Page 4: Table Of Contents
Contents Overview Comfort Visibility Ventilation Lighting controls Rear screen demist/defrost LED daytime running lamps Heating Cornering lighting Manual air conditioning Headlamp adjustment Dual-zone digital air conditioning Wiper controls Scented air freshener Courtesy lamps Front seats Boot lamp Eco-driving Rear seats Mirrors Steering wheel adjustment Monitoring...
Page 5 Contents Technical data Checks Safety Direction indicators Bonnet Petrol engines Hazard warning lamps Petrol weights Running out of fuel (Diesel) Horn Petrol engines Diesel engines Under-inflation detection Diesel weights Diesel engine Braking assistance systems Checking levels Dimensions Identification markings Trajectory control systems Checks Front seat belts Airbags...
Page 6 Overview Exterior Rear parking sensors / Reversing camera Glass panoramic sunroof These two systems warn you if an obstacle is detected behind the vehicle This roof provides incomparable visibility and when reversing. light in the passenger compartment. 137 / 139 ASR and DSC systems Guide-me-home lighting These systems are linked to assure the...
Page 7 Overview Interior Dual-zone digital air Scented air freshener conditioning This air freshener diffuses the fragrance This system allows you to set a different that you have selected throughout the level of comfort for the driver and front passenger compartment by means of its passenger.
Page 8: Instruments And Controls
Overview Instruments and controls Cruise control / speed limiter switches. 2. Steering wheel adjustment control. 3. Lighting and direction indicator control stalk. 4. Instrument panel. 5. Driver's airbag. Horn. 6. Gear lever. Bonnet release. 8. Door mirror controls. Electric window controls. Rear electric windows and doors deactivation control.
Page 9 Overview Instruments and controls Steering lock and ignition. 2. Audio equipment steering mounted control stalk. 3. Wiper / screenwash / trip computer control stalk. 4. Central adjustable air vents. 5. Storage. Navigation screen and scented air freshener. 6. Sunshine sensor. Passenger's airbag.
Page 10 Eco-driving Eco-driving Eco-driving is a range of everyday practices that allow the motorist to optimise their fuel consumption and CO emissions. Optimise the use of your gearbox Control the use of your electrical equipment With a manual gearbox, move off gently and change up without waiting. Before moving off, if the passenger compartment is too warm, ventilate it by opening the windows and air vents before using the air conditioning.
Page 11 Eco-driving Limit the causes of excess consumption Observe the recommendations on maintenance Spread loads throughout the vehicle; place the heaviest items in the Check the tyre pressures regularly, when cold, referring to the label in bottom of the boot, as close as possible to the rear seats. the door aperture, driver's side.
Page 12: Instrument Panel
Monitoring Petrol - Diesel instrument panel Multifunction screen Panel grouping together the digital indicator, the multifunction screen and the vehicle operation indicator and warning lamps. This screen groups together the warning and information messages. Indicator lamps display zone This zone groups together the vehicle Translucent digital instrument panel operation indicator lamps.
Page 13: Indicator And Warning Lamps
Monitoring Indicator and warning lamps Visual indicators informing the driver that a system is in operation (operation or deactivation indicator lamps) or of the occurrence of a fault (warning lamp). When the ignition is switched on Associated warnings Certain warning lamps may come on in one of two different modes.
Page 14 Monitoring Warning/indicator lamp is on Cause Action / Observations fixed. The front foglamps are switched on Turn the ring on the lighting control stalk rearward Front foglamps twice to switch off the front foglamps. using the ring on the lighting control stalk.
Page 15 Monitoring Warning/indicator lamp is on Cause Action / Observations fixed. The control switch, located at the Turn the control switch to the "OFF" position to Passenger airbag system passenger's end of the dashboard, is in deactivate the front passenger's airbag. You can install a rearward facing child seat on the the "ON"...
Page 16 Monitoring Deactivation indicator lamps If one of the following indicator lamps comes on, this confirms that the corresponding system has been switched off intentionally. This is may be accompanied by an audible signal and a message in the multifunction screen. Warning/indicator lamp is on Cause...
Page 17 Monitoring Warning lamps When the engine is running or the vehicle is Any fault resulting in the illumination of a warning lamp must be investigated further by reading the being driven, the illumination of one of the associated message in the multifunction screen. following warning lamps indicates a fault which If you encounter any problems, do not hesitate to contact a CITROËN dealer or a qualified workshop.
Page 18 Monitoring Warning/indicator lamp is on Cause Action / Observations fixed, associated with Braking The braking system fluid level is too You must stop as soon as it is safe to do so. the STOP warning low. Top up with brake fluid recommended by CITROËN. lamp.
Page 19 Monitoring Warning/indicator lamp is on Cause Action / Observations fixed. Low fuel level When it first comes on there remains You must refuel as soon as possible to avoid running approximately 5 litres of fuel in the out of fuel. This warning lamp will come on every time the ignition tank.
Page 20 Monitoring Warning/indicator lamp is on Cause Action / Observations fixed if the speed is Door(s) open A door or the boot is still open. Close the door or boot. below 6 mph (10 km/h). fixed and accompanied by an audible signal if the speed is above 6 mph (10 km/h).
Page 21 Monitoring Warning/indicator lamp is on Cause Action / Observations fixed, accompanied by Under-inflation The pressure in one or more tyres is Check the tyre pressures as soon as possible. too low. This check should preferably be carried out when the an audible signal and a message.
Page 22 Monitoring Warning/indicator lamp is on Cause Action / Observations fixed, on switching ® Have the AdBlue ® AdBlue additive The remaining driving range is additive tank topped up as soon between 350 miles (600 km) and (BlueHDi Diesel) on the ignition, as possible: go to a CITROËN dealer or a qualified workshop, or carry out this operation yourself.
Page 23 Monitoring Warning/indicator lamp is on Cause Action / Observations fixed, on switching A fault with the SCR emissions This alert disappears once the exhaust emissions SCR emissions control system on the ignition, control system has been detected. return to normal levels. associated with the (BlueHDi Diesel) SERVICE and engine...
Page 24: Indicators
Monitoring Indicators Service indicator More than 1 800 miles (3 000 km) Less than 600 miles (1 000 km) remain before the next service is due remain before the next service is due When the ignition is switched on, no service Example: 560 miles (900 km) remain before the next service is due.
Page 25 Monitoring Service overdue For 5 seconds after the ignition is switched on, The distance remaining may be the spanner flashes to indicate that the service weighted by the time factor, depending must be carried out as soon as possible. on the driving conditions. Example: the service is overdue by 180 miles Therefore, the spanner may also come (300 km).
Page 26 Monitoring Resetting the service indicator If you have to disconnect the battery following this operation, lock the vehicle and wait at least five minutes for the reset to be registered. Retrieving the service information You can access the service information at any time.
Page 27: Engine Oil Level Indicator
Monitoring Engine oil level indicator* On versions fitted with an electric oil level Oil level correct Oil level indicator fault gauge, information on the engine oil level is displayed for a few seconds in the instrument panel when the ignition is switched on, after the service information.
Page 28: Distance Recorders
Monitoring Distance recorders Lighting dimmer Total distance recorder System for manual adjustment of the brightness of the instruments and controls to suit the ambient light level. It measures the total distance travelled by the vehicle since its first registration. The total and trip distances are displayed for thirty seconds when the ignition is switched off, when the driver's door is opened and when the vehicle is locked or unlocked.
Page 29: Multifunction Screens
Multifunction screens Monochrome screen A (without audio equipment) Displays in the screen Controls Main menu F Press the "MENU" button to scroll through the various menus of the main menu: - vehicle configuration, - options, This displays the following information: - display adjust, There are three display control buttons: - language,...
Page 30 Multifunction screens Display adjust Language Once the "Display adj" menu has been selected, Once the "Language" menu has been you can gain access to the following settings: selected, you can change the language used year, by the display by selecting a language from the month, list offered.
Page 31: Monochrome Screen A
Multifunction screens Monochrome screen A Displays in the screen Controls Main menu F Press the "MENU" button for access to the main menu, then press the "5" or "6" buttons to scroll through the various menus: - radio-CD, This displays the following information: From the audio equipment control panel, you - vehicle configuration, time,...
Page 32 Multifunction screens Display adjust Once the "Display adjust" menu has been selected, Setting the date and time you can gain access to the following settings: F Press the MENU button F Select "Display adjust" using the "5" year, month, or "6" button. F Press OK to confirm the selection.
Page 33 Multifunction screens Language As a safety measure, configuration of the multifunction screen by the driver Once the "Language" menu has been must only be done when stationary. selected, you can change the language used by the display, by choosing a new language from the list offered.
Page 34 Multifunction screens Monochrome screen A associated with the eMyWay colour screen Displays in screen A Main menu F Press the "MENU" button to scroll through the various menus of the main menu: - vehicle configuration, This displays the following information: Controls - options, ambient temperature (this flashes if there is...
Page 35 Multifunction screens Options Units Once the "Options" menu has been selected, Once the "Units" menu has been selected, you can change the units of the following you can start diagnostics of the status of the equipment (active, not active, faulty). parameters: Vehicle configuration temperature (°C or °F),...
Page 36 Multifunction screens Displays in the eMyWay system colour screen Display configuration This menu allows you to choose a colour scheme for the display screen, adjust the brightness, the date and time, and choose the units for distance (km or miles), fuel consumption (l/100 km, mpg or km/l) and temperature (°Celsius or °Fahrenheit).
Page 37 Multifunction screens Adjusting the voice synthesis Trip computer This menu allows you to adjust the volume for This menu allows you vies information on the state of the vehicle. You can choose between the navigation instructions and choose the type the following functions: of voice (male or female).
Page 38 Multifunction screens Monochrome screen C Displays in the screen Controls Main menu F Press the "MENU" button for access to the main menu: - audio functions, - trip computer (refer to the end of the This displays the following information: section), From the audio equipment control panel, you - personalisation-configuration,...
Page 39 Multifunction screens "Audio functions" "Trip computer" menu menu With the audio equipment switched on, once F Press the "MENU" button for access to the Once this menu has been selected, you can this menu has been selected you can activate consult information concerning the status of the main menu.
Page 40 Multifunction screens "Personalisation- Configuration" menu F Press the "7" or "8" buttons to set the Once this menu has been selected, you can gain access to the following functions: value required (15, 30 or 60 seconds), then press the "OK" button to confirm. define the vehicle parameters, Example: setting of the duration of the guide- display configuration,...
Page 41: Telephone Menu
Multifunction screens Telephone menu Display configuration Choice of language With the Audio system on and this menu selected, you can configure your Bluetooth Once this menu has been selected, you can Once this menu has been selected, you can hands-free system (pairing), view the various gain access to the following settings: change the language used by the display, by telephone directories (calls log, services...) and...
