1
SERVICE MANUAL
Level 1&2
RM-504
Transceiver characteristics
Band:
GSM/EDGE 850/900/1800/1900
Display:
Touch screen (Full touch UI) nHD (640*360px),
2.9"/active area, 36.18mm x 64.32 mm colour display,
up to 16M colours
Automatic orientation sensor for display rotation
Camera:
3.2 Mpix, 4 x digital zoom
Operating System:
Series 60 release Taco 5.0
Connections:
Transceiver with BL-4U battery pack
Talk time
GSM:
Up to 4.9 hours
Confidential • Copyright © 2010 Nokia • All rights reserved
Nokia 5530 XpressMusic RM-504
Bluetooth 2.0 (A2DP/AVRCP)
2.0 Charger connector
USB 2.0 high speed through micro-USB interface
3.5 mm Nokia AV connector
Micro SD card (hot swap)
Standby
GSM:
Up to 351 hours
Service Manual Level 1&2
Note
Talk times are
dependent on
network
parameters and
phone settings
Version 7.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5530 XpressMusic and is the answer not in the manual?

Questions and answers

Summary of Contents for Nokia 5530 XpressMusic

  • Page 1 Transceiver with BL-4U battery pack Talk time Standby Note GSM: GSM: Talk times are Up to 4.9 hours Up to 351 hours dependent on network parameters and phone settings Confidential • Copyright © 2010 Nokia • All rights reserved Version 7.0...
  • Page 2: Table Of Contents

    ................................7 Battery information ................................8 Exploded view ..................................9 Service devices ..................................10 SW-update ....................................11 Disassembly instructions ..............................12 Assembly hints ................................... 18 Solder components ................................20 Confidential • Copyright © 2010 Nokia • All rights reserved Version 7.0...
  • Page 3: Change History

    The purpose of this document is to help NOKIA service levels 1 and 2 workshop technicians to carry out service to NOKIA products. This Service Manual is to be used only by authorized NOKIA service suppliers, and the content of it is confidential. Please note that NOKIA provides also other guidance documents (e.g.
  • Page 4: Copyright

    Nokia operates a policy of continuous development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice. Under no circumstances shall Nokia be responsible for any loss of data or income or any special, incidental, consequential or indirect damages howsoever caused.
  • Page 5: Warnings And Cautions

    3. Use only approved components as specified in the parts list. 4. Ensure all components, modules screws and insulators are correctly re–fitted after servicing and alignment. 5. Ensure all cables and wires are repositioned correctly Confidential • Copyright © 2010 Nokia • All rights reserved Version 7.0...
  • Page 6: Esd Protection

    Nokia 5530 XpressMusic RM-504 Service Manual Level 1&2 ESD PROTECTION Nokia requires that service points have sufficient ESD protection (against static electricity) when servicing the phone. Any product of which the covers are removed must be handled with ESD protection. The SIM card can be replaced without ESD protection if the product is otherwise ready for use.
  • Page 7: Care And Maintenance

    All of the above suggestions apply equally to the product, battery, charger or any accessory. Confidential • Copyright © 2010 Nokia • All rights reserved Version 7.0...
  • Page 8: Battery Information

    Batteries’ performance is particularly limited in temperatures well below freezing. Do not dispose batteries in a fire! Dispose of batteries according to local regulations (e.g. recycling). Do not dispose as household waste. Confidential • Copyright © 2010 Nokia • All rights reserved Version 7.0...
  • Page 9: Exploded View

    STYLUS C-COVER I0027 I0026 BATTERY COVER GASKET I0032 ANTENNA ASSY I0029 BATTERY COVER I0030 Only available as These parts can not be Ver. 6.0 assembly reused after removal Confidential • Copyright © 2010 Nokia • All rights reserved Version 7.0...
  • Page 10: Service Devices

    Online. Supplier or manufacturer V2.0 V3.0 contacts for tool re-order can be found in “Recommended service BL-4U Battery SS-210 v2.0/3.0 Camera removal equipment” document on NOKIA tool Online. Confidential • Copyright © 2010 Nokia • All rights reserved Version 7.0...
  • Page 11: Sw-Update

    To use the FLS-5 Flash Dongle, follow the user guide inside the sales package. Please check always for the latest version of flash software, wich is available on Nokia Online. Confidential • Copyright © 2010 Nokia • All rights reserved...
  • Page 12: Disassembly Instructions

    Insert the SRT-6 between the covers and slide mesh stays in its place underneath the cover. it around the phone. Be careful not to damage the A-COVER edges! Confidential • Copyright © 2010 Nokia • All rights reserved Version 7.0...
  • Page 13 Then use the SS-93 to unlock the locking remove the LCD. mechanism of the LCD connector. While opening the connector, be careful to not to damage the connector! Confidential • Copyright © 2010 Nokia • All rights reserved Version 7.0...
  • Page 14 17) Lift the UI DECK and place it on top of the TOUCH 18) Use the SS-93 to disconnect the UI FLEX ASSY WINDOW ASSEMBLY. from the engine board. While opening the connector, be careful to not to damage it! Confidential • Copyright © 2010 Nokia • All rights reserved Version 7.0...
  • Page 15 23) The UI Deck can be taken away. 24) Use the charger plug to detach the DC jack from C-COVER ASSY. Remove the DC jack with the tweezers. Confidential • Copyright © 2010 Nokia • All rights reserved Version 7.0...
  • Page 16 Be careful not to damage the IHF gasket! The the door out. speaker and the speaker adhesive cannot be reused. Also remove the MICROPHONE with the dental tool. Confidential • Copyright © 2010 Nokia • All rights reserved Version 7.0...
  • Page 17 SS-210. Then press down the metal sheets. Press the metal plates from the sides to -END OF DISASSEMBLY- tighten them to camera. Lift up the SS-210 - and remove the CAMERA. Confidential • Copyright © 2010 Nokia • All rights reserved Version 7.0...
  • Page 18: Assembly Hints

    UPPER FLEX. torque of 18 Ncm in the order shown. 5) Tighten the two TORX + size 4 screws to the torque of 15 Ncm in the order shown. Confidential • Copyright © 2010 Nokia • All rights reserved Version 7.0...
  • Page 19 ASSEMBLY using the guide of the SS-214. guiding on bottom side to position the assembly correctly. 4) Close the SS-214 and keep it closed at least 3 seconds to activate the adhesive. Confidential • Copyright © 2010 Nokia • All rights reserved Version 7.0...
  • Page 20: Solder Components

    Nokia 5530 XpressMusic RM-504 Service Manual Level 1&2 SOLDER COMPONENTS X2500 S2505 X2450 X2501 X2470 BOTTOM F2000 S2401 S2500 Ver. 2.0 Confidential • Copyright © 2010 Nokia • All rights reserved Version 7.0...
