Page 1: Service Manual
Website: www.mideaaircon.com Service manual CAUTION - BEFORE SERVICING THE UNIT, READ THE SAFETY - PRECAUTIONS IN THIS MANUAL. - ONLY FOR AUTHORIZED SERVICE PERSONNEL. MODELS: MWF-07CM MWF-09CM MWF-12CM MWF-16CM MWF-18CM MWF-21CM MWF-24CM... -
Page 2: Table Of Contents
GD Midea Refrigerant Equipment Co. Ltd Service manual for E1 Window CONTENTS 1. PREFACE 1.1 SAFET PRECAUTIONS.........................1 1.2 INSULATION RESISTANCE TEST....................1 1.3 FEATURES.............................2 1.4 CONTROL LOCATIONS........................2 1.5 OUTSIDE DIMENSIONS........................2 2. INSTALLATION 2.1 SELECT THE BEST LOCATION....................3 2.2 CHECK OF INSTALLATION......................3 2.3 HOW TO DRAIN..........................3... -
Page 3: Features
GD Midea Refrigerant Equipment Co. Ltd Service manual for E1 Window 1.3 FEATURES Designed for HEAT PUMP. panel. Powerful cooling & heating. Super compact design. Slide-in and slide-out chassis for the simple Reliable and efficient rotary compressor is installation and service. -
Page 4: Installation
GD Midea Refrigerant Equipment Co. Ltd Service manual for E1 Window 2 INSTALLATION 2.1 SELECT THE BEST LOCATION 1. To avoid vibration and noise, make sure the unit is installed securely and firml. 2. Install the unit where the sunlight does not shine directly on the unit. If the unit receives direct sunlight, build an awning to shade the cabinet. -
Page 5: How To Install
GD Midea Refrigerant Equipment Co. Ltd Service manual for E1 Window 4. Connect the drain hose to the outlet located at the bottom of the drain pan. You can purchase the drain hose or tubing locally to satisfy our particular needs (Drain hose is 2.4 HOW TO INSTALL... - Page 6 GD Midea Refrigerant Equipment Co. Ltd Service manual for E1 Window 2.4.2 Installation of the unit into the housing 1. Slide the unit into the housing until it is firmly against the rear of the housing. Care is required to ensure the foam sealing strips on the housing remain in position.
- Page 7 GD Midea Refrigerant Equipment Co. Ltd Service manual for E1 Window 2.4.4 Installation steps Step 1. Remove the front panel and the air filter 1. Hold the slot under the front panel, then uplift it outwards, and remove the front panel (See Fig.1).
-
Page 8: Troubleshooting Guide
GD Midea Refrigerant Equipment Co. Ltd Service manual for E1 Window Step 5. Install the air filter and front panel. 1. Install the air filter into the frame's slot from upside to underside (See Fig.2). 2. Hang the front panel on the frame's buckle, then press the front panel into the frame's slot until you hear a click (See Fig10). - Page 9 GD Midea Refrigerant Equipment Co. Ltd Service manual for E1 Window...
- Page 10 GD Midea Refrigerant Equipment Co. Ltd Service manual for E1 Window 3.2 TROUBLESHOOTING GUIDE In general, possible trouble is classified in three kinds. One is called Starting Failure which is caused from an electrical defect, another is ineffective Air Conditioning caused b a defect in the refrigeration circuit and improper application, and the other is called the Structure Damage.
- Page 11 GD Midea Refrigerant Equipment Co. Ltd Service manual for E1 Window Air filter Clean or replace if restricted. Vent. door Close if open. Determine if the unit is properly sized for the area to be Unit undersized cooled or heated.
-
Page 12: Wiring Diagram
GD Midea Refrigerant Equipment Co. Ltd Service manual for E1 Window Voltage Check voltage. Call Supply Authority if not within limits. Check the wire connections, if loose, repair or replace the terminal. If wires are off, refer to wiring diagram for Wiring identification, and replace. - Page 13 GD Midea Refrigerant Equipment Co. Ltd Service manual for E1 Window 4.2 For models: MWF-12CM 4.3 For models: MWF-16CM...
- Page 14 GD Midea Refrigerant Equipment Co. Ltd Service manual for E1 Window 4.4 For models: MWF-18CM...
-
Page 15: Exploded View
GD Midea Refrigerant Equipment Co. Ltd Service manual for E1 Window 4.5 For models: MWF-21CM MWF-24CM 5 EXPLODED VIEWS (See attached files) 6 SPECIFICATIONS (See attached files)