Page 42: Trip Computer
Multifunction screens Trip computer System that gives you information on the current journey (range, fuel consumption…). Monochrome screen A The trip computer provides the following F The next press returns you to the current information: display. - range, Zero reset - current fuel consumption, Information displays - distance travelled,...
Page 43 Multifunction screens Monochrome screen C the trip "2" tab with: ● the distance travelled, ● the average fuel consumption, ● the average speed, for the second trip. F Pressing the button again returns you to Information displays the normal display. F Press the button, located at the end of the wiper stalk, to display the various trip computer tabs in succession:...
Page 44 Multifunction screens Trip computer, a few definitions Current fuel Range Distance travelled consumption (miles or km) (miles or km) The distance which can still be (mpg or l/100 km or km/l) Calculated since the last trip Calculated over the last few seconds. travelled with the fuel remaining computer reset.
Page 45: Comfort
Comfort Ventilation System which creates and maintains comfortable conditions in the vehicle's passenger compartment. Air intake The air circulating in the passenger compartment is filtered and originates either from the outside via the grille located at the base of the windscreen or from the inside in air recirculation mode.
Page 46 Comfort Recommendations for ventilation and air conditioning In order for these systems to be fully effective, follow the guidelines on operation and The condensation created by the air maintenance below: conditioning results in a discharge of water under the vehicle which is F If the interior temperature remains very high after the vehicle has been parked in the sun for a considerable time, first ventilate the passenger compartment for a perfectly normal.
Page 47: Rear Screen Demist/Defrost
Comfort Rear screen demist/defrost The control button is Switching off located on the heating The demist/defrost switches off automatically to or air conditioning prevent an excessive consumption of current. system control panel. F It is possible to stop the demist/defrost operation before it is switched off automatically by pressing the button again.
Page 48: Heating
Comfort Heating / Ventilation Manual air conditioning 3. Air distribution adjustment Windscreen and side windows. Windscreen, side windows and footwells. Footwells. The heating / ventilation or air conditioning systems can only operate with the engine running. 2. Air flow adjustment 1.
Page 49 Comfort 4. Air intake / Air recirculation 5. Air conditioning On / Off The intake of exterior air prevents the formation of mist on the windscreen and side windows. The air conditioning is designed to The recirculation of interior air isolates the operate effectively in all seasons, passenger compartment from exterior odours with the windows closed.
Page 50: Dual-Zone Digital Air Conditioning
Comfort Dual-zone digital air conditioning The air conditioning only operates when the engine is running. Automatic operation 1. Automatic comfort programme 2. Driver's side adjustment 3. Passenger's side adjustment F Press the "AUTO" button. The The driver and front passenger can indicator lamp in the button each adjust the temperature to their comes on.
Page 51: Manual Operation
Comfort Manual operation If you wish, you can make a different choice 4. Automatic visibility 5. Air conditioning On / Off programme from that offered by the system by changing a setting. The other functions will still be F Press this button to switch off The automatic comfort programme controlled automatically.
Page 52: Switching The System Off
Comfort Switching the system off F Turn the air flow control to the left until all 6. Air distribution adjustment 8. Air intake / Air recirculation of the indicator lamps go off. This action switches off the air conditioning and F Press one or more buttons to F Press this button for recirculation direct the air flow towards:...
Page 53: Scented Air Freshener
Comfort Scented air freshener System permitting the diffusion of a fragrance in the passenger compartment in accordance with your requirements, by means of the adjustment dial and the various fragrance cartridges available. Adjustment dial Fragrance cartridge This cartridge can be removed easily. Removing the cartridge You can change it at any time and store it in the F Press the dial and turn it a quarter of a turn...
Page 54: Front Seats
Comfort Front seats Seat consisting of a seat cushion, a seat back and a head restraint which can all be adjusted to adapt your position for ease of driving and comfort. Forwards-backwards adjustment Driver's seat height adjustment Seat back angle adjustment F Pull the control lever upwards to raise F Push the control rearwards.
Page 55 Comfort Additional adjustments Head restraint height adjustment Adjusting the armrest The head restraint is fitted with a frame with notches which prevents it from F To raise the head restraint, pull it upwards. F Press the control located under the front lowering;...
Page 56 Comfort Heated seats control With the engine running, the front seats can be heated separately. F Use the adjustment dial, placed on the side Table position of the front Do not forget to fold the "aircraft" type of each front seat, to switch on and select passenger seat table fixed on the back of the seat first.
Page 57: Rear Seats
Comfort Rear seats Each section (1/3 - 2/3) can be adjusted individually. Forwards and backwards adjustment Seat back angle adjustment Head restraint adjustment F Raise the control and slide the seat The seat can be adjusted to 2 different The 1/3 - 2/3 rear seat is fitted with head forwards or backwards.
Page 58 Comfort Fully-folded position F Move the corresponding front seat forward When putting back in position, take care if necessary. not to jam the seat belts. F Put the rear seat in the fully back position. F Place the head restraints in the low position.
Page 59: Mirrors
Comfort Mirrors Door mirrors Folding F From outside: lock the vehicle using the remote control or the key. F From inside: with the ignition on, pull the control A in the central position rearwards. If the mirrors are folded using control A, they will not unfold when the vehicle is unlocked.
Page 60: Steering Wheel Adjustment
Comfort Steering wheel adjustment Rear view mirror Adjustable mirror providing a central rearward view. Equipped with an anti-dazzle system, which darkens the mirror glass and reduces the nuisance to the driver caused by the sun, headlamps from other vehicles... Manual day/night model Automatic day/night model F When stationary, pull the control lever to release the adjustment mechanism.
Page 61: Access
Access Remote control key System which permits central unlocking or locking of the vehicle using the door lock or from a distance. It is also used to locate and start the vehicle, as well as providing protection against theft. Unlocking the vehicle Unlocking using the key Locking is confirmed by fixed lighting of F Turn the key to the left in the driver's door...
Page 62 Access Remote control problem Following disconnection of the vehicle battery, Changing the battery replacement of the remote control battery or in the event of a remote control fault you can no longer unlock, lock or locate your vehicle. F First of all, use the key in the lock to unlock or lock your vehicle.
Page 63: Remote Control
Access Do not throw the remote control Lost keys batteries away, they contain metals Go to a CITROËN dealer with the vehicle's registration document, your personal which are harmful to the environment. identification documents and if possible the key code label. Take them to an approved collection The CITROËN dealer will be able to look up the key code and the transponder code point.
Page 64: Window Controls
Access Window controls System which opens or closes a window Electric windows One-touch electric manually or automatically. It is fitted with windows anti-pinch protection if an obstacle is detected F Press or pull the switch. The There are two methods on the one-touch models and a deactivation window stops as soon as the system to prevent misuse of the rear switches...
Page 65 Access Reinitialisation In the event of a malfunction you must reinitialise Safety anti-pinch the operation of the electric windows: The one-touch electric windows are fitted with F release the switch and pull it again until the a safety anti-pinch function. window closes completely, When the window rises and meets an obstacle, F hold the switch for approximately...
Page 66: Doors
Access Doors Opening Closing When a door is not closed correctly: when the engine is running, this warning lamp comes on, accompanied by a message in the multifunction screen for a few seconds, when the vehicle is moving (speed higher than 6 mph (10 km/h)), this warning lamp comes on, accompanied by an audible signal and a message in the multifunction screen for a few seconds.
Page 67: Automatic Central Locking
Access Manual central locking Unlocking Automatic central locking control System which provides full automatic locking F Press button A again to unlock the vehicle. or unlocking of the doors and the boot while System which provides full manual locking or The red indicator lamp on the button switches off.
Page 68: Emergency Control
Access Emergency control System which locks or unlocks the doors mechanically in the event of a malfunction of the battery or of the central locking. In the event of a fault with the central locking, you must disconnect the battery to lock the boot and so ensure the complete locking of the vehicle.
Page 69: Boot
Access Boot Opening Closing Tailgate release F Lower the tailgate using the interior grab System for mechanical unlocking of the boot in the event of a battery or central locking handle. malfunction. If the tailgate is not closed correctly: when the engine is running, this warning lamp comes on, accompanied by a message on the multifunction screen for a few...
Page 70: Panoramic Sunroof
Access Panoramic sunroof System which consists of an area of panoramic tinted glass to increase the light and visibility in the passenger compartment. It is fitted with 2 independent manual blinds to help maintain a comfortable temperature. Opening Closing F Raise the blind's handle and release. Front blind F Pull the blind rearwards until it locks in.
Page 71: Fuel Tank
Access Fuel tank Fuel tank capacity: approximately 50 litres Filling (petrol) or 48 litres (Diesel); (Depending on A label affixed to the inside of the flap reminds version: approximately 30 litres (petrol or you of the type of fuel to be used depending on Diesel)).
Page 72 Access Fuel used for petrol Fuel used for Diesel engines engines The petrol engines are compatible with The Diesel engines are compatible with biofuels which conform to current and future E10 bio-petrol (containing 10 % ethanol), European standards (Diesel fuel which conforming to European standards EN 228 and complies with standard EN 590 mixed with EN 15376.
Page 73: Misfuel Prevention (Diesel)
Access Misfuel prevention (Diesel)* Mechanical device which prevents filling the tank of a Diesel vehicle with petrol. It avoids the risk of engine damage that can result from filling with the wrong fuel. Located in the filler neck, the misfuel prevention device appears when the filler cap is removed. It remains possible to use a fuel can to fill the tank.
Page 74: Visibility
Visibility Lighting controls System for selection and control of the various front and rear lamps providing the vehicle's lighting. Manual controls The lighting is controlled directly by the driver by means of the ring A and the stalk B. Main lighting Model without AUTO lighting A.
Page 75 Visibility When the lighting is switched off automatically C. Foglamp selection ring. The foglamps operate with the dipped and main (with AUTO model) or when the dipped headlamps are switched off manually, the beam headlamps. Model with rear foglamp only foglamps and sidelamps will remain on.
Page 76 Visibility Manual guide-me-home lighting Lighting on audible warning The temporary illumination of the dipped beam headlamps after the vehicle's ignition has been When the ignition is switched off, all switched off makes the driver's exit easier of the lamps switch off automatically, when the light is poor.
Page 77: Automatic Illumination Of Headlamps
Visibility Automatic illumination of headlamps Linked with the Guide-me-home Operating fault lighting The sidelamps and dipped beam headlamps are In the event of a malfunction of the switched on automatically, without any action on the part Association with the automatic illumination sunshine sensor, the lamps come of the driver, when a low level of external light is detected on, this warning lamp is displayed...
Page 78: Led Daytime Running Lamps
Visibility LED daytime running lamps Allowing the signature of the vehicle to be identified, this daytime external lighting comprises two sets of light emitting diodes (LEDs), located below each front lamp unit. Setting In countries where daytime lamps For countries where exterior lighting by day is are a legal requirement: this function is activated by default;...
