TECHNICAL DATA

& SERVICE MANUAL
OUTDOOR UNIT: AER518SC
SPLIT SYSTEM AIR CONDITIONER
Model No.
AER518SC
AER518SCL
AER522SC
AER518SCL
AER522SC
Product Code No.
387007114
387007140
387007142
0.8180.267.0
05/2002

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AER518SC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Euro-Line AER518SC

Summary of Contents for Euro-Line AER518SC

  • Page 1: Technical Data

    TECHNICAL DATA & SERVICE MANUAL OUTDOOR UNIT: AER518SC AER518SCL AER522SC SPLIT SYSTEM AIR CONDITIONER Model No. Product Code No. AER518SC 387007114 AER518SCL 387007140 AER522SC 387007142 0.8180.267.0 05/2002...
