Features
Large stainless steel tank
Suspendible basket
Drainage valve
2 x industrial grade
ultrasonic transducers
2 x ceramic heaters
3 x colour LED display
Independent control circuit
for each ultrasonic transducer
Multiple circuit protectors
Moisture-proofed PCB with
industrial IC
2 x cooling fans
Degas feature
Engineering grade plastics
Professional Ultrasonic Cleaner
Tank capacity 6.0 L / 1.6 gallon;
Tank size 32.5 x 20.5 x 9.9 cm / 12.7" x 8.1" x 3.9"
Patented design, basket can be raised and
suspended to drain water
Convenient to use
Uniform distribution of ultrasonic waves,
strong cleaning, high durability
Mounted underneath the bottom of the tank for safe
and even heating; more durability construction
1 to 30-minute full range timer, 5 temperature settings, actual
temperature thermometer, degas and solution usage timer
40% higher efficiency, not susceptible to
interference, more durable
When overloaded or improperly used, the protectors
shut down the power to certain areas to protect the machine
Capable for different working environments with better
anti-interference performance
One for cooling of PCB boards, one for cooling of ultrasonic
transducers. Improve heat dissipation and beneficial for
continuous operations
Removes air bubbles quickly
Better water-proof and drop-proof properties
User Manual
14/05/047-V1
Advertisement
Table of Contents
Related Manuals for James ULTRA 9020
Summary of Contents for James ULTRA 9020
- Page 1 14/05/047-V1 Professional Ultrasonic Cleaner User Manual Features Large stainless steel tank Tank capacity 6.0 L / 1.6 gallon; Tank size 32.5 x 20.5 x 9.9 cm / 12.7” x 8.1” x 3.9” Suspendible basket Patented design, basket can be raised and suspended to drain water Drainage valve Convenient to use...
-
Page 2: Table Of Contents
INTRODUCTION Use tap water. Special solutions are not necessary in most cases. Principles of ultrasonic cleaning: Millions of tiny air bubbles are generated within liquid by high frequency vibration. The air bubbles burst when in contact with object and dislodge the debris to achieve the cleaning effect. •... -
Page 3: Safety Precautions
SAFETY PRECAUTIONS Keep it away from children! This appliance can be used by children aged from 8 years and above if they have been given supervision or instruction concerning use of the appliance in a safe way and if they understand the hazards involved. -
Page 4: Items Not Suitable For Ultrasonic Cleaning
SAFETY PRECAUTIONS Other observations: • Do not operate the product without filling the tank with water. Running dry will damage the unit. • Do not plug in the power cord before adding water to the tank. To avoid overspill, do not fill the tank above the ‘Max’... -
Page 5: Applications
APPLICATIONS 1. Metal Processing Manufacturers and Jewellery Makers: - Ultrasonic cleaning can remove grease or abrasive powder from work-in- process metal items and keep them clean. - Jewellery made with investment casting often has wax layer in addition to debris. Turning on the heater will raise the water temperature, melt the wax and improve the cleaning. -
Page 6: Applications 3
APPLICATIONS 7. Watch and Precision Metal Part Manufacturers: Machined watch components and other precision metal parts often have coolant and debris left on the surfaces. Ultrasonic cleaning can remove the debris and keep the parts clean. 8. Shooting Clubs To reuse brass cartridges: Adding special solution such as SeaClean2 solution can make fired brass casings useable and like new again. -
Page 7: Applications 3
APPLICATIONS 12. Homes: Silverware, silver, copper or brass decorations: It’s difficult to clean debris hidden in the patterns with regular methods. Ultrasonic cleaning with 50ml (3 tablespoons) of dish soap will clean the debris quickly. For silver, copper or brass items with oxidation which has darkened the items, adding small amount of SeaClean2 solution helps to remove oxidation and using ultrasonic cleaning will restore the shine. -
Page 8: Sample Applications
SAMPLE APPLICATIONS JEWELLERY PERSONAL ITEMS MEDICAL / DENTAL Eyeglasses, sunglasses, Necklaces, rings, Surgical instruments, shaver heads, watch bands, earrings, bracelets, etc. pliers, handpieces, etc. diver’s watches, dentures, etc. PRECISION PARTS SILVER, COPPER OR BRASS BABY ITEMS Bearings, gears, valves, Silverware, silver, copper or Toys, baby items, tools, fuel injectors, etc. -
Page 9: Product Structure And Accessories
PRODUCT DETAIL A. Top cover B. Stainless steel tank C. Housing D. Drainage pipe fitting E. Drainage valve handle F. Control panel Plastic Basket G. Handles H. Power switch I. Power socket J. Cover holder Hose Power Cord Optional Accessory Indirect cleaning tank Size: 21.7x18.5x7.4 cm Capacity: 2.1 L... -
Page 10: Product Explosion View
PRODUCT EXPLODED VIEW... - Page 11 Item Material Top handle Lid-window Lid-top Lid-bottom Top ring Stainless steel handle SUS 304 Basket foldable handle 1 Basket foldable handle 2 Plastic basket Left up handle Left down handle Silicone seal Silicone rubber Left cover Stainless steel tank SUS 304 Front cover Spout SUS 304...
