated.
Page 171 UNDERSTANDING YOUR INSTRUMENT PANEL 169 and the oil temperature sensor reading indicates an CAUTION! engine block heater has not been used. The Glow Plug light will flash during in cold weather for up to 10 The TPMS has been optimized for the original seconds.
Page 172 170 UNDERSTANDING YOUR INSTRUMENT PANEL as it was before the repair or service. If s/he cannot do so, 24. Electronic Throttle Control (ETC) Light then the odometer must be set at zero, and a sticker must This light informs you of a problem with the be placed in the door jamb stating what the mileage was Electronic Throttle Control (ETC) system.
Page 173: Electronic Vehicle Information Center (Evic)
UNDERSTANDING YOUR INSTRUMENT PANEL 171 25. Anti-Lock Brake (ABS) Light ELECTRONIC VEHICLE INFORMATION CENTER (EVIC) This light monitors the Anti-Lock Brake System The Electronic Vehicle Information Center (EVIC) fea- (ABS). The light will turn on when the ignition tures a driver-interactive display that is located in the switch is turned to the ON/RUN position and instrument cluster.
Page 174: Evic Control Buttons
172 UNDERSTANDING YOUR INSTRUMENT PANEL • Outside temperature Push and release the UP button to scroll upward through the displayed menu and the related options • Gear Indicator or to increase the displayed value. • Odometer (display of distance travelled in miles/ Push and release the DOWN button to scroll down- kilometers)
Page 175: Electronic Vehicle Information Center (Evic) Setup Menu
UNDERSTANDING YOUR INSTRUMENT PANEL 173 Electronic Vehicle Information Center (EVIC) Push and release the UP or DOWN button (by Setup Menu single pushes) to select the new setting. The menu comprises a series of functions arranged in a Briefly push and release the MENU button to store the cycle.
Page 176: Change Engine Oil Indicator System
174 UNDERSTANDING YOUR INSTRUMENT PANEL Push and release the UP or DOWN button (by indicator system is duty cycle based, which means the single pushes) to select the new setting for this sub- engine oil change interval may fluctuate, dependent menu option.
Page 177: Trip Computer
UNDERSTANDING YOUR INSTRUMENT PANEL 175 Trip Computer The Trip Computer is located in the instrument cluster. It features a driver-interactive display (displays informa- tion such as; trip information, range, fuel consumption, average speed and travel time). Trip Button The TRIP button, located on the right steering column stalk, can be used to display and to reset the previously described values.
Page 178: Trip Functions
176 UNDERSTANDING YOUR INSTRUMENT PANEL New Trip Start Of Trip Procedure To reset: With the ignition on, push and hold the TRIP button for over one second to reset. • Push and hold the TRIP button to reset the system manually.
Page 179: Values Displayed
UNDERSTANDING YOUR INSTRUMENT PANEL 177 • Trip distance A Values Displayed • Average Economy A Range • Instant Economy This indicates the distance which may be traveled with the fuel remaining in the tank, assuming that driving • Average speed A conditions will not change.
Page 180: Personal Settings (Customer-Programmable Features)
Belt Buzzer (Buzzer Activation For BeltAlert® Indication) Instant Economy This function will only be displayed after a FIAT Group This indicates the fuel consumption. The value is con- Automobiles Dealership has deactivated the BeltAlert® stantly updated. The message “----” will appear on the system.
Page 181 UNDERSTANDING YOUR INSTRUMENT PANEL 179 Buzzer Volume (Adjusting The Failure/Warning Speed Buzzer (Speed Limit) Buzzer Volume) With this function it is possible to set the car speed limit With this function the volume of the buzzer accompany- (mph or km/h); when this limit is exceeded the driver is ing any failure/warning indication can be adjusted to immediately alerted.
Page 182 180 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: Selection is possible between 20 – 125 mph or 3. Briefly push and release the MENU button to go back (32 – 201 km/h), depending on the selected unit. The to the menu screen, or push and hold the MENU setting will increase/decrease by five units each time button (approximately one second) to go back to the the UP/DOWN button is pushed.
Page 183: Uconnect® Radios
UNDERSTANDING YOUR INSTRUMENT PANEL 181 Hill Start Assist Exit Menu This function is used when starting a vehicle from a stop This function closes the initial menu screen. on a hill. Hill Start Assist maintains the same level of Briefly push and release the MENU button to go back to brake pressure the driver applied for a short period of the main screen.
Page 184: Steering Wheel Audio Controls
182 UNDERSTANDING YOUR INSTRUMENT PANEL STEERING WHEEL AUDIO CONTROLS The remote sound system controls are located at the rear of the steering wheel. Reach behind the wheel to access the switches. USB/AUX Ports 1 — USB Connector 2 — AUX/Cable Jack Refer to the Uconnect®...
Page 185: Radio Operation
UNDERSTANDING YOUR INSTRUMENT PANEL 183 The right-hand control is a rocker-type switch with a Radio Operation pushbutton in the center and controls the volume and Pushing the top of the switch will “Seek” up for the next mode of the sound system. Pushing the top of the rocker listenable station and pushing the bottom of the switch switch will increase the volume, and pushing the bottom will “Seek”...
Page 186: Cd/Dvd Disc Maintenance
184 UNDERSTANDING YOUR INSTRUMENT PANEL CD/DVD DISC MAINTENANCE NOTE: If you experience difficulty in playing a particular disc, it may be damaged (i.e., scratched, reflective coating To keep a CD/DVD in good condition, take the following removed, a hair, moisture or dew on the disc) oversized, precautions: or have protection encoding.
Page 187: Climate Controls
UNDERSTANDING YOUR INSTRUMENT PANEL 185 CLIMATE CONTROLS 1. Temperature Control Manual Climate Control System Rotate this control to regulate the temperature of the air inside the passenger compartment. Rotating the dial to Controls the left into the blue area of the scale indicates cooler temperatures, while rotating to the right into the red area indicates warmer temperatures.
Page 188 186 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: 4. A/C Button • Continuous use of the Recirculation mode may make Push this button to engage the Air Conditioning. A light will illuminate when the Air Conditioning system is the inside air stuffy and window fogging may occur. engaged.
Page 189 UNDERSTANDING YOUR INSTRUMENT PANEL 187 • Mix 6. Mode Control Air is directed through the floor, defrost, and Rotate this control to change the system between Modes side window demister outlets. This setting (Panel, Bi-Level, Floor, Mix, Defrost). works best in cold or snowy conditions that •...
Page 190 188 UNDERSTANDING YOUR INSTRUMENT PANEL Rear Window Defrosting Air Recirculation Push and release the rear window defrost button to turn Push and release the Air Recirculation button, so that the the function on/off. LED on the button switch is on, to enter recirculation mode.
Page 191 UNDERSTANDING YOUR INSTRUMENT PANEL 189 Air Distribution Selection Air flow to central/side dashboard vents (passen- Rotate the Mode Control knob to manually select one of ger’s body). the five possible air distribution settings in the passenger compartment: Air flow to windshield and side windows. Air flow to the front windshield, front side win- Selecting the footwell/windshield or only windshield dow and front/rear footwell diffusers.
Page 192 • outside temperature low; least once a month for about 10 minutes. • engine coolant temperature low; Have the system inspected at a Fiat dealership before the summer. • engine on; NOTE: The system uses R-1234yf coolant which does not •...
Page 193: Automatic Dual Zone Climate Control System (If Equipped)
UNDERSTANDING YOUR INSTRUMENT PANEL 191 Automatic Dual Zone Climate Control System (If 1. Driver Temperature Control Equipped) Provides the driver with independent temperature con- Controls trol. Rotate adjustment knob to set desired temperature. NOTE: In Sync mode, this button will also automatically adjust the passenger temperature setting at the same time.
Page 194 192 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: 4. A/C Control • When in Defrost mode, the Recirculation button will Push and release the A/C Control Button to change the flash if pushed. This indicates that you can not current setting. The indicator illuminates when A/C is proceed to this mode due to fogging risk.
Page 195 UNDERSTANDING YOUR INSTRUMENT PANEL 193 7. Blower Control Indicator LEDs 10. Passenger Temperature Control LEDs illuminate to visually indicate blower speed. Provides the passenger with independent temperature control. Rotate adjustment knob to set desired tempera- 8. Mode Control ture. The airflow distribution mode can be adjusted so air NOTE: Rotating the Passenger Temperature Control comes from the instrument panel outlets, floor outlets, knob while in Sync mode will automatically exit Sync.
Page 196 194 UNDERSTANDING YOUR INSTRUMENT PANEL 12. AUTO Button NOTE: The reference temperature is 72° F (22° C) for optimal comfort management. Automatically controls the interior cabin temperature by adjusting airflow distribution and amount. Performing The automatically controlled parameters and functions this function will cause the ATC to switch between are: manual mode and automatic modes.
Page 197 UNDERSTANDING YOUR INSTRUMENT PANEL 195 • rapid defrosting/demisting function Manual selections always take priority over automatic ones and are stored until the AUTO button is pushed or • air recirculation the system itself intervenes for specific safety reasons. • heated rear window The amount of air introduced into the passenger com- •...
Page 198 196 UNDERSTANDING YOUR INSTRUMENT PANEL In this way the system operates completely automatically MANUAL mode (the set temperatures will flash on the to adjust the temperature, quantity and distribution of display). The fan speed is the same in all the zones of the the air introduced into the passenger compartment.
Page 199 UNDERSTANDING YOUR INSTRUMENT PANEL 197 • Right Arrow – Air flow at central and side dashboard Turning the control knobs completely in one direction or the other activates the HI (maximum heating) or LO vents to ventilate the chest and the face during the hot (maximum cooling) functions respectively.
Page 200 198 UNDERSTANDING YOUR INSTRUMENT PANEL • Up/Right Arrows – Air flow distribution between pushed. If a button whose function is already active is windshield defrosting diffusers and side and central pushed, the operation is cancelled and the corresponding dashboard vents. This allows air to be sent to the LED switches off.
