- Page 1 Vintage 15 Manual Model: V15 www.vintagesoundamps.com...
-
Page 2: Specifications
Specifications Power Output 15 Watts Output Tubes 2 - 6V6 Preamp Tubes 1 - 12AT7; 3 - 12AX7 Rectifier 1 - 5AR4/GZ34 Controls Front Panel: Volume.Treble.Middle.Bass.Reverb.Speed.Intensity Rear Panel: Dwell Control on Rear Panel Configurations 1x12 Cabinet Head & Matching 1x12 Speaker Cabinet Colors Assorted colors available Dimensions &... - Page 3 15) Avoid placing any liquids on or near the amplifier that may splash or drip such as those contained in bottles, cans, glasses, etc. 16) Vintage Sound amplifiers are capable of producing very high sound pressure levels which can cause temporary or permanent hearing damage dropped.
-
Page 4: Front Panel
14. FUSE SLO-BLOW - The fuse protects the amp from electrical faults. Replace only with a 1 amp slo blow fuse. If the amp repeatedly blows the fuse, contact your dealer or Vintage Sound Amps. 15. ON - This switch turns the AC power ON and OFF. When the switch is OFF, the amplifier is completely shut down 16. - Page 5 damage to the amplifier. When using only the internal speaker jack, a speaker impedance load of 8ohms (minimum) should be used to avoid distortion or damage to the amplifier. 18. EXT SPKR - Plug-in connection for an external speaker. This jack is wired in parallel with the INTERNALSPEAKER JACK {17} and affects the speaker impedance load.
-
Page 7: Made In Usa
MODEL: SERIAL NUMBER: INPUT VOLTAGE: MADE IN USA... -
Page 8: Declaration Of Conformity
Vintage Sound Amps, declare, taking this declaration under our total responsibility, that guitar amplifier model Vintage 15 (V15) is in conformity with EN 55013, 61000-3-2, EN 61000-3-3, and EN 55020 in accordance with the Directive 2006/95/EC of 12 December 2006,...
