INSTRUCTION MANUAL
Ver 1.4
Megapixel IP PTZ Camera
HA0312OCT16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HA0312OCT16 and is the answer not in the manual?

Questions and answers

Related Manuals for Huntcctv HA0312OCT16

Summary of Contents for Huntcctv HA0312OCT16

  • Page 1 INSTRUCTION MANUAL Ver 1.4 Megapixel IP PTZ Camera HA0312OCT16...
  • Page 2 CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION : TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT OPEN THE COVERS. NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONAL This lightning flash with arrowhead symbol is intended to alert the user to the presence of un-insulated "dangerous voltage"...
  • Page 3 NOTICE Important Safety Guide 1. Read, heed and follow all the Instructions Read all the safety and operating instructions before using the product. 2. Keep this manual Keep this manual for reference in future. 3. Attachments / Accessories Use only the attachments or accessories specified by the manufacturer. 4.
  • Page 4 NOTICE Caution Operating Before using, make sure that the power supply and others are properly installed. While operating, if any abnormal condition or malfunction is observed, stop using the product immediately and then contact your local dealer. Handling Do not disassemble or tamper with the parts inside the product. Do not drop or subject the product to shock and vibration as this can damage the product.

  • Page 5: Table Of Contents

    TABLE OF CONTENTS ① Introduction Model Code Features Package Components Main Part Description ② Installation DIP Switch Setup Installation with Ceiling Mount Bracket Installation with Wall Mount Bracket Installation with In-Ceiling Mount Bracket Wiring and Cabling ③ Operation Check Point before Operation Check Points for Preset and Pattern Function before Operation Reserved Preset (Hot Keys) Preset...

  • Page 6: Model Code

    INTRODUCTION Model Code H A - N 2 0 S W - S N P PoE for IP model P : PoE+ Blank : No PoE+ Network N : H.264 IP Function Video Output S : HD-SDI C : CVBS(Composite Video) Mount Bracket W : Wall Mount C : Ceiling Mount...

  • Page 7: Features

    INTRODUCTION Features Powerful Zoom Camera & Setup Options Image Sensor : 1/3" Exmor CMOS Image Sensor, 2 Mega pixels (20S model) 1/3" Solid State Progressive Scan CCD, 1.3 Mega pixels (18H model) 1/3" PS CMOS Image Sensor, 2 Mega pixels (20T model) 1/3"...
  • Page 8 INTRODUCTION Preset, Pattern, Swing, Group, Privacy Mask and More… MAX. 128 Presets are programmable. MAX. 8 sets of Swing are programmable. This function is that a camera moves repetitively between two preset positions at programmed speeds. MAX. 4 Patterns are programmable. This function is that a camera memorizes the path (mostly curve path) by the joystick of the controller and revives the trajectory operated by the joystick as closely as possible.

  • Page 9: Package Components

    INTRODUCTION Package Component Product & Accessories Main Body & Dome Cover (Wall/Ceiling model) Main Body & Dome Cover (In-ceiling model) Default Accessories [Main Cable, Wrench, Cross LAN cable, Audio cable, CD] Speed Dome Camera Instruction Manual 9/33...
  • Page 10 INTRODUCTION Brackets (Optional) Wall Mount Bracket Ceiling Mount Bracket [Screws : , Hex Lag [Screws : , Anchor Bolt TORX Machine M4×L18 TORX Machine M4×L18 #14×50] 3/8"×70] In-Ceiling Mount Bracket [Screws : Tapping FH Ø4×L20, Machine Sams M3×L8] Speed Dome Camera Instruction Manual 10/33...

  • Page 11: Main Part Description

    INTRODUCTION Main Part Description Mounting Screw Hole Drop Prevention Spring IP Reset Switch DIP Switch LAN Port Audio Port BNC Connector Main Connector Dome Cover Dome Cover Do not detach the protection vinyl from the dome cover before finishing all the installation process to protect the dome cover from scratches or dust.

  • Page 12: Dip Switch Setup

    INSTALLATION DIP Switch Setup Before installing the camera, set up the DIP switch to configure the camera ID and the communication protocol. Camera ID Setup ID numbers of cameras are set up with binary numbers. See the examples shown below. Binary Value ex) ID=5 ex) ID=10...
  • Page 13 INSTALLATION Communication Protocol Setup Select an appropriate Protocol with the DIP switch combination. Switch Mode Protocol (Pin 1) (Pin 2) (Pin 3) PELCO-D, 2400 bps PELCO-D, 9600 bps PELCO-P, 4800 bps PELCO-P, 9600 bps Others Reserved Match the camera protocol with the camera protocol in the setting of your DVR or controller to control the camera.

