- Page 1 MXD105 INSTALLATION/OWNER'S MANUAL AM/FM Receiver with Detachable Face...
-
Page 2: Preparation
MXD105 INSTALLATION Preparation Please read entire manual before installation. Before You Start • Disconnect negative battery terminal. Consult a qualified technician for instructions. • Avoid installing the unit where it would be subject to high temperatures, such as from direct sunlight, or where it would be subject to dust, dirt or excessive vibration. -
Page 3: Wiring Diagram
Connect to an amplifier input Antenna Connector 10 AMP FUSE AGC Fuse When replacing the fuse, make sure new fuse is the correct type and amperage. Using an incorrect fuse could damage the radio. The MXD105 uses one 10 amp AGC fuse located in-line. -
Page 4: Control Locations - Receiver
MXD105 OPERATION Control Locations - Receiver Release Preset 3 / Intro Power Preset 2 / Random Volume Knob Preset 1 / Repeat Audio / Menu Display USB Port Tune Up Auxiliary Input Tune Down Preset 6 / Folder Up Band / Go Back... -
Page 5: Control Locations - Remote
MXD105 OPERATION Control Locations - Remote Power Volume Down Volume Up Tune Down Tune Up Mode... -
Page 6: General Operation
SD and USB modes will not appear unless an SD Card is inserted or a USB device is connected. The MXD105 offers a 3.5 mm auxiliary input port on the front Auxiliary Input panel of the unit for connecting an audio device, MP3 player, etc. -
Page 7: Setup Menu
MXD105 OPERATION General Operation - Setup Menu Menu Function Options Action Auto Station Press SELECT to seek and save 6 strong stations in the AUTO STORE Store current band. (Tuner mode only) LOCAL OFF Activates distance tuning (Tuner mode only). Local/Distance Activates local tuning for strong station reception only (Tuner ... - Page 8 MXD105 OPERATION General Operation Audio Press AUDIO/MENU momentarily to select between Bass, Treble, Balance and Fader. BASS MIDDLE TREBLE BALANCE FADER LOUDNESS SOURCE LEVEL SUBWOOFER FREQUENCY SUBWOOFER Bass Press AUDIO/MENU until BASs appears then rotate volume knob left/right to adjust ( -7 minimum / +7 maximum).
- Page 9 MXD105 OPERATION AM/FM Tuner Operation Seek Tuning Press TUNE or TUNE momentarily to seek to the next strong station. Manual Tuning Press and hold TUNE or TUNE until "MANUAL" appears, then press TUNE or TUNE momentarily to change radio frequency up or down one step at a time.
-
Page 10: Usb / Sd Card Operation
Connecting a USB Device To play MP3/WMA files from most USB mass storage (sold separately) devices, line up the USB connector and insert the USB device into the MXD105's USB port. Inserting an SD Card To play MP3/WMA/WAV files from an SD card, insert an SD (sold separately) card into the SD card slot with the label facing left. - Page 11 MXD105 OPERATION USB / SD Card Operation Character Support Maximum character display information • Track name – 64 character maximum • Directory name – 64 character maximum • *Song title – 64 character maximum • *Artist name – 64 character maximum • *Album name – 64 character maximum *Song title, artist name and album name will only be displayed if included with the MP3/WMA file.
- Page 12 MXD105 OPERATION USB / SD Card Operation Additional MP3/WMA Only MP3 files with filename extension (.mp3) can be played. Information Only WMA files with filename extension (.wma) can be played. Do not attempt to play non-MP3/WMA files with the MP3/WMA extension. Sampling Frequency Rates 8kHz ~ 48kHz 8kHz ~ 48kHz Transfer Bit rates...
-
Page 13: Troubleshooting
MXD105 OPERATION Troubleshooting Problem Cause Action Yellow wire not connected or incorrect Check connections for proper voltage Red wire not connected or Unit will not turn on voltage (11~16VDC) incorrect voltage (no power) Black wire not connected Check connection to ground Fuse blown Replace fuse... -
Page 14: Limited One Year Warranty
2. If you require service during the the original purchase. warranty period, you must carefully pack the product (preferably in the Dual Electronics Corp. agrees, at our original package) and ship it by prepaid option, during the warranty period, transportation with a copy of the original... -
Page 15: Fcc Compliance
MXD105 OPERATION FCC Compliance This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 16: Specifications
MXD105 OPERATION Specifications FM Tuner Tuning range: 87.5MHz-107.9MHz Usable sensitivity: 8.5dBf 50dB quieting sensitivity: 10dBf Stereo separation @ 1kHz: >30dB Frequency response: 30Hz-13kHz AM Tuner Tuning range: 530kHz-1710kHz Usable sensitivity: <42dBu Frequency response: 30Hz-2.2kHz General Speaker output impedance: 4~8 ohms Line output voltage: 2 Volts RMS... - Page 17 MXD105 OPERATION Notes...
- Page 18 Dual Electronics Corp. Toll Free: 1-866-382-5476 9AM-5PM EST, Monday-Friday www.dualav.com ©2014 Dual Electronics Corp. All rights reserved. Other trademarks and trade names are those of their respective owners. NSA0114-V01...
