www.philips.com/welcome
EN
User manual
Customer care and warranty
Troubleshooting & FAQs
BDM4037U
1
24
29

Advertisement

Table of Contents
loading

Related Manuals for Philips BDM4037UW

Summary of Contents for Philips BDM4037UW

  • Page 1 BDM4037U www.philips.com/welcome User manual Customer care and warranty Troubleshooting & FAQs...

  • Page 2: Table Of Contents

    4.1 Resolution & Preset Modes ..19 5. Power Management ....20 6. Customer care and warranty .. 21 6.1 Philips’ Flat Panel Displays Pixel Defect Policy ....... 21 6.2 Customer Care & Warranty ..24 7. Troubleshooting & FAQs ..29 7.1 Troubleshooting ......29...

  • Page 3: Important

    This electronic user’s guide is intended • If turning off the Display by for anyone who uses the Philips Display. detaching the power cable or DC Take time to read this user manual power cord, wait for 6 seconds before you use your Display.

  • Page 4: Notational Descriptions

    1. Important • If foreign substance or water gets in Service your Display, please turn the power • The casing cover should be opened off immediately and disconnect only by qualified service personnel. the power cord. Then, remove the • If there is any need for any foreign substance or water, and document for repair or integration, send it to the maintenance center.

  • Page 5: Disposal Of Product And Packing Material

    From the planning, design and production stages, Philips emphasizes the important of making products that can easily be recycled. At Philips, end-of-life management primarily entails participation in national take- back initiatives and recycling programs This marking on the product or on...

  • Page 6: Setting Up The Display

    User’s Manual 保留备用 Display drivers hands and firmly insert the base www.philips.com/welcome Philips and the Philips’ Shield Emblem are registered trademarks of Koninklijke Philips N.V. and are used under license from Koninklijke Philips N.V. stand into the base column. * CD...
  • Page 7 2. Setting up the monitor Connecting to your PC Connect to PC 1. Connect the power cord to the back of the Display firmly. 2. Turn off your computer and unplug its power cable. 3. Connect the Display signal cable to the video connector on the back of your computer.

  • Page 8: Operating The Display

    2. Setting up the monitor Customize your own “User Key" 2.2 Operating the Display “User Key” allows you to setup your Description of the control buttons favorite function buttons. 1. Toggle to the right to enter OSD menu screen.  ...
  • Page 9 On-Screen Display (OSD) is a feature in to the [Audio In] port of this Display, and all Philips LCD Displays. It allows an end still watch your video source connected user to adjust screen performance or from [MHL-HDMI 1.4], [MHL-HDMI 2.0],...
  • Page 10 Main menu Sub menu Input MHL-HDMI 1.4 MHL-HDMI 2.0 DisplayPort1 DisplayPort2 To access the OSD menu on this Philips Picture Picture Format Wide Screen, 4:3, 1:1 Brightness 0~100 Display simply use the single toggle Contrast 0~100...
  • Page 11 2. Setting up the monitor Resolution notification This Display is designed for optimal performance at its native resolution, 3840 x 2160 @ 60 Hz. When the Display is powered on at a different resolution, an alert is displayed on screen: Use 3840 x 2160 @ 60 Hz for best results.

  • Page 12: Multiview

      complex multi-tasking work a breeze.  Why do I need it?  With the ultra high resolution Philips MultiView display, you can experience 3. Toggle to the right to confirm your a world of connectivity in a comfortable selection.
  • Page 13 2. Setting up the monitor 3. Toggle to the up or down to select Open up three sub- [PIP / PBP Mode], then toggle to the windows of other signal (main) right. sources. 4. Toggle to the up or down to select [Off], [PIP], [PBP 2Win], or...

  • Page 14: Remove The Base Assembly For Vesa Mounting

    2. Setting up the monitor Swap A and B source in [PIP] mode: ↔ (main) (main) • Off: Stop MultiView function. Note When you do the SWAP function, the video and its audio source will swap at the same time. (Refer to page <7>...

  • Page 15: Mhl (Mobile High-Definition Link) Introduction

    An optional MHL cable allows you to simply connect your MHL capable mobile device to this large Philips MHL Note display, and watch your HD videos come • The port marked [MHL-HDMI] is to life with full digital sound. Now not...

  • Page 16: Image Optimization

    Whether you're working SamrtImage on screen display. with text applications, displaying images 2. Toggle to the up or down to select or watching a video, Philips SmartImage between Office, photo, Movie, Game, delivers great optimized Display Economy, SmartUniformity and Off.

  • Page 17: Smartcontrast

    LCD Displays. Typical backlight intensity. This function will uniformity is measured around dynamically enhance contrast for a great 75-80%. By enabling Philips entertainment experience when viewing SmartUniformity feature, display videos or playing games. uniformity is increased to above 95%.

  • Page 18: Technical Specifications

    4. Technical Specifications 4. Technical Specifications Picture/Display Display Panel Type VA LCD Backlight W-LED system Panel Size 40" (101.6 cm) Aspect Ratio 16:9 SmartContrast (typ.) 20,000,000:1 SmartResponse (typ.) 4 ms (GtG) VGA: 1920 x 1080 @ 60Hz HDMI 1.4: 3840 x 2160 @ 30Hz Optimum Resolution HDMI 2.0: 3840 x 2160 @ 60Hz DisplayPort 1.1: 3840 x 2160 @ 30Hz...
  • Page 19 4. Technical Specifications AC Input AC Input AC Input Consumption Voltage at Voltage at Voltage at 100VAC , 50Hz 115VAC , 60Hz 230VAC, 50Hz Normal Operation 61.57 W (typ.) 61.67 W (typ.) 61.77 W (typ.) Sleep (Standby) 0.5 W (typ.) 0.5 W (typ.) 0.5 W (typ.) 0.3 W (typ.)
  • Page 20 Cabinet Color White Finish Glossy Note 1. This data is subject to change without notice. Go to www.philips.com/support to download the latest version of leaflet. 2. Smart response time is the optimum value from either GtG or GtG (BW) tests.