  • Page 14: Installation With Ceiling Mount Bracket

    INSTALLATION Installation with Ceiling Mount Bracket ① Remove the ceiling tile from the ceiling ② Hook up “Drop Prevention Spring” on and cut a hole whose diameter is main body to prevent camera from 30~40mm on the ceiling tile to pass the unexpected drop and pull the wire(s) and wire(s) and cable(s) through to the upside cable(s) for the system as below.

  • Page 15: Installation With Wall Mount Bracket

    INSTALLATION Installation with Wall Mount Bracket ① Make a hole whose diameter is 30~40mm ② Hook up “Drop Prevention Spring” on on the mounting surface to pass the main body to prevent camera from wire(s) and cable(s) through the mounting unexpected drop and pull the wire(s) and surface.

  • Page 16: Installation With In-Ceiling Mount Bracket

    INSTALLATION Installation with In-ceiling Bracket ① Assemble the dome cover and the braket ② Cut a hole whose diameter is 215mm on with the main body the ceiling tile and insert the camera into the hole. Open the cover and make all the connections.

  • Page 17: Wiring And Cabling

    INSTALLATION Wiring and Cabling MONITOR BNC CABLE POWER INTERNET SENSOR I/O LAN CABLE BROWSER DOOR AUDIO SENSOR SWITCH CABLE MIC SPEAKER MAIN CABLE RS-485 CONTROLLER / DVR Port Description Main Cable Port Pin Number Wire Color Signal Black RS-485 + Brown RS-485 - DC 12V...
  • Page 18 INSTALLATION Power Description Carefully check the voltage and current capacity of the rated power. Input Voltage Range Current Consumption DC 11V ~ 18V 2.0 A For the DC input, be careful with the polarity of DC power. The system should be permanentally damaged by wrong DC input.
  • Page 19 INSTALLATION Video (HD-SDI or CBVS) Use BNC coaxial cable only. Transmission Distance of HD-SDI Video Signal should be variable by cables. There may be no video on a monitor due to cable quality or specification. Use proper BNC Coaxial Cables after considering transmission distance. For your reference, see the below table.
  • Page 20 INSTALLATION Alarm Input IN 1 Sensor 1 IN 2 Sensor 2 IN COM Sensor Input is detected by Short or Open between Sensor IN Terminal and COMMON Terminal. If you want to use Alarm Input, the types of sensors must be selected. The sensor types are divided into Normal Open and Normal Close.

  • Page 21: Check Point Before Operation

    OPERATION Check Points before Operation Before turning on the system, check if the wire(s) and cable(s) are connected properly. Check if the camera ID on the controller is properly selected. The camera ID must be identical to that of the target camera. The camera ID can be checked by reading the DIP switch of the camera or on Web browser.

  • Page 22: Reserved Preset (Hot Keys)

    OPERATION Reserved Presets (Hot Keys) Description Some Preset numbers are reserved to change some parameters without entering into OSD menu. Hot Keys Go Preset [131~134] : Running Pattern Function 1 ~ 4 Go Preset [141~148] : Running Swing Function 1 ~ 8 Go Preset [151~158] : Running Group Function 1 ~ 8 Go Preset [161] : Turning off Relay Output 1...

  • Page 23: Preset

    OPERATION Preset Function MAX. 128 presets can be configured. Setting Presets Set Preset [1~128] Running Presets Go Preset [1~128] Deleting Presets To delete Presets, use web browser. Swing Function This function is that the camera moves repetitively between two preset positions at programmed speeds. When a swing function runs, the camera moves from the preset assigned as the 1st point to the preset assigned as the 2nd point in CW(Clockwise) direction.

  • Page 24: Pattern

    OPERATION Pattern Function This function is that the camera memorizes the path (mostly curve path) by the joystick of the controller and revives the trajectory operated by joystick as closely as possible. MAX. Patterns programmable Maximum communication commands can be programmed in a pattern. Setting Patterns To set Pattern, use web browser.

