For y our own safety, please read th is us er manual c arefull y be fore your init iall y
st art -up!
Every person involved with the installation, operation and maintenance of this device has to
- be qualified
- follow the instructions of this manual
- consider this manual to be part of the total product
- keep this manual for the entire service life of the product
- pass this manual on to every further owner or user of the product
- include every supplementary update with the original manual
Before your initial start-up, please make sure that there is no damage caused during shipment.
Should there be any, do not use the device and consult your supplier.
SAFETY INSTRUCTIONS
This device has left our premises in absolutely perfect condition. In order to maintain this
condition and to ensure a safe operation, it is absolutely necessary for the user to follow the safety
instructions and warning notes written in this user manual.
Important: Damages caused by the disregard of this user manual are not subject to warranty. The
dealer will not accept liability for any resulting defects or problems.
GLG Lighting products
Creator Picollo RGBWAuV
USER MANUAL
CAUTI ON!
Kee p th is devi ce a way fr om r ai n a nd mo i stur e!
Un pl ug mai ns l ea d b efo re op en in g th e h ousin g!
1
Advertisement
Table of Contents
Related Manuals for GLG creator picollo rgbwauv
Summary of Contents for GLG creator picollo rgbwauv
-
Page 1: User Manual
Creator Picollo RGBWAuV USER MANUAL CAUTI ON! Kee p th is devi ce a way fr om r ai n a nd mo i stur e! Un pl ug mai ns l ea d b efo re op en in g th e h ousin g! -
Page 2: Operating Determinations
Please use the original packaging if the device is to be transported. Please consider that unauthorized modifications on the device are forbidden due to safety reasons! If this device will be operated in any way different to the one described in this manual, it may GLG Lighting products... -
Page 3: Control Panel
This device can be installed directly onto a truss, wall or stage floor in any orientation without altering its operation characteristics. Use proper bolts to mount the device via its brackets. The brackets should be attached to the GLG Lighting products... - Page 4 If you are using controllers with this occupation, you can connect the DMX-output of The controller directly with the DMX-input of the 1st device in the DMX-chain. If you wish to connect DMX-controllers with other XLR-outputs, you need to use adapter-cables. GLG Lighting products...
- Page 5 The control panel on the device allows you to control the device, including DMX start address setting, Automatic operation setting, Manuel dimmer, Rainbow effect setup, etc. Display window The device use a 4-digits red color LED display module for displaying your setting. The module can display some simple letters and figures. GLG Lighting products...
- Page 6 4) [C1--], [C2--], [C3--].….This is manual dimmer of the 5 colors. See page 8. 5) [ACC] or [FADE]. This is automatic operation. See below. 6) [Reset]. This is the loading of the factory default settings. See page 11. GLG Lighting products...
-
Page 7: Auto Operation
Press Up or Down button to select C1, C2, C3, C4 or C5. Press the Enter button, the last 2 digits in the display will show 00-12. This is the level of the manual dimmer. Press Enter button to save or press Menu button to exit. GLG Lighting products... -
Page 8: Dmx Operation
DMX operation The GLG Creator DLX series gives you the possibility to set the spot in different user modes. When you connect a DMX signal to the spots the display will indicate this with a dot on the display. Mode 1: 5 channels. - Page 9 Press the Up/Down button until it shows AXXX in the display. XXX is the address you set last time. Press Enter button. Press Up/Down button to select your desired address, e.g. A001. Press Enter button to save or press Menu button to exit. GLG Lighting products...
-
Page 10: Factory Default Setting
1. All screws used for installing the devices or parts have to be tightly connected and must not be corroded. 2. There must not be any deformations on the housing, fixations and installation spots (ceiling, suspension, trussing, etc.) GLG Lighting products... -
Page 11: Technical Specifications
Auto programs / Manuel setting DMX 512 control, 12 channels max. Dimmension: Net weight: Gross weight: 3,5kgs Please note: Every information is subject to change without prior notice. GLG is a brand of Goed Licht en Geluid. The Netherlands. www.goedlichtengeluid.nl GLG Lighting products...
