Summary of Contents for Bertazzoni DW18PR
- Page 1 Dishwasher Use & Care Manual DW18PR...
-
Page 2: Table Of Contents
CONTENTS Please carefully read this manual before using the dishwasher, it will help you use and maintain the dishwasher properly . IMPORTANT SAFETY INSTRUCTIONS FEATURES OF YOUR NEW DISHWASHER Specification Filter System Smart Wash System OPERATING INSTRUCTIONS Control panel Cycle Chart PREPARING AND LOADING DISHES Loading the Lower Basket Loading the Upper Basket... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTION For your safety, please follow the information in this manual to minimize WARNING the risk of fire, explosion, electric shock, and to help prevent property damage or personal injury. Proper installation Please install your dishwasher properly, follow the installation guide. Water supply inlet temperature should be between 120℉... -
Page 4: Features Of Your New Dishwasher
FEATURES OF YOUR NEW DISHWASHER Specification Capacity 8 place settings Dimension 17 6 . x 22.6 x 32.4 inches (W x D x H) Power Supply 120volts, 60Hz Rated power usage Wash motor 100W Heater 700W Water Feed Pressure ~ 145 psi (0 04 ~ 1MPa) Lock Cup Shelf... -
Page 5: Filter System
FEATURES OF YOUR NEW DISHWASHER Filter System Your dishwasher has a multiple Filter System. In the System there are three mesh filters. It can separate soiled water and clean water in different chambers. The multiple filter system helps your dishwasher to get better performance with less water and less energy. -
Page 6: Wash Cycle Selections
FEATURES OF YOUR NEW DISHWASHER How your dishwasher cleans Getting Started Your dishwasher cleans by spraying 1.Load the dishwasher (See Dish Preparation and a mixture of hot water and detergent Loading sections). through the spray arms against soiled surfaces . 2.Add detergent (See Filling the detergent dispenser). -
Page 7: Operating Instructions
OPERATING INSTRUCTIONS Control panel 1.Start/Cancel 4. Display window Select the washing program or pause the This displays the remained hours and minutes of the washing program when the machine is working. running cycle, delay hours and error codes etc. 2.Wash Cycle Selections 5. -
Page 8: Cycle Chart
OPERATING THE DISHWASHER Status Window Error indication H:01- H:24 In certain situations which are critical to If the Delay Start option is selected, the machines function and safe oper- the number of delay start hours ation, the control shall shut down and shows in the status window. -
Page 9: Preparing And Loading Dishes
PREPARING AND LOADING DISHES Dish Preparation Scrape away large pieces of food, bones, pits, toothpicks, etc. The continuously filtered wash system will remove the remaining food particles. Burned-onfoods should be loosened before loading. Empty liquids from glasses and cups. Foods such as mustard, mayonnaise, vinegar, lemon juice and tomato based products may cause discoloration of stainless steel and plastics if allowed to sit for a long period of time. - Page 10 PREPARING AND LOADING DISHES Loading the Lower Basket The lower basket has been especially designed for dinner dishes, soup bowls, plates, pots, lids, casserole dishes, and plates. Load large items such as pans and pots into the dishwasher so their open sides face downwards. We recommend loading cups, stemware, and small plates into the upper basket.
-
Page 11: Loading The Silverware Basket
PREPARING AND LOADING DISHES Loading the Silverware Basket Adding A Dish The silverware basket can be divided To add or remove items after into three separate modules that can wash cycle starts: be used in both upper and lower racks 1. -
Page 12: Filling The Detergent Dispenser
PREPARING AND LOADING DISHES Filling the rinse aid dispenser Your dishwasher is designed to use a liquid rinse aid. The use of rinse greatly improves drying performance after the final rinse. Do not use a solid or bar-type rinse aid. Under normal conditions, the rinse aid will last approximately one month. -
Page 13: Filling The Rinse Aid Reservoir
PREPARING AND LOADING DISHES Filling the rinse aid reservoir Your dishwasher has been designed to use liquid rinse aid only. Using a powdered rinse aid will clog the reservoir opening and cause the dishwasher to malfunction. Rinse aid improves the drying performance of the dishwasher. Do not add regular detergent to the rinse aid reservoir. -
Page 14: User Maintenance
USER MAINTENANCE Keeping your dishwasher clean improves its performance, reduces unnecessary repairs, and lengthens its life. CLEANING THE EXTERIOR It’s best to clean spills on the outside of your dishwasher as they occur. Use a soft, damp cloth on the control panel to gently wipe away spills and dust. -
Page 15: Cleaning The Nozzles
USER MAINTENANCE 4. Remove any dirt or other remains from the fil ters, and then rinse them under running water. 5. Reassemble the fi lters in the reverse order of the dissasembly, replace the fi lter insert, and rotate clockwise to the close arrow. If the fil ter insert is not closed properly, its performance will be decreased. -
Page 16: Troubleshooting
Troubleshooting Problem Possible cause Solution Shut the door completely make sure it is latched Dishwasher won't start Power supply or power line is not connected Check and connect the power supply Dishwasher won't start Refer to Delay Start section in this manual to reset Delay Start option has been selected Deactivate the child lock, refer to child lock Child Lock activated... - Page 17 Troubleshooting Problem Possible cause Solution Detergent may be too old Use fresh detergent Detergent left in dispenser cup Load the dishes, making sure the spray arms Spray arm is blocked are not blocked Detergent dispenser will not Improper operation of the detergent cover Add the detergent and rinse aid as indicated by shut the manual...
- Page 18 Error Codes When some malfunctions come on, the appliance will display error codes to warn you: 1. check the water supply 2. check the inlet valve during the water inlet step, if the flow meter 3. check the inlet can't detect the defined water after 4 4.
