T
ECHNICAL INFORMATION
Models No.
Description
C
ONCEPTION AND MAIN APPLICATIONS
Model 4101RH is sister version of the existing Model 4101R.
Model 4101RH complies with CE- regulation.
Its brief benefits are;
* More endulable and longer life motor
* Equiped with earth leakage breaker
on power supply cord
S
pecifications
Voltage (V)
230
No Load Speed
Dimension of
Digmond wheel
Insulation class
Net weight
Power supply cord
Max.cutting capacity
Bevel angle
90°
45°
S
tandard equipment
Wrench 22
Hex.Wrench 5
Wrench Holder 5.6
Plug
Vinyl Tube 5X7X5000
Diamond Wheel 110(wet)
<Note>The standard equipment may differ from contry to country.
O
ptional accessories
Diamond wheel 110 (Wet)
Guide Rule
Wing bolt M5xlO (for attaching Guide Rule)
F
eatures and benefits
See the sheets attached for more information.
4101RH
125 mm(5") Cutter
Current (A)
Cycle (Hz)
50/60
4
Outer dis.
Arbor dis.
Dianmond wheel:110mm(4-3/8")
34mm(1-3/8")
21mm(13/16")
1 pc.
1 pc.
1 pc.
1 pc.
1 pc.
1 pc.
Continuous Rating (W)
Input
860
12000rpm
110mm(4-3/8")~125mm(5")
20mm(3/4)
Single
2.9kg(6.4lbs)
3.0m(9.8ft)
Dianmond wheel:125mm(5")
New Tool
Max. Output(W)
Output
580
1200
41.5mm(1-5/8")
26mm(1")

Advertisement

loading

Related Manuals for Makita 4101RH

Summary of Contents for Makita 4101RH

  • Page 1 4101RH Description 125 mm(5") Cutter ONCEPTION AND MAIN APPLICATIONS Model 4101RH is sister version of the existing Model 4101R. Model 4101RH complies with CE- regulation. Its brief benefits are; * More endulable and longer life motor * Equiped with earth leakage breaker...
  • Page 2 Speclally designed covers prevent water More endurable,more powerful, from intruding into motor housing. and longer life motor. Earth Leakage Breaker Vinyl tube Hex. Socket head bolt is removed by Hex.Wrench 5 which can be hold at wrench holder on cord guard. 90"~45"...
  • Page 3 epair Same as 4101R, except the following items 1) In disassembling Motor housing and Gear housing ( See the illustration below ) a) Loosen Pan head screw M5x8, and detach Cover B. b) As Lead unit is earthed to Gear housing, remove Pan head screw M4X8. c) When having removed the screws in three points, Motor housing and Gear housing are dismantled.
  • Page 4 4) In Water-proof cover A, install it so that there may be no gap between the meeting faces with Motor housing. Handle cover Water-proof cover B Motor housing Put Cover B into the Pan head projection for sure. screw M5x8 Gear housing Convex Fan guide...