Page 79: Cornering Lighting
Visibility Cornering lighting With dipped or main beams, this function Switching on makes use of the beam from a front foglamp This function starts: to illuminate the inside of a bend, when the when the corresponding direction indicator vehicle speed is below 25 mph (approximately is switched on, 40 km/h) (urban driving, winding road, intersections, parking manouevres...).
Page 80: Headlamp Adjustment
Visibility Headlamp adjustment Travelling abroad If using your vehicle in a country that drives on the other side of the road, the headlamps must be adjusted to avoid dazzling on-coming drivers. Contact a CITROËN dealer or a qualified workshop. To avoid causing a nuisance to other road users, the height of the halogen headlamps should be adjusted according the load in the vehicle.
Page 81: Wiper Controls
Visibility Wiper controls The vehicle's front and rear wipers are Model with intermittent wiping Manual controls designed to improve the driver's visibility The wiper commands are issued directly by the progressively according to the weather driver by means of the stalk A and the ring B. conditions.
Page 82 Visibility B. Rear wiper selection ring: park, intermittent wipe, Wiping zone wash-wipe (set duration). Rear wiper The curved shape of the rear screen results in a smaller wiping zone. Reverse gear If a significant accumulation of snow or ice is present, or when using a tailgate When reverse gear is engaged, the rear wiper Windscreen wash bicycle carrier, deactivate the automatic...
Page 83 Visibility Automatic rain sensitive Vertical windscreen wiper windscreen wipers position The windscreen wipers operate automatically, It is accompanied by a message in the without any action on the part of the driver, if rain screen. is detected (sensor behind the rear view mirror), The automatic rain sensitive wipers adapting their speed to the intensity of the rainfall.
Page 84: Courtesy Lamps
Visibility Courtesy lamps Selection and control of the various passenger compartment lamps. Front and rear courtesy lamps In permanent lighting mode, different In this position, the courtesy lamp lighting times are available: comes on gradually: with the ignition off, approximately ten minutes, when the vehicle is unlocked, in energy economy mode,...
Page 85: Boot Lamp
Visibility Boot lamp Courtesy lamp with mood lighting LED Switching on The LED comes on with illumination - manual or automatic - of the sidelamps or dipped or main beam. Switching off This comes on automatically when the boot is The courtesy lamp LED goes off: when the sidelamps or dipped or main opened and goes off automatically when the...
Page 86: Fittings
Fittings Front interior fittings Sun visor. 2. Child surveillance mirror. 3. Grab handle with coat hook. 4. Navigation screen and scented air freshener. Storage 5. Storage compartments. 6. Glove box. Storage pockets. 8. Open storage compartment at side of passenger seat. 9.
Page 87: Sun Visor
Fittings Sun visor Child surveillance mirror Glove box Provides protection against sunlight from the front or the side. This has areas for storing a bottle of water, the A child surveillance mirror is installed above the interior rear view mirror. This allows you vehicle's handbook, ...
Page 88 Fittings 12 V accessory socket Storage drawer F To use the 12 V socket (max power: It is located under the front passenger seat. 100 Watts), lift the cap and connect the accessory. Opening F Raise the front of the drawer and pull it. The connection of an electrical device not approved by CITROËN, such as a USB charger, may adversely affect the...
Page 89 Fittings Ticket holder Mats Removable carpet protection. Refitting To refit the mat on the driver's side: F position the mat correctly, F refit the fixings by pressing, F check that the mat is secured correctly. It is located at the top of the dashboard centre panel.
Page 90: Rear Fittings
Fittings Rear interior fittings Seat pockets Cup holder Aircraft style tables They are located on the back of the front seats. There is a cup holder located at the rear of the Lift the catch to release the table and unfold it. centre console.
Page 91: Storage Tray
Fittings Individual reading lamps Side blinds Storage tray Blinds are available for the side windows. Reading lamps are built into the back of the When unfolded, this provides a storage area Pull the side blind longways by the tab to use it. front seats, behind the tables.
Page 92 Fittings Ski flap Device for storing and transporting long objects. Opening F Lower the storage shelf. F Press the flap opening control. F Lower the flap. F Check that the adjustable boot floor is in the high position. F Load the objects from inside the boot.
Page 93: Boot Fittings
Fittings Boot fittings Open storage compartments. 2. Adjustable boot floor. 3. Carrier bag hook. 4. Securing rings. 5. Storage space under boot carpet 6. Rear parcel shelf.
Page 94 Fittings 2-position adjustable boot Placing the adjustable boot floor Placing the adjustable boot floor The two-position adjustable boot floor allows you to: in the low position in the high position maximise the volume of the boot, F Lift the adjustable boot floor by pulling on F Lift the adjustable boot floor by pulling the partition the boot (stowing the rear shelf...), the strap.
Page 95 Fittings Hooks 2-panel rear parcel shelf Refitting the shelf The hooks can be used to hold shopping bags. The rear section is attached to the tailgate by two cords. From the boot: F position the shelf so that the two notches are directly above the fixing pins, Removing the shelf F push the shelf towards the inside of the...
Page 96: Child Safety
Child safety General points relating to child seats Although one of CITROËN main criteria when designing your vehicle, the safety of your children also depends on you. For maximum safety, please observe the CITROËN recommends that children following recommendations: should travel on the rear seats of your in accordance with European regulations, vehicle: all children under the age of 12 or less...
Page 97 Child safety Child seat at the rear Rearward facing Forward facing When a rearward facing child seat is installed When a forward facing child seat is installed on a rear passenger seat, move the vehicle's on a rear passenger seat, move the vehicle's front seat forward and straighten the backrest front seat forward and straighten the backrest so that the rearward facing child seat does not...
Page 98: Child Safety Child Seats
Child safety Child seat in the front* Rearward facing Forward facing When a rearward facing child seat is installed When a forward facing child seat is installed on Passenger seat adjusted to the intermediate longitudinal position. on the front passenger seat, adjust the seat to the front passenger seat, adjust the vehicle's the intermediate longitudinal position, with the seat to the intermediate longitudinal position...
Page 99: Deactivating The Passenger's Front Airbag
Child safety Deactivating the passenger's front airbag The warning label present on both sides of the Never install a rearward facing child passenger's sun visor repeats this advice. In restraint system on a seat protected by line with current legislation, the following tables an active front airbag.
Page 100 Child safety BG НИКОГА НЕ инсталирайте детско столче на седалка с АКТИВИРАНА предна ВЪЗДУШНА ВЪЗГЛАВНИЦА. Това може да причини СМЪРТ или СЕРИОЗНО НАРАНЯВАНЕ на детето. CS NIKDY neumisťujte dětské zádržné zařízení orientované směrem dozadu na sedadlo chráněné AKTIVOVANÝM čelním AIRBAGEM. Hrozí nebezpečí...
Page 101 Child safety LV NEKAD NEuzstādiet uz aizmuguri vērstu bērnu sēdeklīti priekšējā pasažiera sēdvietā, kurā ir AKTIVIZĒTS priekšējais DROŠĪBAS GAISA SPILVENS. Tas var izraisīt BĒRNA NĀVI vai radīt NOPIETNUS IEVAINOJUMUS. MT Qatt m’ghandek thalli tifel/tifla marbut f’siggu dahru lejn l-Airbag attiva, ghaliex tista’ tikkawza korriment serju jew anke mewt lit-tifel/tifla NL Plaats NOOIT een kinderzitje met de rug in de rijrichting op een zitplaats waarvan de AIRBAG is INGESCHAKELD.
Page 102 Child safety Child seats recommended by CITROËN CITROËN offers a range of recommended child seats which are secured using a three point seat belt. Group 0+: from birth to 13 kg "RÖMER Baby-Safe Plus" Installed in the rearward facing position. Groups 2 and 3: from 15 to 36 kg "KLIPPAN Optima"...
Page 103 Child safety Installing child seats secured using the seat belt In accordance with European regulations, this table indicates the options for installing child seats secured using a seat belt and universally approved (a) in accordance with the weight of the child and the seat in the vehicle. Weight of the child and indicative age Under 13 kg From 9 to 18 kg...
Page 104 Child safety When a rearward facing child seat is installed on a front passenger seat, the passenger's airbag must be deactivated. Otherwise, the child would risk being seriously injured or killed during deployment of the airbag. When a forward facing child seat is installed on the front passenger seat, the passenger's airbag must remain active.
Page 105: Isofix Child Seats
Child safety "ISOFIX" mountings Your vehicle is approved to the latest ISOFIX To secure the child seat to the TOP TETHER: remove and stow the head restraint before regulations. The seats represented below, are fitted with installing a child seat on this seat (refit it regulation ISOFIX mountings.
Page 106 Child safety ISOFIX child seat recommended by CITROËN and approved for your vehicle "RÖMER Duo Plus ISOFIX" (size category B1) Group 1: from 9 to 18 kg Installed only in the forwards facing position. Secured to rings A, as well as the third ring B, called the TOP TETHER, using the upper strap.
Page 107 Child safety Table of seating positions for ISOFIX child seats In accordance with European Regulations, this table indicates the options for installing ISOFIX child seats on seats in the vehicle fitted with ISOFIX mountings. In the case of universal and semi-universal ISOFIX child seats, the ISOFIX size category, determined by a letter from A to G, is indicated on the child seat next to the ISOFIX logo.
Page 108 Child safety Advice For optimum installation of the forward facing The incorrect installation of a child seat in a Installing a booster seat vehicle compromises the child's protection in child seat, ensure that the back of the child The chest part of the seat belt must be the event of an accident.
Page 109: Child Lock
Child safety Manual child lock Electric child lock Mechanical system to prevent opening of the Control system to prevent opening of the rear rear door using its interior control. doors using their interior controls and use of Unlocking the rear electric windows. The control is located on the edge of each rear The control is located on the driver's door, with door.
Page 110: Safety
Safety Hazard warning lamps Direction indicators Three flashes Visual warning with of all the direction indicators flashing to alert other road users to a Move the stalk briefly upwards or downwards, vehicle breakdown, towing or accident. without going beyond the point of resistance; the corresponding direction indicators will flash 3 times.
Page 111: Horn
Safety Under-inflation detection Horn Audible warning to alert other road users to an System which automatically checks the pressures of the tyres while driving. imminent danger. The system monitors the pressures in the four Driving with under-inflated tyres tyres, once the vehicle is moving. increases fuel consumption.
Page 112 Safety Under-inflation alert Reinitialisation This is given by fixed illumination of F In the event of a puncture, use the It is necessary to reinitialise the system every this warning lamp, accompanied by time one or more tyre pressure is adjusted, and temporary puncture repair kit or the spare wheel (depending on equipment), after changing one or more wheels.