Page 201 UNDERSTANDING YOUR INSTRUMENT PANEL 199 If the AUTO button is pushed when the AUTO LED is on, SYNC Button the system switches to completely manual mode; it Push the SYNC button (LED on button lit) to align the displays the current flow and distribution status, which passenger side air temperature with that of the driver will no longer be managed automatically.
Page 202 200 UNDERSTANDING YOUR INSTRUMENT PANEL • forced deactivation (air recirculation always off, air NOTE: intake from the outside), signalled by the LED on the • The engagement of the recirculation system makes it Recirculation Control button switching off possible to reach the required heating/cooling condi- Forced activation/deactivation can be selected by push- tions faster.
Page 203 UNDERSTANDING YOUR INSTRUMENT PANEL 201 The system remembers that the compressor has been The climate control system carries out the following switched off, even after the engine has stopped. operations: • switches on the air conditioning compressor when When the compressor is switched off, the system deacti- vates air recirculation to prevent the windows from environmental conditions are suitable;...
Page 204 202 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: The Front Defrost Control (MAX-DEF) function This logic guarantees optimum visibility at the windows. remains on for about three minutes from when the engine It is, however, always possible to manage air recirculation coolant reaches the appropriate temperature. and the climate control system compressor manually.
Page 205 UNDERSTANDING YOUR INSTRUMENT PANEL 203 NOTE: Do not affix stickers to the inside of the heated NOTE: The climate control system control unit stores the rear window over the heating filaments, to avoid damage temperatures set before the system was switched off and that might cause them to stop working properly.
Page 206: Uconnect® Voice Recognition Quick Tips
204 UNDERSTANDING YOUR INSTRUMENT PANEL Uconnect® VOICE RECOGNITION QUICK TIPS Introducing Uconnect® Start using Uconnect® Voice Recognition with these helpful quick tips. It provides the key Voice Commands and tips you need to know to control your Uconnect® 5.0 or 6.5A/6.5AN system. Uconnect®...
Page 207: Get Started
UNDERSTANDING YOUR INSTRUMENT PANEL 205 Get Started All you need to control your Uconnect® system with your voice are the buttons on your steering wheel. 1. Visit UconnectPhone.com to check mobile device and feature compatibility and to find phone pairing instructions.
Page 208 206 UNDERSTANDING YOUR INSTRUMENT PANEL 5. You can interrupt the help message or system prompts by pushing the VR or Phone button and saying a Voice Command from current category. Uconnect® Voice Command 1 — Push To Initiate Or To Answer A Phone Call, Send Or Re- ceive A Text 2 —...
Page 209: Basic Voice Commands
UNDERSTANDING YOUR INSTRUMENT PANEL 207 Basic Voice Commands The basic Voice Commands below can be given at any point while using your Uconnect® system. Push the VR button . After the beep, say • Cancel to stop a current voice session. •...
Page 210: Radio
208 UNDERSTANDING YOUR INSTRUMENT PANEL Push the VR button . After the beep, say • Tune to ninety-five-point-five FM. • Tune to Satellite Channel Hits 1. TIP: At any time, if you are not sure of what to say or want to learn a Voice Command, press the VR button and say “Help.”...
Page 211: Media
UNDERSTANDING YOUR INSTRUMENT PANEL 209 Uconnect® 5.0 Radio Uconnect® 6.5A/6.5AN Radio Media Uconnect® offers connections via USB Port, Bluetooth® and Auxiliary Ports (If Equipped). Voice operation is only available for connected USB and iPod® devices. (Remote CD player optional and not available on all vehicles.)
Page 212 210 UNDERSTANDING YOUR INSTRUMENT PANEL Push the VR button . After the beep, say one of the following commands and follow the prompts to switch your media source or choose an artist. • Change source to Bluetooth®. • Change source to iPod®. •...
Page 213: Phone
UNDERSTANDING YOUR INSTRUMENT PANEL 211 Push the Phone button . After the beep, say one of the following commands • Call John Smith. • Dial 123-456-7890 and follow the system prompts. • Redial (call previous outgoing phone number). • Call back (call previous incoming phone number). TIP: When providing a Voice Command, push the Phone button and say “Call,”...
Page 214: Navigation (6.5A/6.5An)
212 UNDERSTANDING YOUR INSTRUMENT PANEL Uconnect® 5.0 Phone Uconnect® 6.5A/6.5AN Phone Navigation (6.5A/6.5AN) The Uconnect® navigation feature helps you save time and become more productive when you know exactly how to get to where you want to go.
Page 215 UNDERSTANDING YOUR INSTRUMENT PANEL 213 1. To enter a destination, push the VR button . After the beep, say: • For the 6.5AN Uconnect® System, say: “Navigate to 800 Chrysler Drive Auburn Hills, Michigan.” 2. Then follow the system prompts. TIP: To start a POI search, push the VR button .
Page 216: Voice Text Reply
214 UNDERSTANDING YOUR INSTRUMENT PANEL Voice Text Reply PRE-DEFINED VOICE TEXT REPLY RESPONSES Uconnect® will announce incoming text messages. Push Yes. Stuck in Traffic. See you later. the Phone button and say “Listen.” (Must have com- Start without I’ll be Late. patible mobile phone paired to Uconnect®...
Page 217: Additional Information
UNDERSTANDING YOUR INSTRUMENT PANEL 215 Additional Information © 2015 FCA US LLC. All rights reserved. Mopar and Uconnect are registered trademarks and Mopar Owner Connect is a trademark of FCA US LLC. Android is a trademark of Google Inc. SiriusXM and all related marks and logos are trademarks of SiriusXM Radio Inc.
Page 219 STARTING AND OPERATING CONTENTS ▫ Downshifting ......225 STARTING PROCEDURES ....221 ▫...
Page 220 218 STARTING AND OPERATING ▫ Hill Start Assist (HSA) ....255 DRIVING ON SLIPPERY SURFACES ..246 ▫ Acceleration ......246 ▫...
Page 221 STARTING AND OPERATING 219 ▫ Tire Inflation Pressures ....273 TIRE PRESSURE MONITORING SYSTEM (TPMS) ......286 ▫...
Page 222 220 STARTING AND OPERATING ▫ Towing This Vehicle Behind Another RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) ....299 Vehicle ......299...
Page 223: Starting Procedures
STARTING AND OPERATING 221 STARTING PROCEDURES Manual Transmission — If Equipped Before starting your vehicle, adjust your seat, adjust both Apply the parking brake, place the shift lever in NEU- inside and outside mirrors, and fasten your seat belts. TRAL, and press the clutch pedal before starting the vehicle.
Page 224: Cold Weather Operation
222 STARTING AND OPERATING Turn the ignition switch to the AVV/ACC (START) NOTE: Use of the recommended SAE 5W-40 Synthetic oil position and release it when the engine starts. If the and adhering to the prescribed oil change intervals is engine fails to start within 10 seconds, turn the ignition important to prevent engine damage and ensure satisfac- switch to the STOP (OFF/LOCK) position, wait 10 to 15...
Page 225: If Engine Fails To Start
STARTING AND OPERATING 223 4. If the engine fails to start after eight attempts, allow CAUTION! the starter to cool for at least 10 minutes, then repeat • Do not attempt to push or tow your vehicle to get it the procedure.
Page 226: Manual Transmission - If Equipped
224 STARTING AND OPERATING on the type of driving and the amount of cargo, the pump will run for up to 10 minutes after the engine has been shut off to circulate coolant through the turbocharger. Although the pump is rubber-mounted for quiet opera- tion, it is normal to hear it running during this time.
Page 227: Downshifting
STARTING AND OPERATING 225 For most city driving you will find it easier to use only Downshifting the lower gears. For steady highway driving with light Proper downshifting will improve fuel economy and accelerations, sixth gear is recommended. prolong engine life. Never drive with your foot resting on the clutch pedal, or CAUTION! try to hold the vehicle on a hill with the clutch pedal...
Page 228: Automatic Transmission - If
226 STARTING AND OPERATING When turning a corner, or driving up a steep grade, NOTE: You must press and hold the brake pedal while downshift early so that the engine will not be overbur- shifting out of PARK. dened. WARNING! AUTOMATIC TRANSMISSION —...
Page 229: Key Ignition Park Interlock
STARTING AND OPERATING 227 Key Ignition Park Interlock WARNING! (Continued) This vehicle is equipped with a Key Ignition Park Inter- turn the engine OFF, and remove the ignition key. lock which requires the transmission to be in PARK Once the key is removed, the transmission is before the ignition switch can be turned to the LOCK/ locked in PARK, securing the vehicle against un- OFF (key removal) position.
Page 230: Six-Speed Euro Twin Clutch Transmission - If Equipped
228 STARTING AND OPERATING Six-Speed Euro Twin Clutch Transmission — If Equipped The transmission gear position display (located in the instrument cluster) indicates the transmission gear range. You must press the brake pedal and the lock button on the shift lever to move the shift lever out of PARK (refer to “Brake/Transmission Shift Interlock System”...
Page 231 STARTING AND OPERATING 229 accelerator pedal is released and the vehicle is stopped. NOTE: If the shift lever cannot be moved to the PARK, Be sure to keep your foot on the brake pedal when REVERSE, or NEUTRAL position (when pushed for- shifting between these gears.
Page 232 230 STARTING AND OPERATING Never attempt to use PARK while the vehicle is in WARNING! (Continued) motion. Apply the parking brake when leaving the fully when parked to guard against vehicle move- vehicle in this range. ment and possible injury or damage. When parking on a level surface, you may shift the •...
Page 233 STARTING AND OPERATING 231 WARNING! (Continued) WARNING! (Continued) • Unintended movement of a vehicle could injure warned not to touch the parking brake, brake pedal those in or near the vehicle. As with all vehicles, or the shift lever. • Do not leave the ignition key in or near the vehicle you should never exit a vehicle while the engine is running.
