- Page 1 GLG L IGHT ING E QUIPM E NT USER MANUA L Pastello Minibeam MKII www.goedlichtengeluid.nl info@goedlichtengeluid.nl...
-
Page 2: Table Of Contents
GLG LIGHTING EQUIPMENT CONTENTS General information Safety instructions Trait and skill specifications Operation panel Dimensional drawings Photometric data Mounting and Installation Power supply and Signal connection Display menu 10. DMX traits Circuit connecting diagram Trouble dispose 13. Cleaning and Maintenance 14. -
Page 3: General Information
GLG LIGHTING EQUIPMENT 1. GENERAL INFORMATION INTRODUCTION: Congratulations, you have just purchased one of the most innovative and reliable LED fixtures on the market today. Our company has been designed to perform reliably for years when the guidelines in this booklet are followed. Please read and understand the instructions in this manual carefully and thoroughly before attempting to operate this unit. -
Page 4: Safety Instructions
GLG LIGHTING EQUIPMENT 2. SAFETY INSTRUCTIONS Notice: To guarantee proper and consistent operation, it is important to follow the guidelines in this manual. Our company will not accept responsibility for damages resulting from the misuse of this fixture due to the disregard of the information printed in this manual. -
Page 5: Trait And Skill Specifications
GLG LIGHTING EQUIPMENT 3. PERFORMANCE TRAIT AND SKILL SPECIFICATIONS ◎ Voltage：AC100~240V 50/60Hz. ◎ Power：118W. ◎ LED chip：10W，RGBW 4 in 1 LED chip. ◎ LED QTY：7PCS. ◎ LED life：50000H. ◎ Lens degree：standard 8°. ◎ Beam angle:12°. ◎ Color: RGBW macro color system. - Page 6 GLG LIGHTING EQUIPMENT ◎ Other feature : 1.Extend IP address function , each IP address maximum can set 64 2.Support DMX signal priority identification, when lose the signal it would be turn into Black , default scene , Automatic function etc according to your set.
-
Page 7: Operation Panel
GLG L IGHT ING E QUIPM E NT 4. OPERATION PAN EL 5. DIMENSIONAL D R AWI NGS www.goedlichtengeluid.nl info@goedlichtengeluid.nl... -
Page 8: Photometric Data
GLG LIGHTING EQUIPMENT 6. PHOTOMETRIC DATA 7. MOUNTING AND INSTALLATION Cautions: For added protection mount the fixtures in areas outside walking paths, seating areas, and away from areas were unauthorized personnel might reach the fixture. Before mounting the fixture to any surface, make sure that the installation area can hold a minimum point load of 10 times the device's weight. - Page 9 GLG LIGHTING EQUIPMENT Mounting Our company is fully operational in any mounting position, hanging upside-down, side mounted, or set on a flat level surface, etc. Be sure this fixture is kept at least 0.5m (about 1.6feet) away from any flammable materials (decoration etc.).
-
Page 10: Power Supply And Signal Connection
GLG L IGHT ING E QUIPM E NT 8. POWER SUPPLY AND SIGNAL C ONN ECT I ON 1. Power supp ly Use the professional plug to connect the projector and main power supply. Please pay attention to the voltage, freque ncy the same as the mentioned on the projector. - Page 11 GLG L IGHT ING E QUIPM E NT speaking, DMX terminator is an XLR connector with a 120 1/2w resistor connected across pin 2 and 3.Which is then plugged into the output socket on the last projector in the chain. Refer to the connection as above:(Picture ).We suggest using the DMX signal di s tributor when the...
- Page 12 GLG LIGHTING EQUIPMENT 9. DISPLAY MENU Remark Ⅰ M enu Ⅱ M enu Ⅲ Menu DMX Address 001-512 Fixture ID 000-064 Standard（9CH） Default Channel mode Extended（15CH） Wired input Default DMX input mode Wireless input Reset wireless Hold Black D.scene Program 1...
- Page 13 GLG LIGHTING EQUIPMENT Remark Ⅰ Ⅱ Ⅲ M enu M enu Menu Power on time ****H Fixture times Lamp on time ****H Fixture LAMP_TEM ***℃ temperatures 3888:******** RDM UID 1. Dimmer 0-255 2. Dimmer fine 0-255 3. Shutter 0-255 4. Red 0-255 5.