Page 113 Safety The system is reinitialised with the ignition on and the vehicle stationary, via the vehicle configuration menu. Vehicles without audio or Vehicles with audio system navigation system F Press the MENU button for access to the F Press the MENU button for access to the F Press the "5"...
Page 114: Snow Chains
Safety Operating fault Snow chains The system does not have to be reinitialised after fitting or removing The flashing and then fixed illumination of the snow chains. under-inflation warning lamp accompanied by illumination of the Service warning lamp indicates a fault with the system. The under-inflation alert is only In this case, under-inflation monitoring of the dependable if the system has been...
Page 115: Braking Assistance Systems
Safety Braking assistance systems Group of supplementary systems which help Emergency braking assistance you to obtain optimum braking in complete System which, in an emergency, enables you Operating fault safety in emergency situations: to obtain the optimum braking pressure more anti-lock braking system (ABS), If this warning lamp comes on, quickly, thus reducing the stopping distance.
Page 116: Trajectory Control Systems
Safety Trajectory control systems Anti-slip regulation (ASR) Operating fault and dynamic stability The illumination of this warning lamp control (DSC) comes in the instrument panel and in the button, accompanied by an audible The anti-slip regulation (also known as traction signal and a message in the multifunction control) optimises traction to prevent skidding of screen, indicates a fault in these systems.
Page 117: Front Seat Belts
Safety Seat belts Front seat belts The front seat belts are fitted with a pretensioning and force limiting system. This system improves safety in the front seats in the event of a front or side impact. Depending on the severity of the impact, the pretensioning system instantly tightens the seat belts against the body of the occupants.
Page 118: Rear Seat Belts
Safety Rear seat belts The rear seats are each fitted with a three-point inertia reel seat belt with force limiter (with the exception of the rear centre seat). Fastening F Pull the strap, then insert the tongue in the buckle. F Check that the seat belt is fastened Locking correctly by pulling the strap.
Page 119 Safety row rear centre seat belt The seat belt for the rear centre seat of the row is incorporated at the rear left of the roof. Installation Removal and storing F Pull the strap and insert the tongue A in the F Press the red button on the buckle B, then left-hand buckle.
Page 120 Safety Advice The driver must ensure that passengers use In order to be effective, a seat belt must: Recommendations for children the seat belts correctly and that they are all be tightened as close to the body as Use a suitable child seat if the passenger is fastened before setting off.
Page 121: Airbags
Safety Airbags General information Front airbags System designed to contribute towards improving System which protects the driver and front the safety of the occupants (with the exception of passenger in the event of a serious front impact the rear centre passenger) in the event of violent in order to limit the risk of injury to the head and collisions.
Page 122 Safety Deactivation Operating fault If this warning lamp comes on in the Only the passenger's front airbag can be To assure the safety of your child, it is deactivated: instrument panel, you must contact imperative that the passenger's front F with the ignition off, insert the key in the a CITROËN dealer or a qualified airbag is deactivated when you install a workshop to have the system...
Page 123: Lateral Airbags
Safety Lateral airbags Curtain airbags System which protects the driver and front System which contributes towards improving passenger in the event of a serious side impact the protection of the driver and passengers (with the exception of the rear centre in order to limit the risk of injury to the chest, between the hip and the shoulder.
Page 124 Safety Advice For the airbags to be fully effective, observe the safety recommendations below: Sit in a normal upright position. Front airbags Wear a correctly adjusted seat belt. Do not leave anything between the Do not drive holding the steering wheel by its spokes or resting your hands on the centre part of the wheel.
Page 125: Driving
Driving Driving recommendations If you are obliged to drive through water: Observe the driving regulations and remain Important! vigilant whatever the traffic conditions. Pay close attention to the traffic and keep your hands on the wheel so that you are ready to Never drive with the parking brake react at any time to any eventuality.
Page 126: Starting-Switching Off The Engine
Driving Starting-switching off the engine Anti-theft protection Ignition switch Starting the engine F Apply the parking brake. Electronic engine immobiliser F With a manual gearbox: place the lever in The key contains an electronic chip which has neutral and fully depress the clutch pedal. a special code.
Page 127 Driving Switching the engine off Wait until this warning lamp goes off F Immobilise the vehicle. In temperate conditions, do not F With the engine at idle, turn the key fully in the instrument panel, then operate warm the engine up with the vehicle towards you to position 1 (Stop).
Page 128: Parking Brake
Driving Parking brake Releasing When you leave the vehicle, take the key with you and lock the vehicle. F Pull the parking brake lever gently, press the release button then lower the lever fully. Energy economy mode When the vehicle is being driven, if this warning lamp and the STOP warning lamp After switching off the engine (position 1 - Stop), come on, accompanied by an audible signal...
Page 129: Electronic Gearbox
Driving Electronic gearbox Six-speed electronically controlled gearbox Gear selector positions Steering mounted control paddles which offers a choice between the comfort of fully automatic operation or the pleasure of manual gear changing. There are two driving modes: automated mode for automatic control of the gears by the gearbox, without any action on the part of the driver manual mode for sequential gear changing...
Page 130: Display In The Instrument Panel
Driving Display in the instrument panel Moving off Automated mode F Select position N. F Select position A. F Press the brake pedal down fully. F Start the engine. AUTO and the gear engaged appear in the instrument panel screen. N appears in the instrument panel screen.
Page 131 Driving Manual mode Reverse F Select position M. Temporary control of gear To engage reverse gear R, the vehicle must be immobilised with your foot on the brake pedal. changing The gears engaged appear in F Select position R. You can temporarily take over control of succession in the instrument panel gear changing using the "+"...
Page 132 Driving Stopping the vehicle Operating fault Before switching off the engine, you can: With the ignition on, the flashing of AUTO, move to position N to engage neutral, accompanied by an audible signal and a message in the screen, indicates a malfunction leave the gear engaged;...
Page 133: Gear Efficiency Indicator
Driving Gear shift indicator* System which reduces fuel consumption by advising the driver to change up. Example: With an electronic gearbox, the system You are in third gear. is only active in manual mode. You press the accelerator pedal moderately. Operation In the case of driving which makes The system may suggest that you engage...
Page 134: Hill Start Assist
Driving Hill start assist (with electronic gearbox) Operation System which holds your vehicle temporarily (approximately 2 seconds) when starting on a slope, the time it takes to move your foot from the brake pedal to the accelerator pedal. This function is only active when: the vehicle is completely stationary, with your foot on the brake pedal, On an ascending slope, with the vehicle...
Page 135: Speed Limiter
Driving Speed limiter System which prevents the vehicle from Steering mounted controls Displays in the instrument panel exceeding the speed programmed by the driver. When the programmed speed limit is reached, pressing the accelerator pedal in the normal manner no longer has any effect. The speed limiter is switched on manually: it requires a programmed speed of at least 20 mph (30 km/h).
Page 136 Driving Programming Operating fault F Turn thumb wheel 1 to the "LIMIT" In the event of a speed limiter fault, the speed position: the speed limiter mode is cleared resulting in flashing of the dashes. is selected but is not switched on Have it checked by a CITROËN dealer or a qualified workshop.
Page 137: Cruise Control
Driving Cruise control System which automatically maintains the Steering mounted controls Displays in the instrument panel speed of the vehicle at the value programmed by the driver, without any action on the accelerator pedal. The cruise control is switched on manually: it requires a minimum vehicle speed of 25 mph (40 km/h) and the engaging of at least 4th gear.
Page 138 Driving Programming Operating fault F Turn dial 1 to the "CRUISE" position: In the event of a cruise control malfunction, the cruise control mode is selected the speed is cleared resulting in flashing of the but is not switched on (PAUSE). dashes.
Page 139: Rear Parking Sensors
Driving Rear parking sensors System comprising four proximity sensors, located in the rear bumper. When the distance between the rear of the vehicle This detects obstacles (person, vehicle, tree, Detection zone gate, etc.) behind the vehicle. However, it and the obstacle is less than thirty centimetres, the cannot detect obstacles located just below the audible signal becomes continuous and the "Danger"...
Page 140 Driving Deactivation Reactivation Press button A again to reactivate the system. The indicator lamp in the button goes off. If there is an operating fault, when reverse gear is engaged, the service warning lamp comes on, accompanied by an audible signal (short beep) and a message in the multifunction screen.
Page 141: Reversing Camera
Driving Reversing camera The space between the blue lines represents the A reversing camera is activated automatically The blue lines represent the general direction when reverse gear is engaged. width of your vehicle except for the door mirrors. of the vehicle. The colour image is provided in the navigation The red line represents a distance of about screen.
Page 142: Checks
Checks TOTAL & CITROËN Partners in performance and protecting the environment Innovation in the search for performance For over 40 year, the TOTAL Research and Development departments have developed lubricants for CITROËN, to match the latest technical innovations on CITROËN vehicles, both for competition and for everyday motoring.
Page 143: Bonnet
Checks Bonnet Opening Do not open the bonnet in high winds. When the engine is hot, handle the exterior safety catch and the bonnet stay with care (risk of burns). Closing F Push the exterior safety catch B to the left F Take the stay out of the support notch.
Page 144: Running Out Of Fuel (Diesel)
Checks Running out of fuel (Diesel) On vehicles fitted with HDi engines, the fuel system must be primed if you run out of fuel. BlueHDi engine If the engine does not start first time, F Fill the fuel tank with at least five litres of don't keep trying but start the procedure again from the beginning.
Page 145: Petrol Engines
Checks Petrol engines Screenwash fluid reservoir. 2. Coolant header tank. 3. Air filter. 4. Brake fluid reservoir. 5. Battery. 6. Fusebox. Engine oil dipstick. 8. Engine oil filler cap. To avoid damaging the electrical units, never use a high pressure jet wash in the engine compartment.
Page 146: Diesel Engine
Checks Diesel engine Screenwash fluid reservoir. 2. Coolant header tank. 3. Air filter. 4. Brake fluid reservoir. 5. Battery. 6. Fusebox. Engine oil dipstick. 8. Engine oil filler cap. The Diesel fuel system operates under high pressure: Never carry out any work on this system yourself.
Page 147: Checking Levels
Checks Checking levels Check all of these levels regularly, in line with the manufacturer's service schedule. Top them up if necessary, unless otherwise indicated. If a level drops significantly, have the corresponding system checked by a CITROËN dealer or a qualified workshop. Checking using the dipstick Take care when working under the bonnet, as certain areas of the engine...
Page 148: Brake Fluid Level
Checks Brake fluid level Topping-up the engine oil level Engine oil change The brake fluid level should be close to the "MAX" mark. If it is not, check F Locate the oil filler cap in the engine Refer to the manufacturer's service schedule the brake pad wear.
