BASIC CABINET SETUP
A.
Refer to DATA PLATE for electrical requirements. Cabinets rated at 120V 1440W must
be plugged into either a 15 amp or 20 amp 125VAC receptacle. Cabinets rated at 120V
2000W must be plugged into a 20 amp 125VAC receptacle and used on an individual
branch circuit. Cabinets rated at 220-240V must be plugged into a 15 amp 250VAC
receptacle.
B.
With POWER switch OFF, plug into VAC grounded receptacle.
C.
Fill stainless water pan to top with clean HOT tap water for Proofing or if moisture is
desired for Holding. Check water level every 3 hours (2 hours when Proofing) and
refill with clean HOT tap water as necessary. Water pan does not have to be filled for
Holding. Proofing requires water pan to be filled.
HOLDING INSTRUCTIONS (Holding, Combo, Moisture Holding)
1)
Set Combination Module switch to HOLD.
2)
Set POWER switch to the ON position.
3)
Set TEMPERATURE control to 10.
4)
Moisture Module Only: Set MOISTURE control to 10 (or desired level).
5)
Pre-heat cabinet until desired temperature is reached (typical heat-up time from 72°
(22°C) ambient to 160° (71°C) is approximately 45 minutes).
6)
Re-set TEMPERATURE control and adjust as necessary to reach desired temperature -
setting 6-8 is typical for 150° (66°C) to 160° (71°C). Indicator light will turn on and off as
the heat thermostat cycles.
PROOFING INSTRUCTIONS (Combo and Proofing)
1)
Set Combination Module switch to PROOF.
2)
Set POWER switch to the ON position.
3)
Set TEMPERATURE control to 2.
4)
Set MOISTURE control to 10.
5)
Pre-heat cabinet until desired temperature and humidity is reached (typical heat-up
time from 72° (22°C) ambient to 95° (35°C) and 95% relative humidity is approximately
30 minutes).
6)
Adjust settings as necessary to reach desired temperature and humidity levels. Power
indicator lights will turn on and off as the heat and moisture thermostats cycle.
STAINLESS WATER PAN MUST BE PLACED INSIDE CABINET DURING
MODULE OPERATION. PLASTIC DRIP PAN MUST BE PLACED UNDER THE
FRONT BUMPER DRIP TROUGH OF THE CABINET.
UNPLUG CABINET FROM WALL AND ALLOW CABINET (AND WATER) TO
COOL BEFORE CLEANING OR SERVICING.
DO NOT SPRAY OR POUR WATER ON THE MODULE WHEN CLEANING AND
DO NOT IMMERSE THE MODULE IN WATER. WIPE WITH A DAMP CLOTH
AND DRY WITH A TOWEL.
KEEP CABINET AND MODULE CLEAN. ACCUMULATION OF GREASE AND
OTHER DRIPPINGS MAY IGNITE.
3 & 1 SERIES