Page 234 232 STARTING AND OPERATING The following indicators should be used to ensure that NEUTRAL (N) you have engaged the transmission into the PARK posi- Use this range when the vehicle is standing for prolonged tion: periods with the engine running. The engine may be •...
Page 235 STARTING AND OPERATING 233 • During low-speed driving conditions in first gear, CAUTION! (Continued) vehicle momentum changes may feel exaggerated in severe transmission damage. Refer to “Recreational response to changes in accelerator pedal position. This Towing” in “Starting And Operating” and “Towing A behavior is normal and is similar to vehicles equipped Disabled Vehicle”...
Page 236 234 STARTING AND OPERATING • During extremely cold temperatures, the transmission pedal is not applied after a short time, the car will roll back. Either reapply the brake (to hold the vehicle) or will not operate if the oil temperature is -22° F (-30° C) press the accelerator to climb the hill.
Page 237 STARTING AND OPERATING 235 MESSAGE DESCRIPTION GEAR UNAVAILABLE In AutoStick mode, the gear selected by the driver is not available due to a fault condition. See your authorized dealer for diagnosis and service. SHIFT NOT ALLOWED The gear position requested by the driver is currently blocked. This occurs if RE- VERSE is requested while moving (at 6 mph [10 km/h] or faster), or if DRIVE is requested while moving backwards (at 6 mph [10 km/h] or faster).
Page 238 236 STARTING AND OPERATING MESSAGE DESCRIPTION TRANSMISSION The transmission driving clutch is overheating, usually due to repeated launches in GETTING HOT PRESS stop-and-go traffic. Pull over and allow the transmission to cool in NEUTRAL until BRAKE “TRANS. COOL READY TO DRIVE” is displayed. TRANS.
Page 239 STARTING AND OPERATING 237 Transmission Limp Home Mode 3. Turn the ignition switch to the OFF position. Transmission function is monitored electronically for 4. Wait approximately 10 seconds. abnormal conditions. If a condition is detected that could 5. Restart the engine. result in transmission damage, Transmission Limp Home Mode is activated.
Page 240: Six-Speed Automatic Transmission (Aisin F21-250 Hd) - If Equipped
238 STARTING AND OPERATING Six-Speed Automatic Transmission (Aisin F21-250 HD) — If Equipped The transmission gear position display (located in the instrument cluster) indicates the transmission gear range. You must press the brake pedal and the lock button on the shift lever to move the shift lever out of PARK (Refer to “Brake/Transmission Shift Interlock System”...
Page 241 STARTING AND OPERATING 239 shifts can be made using the AutoStick shift control (refer Gear Ranges to “AutoStick” in this section for further information). DO NOT race the engine when shifting from PARK or Moving the shift lever into the AutoStick (+/-) position NEUTRAL into another gear range.
Page 242 240 STARTING AND OPERATING When parking on a hill, apply the parking brake before WARNING! (Continued) shifting the transmission to PARK, otherwise the load on • It is dangerous to shift out of PARK or NEUTRAL the transmission locking mechanism may make it difficult if the engine speed is higher than idle speed.
Page 243 STARTING AND OPERATING 241 WARNING! (Continued) CAUTION! locked in PARK, securing the vehicle against un- • Before moving the shift lever out of PARK, you wanted movement. must turn the ignition switch from the LOCK/OFF • When leaving the vehicle, always remove the igni- position to the ON/RUN position, and also press tion key from the vehicle and lock the vehicle.
Page 244 242 STARTING AND OPERATING • Look at the transmission gear position display and WARNING! verify that it indicates the PARK position. Do not coast in NEUTRAL and never turn off the • With brake pedal released, verify that the shift lever ignition to coast down a hill.
Page 245 STARTING AND OPERATING 243 DRIVE (D) range of torque converter clutch engagement. This is done to prevent transmission damage due to overheat- This range should be used for most city and highway ing. driving. It provides the smoothest upshifts and down- shifts, and the best fuel economy.
Page 246: Autostick
244 STARTING AND OPERATING In the event of a momentary problem, the transmission If the transmission cannot be reset, authorized dealer can be reset to regain all forward gears by performing the service is required. following steps: AUTOSTICK 1. Stop the vehicle. AutoStick is a driver-interactive transmission feature 2.
Page 247 STARTING AND OPERATING 245 forward (-) triggers a downshift, and rearward (+) an or third gear. Starting out in second or third gear can upshift. The current gear is displayed in the instrument be helpful in snow or icy conditions. To select second cluster.
Page 248: Driving On Slippery Surfaces
246 STARTING AND OPERATING position at any time without taking your foot off the WARNING! accelerator pedal. Rapid acceleration on slippery surfaces is dangerous. WARNING! Unequal traction can cause sudden pulling of the front wheels. You could lose control of the vehicle Do not downshift for additional engine braking on a and possibly have a collision.
Page 249: Driving Through Water
STARTING AND OPERATING 247 2. Slow down if the road has standing water or puddles. Flowing/Rising Water 3. Replace the tires when tread wear indicators first WARNING! become visible. Do not drive on or across a road or path where water 4.
Page 250 248 STARTING AND OPERATING WARNING! CAUTION! (Continued) standing water that is deeper than the bottom of • Driving through standing water limits your vehi- the tire rims mounted on the vehicle. cle’s traction capabilities. Do not exceed 5 mph • Determine the condition of the road or the path (8 km/h) when driving through standing water.
Page 251: Electric Power Steering
STARTING AND OPERATING 249 PARKING BRAKE CAUTION! (Continued) Before leaving the vehicle, make sure that the parking damage is not covered by the New Vehicle Limited brake is fully applied. Also, be certain to leave manual Warranty. transmission in REVERSE or first gear. •...
Page 252 250 STARTING AND OPERATING When parking on a hill, it is important to turn the front wheels toward the curb on a downhill grade and away from the curb on an uphill grade. The parking brake should always be applied whenever the driver is not in the vehicle.
Page 253: Brake System
STARTING AND OPERATING 251 WARNING! (Continued) CAUTION! • Do not leave the Key Fob in or near the vehicle or If the Brake Warning Light remains on with the in a location accessible to children. A child could parking brake released, a brake system malfunction operate power windows, other controls, or move is indicated.
Page 254: Electronic Brake Control System
252 STARTING AND OPERATING brakes will still function. However, the effort required to modulate hydraulic pressure, to prevent wheel lock-up brake the vehicle will be much greater than that required and to help avoid skidding on slippery surfaces. with the power system operating. The system’s pump motor runs during an ABS stop to provide regulated hydraulic pressure.
Page 255: Brake Assist System (Bas)
STARTING AND OPERATING 253 the vehicle comes to a stop. This is the result of the WARNING! (Continued) system reverting to the base brake system. firmly on your brake pedal when you need to slow Engagement of the ABS may be accompanied by a down or stop.
Page 256: Traction Control System (Tcs)
254 STARTING AND OPERATING unless braking is no longer desired. Once the brake pedal Traction Control System (TCS) is released, the BAS is deactivated. The Traction Control System (TCS) monitors the amount of wheel spin of each of the driven wheels. If wheel spin WARNING! is detected, brake pressure is applied to the slipping wheel(s) and engine power is reduced to provide en-...
Page 257: Hill Start Assist (Hsa)
STARTING AND OPERATING 255 • Gear selection matches vehicle uphill direction (i.e., Hill Start Assist (HSA) vehicle in NEUTRAL (manual transmission), vehicle The HSA system is designed to assist the driver when facing uphill is in forward gear; vehicle backing uphill starting a vehicle from a stop on a hill.
Page 258: Dynamic Steering Torque (Dst)
256 STARTING AND OPERATING “Electronic Vehicle Information Center (EVIC)” in “Under- Electronic Stability Control (ESC) standing Your Instrument Panel” for further information. This system enhances directional control and stability of the vehicle under various driving conditions. ESC cor- Dynamic Steering Torque (DST) rects for oversteering or understeering of the vehicle by The DST function uses the integration of the ESC system applying the brake of the appropriate wheel to assist in...
Page 259: Esc Activation/Malfunction Indicator Light And Esc Off Indicator Light
STARTING AND OPERATING 257 ESC Activation/Malfunction Indicator Light And WARNING! ESC OFF Indicator Light The Electronic Stability Control (ESC) cannot pre- vent the natural laws of physics from acting on the The ESC Activation/Malfunction Indicator vehicle, nor can it increase the traction afforded by Light in the instrument cluster will come on prevailing road conditions.
Page 260 258 STARTING AND OPERATING Malfunction Indicator Light begins to flash during accel- ESC Operating Modes eration, ease up on the accelerator and apply as little The ESC system has two available operating modes. throttle as possible. Be sure to adapt your speed and Full On driving to the prevailing road conditions.
Page 261 STARTING AND OPERATING 259 “ESC OFF” button and the “ESC Activation/Malfunction NOTE: To improve the vehicle’s traction when driving Indicator Light” will turn off. This will restore the normal with snow chains, or when starting off in deep snow, “ESC On” mode of operation. sand, or gravel, it may be desirable to switch to the “Partial Off”...
Page 262: Electronic Roll Mitigation (Erm)
260 STARTING AND OPERATING Electronic Roll Mitigation (ERM) WARNING! This system anticipates the potential for wheel lift by Many factors, such as vehicle loading, road condi- monitoring the driver’s steering wheel input and the tions, and driving conditions, influence the chance speed of the vehicle.
Page 263: Tire Safety Information
STARTING AND OPERATING 261 TIRE SAFETY INFORMATION NOTE: • P (Passenger) — Metric tire sizing is based on U.S. Tire Markings design standards. P-Metric tires have the letter “P” molded into the sidewall preceding the size designa- tion. Example: P215/65R15 95H. •...
