Safety instructions

Please follow the safety instructions
under "Installation".

Delivery

Your dishwasher has been checked
thoroughly in the factory to ensure that it
is in working order. This may cause
small water stains. These will disappear
after the first wash cycle.

Technical specifications

Weight:
max. 45 kg
Voltage:
220–240 V, 50 Hz or 60 Hz
Connected load:
2.0–2.4 kW
Fuse:
10/16 A (UK 13A)
Power input:
switched off 0.1 W
not switched off 0.1 W
Water pressure:
at least 0.05 MPa (0.5 bar), maximum
1 MPa (10 bar). At a higher water
pressure: connect pressure-reducing
valve ahead.
Inlet rate:
minimum 10 litres/minute
Water temperature:
cold water; hot water max. temperature
60 °C.
Downloaded from DishWasher-Manual.com Manuals
Installation and connection

Installation

The required installation dimensions can
be found in the installation instructions.
Level the appliance with the aid of the
height-adjustable feet. Ensure that the
appliance is situated securely on the
floor.
A built-under or integrated appliance
which is installed subsequently as a
free-standing appliance must be
secured to prevent it from
overturning, e.g. by screwing it to the
wall or by installing it under
a continuous worktop which is
screwed to adjacent cupboards.
The appliance can easily be
installed in a fitted kitchen between
wooden and plastic walls.

Waste-water connection

1. The required work sequence can be
found in the installation instructions.
If required, fit a siphon with an
drainage connection.
2. Connect the waste-water hose to the
drainage connection of the siphon
with the enclosed parts.
Ensure that the drainage hose is not
kinked, crushed or twisted and that
there is no cover plate in the
drainage to prevent the waste water
from flowing out!
