Speedrooter 91™
CAT. NO. DESCRIPTION
S91-100 Frame Complete
S91-101 Frame Only with Axle
S91-101-A Handle Support Knob (2)
S91-101-B Motor Support Bolt, Nut, & Washer
S91-101-C Cord Wrap Cap (2)
S91-103 Stair Climber with Belt (1)
S91-103-A Nuts, Bolts, & Washers (2)
S91-103-B Spacers (2)
S91-107 Plated Handle Assembly
S91-107-A Handle – Left
S91-107-B Handle – Right
S91-107-C 6" Handle Wheel
S91-107-D Axle for Handle Wheel
S91-107-E Bushings (2)
S91-107-F Felt Washers (2)
S91-107-G Bolts and Nuts (2)
S91-107-H Set Screws (2)
S91-108 Brake Rod
S91-108-A Roll Pin
S91-109 Brake Rod Handle with Knob
S91-109-A Knob for Brake Rod
S91-109-B Roll Pin
S91-109-C Brake Rod Latch with Screws
S91-110 10" Wheel with Retaining Cap (1)
S91-111 Wheel Retaining Cap (2)
S91-112 Wheel Spacer Washers (2)
S91-115 Axle
S91-116 Motor Support Spring
S91-118 Motor Support Platform
S91-118-C Nuts, Bolts, & Washers (4)
S91-120 Front Bearing Assembly
S91-120-A Front Bearing Knob
S91-120-D Bolts, Nuts & Washers (2)
S91-130 Rear Drum Shaft Clamp
S91-130-A Drum Clamp Knob
S91-130-D Mounting Bolts & Washers (2)
S91-400 Small Drum Complete with Shaft
and Distributor Tube (15")
S91-402 Drum Shell
S91-404 Drum Hub with Bearings
S91-404-A Bushings (2)
S91-405 Nuts, Bolts, & Washers (5)
S91-407 Shaft Washer
S91-410 Drum Connecting Cable (for 1/2" cables)
S91-410-A Nut, Bolt, & Washer
S91-420 Small Drum Distributor Tube Assem.
S91-421 Distributor Tube Only
S91-422 Bushing
S91-423 Retaining Ring
S91-424 Thrust Bearing Race

Speedrooter 91 Parts List

See back cover for Speedrooter 91 Schematic Diagram.
CAT. NO. DESCRIPTION
S91-425 Distributor Tube Retaining Bolt
S91-430 Drum Shaft
S91-440 Inner Drum Cage
S91-440-A Bushing
S91-450 Large Drum Complete with Shaft
and Distributor Tube (18")
S91-452 Drum Shell
S91-454 Drum Hub Bearings (2)
S91-455 Bearing Spring
S91-460 Drum Connecting Cable
(for 5/8" and 3/4" cables)
S91-460-A Nut, Bolt, & Washer
S91-470 Drum Distributor Tube Assembly
S91-471 Distributor Tube Only
S91-472 Bushing
S91-473 Retaining Ring
S91-474 Thrust Bearing Race
S91-475 Distributor Tube Retaining Knob
with Bearing Assembly
S91-475-A Bearing Assembly for Retaining Knob
S91-480 Drum Shaft
S91-481 Wear Washer
S91-482 Spacer collar with Set Screw
S91-490 Inner Drum Cage
S91-490-A Bushing
S91-600 1/2 hp Motor Complete with Air Foot
Switch, Reverse Switch, & GFCI
S91-600-3/4 3/4 hp Motor Complete with Air Foot
Switch, Reverse Switch, & GFCI
S91-601 V-Belt (64")
S91-602 V-Belt Pulley
S91-602-1 Slip Clutch (Optional)
S91-603 Knob for Mounting Stud
S91-604 20 ft. Power Cord with GFCI
S91-605 Air Foot Switch & Rev. Switch Assem.
S91-605-A Box Only with Cover & Screws
S91-605-B Foot Pedal and Hose
S91-605-C Cable Tie
S91-605-E Power Switch Diaphragm
S91-605-G Reverse Switch – 3-Way
S91-605-H Rubber Boot (Rental)
S91-605-J Barbed Adapter
S91-605-N Strain Relief Nut
S91-609-1/2 Belt Guard (1/2 hp) with Slot
S91-609-3/4 Belt Guard (3/4 hp) with Slot
S91-614 Small Drum V-Belt (57")
S91-TB Tool Box
S91-GT Guide Tube for Speedrooter 91
GTE Guide Tube Extension
S91-DECAL Set of Safety Decals
