Summary of Contents for Roger PR602LCD
- Page 1 Roger Access Control System Installation guide for PR602LCD access controller Firmware version: 1.18.2 or newer Hardware version: 1.1 Document version: Rev. F...
-
Page 2: Table Of Contents
Contents 1. Introduction ......................... 3 1.1 This manual ........................3 2. Description and specification ..................3 3. Installation ........................4 3.1 Wires and connection diagram ................... 4 3.2 LED indicators ........................5 3.3 Power supply ........................6 3.4 Connection of door locking device ..................6 3.5 Connection of external reader and/or extension modules ............. -
Page 3: Introduction
PR602LCD controller belongs to advanced PRxx2 series. The new, factory-made controller has the address ID=00 and is equipped with the MASTER card. PR602LCD is also equipped with built-in reader of EM125kHz standard, so the MASTER card can be used for the initial tests after installation. -
Page 4: Installation
3. I NSTALLATION 3.1 Wires and connection diagram PR602LCD-I controller (indoor version) is equipped with screw terminals, while PR602LCD-O controller (outdoor version) is equipped with connection cable. Table 2. PR602LCD terminals/wires Wire Screw Description colour terminal +12V Positive power supply contact, 12VDC... -
Page 5: Led Indicators
Fig. 1 PR602LCD connection diagram 3.2 LED indicators PR602LCD controllers are equipped with 3 LED indicators. Their functions and colours are specified in table 3 below. Functioning of LEDs can be verified by means of included MASTER card. Page 5 of 15... -
Page 6: Power Supply
The power supply can be provided by means of power supply unit PS10 or PS20, which are available in Roger offer. The power supply units can be connected to backup battery in order to ensure operation of access control in case of power failure. -
Page 7: Prt Series Readers And Extension Modules
Fig. 3 Connection of PRT series reader and XM-2/Xm-8 module via CLK/DTA lines 3.5.2 Wiegand and Magstripe readers PR602LCD controller can operate with various Wiegand type readers which transmit 26 to 66 bits of data in different data formats and with Magstripe readers. Botj types of readers should be connected to PR602LCD controller in accordance with diagram shown in fig. -
Page 8: Input And Output Lines
COM contacts are shorted. In case of lack of the power, the REL1 output is in the off state. 3.6.3 General purpose outputs Two transistor outputs (IO1, IO2) are available in PR602LCD controllers. All these lines are open collector type, i.e. in the normal (off) state are pulled to supply plus via 5.6kΩ resistor and when on, they short to supply minus. - Page 9 cable type (standard telephone cable, shielded or unshielded twisted pair etc.) but the recommended cable is unshielded, twisted pair (UTP). Shielded cables should be limited to installations subject to strong electromagnetic interferences. The RS485 communication standard used in the RACS 4 system guarantees proper communication in a distance of up to 1200 meters as well as high resistance to interferences.
-
Page 10: Controller Mounting
3.8 Controller mounting Fig. 5 Installation of PR602LCD controller Page 10 of 15... -
Page 11: Installation Guidelines
ONFIGURATION 4.1 Controller address If PR602LCD controller with built-in EM125kHz reader works autonomously (standalone mode), then address setting can be skipped (default address ID =00) but if the controller is to be connected with other controllers by means of RS485 bus and operate in network system, then it is necessary to assign unique address to particular controllers (ID number from range 00..99). -
Page 12: Memory Reset Procedure
All commands for manual programming of controller by means of keypad are specified in the document – PRxx2 series controllers, Functional description and Programming Guide, which is available at www.roger.pl. Following Keypad Command can be used for address setting: [*][0][0][#][Login][new ID address][#] The Keypad commands requires previous activation in regard of its schedule and authorization by means of PR Master software. -
Page 13: Controller Programming
4.4 Firmware update The latest version of firmware is available at www.roger.pl. In order to update firmware it is necessary to connect the device by means of RS485 bus to communication interface (UT-2USB, UT- 4DR or RUD-1) and then connect the interface to PC with installed RogerISP software. RogerISP is available free of charge at www.roger.pl. -
Page 14: Ordering Information
· Place jumper on FDM pins Fig. 6 Location of pins for jumpers inside the enclosure of PR602LCD controller · Reset the device (place and remove jumper on RST pins or switch power off/on) · Start RogerISP software and select communication port (in case of RUD-1 select RS-485). -
Page 15: Product History
6. P RODUCT HISTORY Table 5. Product history Product version Released Description PR602LCD v.1.0 11/2008 The first commercial version of the product PR602LCD v.1.1 05/2009 Modification of built-in converter This symbol placed on a product or packaging indicates that the product should not be disposed of with other wastes as this may have a negative impact on the environment and health.
