GeoVision GV-1120 Installing & Operating Manual

Installing Two GV-Combo Cards
(GV-1120, GV-1240, GV-1480)
You can install two video capture cards of the same model for a total of 32
channels. For example, 2 x GV-1480 Cards (16 channels) = 32 channels.
You can also implement two video capture cards of different channels. For
example, GV-1120 Card (8 channels) + GV-1120 Card (12 channels) = 20
channels.
Packing List
(D-Type PCI and PCI-E)
GV-1120/1240/1480 Combo Card x 2
1
Audio Extension Card x 1
2
1-8 D-Type Video Cable x 1
3
9-16 D-Type Video Cable x 1
4
17-24 D-Type Video Cable x 1
5
25-32 D-Type Video Cable x 1
6
1-8 D-Type Audio Cable x 1
7
8 9-16 D-Type Audio Cable x 1
Packing List
(DVI Type PCI)
GV-1120/1240/1480 Combo Card x 2
1
2 1-16 DVI Video plus TV Out Cable x 1
17-32 DVI Video plus TV Out Cable x 1
3
4 1-16 DVI Audio Cable x 1
5 17-32 DVI Audio Cable x 1
9 17-24 D-Type Audio Cable x 1
25-32 D-Type Audio Cable x 1
10
Internal Power Y Cable x 2 (ONLY
11
supplied with D-Type PCI-E Card)
12
Hardware Watchdog Jumper Wire x 1
13 Software DVD x 1
14 Feature Guide x 1
Installation Guide x1
15
6
Hardware Watchdog Jumper Wire x 1
Software DVD x 1
7
8
Feature Guide x 1
Installation Guide x1
9
Rules to Use Two Cards
GV Video Capture Cards have two interface types: PCI and PCI Express (PCI-E).
When you install two video capture cards, ensure they are installed in the right
slots as instructed in the following tables.
Card V1.02/V2.00
Combination and later
PCI-E x 2
V1.02/V2.00 and
later
PCI x 1+ PCI-E x 1
Combo A Cards
X
(GV-1120A/GV-
1240A/GV-1480A)
1. V1.02/V2.00 (and later) and Combo A Cards all support two-card mode, but
the combination of V1.02/V2.00 (and later) and Combo A Cards does not
support two-card mode.
2. When you install two V1.02/V2.00 (and later) Cards, it is required to use two
PCI Express slots or the combination of PCI and PCI Express slots.
3. When you install two Combo A Cards, it is required to use only two PCI
Express slots.
Note: PCI-E GV-Combo Card has x1 interface which can be inserted into the
PCI Express x1, x4, x8 or x16 slot.
Combo A Cards
(GV-1120A/GV-1240A/GV-1480A)
X
PCI-E x 2
