Features
Large stainless steel tank
Touch Screen Control Panel
Drainage valve
3 x industrial grade
ultrasonic transducers
3 x ceramic heaters
3 x colour LED display
Independent control circuit
for each ultrasonic transducer
Multiple circuit protectors
Moisture-proofed PCB with
industrial IC
3 x cooling fans
Solid and advanced structural
design
Professional Ultrasonic Cleaner
Tank capacity 7.5 L / 2.0 gallon;
Tank size 33.1 x 23.8 x 10.5 cm / 13.0" x 9.4" x 4.1"
Glass top panel with capacitive sensing technology. Durable,
reliable, resistant to water and harch chemicals
Convenient to use
Uniform distribution of ultrasonic waves,
strong cleaning, high durability
Mounted underneath the bottom of the tank for safe
and even heating; more durability construction
Easy to operate, with 4 key control panel,
6 timer settings, 3 temperature settings
40% higher efficiency, not susceptible to
interference, more durable
When overloaded or improperly used, the protectors
shut down the power to certain areas to protect the machine
Capable for different working environments with better
anti-interference performance
Two for cooling of PCB boards, one for cooling of ultrasonic
transducers. Improve heat dissipation and beneficial for
continuous operations
4.5mm thick wall housing made from engineering grade plastic
with tongue and groove design for better water-proof and drop-
proof performances. 60% quieter than steel housing designs.
User Manual
15/05/114-V1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for James 9050 Touch
Summary of Contents for James 9050 Touch
- Page 1 15/05/114-V1 Professional Ultrasonic Cleaner User Manual Features Large stainless steel tank Tank capacity 7.5 L / 2.0 gallon; Tank size 33.1 x 23.8 x 10.5 cm / 13.0” x 9.4” x 4.1” Touch Screen Control Panel Glass top panel with capacitive sensing technology. Durable, reliable, resistant to water and harch chemicals Drainage valve Convenient to use...
-
Page 2: Sample Applications
SAMPLE APPLICATIONS JEWELLERY PERSONAL ITEMS MEDICAL / DENTAL Necklaces, rings, Shaver heads, hairdressing Surgical instruments, earrings, bracelets, etc. scissors & combs, etc. pliers, handpieces, etc. PRECISION PARTS SILVER, COPPER OR BRASS BABY ITEMS Bearings, gears, valves, Silverware, silver, copper or Toys, baby items, tools, fuel injectors, etc. -
Page 3: Table Of Contents
INTRODUCTION Use tap water. Special solutions are not necessary in most cases. Principles of ultrasonic cleaning: Millions of tiny air bubbles are generated within liquid by high frequency vibration. The air bubbles burst when in contact with object and dislodge the debris to achieve the cleaning effect. •... -
Page 4: Safety Precautions
SAFETY PRECAUTIONS Keep it away from children! This appliance can be used by children aged from 8 years and above if they have been given supervision or instruction concerning use of the appliance in a safe way and if they understand the hazards involved. -
Page 5: Items Not Suitable For Ultrasonic Cleaning
SAFETY PRECAUTIONS Other observations: • Do not operate the product without filling the tank with water. Running dry will damage the unit. • Do not plug in the power cord before adding water to the tank. To avoid overspill, do not fill the tank above the ‘Max’... -
Page 6: Product Detail
PRODUCT DETAIL A. Top cover F. Drainage pipe fitting B. Handles G. Drainage valve handle C. Stainless steel tank H. Cover holder D. Housing I. Power switch E. Control panel J. Power socket I N C LU DE D A C C E S S O RI E S Power Cord Hose O PT I O NA L A C C ES S O R I E S... -
Page 7: Control Panel And Operations
CONTROL PANEL AND OPERATIONS – Working Time Display. It counts down after work has started. – Multistage Thermometer. Solid green light indicates that the water temperature is 0-30% of the set temperature. Solid orange light indicates that the water temperature is 30-60% of the set temperature. -
Page 8: Applications
APPLICATIONS 1. Metal Processing Manufacturers and Jewellery Makers: - Ultrasonic cleaning can remove grease or abrasive powder from work-in- process metal items and keep them clean. - Jewellery made with investment casting often has wax layer in addition to debris. Turning on the heater will raise the water temperature, melt the wax and improve the cleaning. -
Page 9: Applications
APPLICATIONS 7. Special Education Institutes / Kindergartens: Speech therapy tools or small toys that are reused need to be cleaned to prevent the growth and spread of bacteria. Ultrasonic cleaning can perform thorough cleaning by removing debris hidden inside small holes and crevices before disinfection. -
Page 10: Common Cleaning Methods
COMMON CLEANING METHODS REGULAR CLEANING Only tap water is needed. Suitable Locations: Jewellery makers, biology / chemical labs, homes, speech therapy clinics, dental clinics, automotive repair shops. Cleaning Method: 1. Put the items to be cleaned inside the basket and put the basket inside the tank. - Page 11 ENHANCED CLEANING Debris accumulated over a long period of time, greasy or heavily soiled. Suitable Locations: metal processing and jewellery makers, hardware manufacturers, shooting clubs, automotive repair shops. Cleaning Method: 1. Large items can be put in the tank directly. Small items can be put in the basket, then put in the tank.
-
Page 12: Operation Guidelines
OPERATING GUIDELINES Remove the cover and put it on the cover holder vertically. Put the items in the basket then put them in the cleaning tank. Add water to a level between “MIN” and “MAX” and above the area to be cleaned. If the unit is turned on without water, ultrasonic energy will not be absorbed. - Page 13 Select one of the four cleaning methods recommended earlier. 1. When the heater is needed, press the Temp button to select one of the 3 preset temperatures. Press Heater button, flashes, indicating the heater is turned on. When the water reaches the set temperature, dims, indicating the heater is turned off.
-
Page 14: Care And Maintenance
CARE AND MAINTENANCE Do not turn on the unit without water in the tank. Even though the unit is designed with multiple protections, if it is turned on for over 30 seconds without water in the tank, it may damage the unit or severely reduce the life of the unit. -
Page 15: Optional Accessory Usage Guide
OPTIONAL ACCESSORY USAGE GUIDE PLASTIC BASKET The basket has foldable handles. It can be raised and suspended above the water to drain. STAINLESS STEEL RACK AND TRAY The rack can be used to support cassettes. 2 layers of cassettes can be used on top of each other. -
Page 16: Specification
LIMITED WARRANTY Consequential and incidental damages, including without limitation, loss of property and those arising from breach of any express or implied warranty, are not the responsibility of James Products Limited and to the extent permitted by law, are excluded.