Page 264 262 STARTING AND OPERATING • Temporary spare tires are designed for temporary • High flotation tire sizing is based on U.S. design emergency use only. Temporary high pressure com- standards and it begins with the tire diameter molded pact spare tires have the letter “T” or “S” molded into into the sidewall.
Page 265 STARTING AND OPERATING 263 EXAMPLE: R = Construction code – R means radial construction, or – D means diagonal or bias construction 15, 16, 18 = Rim diameter in inches (in) Service Description: 95 = Load Index – A numerical code associated with the maximum load a tire can carry H = Speed Symbol –...
Page 266: Tire Identification Number (Tin)
264 STARTING AND OPERATING EXAMPLE: Load Identification: Absence of the following load identification symbols on the sidewall of the tire indicates a Standard Load (SL) tire: • XL = Extra load (or reinforced) tire, or • LL = Light load tire or •...
Page 267 STARTING AND OPERATING 265 EXAMPLE: DOT MA L9 ABCD 0301 DOT = Department of Transportation – This symbol certifies that the tire is in compliance with the U.S. Department of Transportation tire safety standards and is approved for highway use MA = Code representing the tire manufacturing location (two digits) L9 = Code representing the tire size (two digits) ABCD = Code used by the tire manufacturer (one to four digits)
Page 268: Tire Terminology And Definitions
266 STARTING AND OPERATING Tire Terminology And Definitions Term Definition B-Pillar The vehicle B-Pillar is the structural member of the body located behind the front door. Cold Tire Inflation Pressure Cold tire inflation pressure is defined as the tire pressure after the vehicle has not been driven for at least three hours, or driven less than 1 mile (1.6 km) after sitting for a minimum of three hours.
Page 269: Tire Loading And Tire Pressure
STARTING AND OPERATING 267 Tire Loading And Tire Pressure Tire And Loading Information Placard Location NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar or the rear edge of the driver’s side door. Example Tire Placard Location (Door)
Page 270 268 STARTING AND OPERATING Tire And Loading Information Placard Example Tire Placard Location (B-Pillar) Tire And Loading Information Placard This placard tells you important information about the: 1. Number of people that can be carried in the vehicle. 2. Total weight your vehicle can carry.
Page 271 STARTING AND OPERATING 269 3. Tire size designed for your vehicle. To determine the maximum loading conditions of your vehicle, locate the statement “The combined weight of 4. Cold tire inflation pressures for the front, rear, and occupants and cargo should never exceed XXX lbs or spare tires.
Page 272 270 STARTING AND OPERATING 4. The resulting figure equals the available amount of NOTE: cargo and luggage load capacity. For example, if • If your vehicle will be towing a trailer, load from your “XXX” amount equals 1,400 lbs (635 kg) and there will trailer will be transferred to your vehicle.
Page 273 STARTING AND OPERATING 271...
Page 274: Tires - General Information
272 STARTING AND OPERATING Safety WARNING! WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and • Improperly inflated tires are dangerous and can increase your stopping distance. Use tires of the cause collisions. recommended load capacity for your vehicle.
Page 275: Tire Inflation Pressures
STARTING AND OPERATING 273 Fuel Economy WARNING! (Continued) Underinflated tires will increase tire rolling resistance • Unequal tire pressures from one side of the vehicle resulting in higher fuel consumption. to the other can cause the vehicle to drift to the right or left.
Page 276 274 STARTING AND OPERATING At least once a month: than 1 mile (1.6 km) after sitting for a minimum of three hours. The cold tire inflation pressure must not exceed • Check and adjust tire pressure with a good quality the maximum inflation pressure molded into the tire pocket-type pressure gauge.
Page 277: Tire Pressures For High Speed Operation
STARTING AND OPERATING 275 Tire pressure may increase from 2 to 6 psi (13 to 40 kPa) WARNING! during operation. DO NOT reduce this normal pressure build up or your tire pressure will be too low. High speed driving with your vehicle under maxi- mum load is dangerous.
Page 278: Tire Types
276 STARTING AND OPERATING Tire Repair Tire Types If your tire becomes damaged, it may be repaired if it All Season Tires — If Equipped meets the following criteria: All Season tires provide traction for all seasons (Spring, • The tire has not been driven on when flat. Summer, Fall and Winter).
Page 279 STARTING AND OPERATING 277 Summer tires do not contain the all season designation or Snow Tires mountain/snowflake symbol on the tire sidewall. Use Some areas of the country require the use of snow tires Summer tires only in sets of four; failure to do so may during the Winter.
Page 280: Run Flat Tires - If Equipped
278 STARTING AND OPERATING While studded tires improve performance on ice, skid See the tire pressure monitoring section for more infor- and traction capability on wet or dry surfaces may be mation. poorer than that of non-studded tires. Some states pro- Spare Tires —...
Page 281 STARTING AND OPERATING 279 equipment tire and wheel found on the front or rear axle Since this tire has limited tread life, the original equip- of your vehicle. This spare tire may be used in the tire ment tire should be repaired (or replaced) and reinstalled rotation for your vehicle.
Page 282 280 STARTING AND OPERATING Full Size Spare — If Equipped your original equipment tire, replace (or repair) the original equipment tire and reinstall on the vehicle at the The full size spare is for temporary emergency use only. first opportunity. This tire may look like the originally equipped tire on the front or rear axle of your vehicle, but it is not.
Page 283: Tire Spinning
STARTING AND OPERATING 281 Tire Spinning Tread Wear Indicators When stuck in mud, sand, snow, or ice conditions, do not Tread wear indicators are in the original equipment tires spin your vehicle’s wheels above 30 mph (48 km/h) or for to help you in determining when your tires should be longer than 30 seconds continuously without stopping.
Page 284: Life Of Tire
282 STARTING AND OPERATING • Performance tires, tires with a speed rating of V or These indicators are molded into the bottom of the tread grooves. They will appear as bands when the tread depth higher, and Summer tires typically have a reduced becomes a 1/16 of an inch (2 mm).
Page 285 STARTING AND OPERATING 283 wear and correct cold tire inflation pressures. The manu- you may have on tire specifications or capability. Failure to use equivalent replacement tires may adversely affect facturer strongly recommends that you use tires equiva- the safety, handling, and ride of your vehicle. lent to the originals in size, quality and performance when replacement is needed.
Page 286: Tire Chains (Traction Devices)
284 STARTING AND OPERATING TIRE CHAINS (TRACTION DEVICES) WARNING! (Continued) Use of traction devices require sufficient tire-to-body • Never use a tire with a smaller load index or clearance. Follow these recommendations to guard capacity, other than what was originally equipped against damage.
Page 287: Tire Rotation Recommendations
STARTING AND OPERATING 285 CAUTION! CAUTION! (Continued) • Observe the traction device manufacturer’s instruc- To avoid damage to your vehicle or tires, observe the tions on the method of installation, operating following precautions: speed, and conditions for use. Always use the •...
Page 288: Tire Pressure Monitoring System (Tpms)
286 STARTING AND OPERATING tires. Rotation will increase tread life, help to maintain mud, snow and wet traction levels, and contribute to a smooth, quiet ride. Refer to the “Maintenance Schedule” for the proper maintenance intervals. The reasons for any rapid or unusual wear should be corrected prior to rotation being performed.
Page 289 STARTING AND OPERATING 287 The tire pressure will vary with temperature by about 1 The TPMS will continue to warn the driver of low tire psi (7 kPa) for every 12°F (6.5°C). This means that when pressure as long as the condition exists, and will not turn the outside temperature decreases, the tire pressure will off until the tire pressure is at or above the recommended decrease.
Page 290 288 STARTING AND OPERATING pressure is sufficiently low enough to turn on the Tire CAUTION! (Continued) Pressure Monitoring Telltale Light. Driving the vehicle sensor damage. Using aftermarket tire sealants may may cause the tire pressure to rise to approximately 27 cause the Tire Pressure Monitoring System (TPMS) psi (186 kPa), but the Tire Pressure Monitoring Telltale sensor to become inoperable.
Page 291: Base System
STARTING AND OPERATING 289 • The TPMS should not be used as a tire pressure gauge Base System while adjusting your tire pressure. • Driving on a significantly under-inflated tire causes This is the TPMS warning indicator located in the instrument cluster.
Page 292 290 STARTING AND OPERATING Tire Pressure Monitoring Low Pressure Warnings the “Service Tire Pressure Monitoring System” text mes- sage will display. If the ignition key is cycled, this The Tire Pressure Monitoring Telltale Light will illumi- sequence will repeat providing the system fault still nate in the instrument cluster, an audible chime will be exists.
Page 293 STARTING AND OPERATING 291 • This occurs for each subsequent ignition key cycle, a NOTE: Your vehicle may be equipped with a compact spare wheel and tire assembly. chime will sound and the Tire Pressure Monitoring Telltale Light will flash on and off for 75 seconds and •...
Page 294: General Information
292 STARTING AND OPERATING General Information FUEL REQUIREMENTS — 1.4L Turbo This device complies with Part 15 of the FCC rules and RSS 210 of Industry Canada. Operation is subject to the This engine is designed to meet all emis- following conditions: sion regulations and provide satisfactory fuel economy and performance when us-...
Page 295: Reformulated Gasoline
STARTING AND OPERATING 293 Reformulated Gasoline CAUTION! Many areas of the country require the use of cleaner Do not use gasoline containing Methanol or E-85 burning gasoline referred to as “Reformulated Gasoline”. Ethanol. Use of these blends may result in starting Reformulated gasoline contain oxygenates and are spe- and drivability problems and may damage critical cifically blended to reduce vehicle emissions and im-...
Page 296: Materials Added To Fuel
294 STARTING AND OPERATING vehicles. The manufacturer recommends that gasoline Fuel System Cautions without MMT be used in your vehicle. The MMT content of gasoline may not be indicated on the gasoline pump, CAUTION! therefore, you should ask your gasoline retailer whether Follow these guidelines to maintain your vehicle’s the gasoline contains MMT.
