WHAT'S IN THE BOX
Wideband
MX-100U
Antennas
Screw x 7pcs
Washer x 6pcs
(M4*L8mm)
USB 3.0 Connector
BEC USB Connector
(male-to-male)
MX-1000 M2M Router
Bracket
Round-Head Screw
USB Connector
4pcs (3Ψ*12mm)
(Male to Male)
w/ screw x 4pcs (4.5mm)
DEVICE OVERVIEW
AUX
Auxiliary Antenna
SMA Female Connector
APPLICATION DIAGRAM
PC / Laptop
Model: MX-100U
Quick Install Guide
Accessory
Options
SIM Slots
(Single Module, Dual SIM)
SIM1
GPS Antenna
SMA Female Connector
(OPTION)
Standard 2.0/3.0 USB Cable
Kiosk, Vending,
OEM Design Applications,
and more.
Embedded System
M
M
2
MAIN
SIM2
Main Antenna
SMA Female Connector
Control Manager
Windows platform:
Use Sierra Wireless
Skylight, connection utility,
to manage the MX-100U.
Contact your BEC Sales
representative for more
information.