-
Page 12: Control Panel And Operations
CONTROL PANEL AND OPERATIONS – Working Time Display. It counts down after work is started. – Multistage Thermometer. Solid green light indicates that the water temperature is 0-30% of the set temperature. Solid orange light indicates that the water temperature is 30-60% of the set temperature. -
Page 13: Common Cleaning Methods
13. On/Off Button. After powering on, the LED displays which is the default time as shown in picture, and the unit is ready with the normal working status. Press On/Off button once and the cleaning starts. The cleaning stops when the timer counts down to . - Page 14 INDIRECT CLEANING Put the items in a separate container. Use ultrasonic waves to penetrate the container to do the cleaning. Suitable Locations: medical instrument sterilisation rooms, precision electrical parts manufacturers, watch and precision parts manufacturers, mobile phone and electronics service shops, large printing shops.
- Page 15 4. Turn the power switch on. Press Temp button to set the water temperature to 45ºC (113ºF). Press Heater button to turn on the heater, flashes. Close the lid. LED lights up. When water reaches the set temperature, dims, indicating the heater is turned off. Warm water and dishwashing liquid can soften grease and improve cleaning efficiency.
-
Page 16: Operation Guidelines
OPERATING GUIDELINES Remove the cover and put it on the cover holder vertically. Put items in the basket then put them in the cleaning tank. Add water to a level between “MIN” and “MAX” and above the area to be cleaned. If the unit is turned on without water, ultrasonic energy will not be absorbed. - Page 17 Select one of the 4 cleaning methods recommended earlier. a. When the heater is needed, press TEMP button to select one of the 5 preset temperatures. Press Heater button, flashes, indicating the heater is turned on. When the water reaches the set temperature, dims, indicating the heater is turned off.
-
Page 18: Care And Maintenance
CARE AND MAINTENANCE Do not turn on the unit without water in the tank. Even though the unit is designed with multiple protections, if it is turned on for over 30 seconds without water in the tank, it may damage the unit or severely reduce the life of the unit. -
Page 19: Usage Guide For Accessories
Add chemicals or special solutions (SeaClean2) in the indirect cleaning tank. Cleaning efficiency can reach 90% of direct cleaning. SPECIFICATIONS Description Professional Ultrasonic Cleaner Model ULTRA 9020 Tank Capacity 6.0 L / Max. 5.0 L / 1.3 gallon (US) 1.6 gallon (US) Min. 3.35 L / 0.9 gallon (US) Tank Size 32.3 x 20.5 x 9.9 cm / 12.7”... - Page 20 *Repair or replacement is at the discretion of the manufacturer. www.jamesproducts.co.uk Registered in England No. 5250754 Registered Office: James Products Ltd, Unit 1, Church Close Business Park, Todber, Sturminster Newton, Dorset DT10 1JH, England...
