5. Power Management

5. Power Management
If you have VESA DPM compliance display card
or software installed in your PC, the Display can
automatically reduce its power consumption
when not in use. If an input from a keyboard,
mouse or other input device is detected,
the Display will 'wake up' automatically. The
following table shows the power consumption
and signaling of this automatic power saving
feature:
Power Management Definition
VESA Mode Video H-sync V-sync
Active ON Yes
Sleep
OFF No
(Standby)
Off
OFF -
(AC switch)
The following setup is used to measure power
consumption on this Display.
• Native resolution: 3840 x 2160
• Contrast: 50%
• Brightness: 100%
• Color temperature: 6500k with full white
pattern
Note
This data is subject to change without notice.
Power Used LED Color
100 W (typ.)
Yes White
165 W (max.)
White
No 0.5 W (typ.)
(blink)
- 0 W (typ.) OFF
21
