BEC 8800N Setup Manual

Wireless vdsl modem
Hide thumbs Also See for 8800N:

Advertisement

Quick Links

Download this manual See also: User Manual
Configuring a BEC 8800N
Wireless VDSL Modem

Setting Up the PC

|
Logging into BEC
|
Setup
Configuring Wireless
|
Finished
Setting Up the PC
Before you can get into your new BEC 8800N Wireless modem, you will need to have the computer's ethernet interface
to be set up for DHCP, or you will have to set up a static IP address.
Use the following address information if setting up a static IP in the computer's ethernet interface:
IP ADDRESS: 192.168.10.100
SUBNET MASK: 255.255.255.0
GATEWAY: 192.168.10.1
PRIMARY DNS: 216.129.224.1
SECONDARY DNS: 216.220.0.1
Back to Top

Advertisement

loading

Related Manuals for BEC 8800N

Summary of Contents for BEC 8800N

  • Page 1: Setting Up The Pc

    Setting Up the PC Before you can get into your new BEC 8800N Wireless modem, you will need to have the computer's ethernet interface to be set up for DHCP, or you will have to set up a static IP address.
  • Page 2 Logging Into the BEC 8800N In order to log in, open a web browser (Internet Explorer works best for this), and in the address bar type in the following IP address. 192.168.10.1 After you input the IP address, press the "GO" button or press "ENTER" on your keyboard to access the page. If everything goes as anticipated, you will see a login screen prompting for username and password (Above).
  • Page 3 Setup After logging into the modem's home page, click the "Configuration" link at the left of the page to begin configuring your modem. Back to Top...
  • Page 4 Next you need to click on the "WAN" link at the left of the page. Back to Top...
  • Page 5 Next click on the “WAN Service” link at the left of the page. Now check the “Remove/Edit” checkbox and click the "Edit" button. Back to Top...
  • Page 6 "IP over Ethernet" option for the "Select WAN service type" should already be selected. Click the "Next" button to continue. Back to Top...
  • Page 7 the customer is DHCP then leave the "IPv4 Protocol" dropdown box on the default option of "Obtain an IP Address Automatically" and click the "Next" button. the customer has a static IP then change the "IPv4 Protocol" dropdown box to "Fixed IP Address"...
  • Page 8 In this section enable "Firewall" by checking the associated "Enable" checkbox and then click the "Next" button. Back to Top...
  • Page 9 Here "CurrentWAN/CurrentWAN" should already be selected for the “Selected WAN Interface”. Click the "Next" button to continue. Back to Top...
  • Page 10 If the customer is DHCP then leave the "DNS Type" set to "Obtain DNS info from a WAN Interface". If the customer has a static IP then choose "Use the following Static DNS IP address" from the "DNS Type" dropdown box, then fill in the following information: Primary DNS server ( 216.129.224.1 ) Secondary DNS server...
  • Page 11 Almost Done! Now click the "Apply/Save" button to save all our changes. Back to Top...
  • Page 12 Configuring Wireless To get to the wireless section click "LAN" on the left side of the page and then click the "Wireless" link under that. Now enter the "SSID" for the customer and click the "Apply" button. You may have to scroll down to see the "Apply"...
  • Page 13 To setup the wireless security click on the "Security" link on the left side of the page under "Wireless". The "Select SSID" should show the SSID you entered on previous page. WPA Pre-Shared Key By default, the modem is programmed to use the MAC address (lowercase letters) which is listed on the underside of the modem as the WPA key.
  • Page 14 Finished Now you are done configuring your BEC 8800N modem! You may need to powercycle the modem. Once it syncs up again, the Internet will be ready for use. Congratulations! You are now done configuring your BEC 8800N Wireless VDSL modem.