Page 149: Coolant Level
Checks Coolant level Screenwash fluid level Used products Top up the level when necessary. The coolant level should be close Avoid prolonged contact of used oil or to the "MAX" mark but should never fluids with the skin. exceed it. Most of these fluids are harmful to health or indeed very corrosive.
Page 150: Checks
Checks Checks Unless otherwise indicated, check these components in accordance with the manufacturer's service schedule and according to your engine. Otherwise, have them checked by a CITROËN dealer or a qualified workshop. 12 V battery Air filter and passenger compartment filter Particle filter (Diesel) The battery does not require any maintenance.
Page 151: Manual Gearbox
Checks Manual gearbox Brake pads Parking brake The gearbox does not require any Brake wear depends on the style If excessive travel or a loss of maintenance (no oil change). of driving, particularly in the case effectiveness of this system is of vehicles used in town, over short Refer to the manufacturer's service noticed, the parking brake must be...
Page 152: Practical Information
Practical information Temporary puncture repair kit Comprising a compressor and a sealant Access to the kit Composition of the kit cartridge, it allows the temporary repair of a tyre so that you can drive to the nearest garage. It is designed to repair most punctures which could affect the tyre, located on the tyre tread or shoulder.
Page 153: Repair Procedure
Practical information Repair procedure F Switch off the ignition. F Uncoil the pipe stowed under the F Remove the valve cap from the tyre to be F Secure the speed limit sticker inside the compressor. repaired, and place it in a clean area. F Connect the pipe from the compressor to F Connect the hose from the sealant vehicle.
Page 154 Practical information If after around 5 to 7 minutes the pressure is not attained, this indicates that the tyre is not repairable; contact a CITROËN dealer or a qualified workshop for assistance. F Check that the compressor switch is at the F Start the compressor by placing the switch Take care, the sealant product "O"...
Page 155 Practical information Checking / adjusting tyre pressures You can also use the compressor, without F Place the switch in the "O" position. F Check that the compressor switch is at the F Remove the kit. injecting sealant, to check and if necessary "O"...
Page 156 Practical information Tyre under-inflation detection After repair of the tyre, the warning lamp will remain on until the system is reinitialised. For more information on under-inflation detection, refer to the corresponding section. F Start the compressor by placing the switch Should the pressure of one or more at the "I"...
Page 157: Spare Wheel
Practical information Spare wheel Procedure for changing a wheel with a damaged tyre for the spare wheel using the tooling provided with the vehicle. Access to the tooling List of tools All of these tools are specific to your vehicle. Do not use them for any purpose other than those indicated below.
Page 158 Practical information Access to the spare wheel Wheel with trim Fitting the "space-saver" type spare wheel When removing the wheel, first If your vehicle is fitted with alloy wheels, detach the trim using the wheelbrace 1 it is normal to notice, when tightening pulling at the valve passage hole.
Page 159 Practical information Taking out the wheel Putting the wheel back in place F Unscrew the yellow central bolt, and F Put the wheel back in its housing. F Put the polystyrene storage box back in F Refit the yellow central bolt in the centre of remove it.
Page 160: Removing A Wheel
Practical information Removing a wheel Parking the vehicle Immobilise the vehicle where it does not block traffic: the ground must be level, stable and non-slippery. Apply the parking brake, switch off the ignition and engage first gear* to lock the wheels. If necessary, place a chock against the wheel diagonally opposite the wheel to be changed.
Page 161 Practical information F Extend the jack 2 until its head comes into F Position the foot of the jack 2 on the F Remove the bolts and store them in a clean ground, ensuring that it is directly below contact with the jacking point A or B used. place.
Page 162: Fitting A Wheel
Practical information Fitting a wheel After changing a wheel To stow the punctured wheel in the boot correctly, first remove the central cover. When using the "space-saver" type spare wheel, do not exceed 50 mph (80 km/h). Have the tightening of the bolts and the pressure of the spare wheel checked by a CITROËN dealer or a qualified workshop without delay.
Page 163 Practical information F Lower the vehicle fully. F Tighten the security bolt (if your vehicle has them) using the wheelbrace 1 fitted with F Fold the jack 2 and detach it. the security socket 4. F Tighten the other bolts using the wheelbrace 1 only.
Page 164: Snow Chains
Practical information Snow chains In wintry conditions, snow chains improve traction as well as the behaviour of the vehicle when braking. Advice on installation All original tyre sizes (15", 16", 17") can be The snow chains must be fitted only fitted with chains.
Page 165: Adblue ® Additive And Scr System
Practical information ® AdBlue additive and SCR system for BlueHDi Diesel engines To assure respect for the environment and The AdBlue ® additive is held in a special Once the AdBlue ® tank is empty, a conformity with the new Euro 6 emissions tank located under the boot at the rear of system required by regulations prevents standard, without adversely affecting the...
Page 166 Practical information Range indicators Once the AdBlue ® tank is on reserve or after In the event of the risk of For more information on topping- detection of a fault with the SCR emissions non-starting related to a lack up the AdBlue ®...
Page 167 Practical information ® Remaining range between 350 and 1500 miles (600 and 2 400 km) Remaining range between 0 and 350 miles (0 and 600 km) Breakdown related to a lack of AdBlue additive When switching on the ignition, the When switching on the ignition, the SERVICE When switching on the ignition, the SERVICE UREA warning lamp comes on, accompanied...
Page 168 Practical information In the event of a fault with the the SCR emissions control system A system that prevents engine starting is activated automatically from 650 miles (1 100 km) after confirmation of a fault with the SCR emissions control system.
Page 169 Practical information Topping-up the AdBlue ® additive Precautions in use Filling the AdBlue ® tank is an operation The AdBlue ® additive is an urea-based Use only AdBlue ® additive that meets the included in every routine service on your solution.
Page 170 Practical information Recommendations on storage Procedure AdBlue ® freezes at about -11°C and Before topping-up, ensure that the vehicle is deteriorates above 25°C. It is recommended parked on a flat and level surface. In wintry conditions, ensure that the that bottles be stored in a cool area and protected from direct sunlight.
Page 171 Practical information F After emptying the bottle, wipe away any Important: in the event of a top-up after spillage around the tank filler using a damp a breakdown because of a lack of cloth. additive, you must wait around 5 minutes before switching on the ignition, without If any additive is split or splashed, wash opening the driver's door, locking the...
Page 172: Changing A Bulb
Practical information Changing a bulb Procedure for replacing a faulty bulb with a new bulb. Front lamps The headlamps are fitted with Changing a bulb should only be done polycarbonate glass with a protective after the headlamp has been switched coating: off for several minutes (risk of serious F do not clean them using a dry...
Page 173 Practical information Changing direction indicator Changing dipped headlamp bulbs bulbs F Remove the protective plastic cover by If either of the direction indicator Amber coloured bulbs, such as the pulling on the tab. warning lamps is flashing quickly, one direction indicators, must be replaced F Turn the bulb-holder by a quarter turn.
Page 174 Practical information Changing main beam headlamp bulbs Changing sidelamp bulbs F Remove the protective plastic cover by F Remove the protective plastic cover by pulling on the tab. pulling on the tab. F Disconnect the bulb connector. F Pull the bulb-holder. F Move the springs to release the bulb.
Page 175 Practical information Changing front foglamp bulbs F Remove the grille located alongside the F Unscrew the two fixing screws of the F Through the cover, remove the foglamp foglamp. finisher by pulling it towards you. module and remove it from its housing. F Disconnect the bulb-holder connector.
Page 176 Practical information Changing the LED lamps Changing integral direction indicator side repeaters F Insert a screwdriver in the edge of the For the replacement of this type of LED lamp, While removing the module: contact a CITROËN dealer or a qualified take care not to damage your vehicle's repeater.
Page 177: Rear Lamps
Practical information Rear lamps Brake lamps / sidelamps (12VP21/5 W). Changing brake lamp/ sidelamp 2. Foglamp, offside (PR21W) and direction indicator bulbs Reversing lamp, nearside (P21W). 3. Direction indicators (P21W) F unscrew the two lamp unit fixing bolts, F turn the bulb-holder a quarter turn, F extract the lamp unit carefully pulling it F remove the failed bulb and replace it.
Page 178 Practical information Changing foglamp / reversing Changing the third brake lamp Changing the number plate lamp lamp bulbs bulbs (4 x W 5 W bulbs) bulbs (W5W) F insert a thin screwdriver into one of the F open the boot, F open the boot, F press on the tabs using 2 screwdrivers, F remove the two plugs located on the boot...
Page 179: Interior Lighting
Practical information Interior lighting Interior lamps (1 / W5W) Front courtesy lamp mood Door mirror lamps (W5W) lighting LED Detach the cover of the interior lamp 1 with a Unclip the cover using a thin screwdriver to thin screwdriver, close to the button, to access For the replacement of the LED, contact a access the faulty bulb.
Page 180: Changing A Fuse
Practical information Changing a fuse Procedure for replacing a failed fuse with a new fuse to rectify a failure of the corresponding function. Access to tooling Changing a fuse Installing electrical accessories Before changing a fuse, the cause of the failure must be identified and rectified.
Page 181: Dashboard Fuses
Practical information Dashboard fuses The fusebox is placed in the lower dashboard (left-hand side). Fuse tables Fuse N° Rating Functions FH36 Trailer relay unit. FH37 15 A Trailer accessories socket supply. FH38 20 A Aftermarket navigation. FH39 20 A Heated seats. FH40 30 A Trailer relay unit.
Page 182 Practical information Fuse N° Rating Functions 20 A Multifunction screen, audio system, navigation radio. 30 A Audio system (aftermarket), 12 V socket. Steering wheel controls. 15 A 15 A Ignition, diagnostic socket. 15 A Rain / sunshine sensor, trailer relay unit. Main stop switch, engine relay unit.
Page 183: Engine Compartment Fuses
Practical information Engine compartment fuses The fusebox is placed in the engine compartment near the battery (left-hand side). Access to fuses F Unclip the cover. F Change the fuse (see corresponding paragraph). F When you have finished, close the cover All work on these fuses, located on carefully to ensure the correct sealing of the fusebox.
Page 184 Practical information Fuse table Fuse N° Rating Functions Engine control unit supply, cooling fan unit control, multifunction 20 A engine control main relay. 15 A Horn. Front / rear wash-wipe. 10 A 20 A Daytime running lamps. 15 A Diesel heater (Diesel engine), fuel pump (petrol engine) ABS/ESP control unit, ABS/ESP cut-off relay, secondary stop 10 A switch.
Page 185 Practical information Fuse N° Rating Functions Windscreen wipers slow / fast speed. 30 A 40 A Built-in systems interface supply (ignition positive). 30 A Valvetronic supply (petrol). 10 A Right-hand main beam headlamp. 10 A Left-hand main beam headlamp. 15 A Left-hand dipped beam headlamp.
