FASD700 aspirated smoke detector
installation manual
version 3-0 / january 2005
WWW.UKPANELS.COM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FASD700 and is the answer not in the manual?

Questions and answers

Summary of Contents for GE Security FASD700

  • Page 1 Security FASD700 aspirated smoke detector installation manual version 3-0 / january 2005 WWW.UKPANELS.COM...
  • Page 2 © 2005 GE Interlogix B.V.. All rights reserved. GE Interlogix B.V. grants the right to reprint this manual for internal use only. GE Interlogix B.V. reserves the right to change information without notice. FASD700 aspirated smoke detector – Installation manual WWW.UKPANELS.COM...
  • Page 3: Table Of Contents

    Panel installation ........................... 7 Pipe installation ..........................7 External connections........................7 User guide .............................. 8 Selecting and programming functions................... 8 FASD710 / FASD712 operation....................9 FASD715 / FASD717 operation....................11 Maintenance............................14 Technical specifications........................15 FASD700 aspirated smoke detectors – Installation manual WWW.UKPANELS.COM...
  • Page 4: Introduction

    NTRODUCTION 1.1 Product description The FASD700 range of aspirated smoke detectors includes: FASD710 and FASD712 panels (conventional or analogue addressable detectors). FASD715 and FASD717 panels (laser detectors). All panels are IP50 rated. An optional IP65 rating is available to allow use in many harsh environments and where regular hosing is performed.
  • Page 5: Installation

    1. Mains power supply (left to right: earth, neutral, live) 2. Temperature sensor 3. Battery 4. Channel 1 relays (left to right: fire, action, fault) 5. Channel 2 relays (left to right: fire, action, fault) 6. External reset FASD700 aspirated smoke detectors – Installation manual WWW.UKPANELS.COM...
  • Page 6: Detector Installation

    Figure 4: FASD710 / FASD712 analogue addressable detector connection 1. To 24 VDC power supply 4. Relay contact 2. Loop in to fire panel 5. To detector 1 3. Loop out to fire panel 6. To detector 2 FASD700 aspirated smoke detector – Installation manual WWW.UKPANELS.COM...
  • Page 7: Panel Installation

    24 VDC External loop disconnect alarm relay (optional) I/O module (optional) 2.5.2 FASD715 / FASD717 panels Mains supply 24 VDC Alarm relays RS232 Isolate External loop disconnect alarm relay (optional) I/O module (optional) FASD700 aspirated smoke detectors – Installation manual WWW.UKPANELS.COM...
  • Page 8: User Guide

    3. Press the SELECT key. 4. Repeat steps 1 to 3 until the complete access code (510) has been entered. The Unlocked LED will flash when the code has been entered correctly. FASD700 aspirated smoke detector – Installation manual WWW.UKPANELS.COM...
  • Page 9: Fasd710 / Fasd712 Operation

    1. Power 6. Fan fault 2. General fault 7. Bar graph of airflow speed 3. Mains fault 8. Code entry 4. Battery low 9. Unlocked 5. Airflow ok / high / low FASD700 aspirated smoke detectors – Installation manual WWW.UKPANELS.COM...
  • Page 10 LED flashes (Fan and Power LEDs flash during calibration). Exit function selection and return to normal mode. A 20 second time- out function will also exit calibration mode. 3.2.3 Unit alarms Airflow or Power fault (1 relay). FASD700 aspirated smoke detector – Installation manual WWW.UKPANELS.COM...
  • Page 11: Fasd715 / Fasd717 Operation

    FASD712 panels (see Figure 5) with the following additions. Figure 6: FASD715 / FASD717 front panel and display LEDs 1. Alert alarm 4. Smoke detector fault 2. Action alarm 5. Isolate 3. Fire alarm 6. Reset FASD700 aspirated smoke detectors – Installation manual WWW.UKPANELS.COM...
  • Page 12 3.3.3 Unit alarms CH1 FIRE; CH1 ACTION; CH2 FIRE; CH2 ACTION (4 relays). CH1 smoke detector, airflow or power Fault (1 relay). CH2 smoke detector, airflow or power Fault (1 relay). FASD700 aspirated smoke detector – Installation manual WWW.UKPANELS.COM...
  • Page 13 These are also the levels at which the alarms can be set. Table 3: Bar graph levels Bar graph LED Obscuration % / metre 0.065 0.098 0.164 0.327 0.655 1.637 3.273 4.887 6.516 FASD700 aspirated smoke detectors – Installation manual WWW.UKPANELS.COM...
  • Page 14: Maintenance

    To change the filter: 1. Remove the panel cover. 2. Remove the filter from the acrylic housing. 3. Insert the new filter. 4. Replace the panel cover. FASD700 aspirated smoke detector – Installation manual WWW.UKPANELS.COM...
  • Page 15: Technical Specifications

    Table 4: Fan speed / supply current with 20 m pipe length and 6 mm end hole Fan speed Supply current (mA) Figure 7: Static Pressure and CFM graph for fan at 2600 rpm and 3600 rpm FASD700 aspirated smoke detectors – Installation manual WWW.UKPANELS.COM...
  • Page 16 1052955 WWW.UKPANELS.COM...
