Introduction
Thank you very much for purchasing the ZOOM
manual. The
has the following features.
Multitrack recorder that can use up to 32 GB
SDHC cards
The
can is an 8-track recorder that supports
SDHC cards of up to 32 GB. After making linear
PCM recordings (WAV format) at 16/24-bit and
44.1/48kHz sampling rate, you can transfer
DAW software.
Hi-Speed USB 2.0 audio interface
You can use the
and its various input and
output jacks as a Hi-speed USB 2.0 audio
interface that can handle 2 inputs and 2 outputs
at up to 24-bit and 96 kHz. Its effects can even
be used (at 44.1 kHz only) and it can also operate
using USB bus power.
(See the Audio Interface Manual on the included SD card for details.)
DAW software control surface
The
can be connected to a computer
by USB cable and used as a control surface
for DAW software. You can operate transport
functions, including play, record and stop keys
and physically control onscreen faders. You can
also assign various DAW functions to the F1–F5
function keys. (The assignable functions depend
on the DAW software.)
(See the Audio Interface Manual on the included SD card for details.)
unit
Cubase LE Download
access code sheet
Please read through this manual carefully in order to understand the functions of the
so that you can use it happily for many years.
After reading through this manual, please keep it along with the warranty in a safe place.
Please note that some details might be changed without notice in order to improve the product.
The package contains the following items. Please verify them.
SD card
USB cable
Operation manual
(this document)
, which we will refer to as the
Handles a variety of input sources including
guitars, microphones and line-level equipment
The
has 2 input jacks that accept both
XLR and standard phone connectors. Both can
supply phantom power (24 or 48 V) and one can
handle high-impedance input. In addition to high-
impedance guitars and basses, the inputs can
handle all types of sources, including dynamic
and condenser microphones, synthesizers and
other line level instruments. The built-in high-
performance microphones are convenient for
recording acoustic guitars and vocals.
(See "Connecting instruments" on P.21.)
Sampler with 8 pads and 8 voices
Use the sampler to assign sounds to each track
(pad) and create loops. Play the pads in real-
time, and combine loops to create performances
for a complete song. By simply lining up drum
loops from the included SD card, anyone can
easily create professional-quality backing parts
and basic tracks. The recorder and sampler work
together seamlessly, so you can record audio on
other tracks while listening to loop playback.
(See "Using the sampler to make songs" on P.60.)
AC adapter
(ZOOM AD-17)
Cubase LE
Startup Guide
オペレーションマニュアル
©株式会社ズーム
本マニュアルの一部または全部を無断で複製／転載することを禁じます。
Note: the Audio Interface Manual (PDF) is on the SD card.
well
in this
3