Page 297: Carbon Monoxide Warnings
STARTING AND OPERATING 295 Carbon Monoxide Warnings CAUTION! (Continued) • The use of fuel additives, which are now being WARNING! sold as octane enhancers, is not recommended. Carbon monoxide (CO) in exhaust gases is deadly. Most of these products contain high concentrations Follow the precautions below to prevent carbon of methanol.
Page 298: Adding Fuel
296 STARTING AND OPERATING 4. Fill the vehicle with fuel – when the fuel nozzle WARNING! (Continued) “clicks” or shuts off the fuel tank is full. • Guard against carbon monoxide with proper main- 5. Remove the fuel nozzle and close the fuel door. tenance.
Page 299 STARTING AND OPERATING 297 Funnel Location For vehicle With Optional Spare Tire Funnel Location Inside Of Tool Kit...
Page 300: Trailer Towing
298 STARTING AND OPERATING WARNING! • Never have any smoking materials lit in or near the vehicle when the fuel door is open or the tank is being filled. • Never add fuel when the engine is running. This is in violation of most state and federal fire regula- tions and may cause the “Malfunction Indicator Light”...
Page 301 STARTING AND OPERATING 299 RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Towing This Vehicle Behind Another Vehicle Automatic Wheels OFF the Manual Euro Twin Clutch Transmission Towing Condition Ground Transmission Transmission (Aisin F21-250 HD Transmission ) Flat Tow NONE Transmission in Transmission in NOT ALLOWED NEUTRAL NEUTRAL...
Page 302 300 STARTING AND OPERATING Vehicles equipped with a manual transmission, or a Euro 4. Release the brake pedal only when the parking brake Twin Clutch transmission, may be flat towed (with all is applied, or the vehicle is securely connected to a tow four wheels on the ground) at any legal highway speed, vehicle.
Page 303 WHAT TO DO IN EMERGENCIES CONTENTS HAZARD WARNING FLASHERS ...303 JACKING AND TIRE CHANGING — IF EQUIPPED ......316 IF YOUR ENGINE OVERHEATS .
Page 304 302 WHAT TO DO IN EMERGENCIES ▫ Automatic Transmission ....333 FREEING A STUCK VEHICLE ... . .329 SHIFT LEVER OVERRIDE .
Page 305: Hazard Warning Flashers
WHAT TO DO IN EMERGENCIES 303 HAZARD WARNING FLASHERS IF YOUR ENGINE OVERHEATS The Hazard Warning flasher switch is located on the In any of the following situations, you can reduce the instrument panel below the radio. potential for overheating by taking the appropriate action. •...
Page 306: Wheel And Tire Torque Specifications
304 WHAT TO DO IN EMERGENCIES CAUTION! WARNING! Driving with a hot cooling system could damage You or others can be badly burned by hot engine your vehicle. If the pointer rises to the H (red) mark, coolant (antifreeze) or steam from your radiator. If the instrument cluster will sound a chime.
Page 307: Torque Specifications
WHAT TO DO IN EMERGENCIES 305 Torque Specifications Lug Nut/Bolt Torque **Lug Nut/ Lug Nut/ Bolt Size Bolt Socket Size 63 Ft-Lbs (86 N·m) M12 x 1.25 17 mm Steel Wheels Only 89 Ft-Lbs (120 N·m) Aluminum Wheels Only **Use only your Authorized Dealer recommended lug nuts/bolts and clean or remove any dirt or oil before Wheel Mounting Surface tightening.
Page 308: Tire Service Kit - If Equipped
306 WHAT TO DO IN EMERGENCIES WARNING! To avoid the risk of forcing the vehicle off the jack, do not tighten the lug nuts fully until the vehicle has been lowered. Failure to follow this warning may result in personal injury. TIRE SERVICE KIT —...
Page 309: Tire Service Kit Components And Operation
WHAT TO DO IN EMERGENCIES 307 Tire Service Kit Components And Operation Using The Mode Select Knob And Hoses Your Tire Service Kit is equipped with the following symbols to indicate the air or sealant mode. Selecting Air Mode Push in the Mode Select Knob (5) and turn to this position for air pump operation only.
Page 310: Tire Service Kit Usage Precautions
308 WHAT TO DO IN EMERGENCIES Using The Deflation Button Push the Deflation Button (2) to reduce the air pressure in the tire if it becomes over-inflated. Tire Service Kit Usage Precautions • Replace the Tire Service Kit Sealant Bottle (1) and Sealant Hose (6) prior to the expiration date (printed at the lower right hand corner on the bottle label) to assure optimum operation of the system.
Page 311 WHAT TO DO IN EMERGENCIES 309 from the vehicle or tire and wheel components. Once WARNING! the sealant dries, it can easily be peeled off and • Do not attempt to seal a tire on the side of the properly discarded. vehicle closest to traffic.
Page 312: Sealing A Tire With Tire Service Kit
310 WHAT TO DO IN EMERGENCIES WARNING! (Continued) WARNING! (Continued) • Keep Tire Service Kit away from open flames or • Tire Service Kit Sealant solution contains latex. In heat source. case of an allergic reaction or rash, consult a phy- •...
Page 313 WHAT TO DO IN EMERGENCIES 311 on the ground. This will provide the best positioning 4. Remove the cap from the valve stem and then screw of the kit when injecting the sealant into the deflated the fitting at the end of the Sealant Hose (6) onto the tire and running the air pump.
Page 314 312 WHAT TO DO IN EMERGENCIES NOTE: Sealant may leak out through the puncture in NOTE: If the Mode Select Knob (5) is on Air Mode and the tire. the pump is operating, air will dispense from the Air Pump Hose (7) only, not the Sealant Hose (6). If the sealant (white fluid) does not flow within 0 –...
Page 315 WHAT TO DO IN EMERGENCIES 313 latch pillar (recommended pressure). Check the tire 3. Immediately disconnect the Sealant Hose (6) from the pressure by looking at the Pressure Gauge (3). valve stem, reinstall the cap on the fitting at the end of the hose, and place the Tire Service Kit in the vehicle If the tire does not inflate to at least 26 psi (1.8 Bar) storage location.
Page 316 314 WHAT TO DO IN EMERGENCIES (D) Drive Vehicle: (E) After Driving: Immediately after injecting sealant and inflating the tire, Pull over to a safe location. Refer to “Whenever You Stop drive the vehicle 5 miles (8 km) or 10 minutes to ensure to Use Tire Service Kit”...
Page 317 WHAT TO DO IN EMERGENCIES 315 If the tire pressure is 19 psi (1.3 Bar) or higher: 5. Remove the Speed Limit sticker from the instrument panel after the tire has been repaired. 1. Push the Power Button (4) to turn on Tire Service Kit and inflate the tire to the pressure indicated on the tire 6.
Page 318: Jacking And Tire Changing - If Equipped
316 WHAT TO DO IN EMERGENCIES 4. Clean any remaining sealant from the Tire Service Kit JACKING AND TIRE CHANGING — IF EQUIPPED housing. WARNING! 5. Position the new Sealant Bottle (1) in the housing so that the Sealant Hose (6) aligns with the hose slot in •...
Page 319: Jack Location
WHAT TO DO IN EMERGENCIES 317 WARNING! (Continued) lift the vehicle for service purposes. The vehicle should be jacked on a firm level surface only. Avoid ice or slippery areas. Jack Location The spare tire jack is located in the rear cargo area underneath the cargo floor.
Page 320: Spare Tire Removal
318 WHAT TO DO IN EMERGENCIES Spare Tire Removal 2. Remove the jack handle and use the wrench end to lower the spare tire. 3. When the spare is clear, replace the jack tools. Spare Tire Location The spare tire is stowed in underneath the rear cargo area Winch Location on the outside of the car.
Page 321: Preparations For Jacking
WHAT TO DO IN EMERGENCIES 319 Preparations For Jacking 5. Turn Off the ignition. 1. Park the vehicle on a firm level surface, avoiding ice or 6. Block both the front and rear of the wheel diagonally slippery areas. opposite of the jacking position. For ex- ample, if changing the right front tire, WARNING! block the left rear wheel.
Page 322: Jacking Instructions
320 WHAT TO DO IN EMERGENCIES Jacking Instructions WARNING! (Continued) • Do not let anyone sit in the vehicle when it is on a WARNING! jack. • Do not get under the vehicle when it is on a jack. If Carefully follow these tire changing warnings to help prevent personal injury or damage to your you need to get under a raised vehicle, take it to a...
Page 323 WHAT TO DO IN EMERGENCIES 321 CAUTION! Do not attempt to raise the vehicle by jacking on locations other than those indicated in the Jacking Instructions for this vehicle. 1. Remove the spare tire, jack, and wheel bolt wrench. 2. If equipped with aluminum wheels where the center cap covers the wheel bolts, use the wheel bolt wrench to pry the center cap off carefully before raising the vehicle.
Page 324 322 WHAT TO DO IN EMERGENCIES engage the jack saddle with the lift area of the sill flange, centering the jack saddle between the locating notches on the sill flange. 5. Raise the vehicle just enough to remove the flat tire and install the spare tire.
Page 325 WHAT TO DO IN EMERGENCIES 323 CAUTION! WARNING! • To avoid the risk of forcing the vehicle off the jack, Be sure to mount the spare tire with the valve stem facing outward. The vehicle could be damaged if the do not tighten the lug nuts fully until the vehicle spare tire is mounted incorrectly.
Page 326: Spare Tire Stowage
324 WHAT TO DO IN EMERGENCIES have them checked with a torque wrench by your Cover the flat tire with the Emergency Spare Tire Bag and authorized dealer or at a service station. stow the flat tire into the trunk. 11.
Page 327: Preparations For Jump-Start
WHAT TO DO IN EMERGENCIES 325 WARNING! Do not attempt jump-starting if the battery is frozen. It could rupture or explode and cause personal injury. CAUTION! Do not use a portable battery booster pack or any other booster source with a system voltage greater than 12 Volts or damage to the battery, starter motor, alternator or electrical system may occur.