- Page 14 GLG LIGHTING EQUIPMENT www.goedlichtengeluid.nl info@goedlichtengeluid.nl...
- Page 15 GLG LIGHTING EQUIPMENT Ⅳ Ⅰ Ⅱ Ⅲ Remark M enu M enu Menu Menu Default PT swap Default Pan invert Pan/Tilt Default Tilt invert Exit Default DMX reset System reset Reset Exit PERSON Quick Open closedown Close P/T angle Close...
-
Page 16: Display Menu
GLG LIGHTING EQUIPMENT Ⅳ Remark Ⅰ Ⅱ Ⅲ M enu M enu Menu Menu English(英文) Default Display Chinese （ 中文) language Light always Default 2 minutes Display sleep 4 minutes 6 minutes Display PERSON 10-100 Default:50 Display intensity Default Display... - Page 17 GLG LIGHTING EQUIPMENT Remark Ⅰ Ⅱ Ⅲ M enu M enu Menu 0-255 Dimmer 0-255 Dimmer fin 0-255 Shutter 0-255 0-255 Green 0-255 Blue 0-255 White 0-255 Macro colo MANUAL 0-255 0-255 Pan fine 0-255 Tilt 0-255 Tilt fine 0-255...
- Page 18 GLG LIGHTING EQUIPMENT Ⅳ Ⅰ Ⅱ Ⅲ M enu M enu Menu Menu Scene 0-100 0-255 Dimmer 0-255 Dimmer fin 0-255 Shutter 0-255 0-255 Green 0-255 Blue 0-255 White 0-255 Macro colo Edit program 1 0-255 0-255 Pan fine 0-255...
- Page 19 GLG LIGHTING EQUIPMENT Ⅳ Ⅰ Ⅱ Ⅲ M enu M enu Menu Menu Start step 0-100 End step 0-100 Set program 1 Step time 0-255 Save Exit Set program 2 Same as Set program 1 Set program Set program 3...
-
Page 20: Dmx Traits
GLG LIGHTING EQUIPMENT 10、DMX TRAITS Channel Effect values Dimmer 0-255 0-100 Dimmer fine 0-255 0-100 Unused range Light→dark ， s low→fast 10-49 4-19 Dark→light ， s low→fast 50-89 20-34 Shutter Dark→light→dark ， s low→fast 90-119 35-46 120-179 47-70 Random fast→slow strobe... - Page 21 GLG LIGHTING EQUIPMENT Channel Effect values Unused range 10-14 Complete reset 15-19 Open 20-24 Close Fixture 25-29 10-11 Quick open control 30-34 12-13 Quick close 35-239 14-93 Unused range 240-244 94-95 Tilt 245-249 96-97 250-255 98-100 Unused range Calibration 0-255...
- Page 22 GLG LIGHTING EQUIPMENT Channel E f f e c t values ID is(3*n)+2 effective,(n=0-20) 204-206 80-81 2 、 5 、 8 、 1 1 、 1 4 … 6 2 ID is(3*n)+3 effective,(n=0-20) 207-209 81-82 3 、 6 、 9 、 1 2 、 1 5 … 6 3...
- Page 23 GLG LIGHTING EQUIPMENT Channel E f f e c t values ID is(6*n)+2 effective,(n=0-10) 240-242 94-95 2 、 8 、 1 4 、 2 0 、 2 6 … 6 2 ID is(6*n)+3 effective,(n=0-10) 243-245 95-96 3 、 9 、 1 5 、 2 1 、 2 7 … 6 3...
-
Page 24: Circuit Connecting Diagram
GLG LIGHTING EQUIPMENT 11. CIRCUIT CONNECTING DIAGRAM www.goedlichtengluid.nl info@goedlichtengeluid.nl... -
Page 25: Trouble Dispose
GLG LIGHTING EQUIPMENT 12. TROUBLE DISPOSE It is recommended some solution for some normal trouble shooting. Any inextricability problems should always be handling by the professional person. Disconnect the power supply before maintenance the light. ●LED off： 1. Please check if install the suitable voltage 2. -
Page 26: Cleaning And Maintenance
GLG LIGHTING EQUIPMENT 13. CLEANING AND MAINTENANCE ■1. In order to ensure the projector could work normally. It should be kept clean always .The lens should also be regularly cleaned to maintain an optimum light output. Do not use any type of solvent on lens.
