- Page 1 Dishwasher Use & Care Manual DW 24XV...
- Page 2 The warranties provided by Bertazzoni Spa in this statement apply exclusively to Bertazzoni appliances and accessories sold as new products to the original owner by a Bertazzoni authorized distributor, retailer, dealer or service center and installed in the United States and Canada. The warranties provided in this statement are not transferable and have validity from the date of installation.
- Page 3 14 Defects and damages arising from transportation of the product to the home of the owner. 15 Defects and damage arising from external forces beyond the control of Bertazzoni SpA such as fire, flood, earthquakes and other acts of God.
-
Page 4: Table Of Contents
Table of Contents Important Safety InstructionS ...... 1 Features of your new dishwasher....2-5 Operating Instructions ......6-9 Preparing and loading dishes ....10-12 Care & cleaning ........13-15 Troubleshooting ........16-17 Installation instructions ......18... -
Page 5: Important Safety Instructions
Important safety instruction When using your dishwasher, WARNING follow basic precautions, including the following: Proper installation Please install your dishwasher properly follow the installation guide. ℉ ℉ Water supply temperature should be 120 or 149 Dispose of the discarded appliance and packing material properly. The dishwasher must be grounded, or it can result in a risk of electric shock. -
Page 6: Features Of Your New Dishwasher
Features of your new dishwasher Specification Capacity 14 place settings (max) Dimension x 623 x 857 mm (W x D x H) Weight unpacked 94lb (42.5 kg) Power Supply 120volts, 60H z Rated power usage Wash motor 5 0W H eater 840 W 20 ~ 120 psi (138 ~ 828kPa) Water Feed Pressure 1 Top light... -
Page 7: Features Of Your New Dishwasher
Features of your new dishwasher Features Filter System Your dishwasher has a multiple Filte System .Inthe System there are four filter-meshes .It can separate soiled water and clean water in different chambers. The multiple filter system helps your dishwasher to get better performance with less water and less energy . -
Page 8: How Your Dishwasher Cleans
Features of your new dishwasher How your dishwasher cleans Getting Started Your dishwasher cleans by spraying 1.Load dishwasher (See preparing and a mixture ofhot water and detergent loading dishes). through the spray arms against soiled surfaces . 2.Add detergent (See Fill detergent to the dispenser). -
Page 9: Control Panel
Control panel Wash Cycle Selections Display Win dow EXTRADRY To display the remained hours and minutes When the " Heated Dry" function is selected, of the running cycle, delayhours and error the heater will work during the drying process. codes etc. HIGH TEMP When the "Hi Temp wash"... -
Page 10: Operating Instructions
Operating dishwasher Functions START CANCEL SANITIZE D indicator light Open the door, select a wash cycle If a cycle with the sanitize function is that you desired, the indicator light finished,the sanitized indicator light beside the pad will turn on. Press the turns on. - Page 11 Operating dishwasher Status Window Error indication H:01- H:24 In certain situations which are critical to If the Delay Start option is s elected, the machines function and safe oper- the number of delay start hours ation, the control shall shut down and shows in the status window.
- Page 12 Operating dishwasher Adjustable Upper Rack The upper rack height can be easily adjusted to accommodate loading taller dishes in either rack. To accommodate taller dishes in the bottom rack, thereare 2 positions available: 1. Lift the rack for upper position Upper rack The upper rack in the upper position Lower rack...
- Page 13 Operating dishwasher Loading the Upper Rack Loading the Bottom Rack The upper rack is designed for cups, bottom rack is designed to load glasses, small plates, bowls and plastic plates, soup bow ls,plates,saucers and items marked safe etc. cookware. The adjustable rackspace For best results, place the bowls, cups, wil l allow you to load maximum 13 inch glasses, sauce pans with soiled surface...
-
Page 14: Preparing And Loading Dishes
Preparing and loading dishes Loading the Silverware Basket Adding A Dish The silverware basket could be divided To add or remove items after wash cycle starts: into three separate modules that can 1. Open door slightly and wait a few be used in both upper and lower racks seconds until wash action stops before completely opening. - Page 15 Preparing and loading dishes Filling the rinse aid dispenser The silverware basket could be divided into three separate modules that can be used in both upper and lower racks Your dishwasher ids esigned to use a liquid rinse aid. The use of rinse greatly improves drying performance after the final rinse.Do not use a solid or bar-type rinse aid.
-
Page 16: Preparing And Loading Dishes
Preparing and loading dishes 1. Push the dispenser cover latch down wards and open it The amount of the detergent needed depends on the cycle and soil level of dishes, refer to the table below and adjust the recommended amount as necessary for your load. -
Page 17: Care & Cleaning
Care & cleaning Cleaning the exterior door and panel 2.Control panel 1. Stainless steel panel Clean the stainless steel door and handle Clean th e control panel with a regularly to remove the debris with cleaning light ly dampen ed cloth, clean it soft cloth. - Page 18 Care & cleaning Clean the Fine Filter Take out the Cylinder Filter and remove the Fine Filter from the dishwasher tub bottom. To rem ove the Fine Filter you m ust first re m ove the bottom spray arm as shown below. Flush the Fine Filter by holding it under running water and replace.
-
Page 19: Care & Cleaning
Care & cleaning Clean the door gasket Air gap Clean the door gasket with a damp If there i s an air gap insta lled with your cloth to removefood particles regularly. dishwasher,make sure it is clean so the dishwasher will drain properly. Air gap is not part of your dishwasher. -
Page 20: Troubleshooting
Preparing and loading dishes Clean the door gasket Problem Possible cause Shut the door completely make Dishwasher won't start sure it is latched Check and connect the power Power supply or power line is not supply connected Dishwasher Refer to Delay Start section in Delay Start option has been selected won't start this manual to rese... -
Page 21: Error Codes
Preparing and loading dishes Problem Possible cause Detergent may be too old Use fresh detergent Detergent left in Load the dishes,making sure the dispenser cup Spray arm is blocked spray arms are not blocked. Add the detergent and rinse aid Improper operation of the Detergent dispenser detergent cover... -
Page 22: Installation Instructions
If overflow occurs, turn off the main water supply before calling a service. If there is water in the base pan because of WARNING an overfill or small leak,the water should be removed before restarting the dishwasher. INSTALLATION INSTRUCTION S Read the installation instructions clearly, and futher more, pay attention to the follow lists: 1.the power-supply receptacle for the appliance shall...