Page 186 Practical information Table of maxi-fuses Fuse N° Rating Functions MF1* 60 A Cooling fan assembly. MF2* 30 A ABS / ESP control unit. MF3* 30 A ABS / ESP control unit. MF4* 60 A Built-in Systems Interface (BSI) supply. MF5* 60 A Built-in Systems Interface (BSI) supply.
Page 187: Battery
Practical information Battery Procedure for charging your battery when it is flat or for starting the engine using another battery. Access to the battery Starting using another battery When the battery on your vehicle is discharged, the engine can be started using a slave battery (external or on another vehicle) and jump leads.
Page 188 Practical information Charging the battery using a battery charger Batteries contain harmful substances such Protect your eyes and face before as sulphuric acid and lead. They must be handling the battery. disposed of in accordance with regulations All operations on the battery must be carried out in a well ventilated area and must not, in any circumstances, be discarded with household waste.
Page 189: Energy Economy Mode
Practical information Load reduction mode Energy economy mode System which manages the period of use of certain functions to conserve a sufficient level of System which manages the use of certain charge in the battery. functions according to the level of charge After the engine has stopped, you can still use functions such as the audio equipment, windscreen remaining in the battery.
Page 190: Changing A Wiper Blade
Practical information Changing a front or rear wiper blade Procedure for replacing a worn wiper blade with a new one without the use of tools. Before removing a front Fitting wiper blade F At the front, check the size of the wiper F Within one minute after switching off the blade as the shorter blade is fitted to the ignition, operate the wiper stalk to position...
Page 191: Towing The Vehicle
Practical information Towing the vehicle Procedure for having your vehicle towed or for towing another vehicle using a removable towing eye. General recommendations Observe the legislation in force in your country. Ensure that the weight of the towing vehicle is higher than that of the towed vehicle. The driver must remain at the wheel of the towed vehicle and must have a valid driving licence.
Page 192: Towing Your Vehicle
Practical information Towing your vehicle Towing another vehicle F Screw the towing eye in fully. F On the front bumper, passenger's side, F On the rear bumper, unclip the cover by F Install the towing arm. remove the protective access cover located pressing at the bottom.
Page 193: Towing A Trailer
Practical information Towing a trailer, ... Towbar suitable for the attachment of a trailer or installation of a bicycle carrier, with additional lighting and signalling. Your vehicle is primarily designed for transporting people and luggage, but it may also be used for towing a trailer. Driving advice Distribution of loads Cooling...
Page 194: Fitting Roof Bars
Practical information Fitting roof bars To fit longitudinal and/or transverse roof bars, visit your CITROËN dealer or a qualified workshop. Braking Towing a trailer increases the braking distance. To avoid overheating of the brakes on a long mountain type of descent, the use of engine braking is recommended.
Page 195: Accessories
Practical information Accessories A wide range of accessories and genuine parts is available from the CITROËN dealer network. These accessories and parts are all suitable for your vehicle and benefit from CITROËN's recommendation and warranty. "Comfort": "Style": "Protection": allow wheels, chromed mirror shells, leather front and rear parking sensors, insulated mats*, seat covers, mudflaps, bumper steering wheel, gear lever knob, aluminium...
Page 196 Practical information "Multimedia": By visiting a CITROËN dealer, you can Depending on the legislation in force in also obtain cleaning and maintenance the country, certain safety equipment semi-integral navigation systems, Bluetooth ® products (interior and exterior), may be compulsory: high visibility hands free kit, audio systems interfaced to safety vests, warning triangles, including the ecological products in...
Page 197: Technical Data
Technical data Engines and gearboxes PETROL ENGINE VTi 95 PureTech 110 VTi 115* Gearbox Manual (5-speed) Manual (5-speed) Manual (5-speed) Electronic (6-speed) Model code: 8FP0 HNZ6 5FJ0 5FJ8/P SH... 8FP6 Cubic capacity (cc) 1 397 1 199 1 598 Bore x stroke (mm) 77 x 75 75 x 90.5 77 x 85.8...
Page 198: Petrol Weights
Technical data Weights and towed loads (kg) PETROL ENGINE VTi 95 PureTech 110 VTi 115* Manual Manual Manual Electronic Gearbox (5-speed) (5-speed) (5-speed) (6-speed) Model code: 8FP0 HNZ6 5FJ0 5FJ8/P SH... 8FP6 Unladen weight 1 246 1 205 1 204 1 205 Kerb weight 1 321...
Page 199: Diesel Engines
Technical data Engines and gearboxes DIESEL ENGINE BlueHDi 100 Gearbox Manual (5-speed) Model code: BHY6 SH... Cubic capacity (cc) 1 560 Bore x stroke (mm) 75 x 88.3 Max power: EU standard (kW)* Max power engine speed (rpm) 3 750 Max torque: EU standard (Nm) Max torque engine speed (rpm) 1 750...
Page 200: Diesel Weights
Technical data Weights and towed loads (kg) DIESEL ENGINE BlueHDi 100 Gearbox Manual (5-speed) Model code: BHY6 SH... Unladen weight 1 240 Kerb weight 1 315 Payload Gross vehicle weight (GVW) 1 800 Gross train weight (GTW) 2 700 on a 12% gradient Braked trailer (within GTW limit) on a 10% or 12% gradient Braked trailer* (with load transfer with the...
Page 201: Dimensions
Technical data Dimensions (in mm)
Page 202: Identification Markings
Technical data Identification markings Various visible markings for the identification of your vehicle. C. Manufacturer's label. This number is indicated on a self- destroying label affixed to the centre pillar, on the left-hand side. D. Tyre/paint label. This label is affixed to the centre pillar, on the left-hand side.
Page 203: Emyway
eMyWay GPS navigation system Multimedia audio system Bluetooth ® telephone CONTENTS 01 First steps - Control panel 02 Steering mounted controls The system is protected in such a way that it will only 03 General operation operate in your vehicle. 04 Navigation - Guidance 05 Traffic information 06 Using the telephone...
Page 204: First Steps - Control Panel
FIRST STEPS Select: Selection and OK confirmation knob: the previous/next line in a list or menu. Selection of an item on the screen or in a list or a menu, Open the the previous / next media folder. then confirmation with a short press. "Configuration"...
Page 205 FIRST STEPS Access to the "RADIO" menu and Access to the "MUSIC" menu, and display of the CD/MP3/ display the list of stations received. Apple ® tracks and folders. Open the "Telephone" menu Long press: display the audio settings Long press: display the audio settings screen for the and display the list of recent screen for the radio tuner source.
Page 206: Steering Mounted Controls
STEERING MOUNTED CONTROLS RADIO: change to the next radio station in the list. Long press: automatic search for a higher frequency. CD: select the next track. CD: press and hold: fast forward play. SRC/TEL button: change the audio source, start a call from the address book, call/end call on the telephone, press for more than 2 seconds: open the address book.
Page 207: General Operation
GENERAL OPERATION Press the MODE button several times in succession for access to the following displays: "MAP IN WINDOW" "RADIO" (If navigation guidance in progress) "TELEPHONE" "FULL SCREEN MAP" (If conversation in progress) Change the audio source: SETUP: PARAMETERS date and time, display configuration, sound, vehicle RADIO: RADIO broadcasts.
Page 208 GENERAL OPERATION Display according to context FULL SCREEN MAP OR IN TELEPHONE A press on the knob gives access A NEW WINDOW: (call in progress): to short-cut menus according to the display in the screen. Stop / Restore guidance Private mode Select destination RADIO: Put call on hold...
Page 209: Navigation - Guidance
NAVIGATION - GUIDANCE Access to the "NAVIGATION" menu To make full use of all of the "Navigation - guidance" functions of your navigation system, update the mapping regularly. Contact a CITROËN dealer or order Press NAV. your mapping update at http://citroen.navigation.com List of recent destinations.
Page 210 NAVIGATION - GUIDANCE Selecting a destination Towards a new destination Selection the town from the list offered, then confirm. Press NAV to display the A pre-set list (by entering the first few "Navigation - guidance" menu. letters) of the towns in the country selected can be accessed directly by selecting and confirming "List"...
Page 211 NAVIGATION - GUIDANCE Towards a recent destination Towards a contact in the directory of contacts Press NAV to display the Navigation towards a contact is only possible if there is an address "Navigation - guidance" menu. entered in the audio navigation system. Select the desired destination and confirm to start navigation.
Page 212 NAVIGATION - GUIDANCE Towards GPS coordinates Towards a point on the map With the map displayed, press OK to Press NAV to display the display the contextual menu. Select "Navigation - guidance" menu. "Move the map" and confirm. Select "Select destination" and Move the cursor using the control to confirm, then select "GPS coordinates"...
Page 213 NAVIGATION - GUIDANCE The points of interest (POI) indicate all of the service locations in the vicinity Towards points of interest (POI) (hotels, various businesses, airports...). Select "Search by Name" to search for POIs by name and not by Press NAV to display the proximity.
Page 214 This icon appears when several POIs are grouped NAVIGATION - GUIDANCE together in the same area. Zooming in on this icon shows details of the POIs. List of principal points of interest (POI) Airport Service station Cinema Railway station Garage Theme parks CITROËN Bus station...
Page 215 NAVIGATION - GUIDANCE Settings for risk area / danger area alerts These functions are only available if risk areas have been Press NAV to display the "Navigation - downloaded and installed on the system. guidance" menu. The detailed procedure for updating risk area POIs can be found at http://citroen.navigation.com.
Page 216 NAVIGATION - GUIDANCE Adding a stage Organising stages To organise stages, carry out Press NAV to display the operations 1 to 2 again, then select "Navigation - guidance" menu. "Order/delete journey legs" and confirm. Select the stage that you want to move Select "Journey leg and route"...
Page 217: Route Options
NAVIGATION - GUIDANCE Route options Calculation criteria Select "Define calculation criteria" and confirm. This function allows modification of: the guidance criteria: ("Fastest Press NAV to display the route", "Shortest route", "Navigation - guidance" menu. "Distance/Time"), the exclusion criteria: ("With tolls" or "With Ferry"), traffic avoidance: ("Traffic info").
Page 218 NAVIGATION - GUIDANCE Map management Selecting the points of interest displayed on the map Select from the various categories Press NAV to display the the ones that you want to display on "Navigation - guidance" menu. the screen. Select "Default" to have only "Filling stations, garages" and Select "Map management"...
Page 219 NAVIGATION - GUIDANCE Map orientation Select: "Vehicle direction" to have the map follow the direction of travel, Press NAV to display the "North direction" to keep the map "Navigation - guidance" menu. always North up, "Perspective view" to display a perspective view.
Page 220 NAVIGATION - GUIDANCE Navigation voice synthesis Adjusting the volume / Deactivation The volume of messages can be adjusted during the transmission of the message using the volume adjustment control. Select the volume graph and confirm. The volume setting of guidance messages is also accessible via the "SETUP"...