  • Page 21: Resolution & Preset Modes

    4. Technical Specifications Note 4.1 Resolution & Preset Modes 1. Please notice that your display works Maximum Resolution best at native resolution of 3840 x 2160 1920 x 1080 @ 60 Hz (analog input) @ 60Hz. For best display quality, please 3840 x 2160 @ 60 Hz (digital input) follow this resolution recommendation.

  • Page 22: Power Management

    5. Power Management 5. Power Management If you have VESA DPM compliance display card or software installed in your PC, the Display can automatically reduce its power consumption when not in use. If an input from a keyboard, mouse or other input device is detected, the Display will 'wake up' automatically.

  • Page 23: Customer Care And Warranty

    Pixel Defect Policy white pixel. When all are dark, the three colored sub pixels together appear as a Philips strives to deliver the highest single black pixel. Other combinations of quality products. We use some of the lit and dark sub pixels appear as single industry's most advanced manufacturing pixels of other colors.
  • Page 24 A red or blue bright dot must be the warranty period, a TFT Display panel more than 50 percent brighter than in a Philips flat panel Display must have pixel or sub pixel defects exceeding the neighboring dots while a green tolerances listed in the following tables.
  • Page 25 6. Customer care and warranty BRIGHT DOT DEFECTS ACCEPTABLE LEVEL 1 lit subpixel 2 adjacent lit subpixels 3 adjacent lit subpixels (one white pixel) Distance between two bright dot defects* >15mm Total bright dot defects of all types BLACK DOT DEFECTS ACCEPTABLE LEVEL 1 dark subpixel 5 or fewer...

  • Page 26: Customer Care & Warranty

    Please contact our Philips Customer Service Representative or local contact center (by Consumer care number) for more details. Philips Customer Care Center number listed below.
  • Page 27 6. Customer care and warranty Germany +49 01803 386 853 € 0.09 Mon to Fri : 9am - Greece Alman +30 00800 3122 Free of Mon to Fri : 9am - 1223 charge Ireland Celestica +353 01 601 1161 Local call Mon to Fri : 8am - tariff Italy...
  • Page 28 Asupport 420 272 188 300 +372 6519900(General) Estonia FUJITSU +372 6519972(workshop) Georgia Esabi +995 322 91 34 71 +36 1 814 8080(General) +36 1814 8565(For AOC&Philips Hungary Profi Service only) Classic Service +7 727 3097515 Kazakhstan I.I.c. +371 67460399 Latvia...
  • Page 29 Tel: +852 2619 9639 9:00am-6:00pm Macau Pixels Technology Ltd. Macau: Sat. 9:00am-1:00pm Tel: (853)-0800-987 REDINGTON INDIA Tel: 1 800 425 6396 Mon.~Fri. India SMS: PHILIPS to 56677 9:00am-5:30pm +62-21-4080-9086 Mon.~Thu. PT. CORMIC (Customer Hotline) 08:30-12:00; 13:00-17:30 Indonesia SERVISINDO +62-8888-01-9086 Fri.
  • Page 30 6. Customer care and warranty Philips Singapore Pte Mon.~Fri. Singapore Ltd (Philips Consumer (65) 6882 3966 9:00am-6:00pm Care Center) Sat. 9:00am-1:00pm Computer Repair Mon.~ Fri. South Africa 011 262 3586 Technologies 08:00am-05:00pm Taiwan FETEC.CO 0800-231-099 Mon.~Fri. 09:00 - 18:00 Axis Computer System Mon.~Fri.

  • Page 31: Troubleshooting & Faqs

    • Disconnect the Display from mains • First, ensure that the power button power source immediately for safety on the front of the Display is in the • Contact with Philips customer OFF position, then press it to the service representative immediately. ON position.

  • Page 32: General Faqs

    For further assistance, refer to the "after-imaging " or "ghost imaging", Consumer Information Centers list on your screen. "Burn-in", "after- and contact Philips customer service imaging", or "ghost imaging" is a representative. well-known phenomenon in LCD * Functionality different according to panel technology.
  • Page 33 Display, make sure that there is no disconnect your old Display and pressure or force applied to the reconnect your Philips LCD Display. panel surface side. This may affect • Turn on your Display and then turn your warranty conditions.
  • Page 34 PC, workstation or Mac? may result in severe “burn-in” or “after- Ans.: Yes. All Philips LCD Displays are image” or “ghost image” symptoms fully compatible with standard that will not disappear and cannot be PCs, Macs and workstations.

  • Page 35: Multiview Faqs

    7. Troubleshooting & FAQs Attention Display control locked 7.3 Multiview FAQs Q1: Can I enlarge the PIP sub window ? Ans.: Yes, there are 3 sizes to select: [Small], [Middle], [Large]. You can press to enter OSD menu. Select your preferred [PIP Size] option from the [PIP / PBP] main menu.
  • Page 36 © 2016 Koninklijke Philips N.V. All rights reserved. Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V. and are used under license from Koninklijke Philips N.V. Specifications are subject to change without notice. Version: BDM4037UE1T...
