NOTICE
It is the Purchaser's/Owner's obligation:
1. To disclose and post all Rules & Regulations, Danger, Warning and Caution
labels affixed on the machine to their customers/users.
2. Equipment to be installed by TFI Authorized Dealer or a service
company approved by TFI.
3. Provide trained personnel, supervision and correct usage of the equipment.
4. Provide scheduled inspection, maintenance & repairs and must be performed
by TFI Authorized Dealer or a service company approved by TFI.
5. Must use only genuine TFI replacement parts.
6.
Machine must be anchored to a solid and level surface.
TUFFSTUFF FITNESS INTERNATIONAL
OWNER'S MANUAL
Maintenance & Assembly Instructions
IMPORTANT: KEEP THIS MANUAL FOR FUTURE REFERENCE
CG-9515
Inner/Outer Thigh
CG-9515 Rev0
Revision Date 10-27-2015
Advertisement
Table of Contents
Related Manuals for TuffStuff CG-9515
Summary of Contents for TuffStuff CG-9515
- Page 1 TUFFSTUFF FITNESS INTERNATIONAL OWNER’S MANUAL Maintenance & Assembly Instructions IMPORTANT: KEEP THIS MANUAL FOR FUTURE REFERENCE NOTICE CG-9515 It is the Purchaser’s/Owner’s obligation: 1. To disclose and post all Rules & Regulations, Danger, Warning and Caution Inner/Outer Thigh labels affixed on the machine to their customers/users.
-
Page 2: Table Of Contents
Should additional information be required, or should situations arise that are not covered by this owner’s manual, the matter should be directed to Customer Service at TuffStuff Fitness International Inc. in Chino, California. -
Page 3: Overhead Specifications
Overhead Specifications L 75” X W 60” X H 59” MAX-LOAD WEIGHT LIMIT -150 lbs CG-9515 Inner/Outer Thigh www.tuffstuffitness.com... - Page 4 DATE MATERIAL REV. TOLERANCES: REPRODUCTION IN PART OR AS A WHOLE FRACTIONAL 1/64 WITHOUT THE WRITTEN PERMISSION OF 8/13/2015 DECIMAL TUFFSTUFF FITNESS INTERNATIONAL IS PROHIBITED. METRIC .5080 TUFFSTUFF FITNESS DRAWN BY: SCALE FINISH SHEET L. VIDARTE 1 OF 1 INTERNATIONAL...
- Page 5 Carefully read ALL Danger, Warning & Caution labels posted on the machine CG-9515 Inner/Outer Thigh www.tuffstuffitness.com...
- Page 6 Carefully read ALL Danger, Warning & Caution labels posted on the machine WARNING Keep body, hands and fingers clear of all moving parts. BNH2926 2-5/8 x 1 inches PMS 152 www.tuffstuffitness.com CG-9515 Inner/Outer Thigh...
- Page 7 You should have received it along with this Owner’s Manual� If you did not receive this Facility Sign with your order, you can obtain one at no cost to you from TuffStuff Fitness by contacting our service department at: 1 (888) 884-8275 service@tuffstuff�net...
-
Page 8: Anchoring Unit
Anchoring Unit Holes on frame are provided for anchoring the unit to the floor� See anchoring hole location below� www.tuffstuffitness.com CG-9515 Inner/Outer Thigh... -
Page 9: Important Safety Instructions
Always warm-up before and cool-down after weight training. 11. Use only genuine TuffStuff replacement parts. Failure to do so will Warm-up for 10-15 minutes with stretching and cardiovascular void warranty and could result in serious injury or death to the users. -
Page 10: Registration, Service & Assembly
Thank you for purchasing the CG-9515 Inner/Outer Thigh. This machine is part of the TuffStuff line of quality strength training equipment. To maximize your use of the equipment, please study the Owner’s Manual thoroughly. Allow ample space around the machine for safe unrestricted use and Registration easier access. -
Page 11: Inspection/Maintenance
Professional Service Company approved by TFI. Keep a service log of all maintenance and repair activities. Extra copies can be downloaded from our website www.tuffstuffitness.com INSPECTION / MAINTENANCE RECORDS DATE REPLACEMENT REPAIRS INSPECTED BY WARRANTY REPAIRS DATE REPLACEMENT REPAIRS INSPECTED BY CG-9515 Inner/Outer Thigh www.tuffstuffitness.com... -
