Bill Of Repair - Nokia 5510 NPM-5 Service Manual

Nokia Mobile Phones Customer Care E&A
Technical Services, Repair Concepts

2. BILL OF REPAIR

SPARE PARTS
ITEM/
QTY PART NO
CIRCUIT REF.
I013 1
I015 1
I010 1
X200 1
IXXX 1
J601-J602 2
I014 1
IXXX 1
IXXX 2
X203 1
X400 1
IXXX 1
M400 1
IXXX 1
I012 1
I008 1
IXXX 1
IXXX 1
I007 1
I005 7
I004 3
I006 1
I009 4
D301-D308 8
S753-S756 4
S419 1
F200 1
I017 1
Service Manual 5510 Level 2
9490478 B-COVER ASSEMBLY
9490480 C-COVER ASSY NPM-5
9460442 SPACER FRAME
5460039 SYS CONN ASSY SPR. 5AF+5DC+MIC
XXXXXXX MIC+BOOT ASSY
5400121 SM JACK 2.5MM+SW ST 3V100MA 90DEG
9452286 PORT COVER-DMD07716 NPM-5
9790575 POWERKEY NPM-5
5400171 ANTENNA POGO PIN DMS02722 SPR
5409153 SM BATT CONN 4POL SPR 200V 2A
5400169 SIM READER
5140191 BUZZER ASSEMBLY DMC02718
6800049 VIB MOT. ASSEMBLY 1.3V 115MA 9500RPM
9460355 BATTERY LOCK DMD05789
0660237 INT.PIFA EGSM/PCN NPM-5
4850219 LCD ASSEMBLY DMC04095 NPM-5
5140067 SPEAKER+SPRING 103+-3DB 32R D13.2
9480588 SPEAKER GASKET DMD05446-EN
6290135 SCREW 1.8X8 T6+ REMFORM
6290109 SCREW 1.8X9 T6+ REMFORM
6290107 SCREW 1.8X7.0 FE T6+
6190023 SCREW 1.6X4 T6
6290133 SCREW 1.8X7 T6+ REMFORM
4864471 LED SML810MT YELGRN>11.5MCD 1305
5200029 SM SW TACT 1POL 12VDC 50MA 90DEG
5209001 SM SW TACT SPST 12V 50MA SIDE KEY
5119019 SM FUSE F 1.5A 32V
0770407 MU4NPM-5 UI-SPARE MODULE AFTERSA
