GV-900A
One GV-900A Card provides up to 32 video channels and 8 audio channels, recording up to
240 / 200 fps (NTSC / PAL) in total with H.264 software compression.
Minimum System Requirements
32-bit
OS
64-bit
CPU
RAM
HDD
Graphic Card
DirectX
Packing List
1. GV-900A Card x 1
2. 1-16 Cams with 4-Port Audio DVI-Type
Cable x 2 / 1-8 Cams with 4-Port Audio
DVI-Type Cable x 2 / 1-4 Cams with
4-Port Audio DVI-Type Cable x 2
Note: The two 1-16 Cams with 4-Port Audio DVI-Type cables are supplied with the
GV-900A card with 32 video inputs, the two 1-8 Cams with 4-Port Audio DVI-Type
cables are supplied with the GV-900A card with 16 video inputs and the two 1-4 Cams
with 4-Port Audio DVI-Type cables are supplied with the GV-900A card with 8 video
inputs.
May 13, 2013
Windows XP / Vista / 7 / 8 / Server 2008
Windows 7 / 8 / Server 2008 / Server 2012
GV-900A
GV-900A x 2
2 x 1 GB Dual Channels
GV-900A
GV-900A x 2
AGP or PCI-Express, 800 x 600 (1280 x 1024 recommended), 32-bit
color
9.0c
Pentium 4, 3.0 GHz with Dual Core
Core i5-750, 2.66 GHz
160 GB
500 GB
3. Hardware Watchdog Jumper Wire x 1
4. Software DVD x 1
1
Advertisement
Related Manuals for GeoVision GV-900A
Summary of Contents for GeoVision GV-900A
-
Page 1: Minimum System Requirements
GV-900A One GV-900A Card provides up to 32 video channels and 8 audio channels, recording up to 240 / 200 fps (NTSC / PAL) in total with H.264 software compression. Minimum System Requirements 32-bit Windows XP / Vista / 7 / 8 / Server 2008... - Page 2 Connecting One GV-900A Card Here we use the GV-900A Card of 8 channels to illustrate the connection. • Connect the video / audio cables into the DVI ports of the GV-900A Card. • Connect the supplied Hardware Watchdog Jump Wire (Figure 3).
- Page 3 Connecting Two GV-900A Cards You can install two GV-900A Cards for up to 32 channels. Normally, the card attached to the lower PCI-E slot number will act as Master, and the card attached to the higher PCI-E slot number will act as Slave.
- Page 4 PC Reset Switch PWSW Motherboard Front Panel Jumper Hardware Watchdog GV-900A Card Figure 3 Note: To locate the motherboard’s Reset (+) pin and (-) pin, please refer to the motherboard’s user manual. May 13, 2013...
-
Page 5: Installing Drivers
Installing Drivers After installing the GV-900A Card in the computer, insert the software DVD. The DVD will run automatically and an installation window will pop up. Select Install or Remove GeoVision GV-Series Driver, and select Install or Remove GeoVision GV-Series Card Drivers to install card drivers. -
Page 6: Specifications
Specifications GV-900A GV-900A x 2 Interface PCI-E (x1) PCI-E (x1) x 2 Input Type Video Input 8, 16, 32 Cams 16, 24, 32 Cams Audio Input 8 Channels 16 Channels 8-port: 240 fps 8+8 port: 480 fps NTSC 32-port: 240 fps...