Page 328 326 WHAT TO DO IN EMERGENCIES 3. Remove the protective cover over the remote positive WARNING! (+) battery post. To remove the cover, pull upward on • Take care to avoid the radiator cooling fan when- the cover. ever the hood is raised. It can start anytime the 4.
Page 329: Jump-Starting Procedure
WHAT TO DO IN EMERGENCIES 327 Jump-Starting Procedure Follow these steps to disconnect the negative (-) battery cable: WARNING! 1. Pull outward on the negative (-) battery cable terminal release lever to the open position. Failure to follow this jump-starting procedure could result in personal injury or property damage due to 2.
Page 330 328 WHAT TO DO IN EMERGENCIES 4. Connect the opposite end of the negative (-) jumper Disconnecting The Jumper Cables cable to the negative (-) battery cable terminal of the 1. Disconnect the negative (-) jumper cable from the discharged vehicle. negative (-) battery cable terminal of the vehicle with the discharged battery.
Page 331: Freeing A Stuck Vehicle
WHAT TO DO IN EMERGENCIES 329 Follow these steps to connect the negative (-) battery FREEING A STUCK VEHICLE cable: If your vehicle becomes stuck in mud, sand or snow, it can often be moved using a rocking motion. Turn the 1.
Page 332 330 WHAT TO DO IN EMERGENCIES CAUTION! (Continued) CAUTION! (Continued) • Revving the engine or spinning the wheels too fast cycles. This will minimize overheating and reduce may lead to transmission overheating and failure. the risk of clutch or transmission failure during prolonged efforts to free a stuck vehicle.
Page 333: Shift Lever Override
WHAT TO DO IN EMERGENCIES 331 SHIFT LEVER OVERRIDE 7. The vehicle may then be started in NEUTRAL. If a malfunction occurs and the shift lever cannot be 8. Reinstall the shift lever boot. moved out of the PARK position, you can use the following procedure to temporarily move the shift lever: 1.
Page 334: Manual Transmission
332 WHAT TO DO IN EMERGENCIES Proper towing or lifting equipment is required to prevent If you must use the accessories (wipers, defroster, etc.) damage to your vehicle. Use only tow bars and other while being towed, the key must be in the ON/RUN equipment designed for this purpose, following equip- position.
Page 335: Automatic Transmission
WHAT TO DO IN EMERGENCIES 333 Euro Twin Clutch Transmission Automatic Transmission • Vehicle can be flat towed (all four wheels on the • Vehicle can be towed with the front wheels elevated. ground) with the transmission in NEUTRAL. • Vehicle can be towed on a flatbed truck (all wheels off •...
Page 336: Ignition Key Removal Override
334 WHAT TO DO IN EMERGENCIES 3. Unlock the steering column, pull the tilt/telescoping CAUTION! (Continued) control handle down. • Towing this vehicle in violation of the above re- 4. Pull the steering wheel outward until it is in the end of quirements can cause severe transmission damage.
Page 337 WHAT TO DO IN EMERGENCIES 335 Lower Steering Column Screw Locations Release Tab Location 6. Pull the release tab downwards using one hand and 7. Once the key is removed, reinstall the steering column with the other one remove the key, sliding it outwards. cover.
Page 338: Cap-Less Fuel Fill Funnel
336 WHAT TO DO IN EMERGENCIES CAP-LESS FUEL FILL FUNNEL CAUTION! The funnel for the Cap-Less Fuel System is located in the It is advisable to contact your Authorized Dealer to rear cargo area inside the tool bag (if equipped), or on the have the reinstall procedure carried out.
Page 339 MAINTAINING YOUR VEHICLE CONTENTS ▫ Body Lubrication .....350 ENGINE COMPARTMENT — 1.4L TURBO ..339 ▫ Wiper Blades ......350 ONBOARD DIAGNOSTIC SYSTEM —...
Page 340 338 MAINTAINING YOUR VEHICLE ▫ Automatic Transmission — Aisin F21-250 HD ▫ Front Turn Signal, Parking And Daytime Transmission — If Equipped ... . .367 Running Lamps..... . .386 ▫...
Page 341: Engine Compartment - 1.4L Turbo
MAINTAINING YOUR VEHICLE 339 ENGINE COMPARTMENT — 1.4L TURBO 1 — Air Cleaner Filter 4 — Battery 7 — Coolant Pressure Cap 2 — Engine Oil Dipstick 5 — Front Distribution Unit (Fuses) 8 — Coolant Pressure Bottle 3 — Brake Fluid Reservoir 6 —...
Page 342: Onboard Diagnostic System - Obd Ii
340 MAINTAINING YOUR VEHICLE ONBOARD DIAGNOSTIC SYSTEM — OBD II CAUTION! Your vehicle is equipped with a sophisticated onboard • Prolonged driving with the MIL on could cause diagnostic system called OBD II. This system monitors further damage to the emission control system. It the performance of the emissions, engine, and Euro Twin could also affect fuel economy and driveability.
Page 343: Dealer Service
MAINTAINING YOUR VEHICLE 341 DEALER SERVICE MAINTENANCE PROCEDURES Your authorized dealer has the qualified service person- The pages that follow contain the required maintenance nel, special tools, and equipment to perform all service services determined by the engineers who designed your operations in an expert manner.
Page 344: Engine Oil
342 MAINTAINING YOUR VEHICLE Engine Oil CAUTION! (Continued) Checking Oil Level • Your vehicle has been built with improved fluids that protect the performance and durability of your To assure proper engine lubrication, the engine oil must vehicle and also allow extended maintenance inter- be maintained at the correct level.
Page 345 MAINTAINING YOUR VEHICLE 343 Engine Oil Selection CAUTION! For best performance and maximum protection for tur- Do not overfill the engine with oil. Overfilling the bocharged engines under all types of operating condi- engine with oil will cause oil aeration, which can tions, the manufacturer recommends synthetic engine lead to loss of oil pressure and an increase in oil oils that are API Certified and meet the requirements of...
Page 346: Engine Oil Filter
344 MAINTAINING YOUR VEHICLE engine oil filler cap location, refer to “Engine Compart- Engine Oil Filter ment” in “Maintaining Your Vehicle” for further informa- The engine oil filter should be replaced with a new filter tion. at every engine oil change. Materials Added To Engine Oil Engine Oil Filter Selection The manufacturer strongly recommends against the ad-...
Page 347: Maintenance-Free Battery
MAINTAINING YOUR VEHICLE 345 Maintenance-Free Battery WARNING! Your vehicle is equipped with a maintenance-free battery. The air induction system (air cleaner, hoses, etc.) can You will never have to add water, nor is periodic main- provide a measure of protection in the case of engine tenance required.
Page 348: Air Conditioner Maintenance
346 MAINTAINING YOUR VEHICLE WARNING! (Continued) CAUTION! (Continued) an output greater than 12 Volts. Do not allow cable battery case. Cable clamps should be tight on the clamps to touch each other. terminal posts and free of corrosion. • Battery posts, terminals, and related accessories •...
Page 349 MAINTAINING YOUR VEHICLE 347 WARNING! CAUTION! • Use only refrigerants and compressor lubricants Do not use chemical flushes in your air conditioning approved by the manufacturer for your air condi- system as the chemicals can damage your air condi- tioning system. Some unapproved refrigerants are tioning components.
Page 350 348 MAINTAINING YOUR VEHICLE A/C Air Filter WARNING! Do not remove the A/C air filter while the blower is operating or personal injury may result. The A/C air filter is located in the fresh air inlet behind the glove box. Perform the following procedure to re- place the filter: 1.
Page 351 MAINTAINING YOUR VEHICLE 349 A/C Air Filter Access Door Open A/C Air Filter Removal 6. Remove the particulate air filters from the HVAC air 7. Install the A/C air filter with the air filter position inlet housing. Pull the filter elements straight out of indicators pointing in the same direction as removal.
Page 352: Body Lubrication
350 MAINTAINING YOUR VEHICLE should be wiped clean to remove dust and grit; after CAUTION! lubricating excess oil and grease should be removed. Particular attention should also be given to hood latching The A/C air filter is identified with an arrow to components to ensure proper function.
Page 353 MAINTAINING YOUR VEHICLE 351 Operation of the wipers on dry glass for long periods To enable the Service Position Strategy the wipers must may cause deterioration of the wiper blades. Always use be in the Park position before placing the ignition in the washer fluid when using the wipers to remove salt or dirt STOP/OFF position.
Page 354 352 MAINTAINING YOUR VEHICLE Function Deactivation: The functionality is reset if: • Turn the ignition to the MAR/RUN position. • Number of subsequent activations is three. • Two minutes timer has expired after turning the ignition OFF. NOTE: When turning the ignition ON, the blades will go into the parking position.
Page 355 MAINTAINING YOUR VEHICLE 353 Rear Wiper Blade Removal/Installation 1. Lift the rear wiper arm upward to raise the wiper blade off of the liftgate glass. 2. Grab the bottom of the wiper blade and rotate it forward to unsnap the blade pivot pin from the wiper blade holder.
Page 356: Adding Washer Fluid
354 MAINTAINING YOUR VEHICLE Adding Washer Fluid If you notice a change in the sound of the exhaust system; or if the exhaust fumes can be detected inside the vehicle; The windshield washer fluid reservoir is located in the or when the underside or rear of the vehicle is damaged; engine compartment, and the fluid level should be have an authorized technician inspect the complete ex- checked at regular intervals.
Page 357 MAINTAINING YOUR VEHICLE 355 WARNING! (Continued) CAUTION! (Continued) • Damage to the catalytic converter can result if your To Know Before Starting Your Vehicle” for further vehicle is not kept in proper operating condition. information. • A hot exhaust system can start a fire if you park In the event of engine malfunction, particularly involving engine misfire or other apparent loss of over materials that can burn.