Page 12: Cable Inspection
A BREAK ON THE CABLE CABLE END SLIPPING OUT IMPORTANT NOTE: DAMAGED OR WORN CABLE (AS SHOWN ABOVE) MAY DAMAGE THE PULLEY(S)� YOU MUST INSPECT THE PULLEYS AT THIS TIME FOR WEAR AND TEAR� REPLACE IF NEEDED� www.tuffstuffitness.com CG-9515 Inner/Outer Thigh... -
Page 13: Step
HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 3 the screws. NYLON INSERT THIN PATTERN LOCK NUT Z/P 3/8-16 Fully Tighten 100% Fully Tighten Wrench tighten all hardware in this step. CG-9515 Inner/Outer Thigh www.tuffstuffitness.com... -
Page 14: Step
PIVOT ACTUATOR PLATE PIVOT AXLE 1”X 13 1/4” PIVOT AXLE SUPPORT TUBE RIGHT LEG ARM FLAT WASHER SAE Z/P 3/8” HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 5 1/4 NYLON INSERT THIN PATTERN LOCK NUT Z/P 3/8-16 www.tuffstuffitness.com CG-9515 Inner/Outer Thigh... -
Page 15: Step
HANDLES FLAT WASHER SAE Z/P 3/8” HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 2 3/4 NYLON INSERT THIN PATTERN LOCK NUT Z/P 3/8-16 Fully Tighten 100% Fully Tighten Wrench tighten all hardware in this step. CG-9515 Inner/Outer Thigh www.tuffstuffitness.com... -
Page 16: Step
Step 4 46 69 Fully Tighten 100% Fully Tighten Wrench tighten all hardware in this step. www.tuffstuffitness.com CG-9515 Inner/Outer Thigh... -
Page 17: Step
8� Open the lube package provided and apply a thin film of lubricant around the first 3 inches of the guide rods above the top plate� 9� After the cables are installed, do a set of reps to spread the lubricant thoroughly� CG-9515 Inner/Outer Thigh www.tuffstuffitness.com... -
Page 18: Step 5 Cable Routing
Step 5 Cable Routing www.tuffstuffitness.com CG-9515 Inner/Outer Thigh... - Page 19 SPLIT BOLT GR-5 Z/P 1/2-13 X 1 1/4 (RND CUT) SPLIT LOCK WASHER Z/P 1/2” SPLIT BOLT GR-8 Z/P 1/2-13 X 3 1/2 (RND CUT) Fully Tighten 100% Fully Tighten Wrench tighten all hardware in this step. CG-9515 Inner/Outer Thigh www.tuffstuffitness.com...
-
Page 20: Step 6 Cable Routing
Step 6 Cable Routing Fully Tighten 100% Fully Tighten Wrench tighten all hardware in this step. www.tuffstuffitness.com CG-9515 Inner/Outer Thigh... - Page 21 Step 6 Assembly List Item # Description Qty. FLOATING PULLEY BRACKET INNER OUTER CABLE BUTTON HEAD SOCKET CAP SCREW Z/P 7/16-14 X 5/8 CG-9515 Inner/Outer Thigh www.tuffstuffitness.com...
-
Page 22: Step
Assembly List Item # Description Qty. WEIGHT SHIELD FRONT WEIGHT SHIELD REAR FLAT HEAD SOCKET CAP SCREW Z/P M6-1.0 X 50 PLASTIC SHROUD LID Fully Tighten 100% Fully Tighten Wrench tighten all hardware in this step. www.tuffstuffitness.com CG-9515 Inner/Outer Thigh... -
Page 23: Step
HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 1 1/4 HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 3 RUBBER BUMPER W/WASHER 3/8 X 1 1/2 SPLIT LOCK WASHER Z/P 3/8” Fully Tighten 100% Fully Tighten Wrench tighten all hardware in this step. CG-9515 Inner/Outer Thigh www.tuffstuffitness.com... -
Page 24: Parts List
BNH3096 PRE ASSEMBLED COMPONENTS Item No. Description Rev. Part No. Qty. Item No. Description Rev. Part No. Qty. CAM PIVOT AXLE SUPPORT TUBE UP8820X1 UP8830X1 CAM SUPPORT TUBE RIGHT LEG ARM UP8821X1 UP8831X1 FLOATING PULLEY BRACKET WEIGHT SHIELD FRONT UP8822X1 UP8468X1 HANDLES WEIGHT STACK FRAME UP8823X1 UP8835X1 LEFT LEG ARM PLASTIC SHROUD LID BNH3393X1 UP8825X1 MAIN FRAME UP8828X1 www.tuffstuffitness.com CG-9515 Inner/Outer Thigh... -
Page 25: Pre-Assembled Components
Pre-Assembled Components *22 UP8835X1 *3 UP8821X1 55 42 *57 BNH3393X1 *2 UP8820X1 *4 UP8822X1 *14 UP8830X1 CG-9515 Inner/Outer Thigh www.tuffstuffitness.com... -
Page 26: Pre-Assembled Components
Pre-Assembled Components *20 UP8468X1 *11 UP8828X1 *15 UP8831X1 *14 UP8830X1 *6 UP8823X1 www.tuffstuffitness.com CG-9515 Inner/Outer Thigh... -
Page 27: Notes
Notes CG-9515 Inner/Outer Thigh www.tuffstuffitness.com...