Page 221 NAVIGATION - GUIDANCE Male voice / Female voice Press SETUP to display the configuration menu. Select "Voice synthesis" and confirm. Select "Select male voice" or "Select female voice" then confirm "Yes" to activate a male or female voice. The system restarts.
Page 222: Traffic Information
TRAFFIC INFORMATION Access to the "TRAFFIC INFORMATION" menu "Traffic information" Press "TRAFFIC". "Geographic filter" List of TMC messages in order of distance from the vehicle. "Select TMC station" (automatic, manual) "Display/Do not display messages" Go from the list to the menu (left/right).
Page 223 TRAFFIC INFORMATION Configure the filtering and display of TMC messages TMC (Traffic Message Channel) messages with GPS Navigation provide traffic information in real time. The system offers a choice of: "Retain all the messages", Press the TRAFFIC button to display the "Traffic information"...
Page 224 TRAFFIC INFORMATION Principal TMC symbols Receiving TA messages The TA (Traffic Announcement) function gives priority to TA alert Black and blue triangle: general information, for example: messages. To operate, this function needs good reception of a radio station transmitting this type of message. When a traffic report is transmitted, the current audio source (Radio, CD, USB, ...) is Traffic reports Weather reports...
Page 225: Using The Telephone
USING THE TELEPHONE Access to the "TELEPHONE" menu In the top bar of the permanent "Telephone" display No telephone connected. Press this button. List of recent calls sent and "Dial" Telephone connected. received with the telephone "Directory of contacts" connected to the system. "Contacts management"...
Page 226 USING THE TELEPHONE For reasons of safety and because they require prolonged attention Pairing a Bluetooth ® telephone on the part of the driver, the operations for pairing the Bluetooth mobile telephone to the hands-free system of the audio unit must be First connection carried out with the vehicle stationary.
Page 227 USING THE TELEPHONE The services available depend on the network, the SIM card and the compatibility of the Bluetooth telephone used. Check the telephone manual and with your network provider for details of the services available to you. Select the name of the desired Enter a minimum 4 figure code in the telephone peripheral from the list of devices and confirm.
Page 228 USING THE TELEPHONE Directory configuration / Synchronisation with the telephone Select "Import all the entries" to import all the contacts in the telephone and Press PHONE then select "Contacts save them in the system. management" and confirm. Once imported, a contact remains visible whatever telephone is connected.
Page 229 USING THE TELEPHONE Editing, importing or deleting a contact Press PHONE then select "Directory of It is not possible to modify or delete contacts in the telephone or the contacts" and confirm. SIM card via the Bluetooth connection. Select "Search", then turn the knob to Once the contact has been imported, the Bluetooth symbol choose in numerical or alphabetical order disappears, replaced by the telephone symbol which shows that the...
Page 230: Making A Call
USING THE TELEPHONE Using the telephone is not recommended while driving. We Making a call recommended that you park safely or make use of the steering mounted controls. Calling a new number Calling a contact Press TEL or twice on PHONE. Press PHONE twice.
Page 231 USING THE TELEPHONE Ending a call Calling a recently entered number Press PHONE then select "OK" to end Press TEL, select "Call list" and the call. confirm, Or make a long press on TEL at the steering mounted controls. Press PHONE to display the calls log. Or make two short presses on TEL at the steering mounted controls.
Page 232: Receiving A Call
USING THE TELEPHONE Receiving a call An incoming call is announced by a ring and a superimposed display on the screen. "Yes" to accept the call is selected by default. Press "OK" to accept the call. Select "No" and confirm to reject the call.
Page 233: Options During A Call
USING THE TELEPHONE Options during a call* Select "DTMF ring tones" to use the numerical keypad, so as to navigate During a call, press the MODE button through the menu of an interactive vocal several times to select display of the server.
Page 234 USING THE TELEPHONE Managing paired telephones Changing the ringtone Press PHONE twice. Press PHONE twice. Select "Phone functions" and confirm. Select "Bluetooth functions". Select "Ring options" and confirm. Select "List of the paired peripherals" and confirm. You can adjust the volume and the type of ringtone.
Page 235: Radio
RADIO Access to the "RADIO" menu "FM / AM band" Press RADIO. Alphabetical list of stations "Change Waveband" ("AM / FM") received. "Guidance options" ("TA, RDS") "Audio settings" "Update radio list" Go from the list to the menu (left/right). Press 5 or 6 or use the rotary control to select the previous or next station in the list.
Page 236 RADIO Changing waveband Selecting a station The external environment (hill, building, tunnel, underground car park...) may interfere with the reception, including in RDS station tracking mode. This phenomenon is a normal result of the way in which radio waves are transmitted and does not in any way indicate a fault with the audio system. The quality of reception is represented by the number of active waves in this symbol.
Page 237 RADIO Presetting a station Activate / Deactivate RDS RDS, if activated, allows you to continue listening to the same station by automatic retuning to alternative frequencies. However, in certain conditions, coverage of an RDS station may not be assured throughout the entire country as radio stations do not cover 100 % of the territory.
Page 238: Music Media Players
MUSIC MEDIA PLAYERS Access to the "MUSIC MEDIA PLAYER" menu "MEDIA" Press MUSIC. List of the current media "Change media" tracks. "Eject USB device" (if USB connected) "Play mode" ("Normal", "Random", "Random on all media", "Repetition") "Audio settings" "Activate / Deactivate AUX input" Go from the list to the menu (left/right).
Page 239 MUSIC MEDIA PLAYERS CD, MP3 CD / USB player Information and advice The audio equipment will only play audio files with ".wma, .aac, .flac, .ogg and .mp3" file extensions and with a bit rate of between 32 Kbps The system supports USB mass storage or iPod devices via the USB port (suitable cable not supplied).
Page 240 MUSIC MEDIA PLAYERS Sources Selection of source The SOURCE button on the steering mounted controls allows a direct change to the next media source. Insert the CD in the player, insert the USB memory stick in the USB player or connect the "CD / CD MP3"...
Page 241 MUSIC MEDIA PLAYERS Selecting a track MUSIC: List of USB or CD tracks or Previous track. folders Next track. Up or down in the list. Previous folder. Confirm, next menu level. Next folder. Fast forward. Long press Fast backward. Long press Up one menu level.
Page 242: Audio Streaming
MUSIC MEDIA PLAYERS Connecting APPLE ® players Audio streaming Connect the Apple ® player to the USB port using a suitable cable (not supplied). Streaming allows audio files on your telephone to be played via the Play starts automatically. vehicle's speakers. Control is via the audio system.
Page 243 MUSIC MEDIA PLAYERS Using the auxiliary input (AUX) JACK/USB audio cable not supplied Select "Activate / Deactivate AUX Connect the portable device input" and confirm. (MP3, WMA player…) to the JACK auxiliary audio socket or First adjust the volume of your portable device (to a high level).
Page 244: Audio Settings
AUDIO SETTINGS They are accessible by the MUSIC The audio settings (Equalizer, Bass, Treble and Loudness) are button in the control panel or by a long different and independent for each sound source. press on RADIO according to the source The settings for distribution and balance are common to all sources.
Page 245: Configuration
CONFIGURATION Display configuration Select "Choose colour" and confirm to select the screen colour harmony and the map presentation mode: day mode, Press SETUP to display the "Configuration" menu. night mode, automatic day/night mode, according to whether the headlamps are on. Select "Adjust luminosity"...
Page 246: Screen Menu Maps
SCREEN MENU MAP(S) Map management Previous destinations MAIN FUNCTION Map orientation Order/delete journey legs Option A Vehicle direction Divert route Option A1 Chosen destination North direction Option A11 Perspective view Guidance options Option B... Define calculation criteria Map details "Navigation - guidance" Fastest route Move the map MENU...
Page 247: Phone Functions
SCREEN MENU MAP(S) Call Contact mem. status "TRAFFIC INFORMATION" MENU Open Phone functions Geographic filter Import Ring options Retain all the messages: Search Delete calls log Retain the messages: Delete Bluetooth functions Around the vehicle Cancel List of the paired peripherals On the route Contacts management Connect...
Page 248 SCREEN MENU MAP(S) "RADIO" MENU "MUSIC" MENU Change Waveband Loudness Change Media Activated / Deactivated Distribution Bluetooth streaming Options Driver USB/iPod RDS station tracking All passengers Audio settings Read mode Le-Ri balance Equalizer Fr-Re balance Normal None Auto. Volume Random Classical Activated / Deactivated Random on all media...
Page 249 SCREEN MENU MAP(S) "SETUP" MENU Select language Define vehicle parameters* Français Trip computer Display configuration English Alert log Choose colour Italiano Status of functions Harmony: Portuguese Cartography: Español Day mode Deutsch Night mode Nederlands Auto Day/Night Turkçe Adjust luminosity Polski Set date and time Русский...
Page 250: Frequently Asked Questions
FREQUENTLY ASKED QUESTIONS The following table groups together the answers to the most frequently asked questions concerning your audio system. QUESTION ANSWER SOLUTION The guidance criteria may conflict with the current location (exclusion of The route calculation is Check the guidance criteria on the Navigation toll roads on a toll motorway).
Page 251 FREQUENTLY ASKED QUESTIONS QUESTION ANSWER SOLUTION Certain traffic jams Wait until the traffic information is being received On starting, it is several minutes before the system begins to receive the traffic information. correctly (display of the traffic information icons on along the route are not indicated in real time.
Page 252 FREQUENTLY ASKED QUESTIONS QUESTION ANSWER SOLUTION Some contacts are The options for synchronizing contacts are synchronizing the contacts Select "Display SIM card contacts" or "Display duplicated in the list. on the SIM card, the contacts on the telephone, or both. When both telephone contacts".
Page 253 FREQUENTLY ASKED QUESTIONS QUESTION ANSWER SOLUTION Some characters in the The audio system does not read some types of characters. Use standard characters to name tracks and media information are not folders. displayed correctly while playing. Playing of streaming files The peripheral device connected does not support automatic play.
Page 254 FREQUENTLY ASKED QUESTIONS QUESTION ANSWER SOLUTION The selection of an ambience imposes specific treble and bass settings. When modifying the Modify the treble and bass settings or choose a treble and bass setting, musical ambience to obtain the desired sound the choice of ambience is quality.
Page 255 FREQUENTLY ASKED QUESTIONS QUESTION ANSWER SOLUTION When the engine is switched off, the system's operating time depends on With the engine off, the Start the vehicle's engine to increase the battery system switches off after the state of charge of the battery. charge.
Page 257: Audio System
Audio system Audio system / Bluetooth ® CONTENTS Your Audio system is coded in such a way that it will 01 First steps only operate in your vehicle. 02 Steering mounted controls 03 Main menu 04 Audio 05 USB Box 06 Bluetooth functions 07 Screen menu map(s) For safety reasons, the driver must only carry out...
