CITROEN C5 Quick Start Manual

OPENING THE BONNET
The bonnet release should only be operated when the
vehicle is stationary.
Open the driver's door.
Pull release lever A to unlock.
Lift up safety catch B , then raise the bonnet.
DIESEL
FUEL TANK
To open the fuel fi ller fl ap, press on it at top left, then pull from
the rear edge.
Locking filler cap
Turn the key a quarter turn to lock and unlock the fi ller cap.
When refuelling, place the cap on hook F .
Tank capacity: approximately 71 litres
MISFUEL PREVENTION
Mechanical device which prevents fi lling the tank of a Diesel vehicle
with petrol. It avoids the risk of engine damage that can result from
fi lling with the wrong fuel.
When a petrol fi ller nozzle is introduced into the fuel fi ller neck of
your Diesel vehicle, it comes into contact with the fl ap. The system
remains closed and prevents fi lling.
Do not persist but introduce a Diesel type fi ller nozzle.
DUAL-ZONE DIGITAL AIR CONDITIONING
It is recommended that automatic mode
be used by pressing the " AUTO " button.
Adjustment of air fl ow.
Front demisting -
defrosting.
Adjustment of temperature on
driver's side.
Driver's side automatic
operation.
Adjustment of air distribution on
driver's side.
Rear screen and door mirrors
demisting - defrosting.
Fiche_loueur_C5_en_01-2010.indd 1 Fiche_loueur_C5_en_01-2010.indd 1
MANUAL PARKING BRAKE
Application
Pull the parking brake lever up to immobilise your vehicle.
To facilitate the action on the lever, you are recommended to press
the brake pedal at the same time .
Release
Press on the end of the lever whilst pulling it then lower it fully.
MAIN MENU
"SETUP" MENU
Press the "SETUP" button to gain access to the "SETUP"
menu.
PERSONALISATION - CONFIGURATION
Adjustment of temperature on
passenger's side.
Adjustment of air distribution on
passenger's side.
Activation/deactivation of air
conditioning
Passenger's side automatic
Air recirculation - fresh air
intake. operation .
READY TO SET OFF
STEERING WHEEL ADJUSTMENT
First, adjust the driver's seat to the most suitable position.
When stationary, pull the lever A to unlock the steering wheel
adjustment.
Adjust for height and reach.
Push the lever to lock the steering wheel adjustment.
ELECTRIC DOOR MIRRORS
1. Selection of door mirror:
A. Left hand side.
B. Right hand side.
C. Foldback/Unfold.
2. Directional control for mirror selected .
REMOTE CONTROL KEY
A. Key release/storage.
B. Normal locking of the vehicle (a single press) or deadlocking
the vehicle (two presses in succession).
C. Guide-me-home lighting.
D. Unlocking the vehicle.
CITROËN C5
ELECTRIC PARKING BRAKE
The application of the parking brake is confi rmed by:
- the lighting of the warning lamp P in control
lever A and in the instrument panel,
- the display of a message "Handbrake on" in the multifunction
screen.
Application with the engine running
With the engine running and the vehicle stationary, in order to
immobilise the vehicle you need to manually apply the parking
brake by pulling on control A
Application with the engine off
With the vehicle stationary, the parking brake is automatically
applied when the engine is switched off.
The application of the parking brake is confi rmed by:
- the extinction of the warning lamp P in control
lever A and in the instrument panel,
- the display of a message "Handbrake off" in the multifunction
screen .
Release
The electric parking brake releases automatically and
progressively when you press the accelerator :
with a manual gearbox (fi rst gear or reverse gear engaged),
press down fully on the clutch pedal then press on the
accelerator pedal and move off.
with an automatic gearbox , accelerate with the selector in
position D , M or R .
When stationary, with the engine running, do not press the
accelerator pedal unnecessarily (particularly when starting the engine,
including in neutral), as you may release the parking brake.
STOP & START
The Stop & Start system puts the engine temporarily on standby -
STOP mode - during stops in the traffi c (red lights, traffi c jams, or
other...). The engine restarts automatically - START mode - as soon
as you want to move off. The restart takes place instantly, quickly
and silently.
Perfect for urban use, the Stop & Start system reduces fuel
consumption and exhaust emissions as well as the noise level when
stationary .
Going into engine STOP mode
The "ECO" warning lamp comes on in the instrument
panel and the engine goes into standby.
Going into engine START mode
The "ECO" warning lamp goes off and the engine starts .