Page 358: Cooling System
356 MAINTAINING YOUR VEHICLE • Do not idle the engine with any spark plug wires NOTE: Intentional tampering with emissions control systems can result in civil penalties being assessed disconnected or removed, such as when diagnostic against you. testing, or for prolonged periods during very rough idle or malfunctioning operating conditions.
Page 359 MAINTAINING YOUR VEHICLE 357 Coolant Checks If the engine coolant (antifreeze) is dirty or contains visible sediment, have an authorized dealer clean and Check engine coolant (antifreeze) protection every 12 flush with OAT coolant (antifreeze) (conforming to months (before the onset of freezing weather, where MS.90032).
Page 360 358 MAINTAINING YOUR VEHICLE CAUTION! (Continued) CAUTION! (Continued) • This vehicle has not been designed for use with Organic Additive Technology (OAT) engine cool- propylene glycol-based engine coolant (antifreeze). ant is different and should not be mixed with Hybrid Organic Additive Technology (HOAT) en- Use of propylene glycol-based engine coolant (an- tifreeze) is not recommended.
Page 361 MAINTAINING YOUR VEHICLE 359 that meets the requirements of FCA Material Standard Please note that it is the owner’s responsibility to main- MS.90032. When adding engine coolant (antifreeze): tain the proper level of protection against freezing ac- cording to the temperatures occurring in the area where •...
Page 362 360 MAINTAINING YOUR VEHICLE Cooling System Pressure Cap WARNING! (Continued) The cap must be fully tightened to prevent loss of engine • Do not use a pressure cap other than the one coolant (antifreeze) and to ensure that engine coolant specified for your vehicle.
Page 363 MAINTAINING YOUR VEHICLE 361 Coolant Level Points To Remember The coolant expansion bottle provides a quick visual NOTE: When the vehicle is stopped after a few miles/ method for determining that the coolant level is ad- kilometers of operation, you may observe vapor coming equate.
Page 364: Brake System
362 MAINTAINING YOUR VEHICLE • If frequent engine coolant (antifreeze) additions are Brake System required, the cooling system should be pressure tested In order to assure brake system performance, all brake for leaks. system components should be inspected periodically. • Maintain engine coolant (antifreeze) concentration at a Refer to the “Maintenance Schedule”...
Page 365 MAINTAINING YOUR VEHICLE 363 Be sure to clean the top of the master cylinder area before Use only manufacturer’s recommended brake fluid. Re- removing the cap. If necessary, add fluid to bring the fer to “Fluids, Lubricants, And Genuine Parts” in “Main- fluid level up to the requirements described on the brake taining Your Vehicle”...
Page 366: Manual Transmission - If Equipped
364 MAINTAINING YOUR VEHICLE WARNING! (Continued) CAUTION! cylinder reservoir cap secured at all times. Brake Use of improper brake fluids will affect overall clutch fluid in a open container absorbs moisture from the system performance. Improper brake fluids may dam- air resulting in a lower boiling point.
Page 367: Euro Twin Clutch Transmission - If Equipped
MAINTAINING YOUR VEHICLE 365 Add fluid, if necessary, to maintain the proper level. the transmission fluid at the correct level using the recommended fluid. No chemical flushes should be used Please see your authorized dealer for service. in any transmission; only the approved lubricant should Frequency Of Fluid Change be used.
Page 368 366 MAINTAINING YOUR VEHICLE CAUTION! CAUTION! If a transmission fluid leak occurs, visit your autho- Do not use chemical flushes in your transmission as rized dealer immediately. Severe transmission dam- the chemicals can damage your transmission compo- age may occur. Your authorized dealer has the proper nents.
Page 369: Automatic Transmission - Aisin F21-250 Hd
MAINTAINING YOUR VEHICLE 367 Automatic Transmission — Aisin F21-250 HD CAUTION! Transmission — If Equipped Using a transmission fluid other than the manufac- Selection Of Lubricant turer’s recommended fluid may cause deterioration It is important to use the proper transmission fluid to in transmission shift quality and/or torque converter ensure optimum transmission performance and life.
Page 370 368 MAINTAINING YOUR VEHICLE CAUTION! CAUTION! If a transmission fluid leak occurs, visit your autho- Do not use chemical flushes in your transmission as rized dealer immediately. Severe transmission dam- the chemicals can damage your transmission compo- age may occur. Your authorized dealer has the proper nents.
Page 371: Appearance Care And Protection From Corrosion
MAINTAINING YOUR VEHICLE 369 Appearance Care And Protection From Corrosion What Causes Corrosion? Corrosion is the result of deterioration or removal of Protection Of Body And Paint From Corrosion paint and protective coatings from your vehicle. Vehicle body care requirements vary according to geo- graphic locations and usage.
Page 372 370 MAINTAINING YOUR VEHICLE • If insects, tar, or other similar deposits have accumu- CAUTION! (Continued) lated on your vehicle, use MOPAR® Super Kleen Bug • Use of power washers exceeding 1,200 psi (8 274 and Tar Remover to remove. kPa) can result in damage or removal of paint and •...
Page 373 MAINTAINING YOUR VEHICLE 371 • If your vehicle is damaged due to a collision or similar • To remove heavy soil and/or excessive brake dust, use cause that destroys the paint and protective coating, MOPAR® Wheel Cleaner. have your vehicle repaired as soon as possible. The NOTE: If your vehicle is equipped with Dark Vapor or cost of such repairs is considered the responsibility of Black Satin Chrome wheels DO NOT USE wheel cleaners,...
Page 374 372 MAINTAINING YOUR VEHICLE • For grease stains, apply MOPAR® Multi-Purpose CAUTION! (Continued) Cleaner to a clean, damp cloth and remove stain. Use or harsh brushes that may damage the wheel’s pro- a fresh, damp towel to remove soap residue. tective finish.
Page 375 MAINTAINING YOUR VEHICLE 373 and MOPAR® Total Clean. Care should be taken to avoid CAUTION! soaking your leather upholstery with any liquid. Please do not use polishes, oils, cleaning fluids, solvents, deter- Damage caused by these type of products may not be gents, or ammonia-based cleaners to clean your leather covered by your New Vehicle Limited Warranty.
Page 376 374 MAINTAINING YOUR VEHICLE To minimize the possibility of scratching the lenses and When cleaning the rear view mirror, spray cleaner on the reducing light output, avoid wiping with a dry cloth. To towel or rag that you are using. Do not spray cleaner remove road dirt, wash with a mild soap solution fol- directly on the mirror.
Page 377 MAINTAINING YOUR VEHICLE 375 Instrument Panel Bezels 2. Dry with a soft cloth. Seat Belt Maintenance CAUTION! Do not bleach, dye or clean the belts with chemical When installing hanging air fresheners in your ve- solvents or abrasive cleaners. This will weaken the fabric. hicle, read the installation instructions carefully.
Page 378: Fuses
376 MAINTAINING YOUR VEHICLE WARNING! WARNING! (Continued) fuse of higher amp rating. Never replace a blown A frayed or torn belt could rip apart in a collision and fuse with metal wires or any other material. Failure leave you with no protection. Inspect the belt system to use proper fuses may result in serious personal periodically, checking for cuts, frays, or loose parts.
Page 379: Underhood Fuses
MAINTAINING YOUR VEHICLE 377 Underhood Fuses The ID number of the electrical component correspond- ing to each fuse can be found on the back of the cover. The Front Distribution Unit is located on the right side of the engine compartment, next to the battery. To access the fuses, press the release tabs and remove the cover.
Page 380 378 MAINTAINING YOUR VEHICLE Cavity Maxi Fuse Mini Fuse Description 60 Amp Blue – Body Controller 60 Amp Blue – Body Controller Rear Distribution Unit 20 Amp Yellow – Ignition Switch 40 Amp Orange – Anti-Lock Brake Pump 70 Amp Tan –...
Page 381 MAINTAINING YOUR VEHICLE 379 Cavity Maxi Fuse Mini Fuse Description – 5 Amp Tan Powertrain (Multiair – If Equipped) – 7.5 Amp Brown Air Conditioning – 30 Amp Green Rear Defroster – 15 Amp Blue Fuel Pump – 20 Amp Yellow Anti-Lock Brake Valves –...
Page 382: Interior Fuses
380 MAINTAINING YOUR VEHICLE Interior Fuses Rear Interior Fuses The interior fuse panel is part of the Body Control The rear interior fuse panel is located on the driver’s side Module (BCM) and is located on the driver’s side under in the rear compartment.
Page 383: Vehicle Storage
MAINTAINING YOUR VEHICLE 381 VEHICLE STORAGE in the fresh air and high blower setting. This will ensure adequate system lubrication to minimize the If you will not be using your vehicle for more than 21 days, possibility of compressor damage when the system is you may want to take steps to preserve your battery.
Page 384 382 MAINTAINING YOUR VEHICLE Exterior Bulbs Bulb Number Front Low and High Beam Headlamp HIR2LL Front Turn Signal Lamps WY21W Front Parking/Daytime Running Lamps W21/5W Front Side Marker Lamps LED (See Authorized dealer) Rear Tail/Stop Lamps P21/5W Rear Tail Lamp LED (See Authorized dealer) Rear Turn Signal Lamps P21W...
Page 385: Bulb Replacement
MAINTAINING YOUR VEHICLE 383 Bulb Number License Plate Lamps NOTE: Numbers refer to commercial bulb types that can be purchased from your authorized dealer. If a bulb needs to be replaced, visit your authorized dealer or refer to the applicable Service Manual. BULB REPLACEMENT NOTE: Lens fogging can occur under certain atmo- spheric conditions.
Page 386 384 MAINTAINING YOUR VEHICLE 2. Rotate the bulb counter-clockwise. 3. Remove the bulb when all the tabs are aligned with the openings in the metal holder. 4. Disconnect the electrical connector from the bulb. Bulb Removal Procedure Electrical Connector Removal...
