2. Specifications:
Engine
Manufacturer: ......... Briggs & Stratton
Type: ..................................... Quantum
2
Version: ..... Fan-air-cooled 1 cylinder-
Bore: ........................................ 68 mm
Stroke: ..................................... 52 mm
Piston displacement: ....... 189.6 ccm
Output: ............... 3.2 kW at 3000 rpm
Spark plug: ....... Champion RJ 19 LM
Ignition:
Electronic magnet ignition,
contactless, ignition point is pre-set,
radio remote screened according to
VDE 0879
Valve lash (engine cold)
Intake: .......................... 0.10–0.15 mm
Outlet: .......................... 0.18–0.23 mm
Starter: .......................... Recoil starter
16

Engine, Type 900-S

4-stroke engine (petrol)
Spark plug gap: 0.75 mm
Power Hoe 900 / 900-S
Fuel tank capacity: .................... 1.4 l
Fuel: .................... Conventional petrol
Octane number min. 85 RON
(refer to fuel recommendations)
Air filter: .................. Dry filter element
Carburetor: ................ Horizontal float
Mix control screw: .... in basic setting
Top no-load speed: ............ 3100 rpm
Idling speed: ............. 2100–2400 rpm
Engine oil:
Filling quantity .................. approx. 0.6 l
Multi-grade oil SAE 10 W-40
API-SC or higher quality grade
Operability on Slopes:
Engine is suited for use on slopes (with
oil level at "max" = upper level mark)
Continuous operation
possible up to ..... 25° inclination (47 %)
Temporary operation
up to ................... 30° inclination (58 %)
carburetor
approx. 1 turn open
