INDEX
Technical specifications of Midland BTSKI ...................................................................................2
Charging batteries ............................................................................................................................2
Description of the unit and installation brackets ..........................................................................3
Description of the BTSKI unit ..........................................................................................................3
Fitting your Midland BTSKI .............................................................................................................3
Switching your Midland BTSKI on and off .....................................................................................5
Adjusting the volume .......................................................................................................................5
Pairing with Bluetooth devices .......................................................................................................6
Using the features of the Bluetooth devices .................................................................................6
Using the telephone feature ............................................................................................................6
Using the MP3 player feature of the mobile phone .........................................................................7
Using the intercom feature ..............................................................................................................7
Resetting all paired devices ............................................................................................................9
Using the wired audio input ............................................................................................................9
Using an i-Pod/MP3 player .............................................................................................................9
Using a Two Way Radio transceiver ...............................................................................................9
Special configurations ...................................................................................................................10
Enabling the intercom by voice (VOX) ..........................................................................................10
Adjusting the sensitivity of the microphone (VOX) ........................................................................10
Disabling the VOX feature (Intercom and telephone) ...................................................................10
Wired connection always on ......................................................................................................... 11
Recommendations for specific uses ............................................................................................ 11
Use at your own risk ......................................................................................................................12
Light and sound signal/ unit functions ........................................................................................13
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Midland BTSKI
Summary of Contents for Midland BTSKI
-
Page 1: Table Of Contents
Description of the unit and installation brackets ................3 Description of the BTSKI unit ......................3 Fitting your Midland BTSKI ......................3 Switching your Midland BTSKI on and off ..................5 Adjusting the volume ........................5 Pairing with Bluetooth devices .......................6 Using the features of the Bluetooth devices .................6 Using the telephone feature ......................6... -
Page 2: Technical Specifications Of Midland Btski
BTSKI allows Bluetooth communications, › For stereo audio input (iPod/MP3 player) through a mobile phone, with another BTSKI › For PMR446 transceivers (with optional device (Intercom function) and music sharing in cable) stereo mode. Attention: before using BTSKI for the first... -
Page 3: Description Of The Unit And Installation Brackets
› Volume -: enables you to decrease the vo- lume Midland BTSKI is the best solution for Bluetooth communications, designed to be used without helmet or with semi-rigid ski helmets. Auxiliary audio jack Audio kit jack... - Page 4 Fitting and removing your Midland BTSKI The BTSKI can be easily fitted by sliding it downwards so that it fits into the slot of the fixing device. BTSKI is maintained in position thanks to the fixing clip located on the upper section (A).
-
Page 5: Switching Your Midland Btski On And Off
(especially whilst wea- ring heavy gloves). Now, fix the BTSKI on the Velcro-band. Wear Adjusting the volume your headset, insert the connection cable of the Your Midland BTSKI uses AGC technology,... -
Page 6: Pairing With Bluetooth Devices
Pairing with Bluetooth devices splay “Midland BTSKI”. Select it and follow the instructions provided in your mobile pho- Your Midland BTSKI is a Bluetooth unit that can ne manual to accept the pairing. When prom- be paired with other Bluetooth devices, such as... -
Page 7: Using The Mp3 Player Feature Of The Mobile Phone
Attention: the voice call command is possi- › To play/pause music , double click the “Con- ble only if the BTSKI has never been con- trol” button. nected to another BTSKI for Intercom com- › To skip forward to the next song , keep munication. - Page 8 › This is enabled by default. To start an Inter- flash rapidly and alternately. com communication, simply start talking. The Now both BTSKI units are trying to pair to each communication will remain active for all the other. time you are talking. If there is no conver-...
-
Page 9: Resetting All Paired Devices
“Volume –“) buttons, cannot be Using the wired audio input used to adjust the volume of the wired audio Your Midland BTSKI is also supplied with a wired source(eg MP3 player). audio input (labeled AUX), that can be used to... -
Page 10: Special Configurations
Your BTSKI is now in “Set up mode”. To communicate via the attached radio, press 2. Press the “Volume+” and “Control” buttons till the transmission Press To Talk (PTT) button to the red indicator will turn to steady blue. -
Page 11: Wired Connection Always On
Intercom feature enabled between two BTSKI devices, you must remember that the Intercom feature is enabled every time you speak by means of the BTSKI’s VOX feature. Consequently, radio communications will be disabled whilst you are talking with somebody, because they have a lower priority compared to Intercom communications. -
Page 12: Use At Your Own Risk
Use at your own risk The use of the headphone-headset will impair your ability to hear other sounds and others around you. Use this device only while waiting for the lift, on the lift, waiting to ride or in the lodge. -
Page 13: Light And Sound Signal/ Unit Functions
LIGHT AND SOUND SIGNALS LED indication Status GENERAL None Unit is switched off or full charged when connected to the power supply Single Blue flash every 3 seconds Unit being turned on/ Unit in working mode Triple red flash Unit being turned off Single Red flash every 3 seconds Standby - low battery RED and BLUE (together) every 3 se-... - Page 14 Short press the Control Button Voice Dial Short press the Control button and state the name of the person to call (only if your BTSKI has not been paired with another BTSKI device). Redial Last number Long press of the Control button...
- Page 15 Pairing a Phone While in Setup mode, press the Control button until the LED light flash Red and Blue alternately Pairing your BTSKI with another BTSKI While in Setup mode, press the Volume + on one unit (the device light will flash Red and Blue alternately), press the Volu- me- on the other unit (the light will flash Red and Blue alternately).
- Page 16 Warranty This product is covered by European warranty rulings and should be returned to the place where purchased for repair or replacement if not repairable. In the event it that it is returned to us by your supplier then we will either repair or replace within 15 working days from receipt.