  • Page 25: ④ Specifications

    SPECIFICATIONS Specifications CAMERA PART (20S Model) Image Sensor 1/3'' Exmor CMOS Sensor Pixels 2,000K pixels Zoom ×20 Optical Zoom, ×12 Digital Zoom Video Signal-to-Noise 50 dB Forcal Length F1.6~3.9, f=3.5~129.5mm Angle of View (H) 55.4°(Wide)~2.9°(Tele) Min. Working Distance 10mm(Wide), 1000(Tele) Zoom Speed 2.3 sec (Wide to Tele) 0.5 Lux (Color, 1/30sec, 50 IRE)
  • Page 26 SPECIFICATIONS CAMERA PART (18H Model) Image Sensor 1/3'' Sloid State Progressive Scan CCD Pixels 1,320K pixels Zoom ×18 Optical Zoom Forcal Length F1.6~2.8, f=4.7~84.6mm Angle of View (H) 55.2°(Wide)~3.2°(Tele) Min. Working Distance ∞ ~ 1000mm(Tele) ~ 10mm(Wide) Minimum Illuminance 0.5 Lux (Color) / 0. 02 Lux (B/W), F1.5, 50IRE, 1/4s, 28dB Day &...
  • Page 27 SPECIFICATIONS CAMERA PART (20T Model) Image Sensor 1/3'' PS CMOS Sensor Pixels 2,000K pixels Zoom ×20 Optical Zoom, ×8 Digital Zoom Video Signal-to-Noise 50 dB Forcal Length F1.6~2.9, f=4.45~89mm Angle of View (H) H : 55.56°(Wide)~3.10°(Tele) / V : 43.32°(Wide)~2.34°(Tele) Min.
  • Page 28 SPECIFICATIONS CAMERA PART (19T Model) Image Sensor 1/3'' PS CMOS Sensor Pixels 1,300K pixels Zoom ×19 Optical Zoom, ×16 Digital Zoom Video Signal-to-Noise 52 dB Forcal Length F1.6~2.9, f=4.5~85.5mm Angle of View (H) H : 55.24°(Wide)~3.16°(Tele) / V : 44.96°(Wide)~2.542°(Tele) Min.
  • Page 29 SPECIFICATIONS CAMERA PART (30L Model) Image Sensor 1/2.8'' CMOS Sensor Pixels 3,270K pixels Zoom ×30 Optical Zoom, ×12 Digital Zoom Forcal Length F1.6~5.0, f=4.3~129.0mm Minimum Illuminance 0.8 Lux (Color, Sens-up Off) / 0. 1 Lux (B/W, Sens-up Off) Day & Night Auto / Day / Night(ICR) Focus Auto / Manual...
  • Page 30 SPECIFICATIONS CAMERA PART (28L Model) Image Sensor 1/4'' CMOS Sensor Pixels 1.3M pixels Zoom ×28 Optical Zoom, ×12 Digital Zoom Forcal Length F1.5~3.7, f=3.5~98.0mm Minimum Illuminance 0.8 Lux (Color, Sens-up Off) / 0. 01 Lux (B/W, Sens-up Off) Day & Night Auto / Day / Night(ICR) Focus Auto / Manual...
  • Page 31 SPECIFICATIONS MECHANISM PART 360°(Endless) Movement Range Tilt 90° Preset 360°/sec. Speed 0.05 ~ 360°/sec. (Proportional to Zoom) Swing 1~ 180°/sec. Preset 128 Presets or 98 Presets Pattern 4 Patterns [768 Commands(Approx. 5 Minute) / Pattern] Swing 8 Swings 8 Groups (MAX. 20 Actions with The Combination of Preset, Group Pattern and Swing) Other Pan/Tilt Functions...
  • Page 32 SPECIFICATIONS IP PART Compression H.264 HP Level4 Streaming Primary : H.264, Secondary : H.264/MJPEG Data Rate Primary : 32Kbps ~ 10Mbps, Secondary : 32Kbps ~ 1Mbps 20S model : Max 1920×1080 Video Resolution 18H model : Max 1280×960 or 1280×720 20S model : 30fps Frame Rate 18H model : 20fps(1280×960), 30fps(1280×720)

  • Page 33: Dimension

    SPECIFICATIONS Dimension Main Body Ceiling Mount Type 56.4 56.4 1.5" NPT 158.2 Wall Mount Type In-Ceiling Mount Type 118.6 292.5 4- 8 [Unit : mm] Speed Dome Camera Instruction Manual 33/33...