Page 387 MAINTAINING YOUR VEHICLE 385 5. Install the new bulb and rotate clockwise to lock in 6. Reinstall the plastic cap. place. Headlamp Sealing Cap Installation New Bulb Installation...
Page 388: Front Turn Signal, Parking And Daytime Running Lamps
386 MAINTAINING YOUR VEHICLE Front Turn Signal, Parking And Daytime Running Front Fog Lamps Lamps To replace the front fog lights, see your authorized dealer. 1. Turn front wheels inboard to access upper cover in Front, Rear Roof Lamps wheel liner. 1.
Page 389: Center High-Mounted Stop Lamp (Chmsl)
MAINTAINING YOUR VEHICLE 387 4. Remove the tail lamp assembly. 8. Remove the backup lamp bulb by pulling straight out. 5. Remove the two screws that secure the backplate to 9. Replace lamps as required and reinstall lamp. the tail lamp housing. Center High-Mounted Stop Lamp (CHMSL) 6.
Page 390: Fluids, Lubricants, And Genuine Parts
388 MAINTAINING YOUR VEHICLE FLUIDS, LUBRICANTS, AND GENUINE PARTS Engine Component Fluid, Lubricant, or Genuine Part Engine Coolant – 1.4L Turbo Engine We recommend you use MOPAR Antifreeze/Coolant 10 Year/150,000 Mile Formula OAT (Organic Additive Technology) or equivalent meeting the requirements of FCA Material Standard MS-90032.
Page 391 MAINTAINING YOUR VEHICLE 389 CAUTION! CAUTION! (Continued) • Do not use water alone or alcohol-based engine • Mixing of engine coolant (antifreeze) other than coolant (antifreeze) products. Do not use additional specified Organic Additive Technology (OAT) en- rust inhibitors or antirust products, as they may not gine coolant (antifreeze), may result in engine be compatible with the radiator engine coolant and damage and may decrease corrosion protection.
Page 392: Chassis
390 MAINTAINING YOUR VEHICLE Chassis Component Fluid, Lubricant, or Genuine Part Manual Transmission – If Equipped We recommend you use MOPAR® C Series Manual & Dual Dry Clutch Transmission Fluid Euro Twin Clutch Transmission – If Equipped Gear Oil: Use only MOPAR® C Series Manual & Dual Dry Clutch Transmission Fluid or equivalent.
Page 393 MAINTENANCE SCHEDULES CONTENTS ▫ Maintenance Chart ....394 MAINTENANCE SCHEDULE ....392...
Page 394 392 MAINTENANCE SCHEDULES MAINTENANCE SCHEDULE Your authorized dealer will reset the oil change indicator message after completing the scheduled oil change. If a Your vehicle is equipped with an automatic oil change scheduled oil change is performed by someone other indicator system.
Page 395 MAINTENANCE SCHEDULES 393 Once A Month Or Before A Long Trip: At Every Oil Change Interval As Indicated By Oil • Check engine oil level. Change Indicator System: • Change oil and filter. • Check windshield washer fluid level. • Rotate the tires. Rotate at the first sign of irregu- •...
Page 396 394 MAINTENANCE SCHEDULES Maintenance Chart Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Additional Inspections Inspect the CV joints. Inspect front suspension, tie rod ends and boot seals, and re- place if necessary. Inspect the brake linings, park- ing brake function.
Page 397 MAINTENANCE SCHEDULES 395 Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Replace Brake Fluid every two years Clean and lube sun roof tracks. Replace spark plugs. **...
Page 398 396 MAINTENANCE SCHEDULES Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Change the transmission fluid (manual, or Euro Twin Clutch) if using your vehicle for any of the following: trailer towing, heavy loading, taxi, police, delivery ser- vice (commercial service), off- road, desert operation or more than 50% of your driving is at...
Page 399 MAINTENANCE SCHEDULES 397 Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Inspect and replace PCV valve if necessary. Replace the timing belt. ** The spark plug change interval is mileage based only, yearly intervals do not apply.
Page 400 398 MAINTENANCE SCHEDULES WARNING! • You can be badly injured working on or around a motor vehicle. Do only service work for which you have the knowledge and the right equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent me- chanic.
Page 401 PUBLICATION ORDER FORMS ... .404 ▫ FIAT Customer Center ....401 DEPARTMENT OF TRANSPORTATION UNIFORM TIRE QUALITY GRADES .
Page 402: Suggestions For Obtaining Service For Your Vehicle
400 IF YOU NEED CONSUMER ASSISTANCE SUGGESTIONS FOR OBTAINING SERVICE FOR Be Reasonable With Requests YOUR VEHICLE If you list a number of items and you must have your vehicle by the end of the day, discuss the situation with Prepare For The Appointment the service advisor and list the items in order of priority.
Page 403: Fiat Customer Center
• If for some reason you are still not satisfied, talk to the 1-888-242-6342 general manager or owner of the authorized dealer. FIAT Canada Customer Center They want to know if you need assistance. P.O. Box 1621 Windsor, Ontario N9A 4H6 Phone: 1-800- •...
Page 404: Service Contract
402 IF YOU NEED CONSUMER ASSISTANCE has access to a TDD or a conventional teletypewriter manufacturer’s Service Contract National Customer (TTY) in the United States, can communicate with the Hotline at 1-800-521-9922 (Canadian residents, call (800) manufacturer by dialing 1-800-380-CHRY. 465-2001 English / (800) 387-9983 French).
Page 405: Warranty Information
IF YOU NEED CONSUMER ASSISTANCE 403 REPORTING SAFETY DEFECTS WARNING! In The 50 United States And Washington, D.C. Engine exhaust (internal combustion engines only), If you believe that your vehicle has a defect that could some of its constituents, and certain vehicle compo- cause a crash or cause injury or death, you should nents contain, or emit, chemicals known to the State immediately inform the National Highway Traffic Safety...
Page 406: In Canada
404 IF YOU NEED CONSUMER ASSISTANCE To contact NHTSA, you may either call the Auto Safety PUBLICATION ORDER FORMS Hotline toll free at 1-888-327-4236 (TTY: 1-800-424- 9153), To order the following manuals, you may use either the or go to http://www.safercar.gov; or write to: Adminis- website or the phone numbers listed below.
Page 407 FIAT Group Automobiles ve- ing, servicing, and repairing FIAT Group Automobiles hicles. Included are starting, operating, emergency and vehicles.
Page 408: Department Of Transportation Uniform Tire Quality Grades
406 IF YOU NEED CONSUMER ASSISTANCE DEPARTMENT OF TRANSPORTATION UNIFORM significantly from the norm due to variations in driving TIRE QUALITY GRADES habits, service practices, and differences in road charac- teristics and climate. The following tire grading categories were established by the National Highway Traffic Safety Administration.
Page 409: Temperature Grades
IF YOU NEED CONSUMER ASSISTANCE 407 Temperature Grades WARNING! The temperature grades are A (the highest), B, and C, The temperature grade for this tire is established for representing the tire’s resistance to the generation of heat a tire that is properly inflated and not overloaded. and its ability to dissipate heat, when tested under Excessive speed, under-inflation, or excessive load- controlled conditions on a specified indoor laboratory...
Page 411 INDEX...
Page 412 410 INDEX Adding Engine Coolant (Antifreeze) ... .358 Air Conditioning Refrigerant ....346, 347 Adding Fuel ......296 Air Conditioning System .
Page 413 INDEX 411 Autostick ......244 Brake System ......251, 362 Fluid and Filter Changes .
Page 414 412 INDEX Chains, Tire ......284 Child Safety Locks ......24 Changing A Flat Tire .
Page 415 INDEX 413 Coolant Level ..... .357, 361 Dipsticks Disposal of Used Coolant ....360 Automatic Transmission .
Page 416 414 INDEX Electronic Vehicle Information Center (EVIC) . .128, 171 Fuel Requirements ..... .292 Exit Trip ......176 Oil .
Page 417 INDEX 415 Filters Adding ......296 Air Cleaner ......344 Additives .
Page 418 416 INDEX Gasoline, Reformulated .....293 Heated Mirrors......89 Gauges Hill Start Assist.
Page 419 INDEX 417 Jacking Instructions ......320 Lighter, Cigar ......142 Jack Location .
Page 420 418 INDEX Service Engine Soon (Malfunction Indicator) ..161 Manual, Service ......404 Tire Pressure Monitoring (TPMS) ... .161 Manual Transmission .
Page 421 INDEX 419 Octane Rating, Gasoline (Fuel) ....292 Operating Precautions ..... .340 Odometer.
Page 422 420 INDEX Pretensioners Replacement Parts......340 Seat Belts ......39 Replacement Tires .
Page 423 INDEX 421 Pregnant Women ......39 SENTRY KEY® Seat Belt Pretensioner .....39 FCC General Information .
Page 424 422 INDEX Cold Weather ......222 Tire and Loading Information Placard ..267, 268 Engine Fails to Start .
Page 425 INDEX 423 Rotation ......285 Maintenance ..... . .365, 367 Safety .
Page 426 424 INDEX Vehicle Loading ......269 Power ....... .25 Vehicle Modifications/Alterations .
Page 427 INSTALLATION OF RADIO TRANSMITTING EQUIPMENT Special design considerations are incorporated into this The antenna cable should be as short as practical and vehicle’s electronic system to provide immunity to radio routed away from the vehicle wiring when possible. Use frequency signals. Mobile two-way radios and telephone only fully shielded coaxial cable.
Page 428 FCA US LLC 15BF-126-AC Third Edition Rev 1 Printed in U.S.A.

Fiat 500L Owner's Manual

Introduction

Things to Know before Starting Your Vehicle

Understanding the Features of Your Vehicle

Understanding Your Instrument Panel

Starting and Operating

What to Do in Emergencies

Maintaining Your Vehicle

If You Need Consumer Assistance

Quick Links

Chapters

Related Manuals for Fiat 500L

Summary of Contents for Fiat 500L
