NOTICE
It is the Purchaser's/Owner's obligation:
1. To disclose and post all Rules & Regulations, Danger, Warning and Caution
labels affi xed on the machine to their customers/users.
2. Equipment to be installed by Tuff Stuff Authorized Dealer or a service
company approved by Tuff Stuff .
3. Provide trained personnel, supervision and correct usage of the equipment.
4. Provide scheduled inspection, maintenance & repairs and must be performed
by Tuff Stuff Authorized Dealer or a service company approved by Tuff Stuff .
5. Must use only genuine Tuff Stuff replacement parts.
6.
Machine must be anchored to a solid and level surface.
OWNER'S MANUAL
Maintenance & Assembly Instructions
IMPORTANT: KEEP THIS MANUAL FOR FUTURE REFERENCE
BY TUFFSTUFF FITNESS
CG-7518
Lat Pulldown
Revision Date 8-14-2012
CG-7518_Rev0
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for TuffStuff CG-7518
Summary of Contents for TuffStuff CG-7518
- Page 1 Maintenance & Assembly Instructions IMPORTANT: KEEP THIS MANUAL FOR FUTURE REFERENCE NOTICE It is the Purchaser’s/Owner’s obligation: BY TUFFSTUFF FITNESS 1. To disclose and post all Rules & Regulations, Danger, Warning and Caution CG-7518 labels affi xed on the machine to their customers/users.
-
Page 2: Table Of Contents
Should additional information be required, or should situations arise that are not covered by this manual, the matter should be directed to Customer Service at Tuff Stuff Fitness Equipment Inc. in Chino, California. CG-7518 Lat Pulldown... -
Page 3: Danger, Warning, & Caution Labels Information
Carefully read ALL Danger, Warning & Caution labels posted on the machine CG-7518 Lat Pulldown... - Page 4 Carefully read ALL Danger, Warning & Caution labels posted on the machine CG-7518 Lat Pulldown...
- Page 5 .net service promptly. DO NOT ATTEMPT to use or fix any piece of equipment that is not functioning properly. ASTM F1749-96 TUFFSTUFF FITNESS EQUIPMENT INC. CHINO, CA 91710 CG-7518 Lat Pulldown...
-
Page 6: Anchoring Unit
ANCHORING UNIT BY TUFFSTUFF FITNESS Holes on shoe plates are provided for anchoring the unit to the fl oor. (See anchoring hole locations below) 7/16” DIAMETER HOLE CG-7518 Lat Pulldown... -
Page 7: Important Safety Instructions
CAUTION: indicates a hazardous situation which, if not avoided, could injury or death. result in minor or moderate injury. CG-7518 Lat Pulldown... -
Page 8: Registration, Service & Assembly
Registration, Service & Assembly BY TUFFSTUFF FITNESS Thank you for purchasing the CALGYM CG-7518 Lat Pulldown. This machine is part of the Tuff Stuff line of quality strength training equipment. To maximize your use of the equipment, please study the Owner’s Manual thoroughly. -
Page 9: Inspection/Maintenance
Professional Service Company approved by Tuff Stuff . Keep a service log of all maintenance and repair activities. Extra copies can be downloaded from our website. INSPECTION/MAINTENANCE RECORD DATE REPLACEMENT REPAIRS INSPECTED BY WARRANTY REPAIRS CG-7518 Lat Pulldown... -
Page 10: Cable Inspection
A BREAK ON THE CABLE CABLE END SLIPPING OUT IMPORTANT NOTE: DAMAGED OR WORNED CABLE (AS SHOWN ABOVE) MAY DAMAGE THE PULLEY(S). YOU MUST INSPECT THE PULLEYS AT THIS TIME FOR WEAR AND TEAR. REPLACE IF NEEDED. CG-7518 Lat Pulldown... -
Page 11: Step 1
Step 1 BY TUFFSTUFF FITNESS WARNING IT IS RECOMENDED TO HAVE ANOTHER PERSON ASSIST YOU WITH THE INSTALLATION OF THIS UNIT. FULLY FASTEN CG-7518 Lat Pulldown... -
Page 12: Step
NYLON INSERT JAM LOCK NUT 3/8-16 RUBBER DONUT 3/4 X 2 1/2 SPLIT LOCK WASHER Z/P 1/2 CUP AND TOWEL HOLDER HEX HEAD CAP SCREW GR-8 Z/P 1/4-20 X 2 1/2 NYLON INSERT LOCK NUT Z/P 1/4-20 FULLY FASTEN CG-7518 Lat Pulldown... -
Page 13: Step
Step 3 BY TUFFSTUFF FITNESS FULLY FASTEN CG-7518 Lat Pulldown... -
Page 14: Step 4 Cable Routing
Step 4 Cable Routing BY TUFFSTUFF FITNESS CG-7518 Lat Pulldown... -
Page 15: Step 5
Step 5 BY TUFFSTUFF FITNESS CG-7518 Lat Pulldown... -
Page 16: Step
Important Safety Instructions Step 6 BY TUFFSTUFF FITNESS CG-7518 Lat Pulldown... -
Page 17: Basic Exercise Guide
It is the responsibility of the fl oor personnel to instruct users on proper operation of the equipment and review the exercise label as shown below. The intended use of this equipment is for Lat Pulldown exercise only. CG-7518 Lat Pulldown... -
Page 18: Parts List
LABEL GLADIATOR SERIES SERIAL # BNH2978 BNH2979 HEX HEAD CAP SCREW GR 8 Z/P 3/8 16 X 1 3/4 BNH2040 LABEL CALGYM BY TUFFSTUFF FITNESS HEX HEAD CAP SCREW GR 8 Z/P 3/8 16 X 2 1/2 BNH2044 LABEL TUFFSTUFF FITNESS BNH2933... -
Page 19: Exploded View
Exploded View BY TUFFSTUFF FITNESS CG-7518 Lat Pulldown... -
Page 20: Warranty
Tuff Stuff ’s facility in Chino. THE FOREGOING SHALL CONSTITUTE THE SOLE REMEDY OF THE PURCHASER AND THE SOLE LIABILITY OF TUFFSTUFF WITH REGARD TO WARRANTY. NO IMPLIED STATUTORY WARRANTY OR IMPLIED STATUTORY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE SHALL APPLY.
