Toshiba Satellite U400 Maintenance Manual page 252

P/N:DFHS12FS002 CONN SMD HOUSING 12P 2R FS(P0.8,H8.35)
PIN No.
1
3
5
7
9
11
CN21 Battery cable Connector
P/N: DFHD14MS014 CONN SMD HEADER 14P 2R MS(P1.5,H19.5)
PIN No.
1
3
5
7
9
11
13
CN22 FAN connector
12
Downloaded from LpManual.com Manuals
Signal name
NC
NC
NC
DIB_P
DIB_N
NC
Signal name
GND ---
GND ---
MBCLK I/O
TEMP_MBAT O
ID O
MBAT+ ---
MBAT+ ---
Satellite U400/Satellite Pro U400/PORTEGE M800 Maintenance Manual
I/O PIN No.
--- 2
--- 4
--- 6
I 8
I 10
--- 12
I/O PIN No.
2
4
6
8
10
12
14
Pin Assignment
Signal name
NC ---
NC ---
NC ---
NC ---
NC ---
NC ---
Signal name I/O
GND ---
GND ---
MBDATA I/O
GND ---
NC ---
MBAT+ ---
MBAT+ ---
I/O