Page 258: First Steps
FIRST STEPS Display the list of Audio settings: front/ Select source: local stations. rear fader, left/right radio, audio CD / MP3 CD, USB, balance, bass/treble, Long press: CD Jack connection, Streaming, Select AM / FM loudness, audio tracks or MP3 Abandon the current wavebands.
Page 259: Steering Mounted Controls
STEERING MOUNTED CONTROLS Radio: automatic search for a higher frequency. CD / MP3 / USB: selection of the next track. CD / USB: continuous press: fast forwards play. Move in the list. Change audio source. Confirm a selection. Call/end call on the telephone. Press for more than 2 seconds: telephone main menu.
Page 260: Main Menu
MAIN MENU Audio functions Trip computer Radio; CD; USB; AUX. Enter distances; Alerts; State of functions. Screen C Personalisation-configuration Bluetooth ® : Telephone - Audio Vehicle parameters; Display; Languages. Pairing; Hands-free kit; Streaming. Screen A For an overview of the menus available, refer to the "Screen menu map"...
Page 261: Audio
The external environment (hills, buildings, tunnels, basement car parks, ...) AUDIO may block reception, including in RDS mode. This is a normal effect of the way in which radio waves are transmitted and does not indicate any failure of the audio system. Selecting a station Press the SOURCE button several Press the MENU button.
Page 262 AUDIO Receiving TA messages CD player The TA (Traffic Announcement) function gives priority to TA alert Insert circular compact discs only. messages. To operate, this function needs good reception of a radio station transmitting this type of message. When a traffic Some anti-pirating systems, on original discs or CDs copied using a personal recorder, may cause faults which are no reflection on the report is transmitted, the current audio source (Radio, CD, ...) is...
Page 263 AUDIO Information and advice Playing an MP3 CD compilation Insert an MP3 CD compilation in the player. The audio system will only play files with the extension ".mp3" with The audio equipment searches for all of the music tracks, a sampling rate of 22.05 KHz or 44.1 KHz. No other type of file which may take anything between a few seconds and several (.wma, .mp4, .m3u...) can be played.
Page 264: Usb Box
USB PLAYER Using the USB PORT Connecting a USB memory stick This unit consists of a USB port and an auxiliary Jack socket*. The audio files are transmitted Connect the memory stick to the port, directly or using a lead. If the audio equipment is switched from a portable device - digital player or a USB memory stick - to your Audio system and heard on, the USB source is detected as soon as it is...
Page 265 USB PLAYER Using the USB PORT Press one of these buttons to gain Press and hold LIST to display the access to the previous / next track on different classifications. the classification list currently being Select by Folder / Artist / Genre / Playlist, played.
Page 266 USB PLAYER Adjusting the volume of the auxiliary Auxiliary socket (AUX) source Connect the portable device (MP3 player, …) to the auxiliary First adjust the volume of your portable device. Jack socket using an audio cable (not supplied). Press the SOURCE button several Then adjust the volume of your audio times in succession and select AUX.
Page 267: Bluetooth Functions
BLUETOOTH FUNCTIONS The services available depend on the network, the SIM card and the ® Pairing a Bluetooth telephone compatibility of the Bluetooth device used. Screen C Consult your telephone's manual and your operator to find out which (Available according to model and version) services are available to you.
Page 268 BLUETOOTH FUNCTIONS Receiving a call Making a call From the "Bluetooth: Telephone - Audio" menu. An incoming call is announced by a ring and a superimposed display in the screen. Select "Manage the telephone call". Select the YES tab on the display using the buttons.
Page 269: Bluetooth Audio Streaming
BLUETOOTH FUNCTIONS Ending a call ® Bluetooth audio streaming Streaming allows music files on the telephone to be played via the During a call, press this button for more than audio system. 2 seconds. Confirm with OK to end the call. Connect the telephone: see the "Telephone"...
Page 270: Screen Menu Map(S)
SCREEN MENU MAP(S) Screen A Main function Radio-CD Options Option A RDS options Diagnostic Option A1 View REG mode Option A11 CD repeat Abandon Option B... Shuffle play Vehicle config* R wiper in rev Guide lighting * The settings vary according to the trim level of the vehicle.
Page 271 SCREEN MENU MAP(S) Display adjust Language Units Temperature: °Celsius / °Fahrenheit Year Français Fuel consumption: Month Italiano KM/L - L/100 - MPG Nederlands Hour Portuguès Minutes Português do Brasil 12 H/24 H mode Deutsch English Español Čeština Hrvatski Magyar...
Page 272 SCREEN MENU MAP(S) Press the OK dial for access to short-cut menus according Screen C to the display on the screen. CD / MP3 CD Radio activate / deactivate Intro activate / deactivate track repeat (of the activate / deactivate RDS current folder / artist / genre / playlist) activate / deactivate track repeat (the activate / deactivate REG mode...
Page 273 SCREEN MENU MAP(S) Screen C Pressing the MENU button displays: Audio functions Activate / deactivate Trip computer Play modes Audio functions Enter distance to destination Album repeat (RPT) Distance: x miles FM preferences Activate / deactivate Alternative frequencies (RDS) Warning log Track random play (RDM) Activate / deactivate Vehicle diagnosis...
Page 274 SCREEN MENU MAP(S) Personalisation-configuration Bluetooth: Telephone - Audio Define the vehicle parameters* Bluetooth configuration Display configuration Connect/Disconnect an equipment Brightness-video adjustment Telephone function Normal video Audio Streaming function Inverse video Consult the paired equipment Brightness (- +) adjustment Delete a paired equipment Date and time adjustment Perform a Bluetooth search Setting the day/month/year...
Page 275: Frequently Asked Questions
FREQUENTLY ASKED QUESTIONS QUESTION ANSWER SOLUTION There is a difference in For optimum sound quality, the audio settings (Volume, Bass, Treble, Check that the audio settings (Volume, Bass, sound quality between Ambience, Loudness) can be adapted to the different sound sources, Treble, Ambience, Loudness) are adapted to which may result in audible differences when changing source (radio, the different audio...
Page 276 FREQUENTLY ASKED QUESTIONS QUESTION ANSWER SOLUTION Few telephones or service providers allow the use of this function. I am unable to access my voicemail. The CD player sound is The CD used is scratched or of poor quality. Insert good quality CDs and store them in suitable poor.
Page 277 FREQUENTLY ASKED QUESTIONS QUESTION ANSWER SOLUTION Sound cut-outs of 1 to During this brief sound cut-out, the RDS searches for any frequency Deactivate the RDS function if the phenomenon is too frequent and always on the same route. 2 seconds in radio mode. permitting better reception of the station.
Page 278 Visual search Exterior Remote control key 59-61, 124-126 opening/closing battery Wiper controls 79-81 anti-theft protection Changing a wiper blade starting Accessories 193-194 Door mirrors Boot Temporary puncture repair kit 150-154 Spare wheel 155-161 Lighting controls 72-75 tools LED daytime running lamps removing/refitting Snow chains Cornering lighting...
Page 279 Visual search Interior Front seats 52-54 Boot fittings 91-93 rear parcel shelf adjustable boot floor hooks stowing rings ® Adblue tank 167-169 Airbags 119-122 Rear seats 55-56 Interior fittings 84-90 auxiliary sockets centre armrest Glove box Child seats 94-102, 106 Deactivating the passenger's airbag 97, 120 ISOFIX child seats...
Page 280 Visual search Instruments and controls Rear view mirror Instrument panels Warning lamps 11-21 Sun visor 84-85 Indicators 22-25 Multifunction screens 27-39 Adjustment buttons trip distance recorder /clock lighting dimmer/ black panel Wiper controls 79-81 Trip computer 40-42 Lighting controls 72-75 Headlamp adjustment Hazard warning lamps Speed limiter...
Page 281 Visual search Technical data - Maintenance Petrol weights Diesel weights Checking components 148-149 battery air filter / passenger compartment filter Running out of Diesel oil filter AdBlue ® additive and SCR system particle filter (Diesel) (BlueHDi Diesel) 163-169 brake pads / discs Checking levels 145-147 Dimensions...
Page 282 Alphabetical index Checking the engine oil level ....25, 145 ABS and EBFD systems ......113 Battery ..........148, 185 Accessories ..........193 Battery, charging .........186 Checking the levels ......145-147 Checking tyre pressures (using the kit) ..153 Accessory socket, 12V ......84, 86 Battery, remote control ......60, 61 Additive, AdBlue ........20, 163 Blind, panoramic roof ........68 Checks ..........143-149...
Page 283 Alphabetical index Defrosting ............45 Filling the fuel tank ........69-71 Guidance (Navigation) ........207 Dials .............. 10 Filter, air ............148 Guide-me-home ........74, 75 Diesel ............70 Filter, oil ............148 Dimensions ..........199 Filter, particle ........147, 148 Dipstick ..........25, 145 Filter, passenger compartment ....148 Fitting a wheel ..........160 Direction indicators .....
Page 284 Alphabetical index Instrument panel ........... 10 Levels and checks .......143-147 Navigation ...........207 Level, screenwash Instrument panel screen ....... 10 Number plate lamps ........175 fluid ............147 ISOFIX ............103 Isofix mountings ..........103 Lighting bulbs (replacement) ..........170 Lighting, dashboard ........26 Lighting dimmer ..........26 Lighting, guide-me home ......
Page 285 Alphabetical index Priming the fuel system ......142 Reversing camera ........139 Serial number, vehicle ............200 Protecting Reversing lamp ........175, 176 children ........ 94-107, 118, 120 Service indicator ...........22 Risk areas (update) ........212 Puncture ............150 Servicing ............8 Roof bars .............192 Settings, equipment ........270 Running out of fuel (Diesel) ......
Page 286 Alphabetical index Table of weights ........196, 198 Under-inflation (detection) ......19, 109-112, 154 Table position ..........54 Unlocking ............59 Tables, aircraft ..........88 Unlocking from the inside ......65 Tables of engines ........195, 197 Updating risk areas ........212 Tables of fuses ..........178 UREA ..........163, 164 Tank, AdBlue ®...
Page 291 Labels are applied at various points on your vehicle. They We draw your attention to the following points: carry safety warnings as well as vehicle identification The fitting of electrical equipment or accessories not information. Do not remove them: they form an integral part listed by CITROËN may cause faults and failures with the electrical system of your vehicle.
Page 292 2015 – DOCUMENTATION DE BORD 4Dconcept Diadeis Interak 15C3O.0040 Anglais...

CITROËN C3 PICASSO Handbook

Table of Contents

Emyway

Audio System

Quick Links

Chapters

Related Manuals for CITROËN C3 PICASSO

Summary of Contents for CITROËN C3 PICASSO

Table of Contents
